Honeywell CT62A User manual

WARNING
This thermostat is a line voltage control (120 Volts to
240 Volts.) Do not install it if you are not completely
familiar with house wiring. If handled improperly,
there can be risk of a 120 Volt to 240 Volt electric
shock hazard, which may cause serious injury or
death.
CT62A,B
Line Voltage Electric Heat Thermostats
S.M. • Rev. 11-94 • ©Honeywell Inc. 1994 • Form Number 69-0829—1
Your Honeywell Thermostat
Your new Honeywell CT62 Electric Heating Thermostat
provides line voltage control of a radiant cable, electric
baseboard, and resistive-rated fan forced heaters within
the ratings listed above.
Installation Instructions
CT62A provides single-line break.
CT62B provides double-line break.
Temperature Range: 50°F to 80°F (10°C to 25°C)
Electrical Ratings: 60 Hz noninductive
22A at 120-240 Vac; 19A at 277 Vac
Do-It-Yourself models
3REMOVE OLD THERMOSTAT
WARNING
Begin by turning off power to the heating circuit at
the main service panel.
Remove cover of old thermostat—cover normally
snaps off when pulled firmly from the bottom. If it
resists, check for a screw that locks the cover.
Loosen screws holding thermostat base to outlet
box and lift away.
Disconnect wires from old thermostat. As you
disconnect each wire, tape the end and label it with
the letter of the terminal designation to make reconnection
to new thermostat easier.
Check the old insulation for cracks, nicks or fraying,
and apply high quality plastic tape where necessary
for adequate insulation.
Retain the old thermostat for reference purposes
and until your new thermostat is functioning
smoothly.
1PREPARATION
Proper installation of your Honeywell thermostat will
occur if you follow these instructions STEP-BY-
STEP. It is recommended that as you read, understand
and complete each step, you check ✓it off with pencil or
pen.
Check thermostat suitability for your home’s system
by reviewing the ratings listed above.
Make certain that your heating system is working,
especially if it has been inoperative for a length of
time. If the system does not work, contact your local
electrician for assistance.
Carefully unpack your new thermostat. To avoid
damage to the sensing element, do NOT remove
the thermostat cover until wiring has been completed.
Save packages of screws, instructions, receipt and
proof-of-purchase.
THERMOSTAT MOUNTING
2DIMENSIONS
M5795A
FRONT VIEW SIDE VIEW
80
•
70
•
60
•
50
•
˚F
4-3/8
(111)
2-7/8 (73) 1-1/2
(39)
1-3/4
(48)
3/4
(19) 1/2 (13)
1/2 (13)
2-1/8
(54)
3-1/4
(83)

4WIRE AND MOUNT NEW THERMOSTAT
Turn the temperature setting knob to 65°F (18°C).
This will prevent accidental damage to the knob
stop during mounting.
Remove thermostat cover by grasping the top and
bottom ends with fingers, and pulling outward.
Connect wires to the thermostat as shown in the
applicable wiring diagram. Push the wires into the
outlet box, and insert the thermostat into the box for
mounting by pushing against top and bottom of the
thermostat base.
IMPORTANT:
Do not press on setting knob.
Secure the thermostat to the box with the two
captive mounting screws provided.
Replace thermostat cover.
Set knob to desired room temperature.
IMPORTANT:
Rough handling or strong pressure can
damage knob or sensing element, and change
calibration.
69-0829—12
5
5
6
0
6
5
7
0
7
5
8
0
8
5
o
F
M8422
L1
(HOT) L2
1
1
1
2
3
4
3
244
POWER SUPPLY. PROVIDE DISCONNECT MEANS AND OVERLOAD
PROTECTION AS REQUIRED.
BREAKS ON POSITIVE OFF.
EXPOSED UNUSED LEADWIRES TO BE PROPERLY INSULATED.
THERMALLY ACTIVATED—BREAKS ON TEMPERATURE
RISE. MAKES ON TEMPERATURE FALL.
L2 L1 L1
T2 T1 T1
CT62ACT62B
3
ELECTRIC
HEATER
CAUTION:
SPECIAL SERVICE CO/ALR SOLDERLESS CONNECTORS MUST
BE USED WHEN CONNECTING WITH ALUMINUM CONDUCTORS;
OTHERWISE, A FIRE HAZARD CAN RESULT.
TO
ELECTRIC
HEATER
M8420
5CHECK OUT THERMOSTAT
Turn on the power to the heating system.
Turn setting knob all the way clockwise ; listen
for clicking sound as switch makes contact. Electric
heater should begin operation.
Turn knob all the way counterclockwise ; listen
for clicking sound as switch breaks contact. Electric
heater should shut off.
6SETTING THERMOSTAT
Begin with setting knob at 70°F (20°C) on the scale.
If this setting is not satisfactory after at least two
hours of operation, turn setting knob upscale to
raise the temperature, or downscale to lower the tempera-
ture. Move knob only a degree each time.

Symptom Checkout Action
No heat. Make sure power is on at
main service panel. Turn
the temperature setting
knob fully clockwise .
Heater should start to warm up within two minutes. If not,
contact qualified electrician to check thermostat and heater.
Improper connections to
thermostat. With power to circuit OFF, tighten all wiring connections. Repair any frayed or broken wires.
Other. Contact a qualified electrician for assistance.
Heater never turns
off. Turn temperature setting knob fully
counterclockwise .
Heater should start to cool within minutes. If not, turn off power
at the main service panel, and contact qualified electrician.
Thermostat setting
and thermometer
reading disagree.
Thermostat affected by
drafts or radiant heat. Contact electrician to change the location. The thermostat should be about 5 ft (1.5m) above the floor and on an inside
wall.
Thermometer is out of
calibration. Recalibrate. See step 8.
3 69-0829—1
Check Calibration
Turn the setting knob clockwise until the switch
makes (clicking sound). The heating equipment and
fan start.
No recalibration is necessary if the thermostat switch
makes with the thermostat setting at the same
temperature as indicated on the thermometer.
If the thermostat setting differs from the thermom-
eter, record the temperature difference and
recalibrate as instructed in the Recalibration Procedure
section.
Recalibration Procedure
Note the temperature difference between the
temperature setting and the thermometer.
Remove the thermostat cover.
Rotate setting knob clockwise until you hear
switch click.
Hold the setting knob firmly and rotate the set point
scale ring counterclockwise until the
12 o'clock position of the ring agrees with the cover
thermometer.
7TROUBLESHOOTING
Your Honeywell thermostat requires little or no attention. Most problems can generally be traced to the following:
8CALIBRATION
The CT62 Thermostats are calibrated at the factory using
precise instruments under closely controlled conditions.
Recalibration should not be necessary. Allow the thermo-
stat to operate for several hours before checking the
calibration. The CT62 Thermostat vapor-filled dual
diaphragm sensing element is affected by barometric
pressure and altitude. Temperature deviations of 1°F
(0.5°C) are normal. If the thermostat is mounted in a
suitable location and still appears out of calibration, check
calibration as follows:
M5796
THERMOSTAT
BASE
SETTING KNOB
AT 12 O'CLOCK
POSITION
SETTING KNOB
SCALE RING
8
0
7
5
7
0
6
5
6
0
5
5
5
0
The heat from your hand will affect the diaphragm
sensor. Replace thermostat cover, wait five minutes
and recheck calibration.
