Honeywell Lyric User manual

Installation Guide
Removing your existing thermostat .............. 3
Installing your Lyric thermostat ...................... 5
Connecting your Lyricthermostat .................. 7
Configuring your Lyricthermostat ................. 8
Personalize your Lyric thermostat ................. 9
All manuals and user guides at all-guides.com
all-guides.com

Get started
2
LYRIC INSTALLATION GUIDE
Next, verify you have the following
in your package:
• Thermostat
• Wallplate
• Mounting screws
• Backplate - this is an optional piece
used to help cover marks left
by the old thermostat.
To get started, download the app by
searching for Lyric in the App Store
or Google play. Follow the steps to
create an account before you get
started.
You will need:
• Wi-Fi password
• Ballpoint pen
• Phillips screwdriver
• Pencil
All manuals and user guides at all-guides.com

Verify the power is o. Go to your thermostat and try
increasing or decreasing the temperature. Many digital
thermostats are battery powered, which makes it dicult
to tell if the power is o. Listen to ensure your system is
turned o before continuing.
Switch o the power to your heating and/or cooling
system at the circuit breaker box or at the system switch
or on your heating and/or cooling unit.
Remove your existing thermostat
3
LYRIC INSTALLATION GUIDE
72
listen
feel
12
All manuals and user guides at all-guides.com

Remove your existing thermostat
continued
4
LYRIC INSTALLATION GUIDE
In your app, you’ll find a prompt to take a picture of your
current wire configuration.
Remove the front of the old thermostat but keep the
wallplate with wires attached. Check the wires to see what
type of voltage you have. Do you have thick black wires
with wire nuts? Is your thermostat 110 volts or higher?
If yes, you have a line voltage system, and the Lyric
thermostat will not work. For more options, please visit
yourhome.honeywell.com/home/Products/Thermostats
R
W
Y
G
R
W
Y
G
R
W
Y
G
Once all wires have been recorded, disconnect them from
your old thermostat. Remove the old wallplate from the
wall. To prevent wires from falling back into the wall, wrap
the wires around a pencil.
Record your current wiring. Within your Lyric app, select
the terminals on your old thermostat that have wires
connected to them.
FPO
app screen showing
terminal configuration
process
R
W
Y
G
R
W
Y
G
3 4
5 6
All manuals and user guides at all-guides.com

To insert wires, slide each wire into its corresponding
terminal and ensure it is secure by gently tugging.
To remove wires, gently push down on the terminal tab(s)
with a ballpoint pen as you pull the wire.
Screw the wallplate in place using the included hardware.
Note that the screws included in your packaging are
specially designed for the Lyric thermostat and are self-
anchoring.
Install your Lyric thermostat
5
LYRIC INSTALLATION GUIDE
After threading the wires through the wallplate, mount
the wallplate of the Lyric thermostat. Make sure it’s
level by verifying the bubble of the self-contained level is
between the two lines. (Included in the box is an optional
trim ring you can use to cover wall blemishes. If you
choose to use the trim ring, attach it to the wallplate prior
to mounting.)
Follow the directions within the Lyric app based on your
unique wiring. Your app will show you the terminals and
wires you recorded from your old thermostat.
FPO
app screen showing
terminal configuration
process
12
34
All manuals and user guides at all-guides.com

Lyric Stat 03
I’m looking
for your device.
Download and open
the Lyric app.
FPO
Lyric Stat 03
I’m looking
for your device.
Download and open
the Lyric app.
FPO
Install your Lyric thermostat
continued
6
LYRIC INSTALLATION GUIDE
Go to the Lyric app to see how to configure and
personalize your Lyric thermostat. You can also view
additional videos at lyric.honeywell.com.
Your app will also tell you whether the slider tab on the
left and right of the wallplate needs to be pushed up
or down based on your R-wire installation. If your old
thermostat had only one R-wire connected, make sure the
slider tab is pushed up to cover the RC connection. If your
thermostat has two R-wire connections, R and RC, push
the slider tab down.
1 wire
2 wire
R
R & RC
After connecting your wiring, attach the thermostat by
gently pressing it to the wallplate.
Turn the power to your unit back on.
Lyric Stat 03
I’m looking
for your device.
Download and open
the Lyric app.
Your thermostat will light up while it starts up - this may
take up to 3 minutes. When the thermostat stops, it will
display a unique network name, for example, Lyric Stat 03.
When you see the unique network name, touch “OK” to
begin your thermostat configuration.
5
78
6
All manuals and user guides at all-guides.com
all-guides.com

Connect your Lyric thermostat
7
LYRIC INSTALLATION GUIDE
Connect your smartphone or tablet to the thermostat
network. Your new thermostat should be displaying a
unique network name, such as Lyric Stat 03.
unique Lyric
network name
Lyric Stat 03
I’m looking
for your device.
Download and open
the Lyric app. unique Lyric
network name
Lyric Stat 03
I’m looking
for your device.
Download and open
the Lyric app.
If you have an Android smartphone or tablet: The app will
automatically connect to your thermostat.
android
devices
If you have an iOS smartphone or tablet: To connect
your iOS smartphone or tablet to the thermostat network,
leave the Lyric app, go to your iOS settings and view your
Wi-Fi networks. Find and connect to the thermostat’s
unique network name such as Lyric Stat 03. Close your iOS
settings and return to the Lyric app to complete the setup
process.
1
3
2
All manuals and user guides at all-guides.com

Configure your Lyric thermostat
8
LYRIC INSTALLATION GUIDE
Select the temperatures you prefer when you are home.
Select whether you prefer automatic or manual
mode when you are away. If you select automatic,
your thermostat will change your away temperatures
automatically to maximize your savings. If you select
manual, you will set your away temperatures for your
thermostat.
Review your configuration selections and, if everything
looks correct, click “next” to complete the configuration.
Configure your heating and cooling equipment: The
app will ask you a series of questions to determine your
equipment configuration.
1
34
2
All manuals and user guides at all-guides.com

lyric.honeywell.com
Personalize your Lyric thermostat
9
LYRIC INSTALLATION GUIDE
Personalize and register your thermostat with Honeywell.
Give your thermostat a location name (home, cabin) and
thermostat name (living room, basement).
FPO
app screen
showing
multiple
thermostats
Complete your profile to register your thermostat with
Honeywell by providing your address and time zone.
FPO
iOS app screen
showing
network sync
Lyric Stat 03
The Lyric app
will tel you how
to connect to me
To learn more about your Lyric thermostat and how to get
the most out of it, visit lyric.honyewell.com
From the Lyric app, select your Wi-Fi network to
connect your thermostat (or manually add it). Enter your
password if password protected. The thermostat is now
connecting to your home Wi-Fi network. It will take up
to three minutes to establish a connection and sync with
Honeywell. (During this time, do not navigate away from the
Lyric app.) If an error appears on your thermostat screen,
touch “Connect Again” to re-establish the connection.
FPO
iOS app screen
showing
network sync Lyric Stat 03
The Lyric app
will tel you how
to connect to me
FPO
app screen
showing
multiple
thermostats
1 2
34
