Honeywell Lyric T6 User manual

User Guide
EN
Lyric™T6 & T6R Smart Thermostat
Lyric™T6
Programmable Thermostat
Lyric™T6R
Wireless Programmable Thermostat

2
• Connects to the Internet so you can control your heating system from anywhere with
the Lyric App.
• Remotely view and change your heating system settings.
• Diverse programming options that fit any lifestyle:
- Time Scheduling – program schedule supports daily or 52 with 6 time periods for each day
- Geofencing – use a smartphone’s location to manage comfort when home or away
- Smart Scheduling – use a combination of geofencing and time scheduling to fit a busy lifestyle
• Group scheduling for multiple devices and locations (set-up and manage via the
Lyric App).
• Receive alerts (such as boiler failure) from the Thermostat, App, and email.
• Get automatic upgrades.
• The free Honeywell Lyric App is available for Apple®iPhone®and iPad®devices at
iTunes®or at Google Play®for all Android™ devices.
Need help?
If you need more information, or for help with your Lyric Thermostat go to:
getconnected.honeywell.com
Lyric T6 & T6R Smart Thermostat Features
Lyric

3
Contents
Quick reference to the display.............................................................................4
Quick reference to the icons ................................................................................5
Navigating the menu................................................................................................5
Main menu.....................................................................................................................6
Connecting to a WiFi® network .........................................................................7
Disconnect or reconnect to a WiFi network ...............................................7
Setting the system mode.......................................................................................8
Turn the schedule On/Off......................................................................................8
Schedule options .......................................................................................................8
Preset energy-saving schedules........................................................................9
Setting the vacation mode....................................................................................9
Adjusting a program schedule .........................................................................10
Overriding a program schedule.......................................................................11
Optimisation functions ........................................................................................13
Locking the interface............................................................................................13
Troubleshooting.......................................................................................................14

4
Quick reference to the display
1234
210
Note: To save power, the screen will dim and enter idle mode 45 seconds after
the last button touch. The screen will light up when you touch any button.
Save
- Saves schedule
settings
Messaging centre
- Shows device setup
options, reminders and
alerts, status of program
schedule overrides
Menu
- Touch to display
options
Start/stop Schedule
- Activates or deactivates
program schedule
Delete
- Deletes a
schedule period
Schedule period
- Indicates current
schedule period
Cancel
WiFi communication
Select
- Touch to access sub-menus
or confirm selection
Return
Lock
System Mode
- Heat/Off
Actual room
temperature
Setpoint
temperature
Receiver module
communication
Current time

5
Quick reference to the icons
Navigating the menu
Geofencing active
Geofencing home active
Geofencing away active
Geofencing sleep active
Failure/Alarm
Optimisation active
Schedule disabled
Schedule enabled
Temporary Hold active
Heating demand active
Receiver module communication
Communication failure
WiFi communication
WiFi failure
(MENU): Touch to access all sub-menus, configurable options.
and (ARROWS): Touch to navigate the sub-menus and options.
and (PLUS/MINUS): Touch to change settings (temperature, date)
(RETURN): Touch to or go back to previous menu.
(SELECT/CONFIRM): Touch to confirm selection, or access a sub-menu.
Note: In addition to touching (SELECT), a sub-menu can be accessed
by touching the text in the message area (for example, SCHEDULE).

6
Main menu
The main menu lets you customise how the Thermostat displays information or responds
to certain situations. The menus are:
SCHEDULE
View or edit the schedule
WI-FI
Setup or change WiFi settings
CLEAN SCREEN
Disables screen for 30 seconds
in order to clean it
LOCK
Restricts access to thermostat interface
LANGUAGE
Change the language
CLOCK
Set the time and date
IDLE BRIGHTNESS
Set the backlight brightness
for the idle screen
SCHEDULE OPTIONS
Select the type of schedule to run
OPTIMISE
Configure optimisation settings
(start/stop/delay)
TEMPERATURE OFFSET
Offsets the measured temperature
RESET
Reset the schedule, WiFi or Homekit
to factory default settings
DEVICE INFO
Device information like
model, MAC code, etc.

7
Connecting to a WiFi®network
Before continuing you should:
• Ensure your WiFi is secure and set to 2.4GHz.
• Have a note of your home WiFi network name and password.
• Switch on your smartphone or tablet WiFi.
Once connected to your WiFi network and Lyric App, the Thermostat will briefly display
SUCCESs and the connected symbol will be displayed in the upper right corner. The
Thermostat will also set the time and date automatically once connected to the internet.
Disconnect or reconnect to a WiFi network
If you need to disconnect the Thermostat from your WiFi network (for example, you’re
replacing your router), or if you need to reconnect to another WiFi network, follow the
instructions described in the Lyric App under the menu ‘Thermostat Configuration’.
1Download and install the
Honeywell Lyric App from the
Google Play or Apple App Store.
2Open the Lyric App, press
“CREATE ACCOUNT” and
follow the App instructions.
To connect your thermostat to your Wi-Fi network and register:
CREATE ACCOUNT
LOGIN
INSTALL A DEVICE
Lyric
Life in tune
Lyric

8
Setting the system mode
• When the button is touched, the
Thermostat toggles the system Heating or Off.
• The available modes are:
- Heating On:Controls the heating
system to achieve desired temperature.
- Off
Your Lyric Thermostat can switch heating equipment on or off, to effectively manage your
comfort depending on the indoor condition and your preferred temperature.
Turn the schedule On/Off
Your Lyric Thermostat is a programmable thermostat with a schedule, but the schedule
can also be turned off.
• Touch to deactivate or activate the schedule.
Schedule options
Your Lyric Thermostat has three schedule types:
• Daily (7-day) : Individual program for each day of the week.
• 5 + 2 days : Individual program for weekdays and weekend.
• Geofence : Location based temperature control.
Can only be enabled and configured using the Lyric App.
1004
210

9
Preset energy-saving schedules
Your Lyric Thermostat comes with the following default schedule. To change
these settings go to ‘Adjusting program schedules’ on the next page.
MonFri Sat + Sun
Period Time Temperature Time Temperature
16:30 - 8:00 19 °C 8:00 - 10:00 19 °C
28:00 - 18:00 16 °C 10:00 - 17:00 16 °C
518:00 - 22:30 21 °C 17:00 - 23:00 21 °C
622:30 - 6:30 16 °C 23:00 - 8:00 16 °C
For more scheduling options, go to your Lyric App.
Setting the holiday mode
This feature helps you save energy while you are away for longer periods,
and restores comfortable settings just before you return home.
• To activate your holiday period, in your Lyric App go to
Menu/Setting/Holiday
• HOLIDAY is indicated on the Thermostat.
• You can cancel Holiday Mode either on the Thermostat or in the Lyric App.
Touch on your Thermostat home screen to
resume the regular program schedule.

10
Adjusting a program schedule
1. Use and to go to SCHEDULE
Delete a period
Touch to delete the
selected period. The
screen will read DELETE.
Touch to confirm or
to cancel without deleting.
Touch to save the
schedule changes.
SCHED
***MON-FRI** 1040*TO∂1500
MO-FR
1040*TO∂1500
MO-FR
1050*TO∂1500
MO-FR
1050*TO∂1500
MO-FR
2. Select day(s) to
be adjusted.
3. Select time period to be
adjusted. The selected
period flashes.
4. Touch time that needs
to be changed. Touch
or to change it.
Repeat with other time.
5. Touch the period’s
temperature to change it.
It will start flashing.
Touch or to
adjust the temperature.
Touch to confirm
the changes.
6. When you have
finished adjusting the
schedule, touch
to save the changes.
