Honeywell CM701 Installation instructions

EN0H 8559 UK07 R0 09/06
CM701 (UK Version)
PROGRAMMABLE THERMOSTAT
PRODUCT SPECIFICATION SHEET
The CM701 thermostat is designed to provide automatic time
and temperature control of heating systems in villas and
apartments.
It can be used as part of a system in conjunction with combi-
boilers, oil-burners and gas fired boilers, circulation pumps,
thermal actuators, zone valves and electric heat systems
(<5A).
The CM701 is designed with the installer in mind and
includes a moulded back-plate with trunking guides and
wiring breakouts to make installation quick and easy.
The CM701 large LCD display, button layout based on the
same simple programming philosophy used on our acclaimed
CM20 products and the introduction of an ‘OK’ button makes
it easier to install and more user friendly.
The unit is ideal for consumers who want reliable precise
temperature control from a modern looking, simple to
program and easy to use product.
FEATURES
•Attractive slim, modern styling makes it ideal for
location in any type of home.
•24 hour heating program.
•Up to 4 daily independent time and temperature level
changes let you set 4 time and temperatures pairs to
suit your lifestyle.
•LCD Backlighting to illuminate the display for easier
viewing in low light conditions.
•Temporary programmed temperature override to
temporarily override the programmed temperature till
the next switch point.
•Room Temperature Enquiry.
•EEPROM memory holds the user program
indefinitely.
•OFF mode has an integral frost protection setting at
minimum 5°C (installer adjustable) so that pipes in
the house will never freeze in winter.
•24...230V 5A resistive, 2A inductive SPDT relay
provides compatibility with most domestic central
heating systems reducing the need to stock many
different models.
•Battery powered by 2 x AA size (LR6) alkaline cells.
•Minimum battery life of 2 years with low battery
warning indicator.
•Built-in default heating program.
•Automatic Summer / Winter time change adjusts the
time automatically to daylight saving time.
•Scheduled Maintenance Alert Period.
•Surface or wall box mounting options, with trunking
guides and wiring breakouts to simplify installation.
•No installer links or special installer switches on the
back of the unit mean no adjustment is required for
combi-boilers and most domestic central heating
systems.
•User Set-Up Mode allows extra functions to be set at
the discretion of the user:
•AM-PM or 24hr time display.
•Resetting the heating profile to factory default.
•Enable / disable of Auto Summer / Winter time
change.
•Installer Set-Up Mode allows extra functions to be set
at the discretion of the installer to match the
consumers applications and needs:
•Optimisation.
•Pump Exercise.
•Upper / Lower Set point Limit Adjust.
•Temperature offset.
•Minimum ON time.
•Cycle rate.
•Proportional Band Width.
•Diagnostic Mode to assist in faultfinding.

CM701 CHRONOTHERM
2 EN0H 8559 UK07 R0 09/06
SPECIFICATIONS
CONTROLS / DISPLAY LAYOUT
Batteries :2 x 1.5 V IEC LR6 (AA) Alkaline cells
Battery life :Minimum 2 years
Battery
replacement
:Program retained in EEPROM
Switch type :SPDT (potential free)
Electrical rating :230 V~, 50...60 Hz, 0.1 A to 5 A resistive
0.1 A to 2 A inductive (0.6 pf)
24 V~, 50...60 Hz, 0.5 A to 5 A resistive
0.5 A to 2 A inductive (0.6 pf)
Time display :24 hour or 12 hour AM/PM format
Time keeping
accuracy
:Typically better than 10 minutes per year
Program :4 daily time and temperature level
changes
Time setting
resolution
:Time of day - 1 minute
Program - 10 minute steps
Sensing element :100K (@ 25 oC ) NTC thermistor
Temperature
setting range
:Program : 5 to 35oC in 0.5 oC steps
Frost : 5 oC or equal to lower limit
(5 oC to 21 oC).
Temperature
control accuracy
:±0.5 K (nominal) @ 20oC, 50% load
3 K Δ/hour
Room
Temperature
display range
:From 0 oC to 50 oC
Control form :P + I (Proportional + Integral)
Minimum ON
time
:10% of cycle time (min one minute),
adjustable to 2 to 5 min (see installer set
up)
Cycle rate :Selectable by application (see installer
set up)
Wiring :Terminal block capable of accepting
wires up to 2.5 mm2
Wire access :Mains wiring – rear right.
Low voltage wiring – rear right.
Dimensions :133 x 88.5 x 26 mm (w x h x d)
130 x 175 x 26 mm (w x h x d)
(flap open)
Environmental :Operating temperature range 0 to 40oC
Shipping and storage temperature range
-20 to 55oC
Humidity range 10 to 90% rh, non-
condensing
Approvals :Designed to meet European EN
approvals EN60730-1(Nov 2000),
EN55014-1 (1997), EN55014-2 (2000)
PRODUCT LAYOUT:
1. LCD Screen
2. Battery Low Indicator
3. Time Display
4. Burner On Indicator
5. Temperature Display
6. Temperature Change Buttons
7. Information Enquiry Button
8. Operating Mode Buttons
9. Green OK Button
10. Battery Compartment
11. Battery Cover
12. Program Buttons
13. Time Change Buttons
14. Date Button

CM701 CHRONOTHERM
3 EN0H 8559 UK07 R0 09/06
INSTALLER SET-UP
Specific Applications Setting What do you need to change?
Cycle/
Hour
Minimum
ON time
(in minutes)
Note :
a. To change Cycle/Hour, please go to parameter n. 2, category 2
in the installer set-up mode.
b. To change Minimum ON Time, please go to parameter n. 1,
category 2 in the installer set-up mode.
Heating Gas Boilers
(<30KW)
6 1 No action required
Oil Boiler 3 4 1. Set Minimum ON Time to 4 minutes.
2. Set Cycle/Hour to 3.
Thermal Actuator 12 1 Set Cycle/Hour to 12.
Zone valve 6 1 No action required.
Electric heating
(for applications
<5A
)
12 1
1. Set Cycle/Hour to 12.
In Installer set-up we can:
❑Set-up specific applications
❑Enable special features
To enter the installer set-up mode:
a) Press the OFF button.
b) Press and hold the INFO ibutton and the two program
buttons ‘< >’ together.
c) The unit will display the first parameter of installer
parameter group category 1 (from n.1 to n.19).
d) Press the TEMP or buttons to change the factory
setting. The display will flash indicating that a change has
been made.
e) Press the green OK button to confirm this change and the
display will stop flashing.
f) Press the +button to go to the next parameter.
g) Press the program button >to go to category 2 in the
Installer mode (from n.1 to n.5).
h) To exit the installer mode, press the AUTO, MAN or OFF
buttons.
Abbreviated Set-Up Description
e.g. Cl = Clock Format
Installer Set-up Number
(Press + or - to change)
e.g. 1= Clock Format
Factory Setting or New Choice
Press TEMP or to change
e.g. 12 = AM/PM Format
24 = 24hr Format

CM701 CHRONOTHERM
EN0H 8559 UK07 R0 09/064
Special Features Description What to do if we wish this
feature
Optimisation (Variable
Start Time)
Adaptive Intelligence
recovery TM
The thermostat will adjust the start time in the
morning/afternoon so the desired temperature is
reached by the start of the program period e.g. Time
7:00, Temp 21 oC. The thermostat will monitor the
accuracy of the start up and use this information to
modify the calculation for the following day by changing
the ramp rate (initial 3 K/hr) .The system will restrict the
start time to a max of 2 hours.
Note: Optimisation will not work in cooling mode.
Set parameter n.8, category 1 in the
installer set-up mode to 1.
AM-PM/ 24hr Display Change display format (default 24hr). Set parameter n.1, category 1 in the
installer set -up mode to 12.
Pump exercise When enabled the Pump Exercise will switch the relay
on for 1 minute at 12:00 if the relay has not been
switched on since 12:00 the previous day.
While in Holiday mode the Pump Exercise feature, if
enabled, will operate.
Set parameter n.5, category 2 in the
installer set -up mode to 1.
Upper Temperature Limit The normal upper temperature limit of 35oC can be
reduced down to 21 oC to save the homeowner energy.
Useful if the homeowner rents to tenants.
Set parameter n.6, category 1 in the
installer set -up mode to the desired
limit.
Lower Temperature Limit The normal lower temperature limit of 5 oC can be
increased up to 21 oC to protect the inhabitants from
cold. Useful if the inhabitants include the elderly,
children or disabled.
Set parameter n.7, category 1 in the
installer set -up mode to the desired
limit.
Temperature Offset If the thermostat is located in a hot/cold location and
cannot be moved because of wiring then the measured/
displayed temperature can be adjusted by +/- 3 oC.
Useful if the homeowner wants the reading to match
another appliance temperature display.
Set parameter n.12, category 1 in the
installer set -up mode to the desired
offset value.
Proportional Band Width Can be adjusted up to 3 oC (default is 1.5 oC) to provide
better temperature control (less overshoot).
Useful for:
a. Well insulated homes with over-sized heating
systems.
b. Air systems with fast response.
Set parameter n.13, category 1 in the
installer set -up mode to the desired
value.
Scheduled Maintenance
Alert Period
Can be set to the required number of months between
1-48. After the specified number of months the
Chronotherm will display ‘SERVICE’ prompting user to
arrange a maintenance call
Set parameter n.19 in the installer set
-up mode to the desired value.

CM701 CHRONOTHERM
EN0H 8559 UK07 R0 09/065
Parameter Installer Set-
Up Number /
Abbreviation
(Press + or -
keys to select)
Factory Setting Optional Setting Installer Set-
Up Category
(Press PROG
keys ‘< or >’ to
select)
Display Description Display/Setting Description
Category 1: Thermostat Parameters
AM-PM / 24hr
Display
1:Cl 24 24 hr clock display 12 12 hr AM / PM clock display 1
RESET Time /
Temperature
Program
2:rP 1 Time / Temperature
profile set to factory
default
Changes to 0 when
one of the time/temp
profiles are changed
0
1
Time / Temperature are
as programmed
To restore the factory
profile set to 1
1
Auto
Summer/Winter
Time Change
3:tC 1 Auto
Summer/Winter
Time Change
enabled
0 Auto Summer/Winter
Time Change disabled
1
LCD Backlighting 5:bL 1 Backlighting enabled 0 Backlighting disabled 1
Upper
Temperature Limit
6:uL 35 35°C Upper Temp.
Limit
21 to 34 21°C to 34°C
adjustment in 1°C steps
1
Lower
Temperature Limit
7:LL 5 5°C Lower Temp.
Limit
6 to 21 6°C to 21°C adjustment
in 1°C steps
1
Optimisation 8:Op 0 Optimisation
disabled
1 Optimisation enabled 1
Temperature
Offset
12:tO 0 No offset -3 to +3 -3°C to +3°C adjustment
in 0.1°C steps
1
Proportional Band
Width
13:Pb 1.5 1.5°C Proportional
Band
1.6 to 3.0 1.6°C to 3.0°C
adjustment in 0.1°C
steps
1
Scheduled
Maintenance Alert
Period
19:SP 0 Scheduled
Maintenance Alert
Period disabled
0 to 48 0 to 48 months
adjustments in 1 month
steps
1
Reset Parameters
to Factory
Defaults
20:FS 1 All settings held are
the factory defaults.
Changes to 0 when
one of the
parameter values
are changed
0
1
Settings are as modified
above
To restore the factory
profile set to 1
1
‘Category 2: System Parameters (You must press the ‘>’ program key to enter this section)
Minimum ON Time 1:Ot 1 1 minute minimum
ON time
2 to 5 2 - 2 minutes
3 - 3 minutes
4 - 4 minutes
5 - 5 minutes
2
Cycle Rate 2:Cr 6 6 cycles per hour
(cph) for gas boilers,
zone valves and fan-
coil
3, 9, 12 3 - 3 cph
9 - 9cph
12 - 12 cph
2
Pump Exercise 5:PE 0 Pump Exercise
Disabled
1 Pump Exercise Enabled 2

CM701 CHRONOTHERM
EN0H 8559 UK07 R0 09/066
DIMENSIONS
LOCATION
The CM701 thermostat is the control element of the heating
system and, therefore, MUST be located in a position with
good air circulation, at average room temperature and on an
inside wall, 1.5 metres above the floor level. Do not position
the CM701 thermostat near sources of heat (radiators, hot air
vents, TV or lights), near doors or windows, or in direct
sunlight.
MOUNTING
The CM701 thermostat can be mounted directly on the wall
surface or on to an electrical wall box.
WIRING
The CM701 thermostat is designed for fixed wiring only and
must be installed in accordance with the latest l.E.E.
regulations. Ensure the wiring connection to the supply is via
a fuse rated at no more than 5 amps and a Class "A" switch
(having contact separation of at least 3 mm in all poles).
IMPORTANT
1. The installer must be a trained service engineer
2. Disconnect the power supply before beginning
installation
INSTALLATION

CM701 CHRONOTHERM
Honeywell Control Systems Limited http://europe.hbc.honeywell.com
Newhouse Industrial Estate
Motherwell ML1 5SB
United Kingdom
EN0H 8559 UK07 R0 09/06
WIRING
ORDERING SPECIFICATION
Description Model Logo Literature Availability Spec Sheet
1-day programmable thermostat CMT701A1014 Honeywell English Oct 06 ENOH8559
