TC300 Thermostat
BACnet Integration Guide

3
Table Of Contents
Declaration .......................................................................................................................................7
Waste Electrical and Electronic Equipment (WEEE) ................................................ 7
FCC Part 15 compliant .......................................................................................................... 7
Regulation (EC) No 1907/2006 ........................................................................................ 8
Important Safety Information and Installation Precautions.................................. 8
Chapter 1 - Introduction............................................................................... 11
Scope of the document ...................................................................................................... 11
Reference documents......................................................................................................... 11
Terms, Acronyms, and Abbreviations............................................................................ 12
Setting up BACnet MS/TP ................................................................................................ 13
Adding a thermostat to the BACnet network ............................................................. 17
Chapter 2 - Wiring and installation ............................................................ 21
Power supply guidelines and requirements............................................................... 21
RS485 Interface cable Type.............................................................................................. 24
Thermostat powered by separate transformer ......................................................... 24
Thermostat powered by public transformer .............................................................. 25
Chapter 3 - Terminal input/output and IO configuration ..................... 27
IO status ................................................................................................................................... 28
IO Assignment........................................................................................................................ 28
Terminal input........................................................................................................................ 32
Terminal output and network output............................................................................ 32
IO configuration .................................................................................................................... 33

4
TC300 THERMOSTAT BACNET INTEGRATION GUIDE
Chapter 4 - Alert ............................................................................................. 35
Alerts ..........................................................................................................................................36
Alert configuration................................................................................................................39
Chapter 5 - Network output ......................................................................... 41
Network outputs ....................................................................................................................42
Schedule ...................................................................................................................................45
Sylk sensor reading ..............................................................................................................45
Chapter 6 - Application configuration....................................................... 47
Auxiliary heat configuration .............................................................................................48
Cooling configuration .........................................................................................................48
Deadband.................................................................................................................................48
Dehumidification Configuration.....................................................................................49
Fan configuration..................................................................................................................49
Fan speed .................................................................................................................................51
Heating configuration.........................................................................................................51
Chapter 7 - Common configuration............................................................ 53
Control.......................................................................................................................................54
Equipment ...............................................................................................................................54
General ......................................................................................................................................58
Home..........................................................................................................................................58
Indoor temperature limits..................................................................................................58
Multi sensor.............................................................................................................................60
Occupancy setpoints...........................................................................................................62
Purge ..........................................................................................................................................62
Recovery setpoint configuration.....................................................................................63
Discharge air control ...........................................................................................................64
Sylk calibration offsets........................................................................................................64
Sylk sensor configuration ..................................................................................................65
Wall module configuration................................................................................................66
Network .....................................................................................................................................66

5
TC300 THERMOSTAT BACNET INTEGRATION GUIDE
Chapter 8 - Network inputs...........................................................................67
Fail detect .................................................................................................................................68
Tuning Policy ...........................................................................................................................69
Network inputs .......................................................................................................................71
Network sensor configuration..........................................................................................72
Service mode ...........................................................................................................................72
Chapter 9 - Calendar & schedule .................................................................75
Calendar....................................................................................................................................76
Schedule ...................................................................................................................................76
Chapter 10 - BACnet Guidelines for TC300 ..............................................77
Situational BACnet guidelines for TC300....................................................................78
TC300 proprietary properties list....................................................................................78
List of all BACnet objects ...................................................................................................80

6
TC300 THERMOSTAT BACNET INTEGRATION GUIDE

TC300 BACnet Integration Guide 7
Declaration
This document contains Honeywell proprietary information. Information contained
herein is to be used solely for the purpose submitted, and no part of this document
or its contents shall be reproduced, published, or disclosed to a third party without
the express permission of Honeywell International Inc.
While this information is presented in good faith and believed to be accurate, Hon-
eywell disclaims the implied warranties of merchantability and fitness for a pur-
pose and makes no express warranties except as may be stated in its written
agreement with and for its customer.
In no event is Honeywell liable to anyone for any direct, special, or consequential
damages. The information and specifications in this document are subject to
change without notice.
Copyright 2023 – Honeywell International Inc.
Waste Electrical and Electronic Equipment (WEEE)
FCC Part 15 compliant
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
WEEE: Waste Electrical and Electronic Equipment Directive
• At the end of the product life, dispose of the
packaging and product in an appropriate
recycling center.
• Do not dispose of the device with the usual
domestic refuse.
• Do not burn the device.

8 TC300 BACnet Integration Guide
Regulation (EC) No 1907/2006
According to Article 33 of Reach Regulation, be informed that the substances listed
below may be contained in these products above the threshold level of 0.1% by
weight of the listed article.
Important Safety Information and Installation Precautions
Read all instructions.
Failure to follow all instructions may result in equipment damage or a hazardous
condition. Read all instructions carefully before installing equipment.
When performing any work (installation, mounting, start-up), all manufacturer
instructions and in particular the TC300 Commercial Thermostat Mounting
Instructions (31-00642) are to be observed.
• TC300 Thermostat may be installed and mounted only by authorized and trained
personnel.
• It is recommended that devices be kept at room temperature for at least 24 hours
before applying power. This is to allow any condensation resulting from low
shipping/storage temperatures to evaporate.
• Do not open TC300 Thermostat, as it contains no user-serviceable parts inside!
• Investigated according to United States Standard UL- 60730-1, and UL60730-2-
9.
• Investigated according to Canadian National Standard(s) C22.2, No. 205-M1983
(CNL-listed).
• CE declarations according to LVD Directive 2014/35/EU and EMC Directive
2014/30/EU.
• Product standards are EN 60730-1 and EN 60730-2-9.
• TC300 Thermostat is Class B digital apparatus and complies with Canadian ICES-
003.
Local codes and practices
Always install equipment in accordance with the National Electric Code and in a
manner acceptable to the local authority that have jurisdiction.
Electrostatic sensitivity
This product and its components may be susceptible to electrostatic discharge
(ESD). Use appropriate ESD grounding techniques while handling the product.
When possible, always handle the product by its non-electrical components.
Product/Part Code Substance Name CAS Number
Only TC300 thermostat mainboard CBA,
thermostat wall plate board PCBA
Lead 7439-92-1
Lead oxide 1317-36-8

TC300 BACnet Integration Guide 9
High voltage safety test
Experienced electricians, at first contact, always assume that hazardous voltages
may exist in any wiring system. A safety check using a known, reliable voltage
measurement or detection device should be made immediately before starting work
and when work resumes.
Lightning and high-voltage danger
Most electrical injuries involving low-voltage wiring result from sudden, unexpected
high voltages on normally low voltage wiring. Low voltage wiring can carry hazardous
high voltages under unsafe conditions. Never install or connect wiring or equipment
during electrical storms. Improperly protected wiring can carry a fatal lightning surge
for many miles. All outdoor wiring must be equipped with properly grounded and
listed signal circuit protectors, which must be installed in compliance with local,
applicable codes. Never install wiring or equipment while standing in water.
Wiring and equipment separations
All wiring and controllers must be installed to minimize the possibility of accidental
contact with other potentially hazardous and disruptive power and lighting wiring.
Never place 24 VAC or communications wiring near other bare power wires, lightning
rods, antennas, transformers, or steam or hot water pipes. Never place wire in any
conduit, box, channel, duct, or other enclosure containing power or lighting circuits
of any type. Always provide adequate separation of communications wiring and
other electrical wiring according to code. Keep wiring and controllers at least six feet
from large inductive loads (power distribution panels, lighting ballasts, motors, etc.).
Failure to follow these guidelines can introduce electrical interference and cause the
system to operate erratically.
Warning
By using this Honeywell literature, you agree that Honeywell will have no liability for
any damages arising out of your use, or modification to, the literature. You will defend
and indemnify Honeywell, its affiliates and subsidiaries, from and against any
liability, cost, or damages, including attorneys' fees, arising out of, or resulting from,
any modification to the literature by you.
The material in this document is for information purposes only. The content and the
product it describe are subject to change without notice. Honeywell makes no
representations or warranties with respect to this document. In no event shall
Honeywell be liable for technical or editorial omissions or mistakes in this document,
nor shall it be liable for any damages, direct or incidental, arising out of or related to
the use of this document. No part of this document may be reproduced in any form
or by any means without prior written permission from Honeywell.
Safety Information as per EN60730-1
TC300 Thermostat is intended for commercial and residential environments.
TC300 Thermostat is an independently mounted electronic control system with fixed
wiring.
TC300 Thermostat is used for the purpose of building HVAC control and is suitable
for use only in non-safety controls for installation on or in appliances.

10 TC300 BACnet Integration Guide

CHAPTER
1
Scope of the document 11
INTRODUCTION
Topics covered
Scope of the document
Reference documents
Terms, Acronyms, and Abbreviations
Setting up BACnet MS/TP
Adding a thermostat to the BACnet network
Scope of the document
The BACnet Integration document contains information related to BACnet Objects
and the properties of the thermostat that help engineers to integrate and configure
the settings via a BACnet tool. It also contains wiring and installation of the ther-
mostat.
Reference documents
• TC300 Commercial Thermostat User Guide (31-00644)
• TC300 Commercial Thermostat Datasheet (31-00645)
• TC300 Commercial Thermostat Mounting Instructions (31-00642)
• TC300 Commercial Thermostat Pocket Guide(31-00648)
• TC300 Deco Plate Pocket Guide (31-00657)
• TC300 Safety Sheet (31-00643)
• TC300 Thermostat BACnet Integration Guide (31-00646)

12 Terms, Acronyms, and Abbreviations
Terms, Acronyms, and Abbreviations
Table 1 Terms, Acronyms, and Abbrevations
Term, Acronym, Abbreviation Definition
UI Universal Input
UIO Universal Input/Output
DO Digital Output
Cfg Configuration
BAS Building Automation System
ni Network Input
no Network Output
NC Network Configuration

Setting up BACnet MS/TP 13
Setting up BACnet MS/TP
The BACnet MS/TP network can be configured while setting up the thermostat.
Refer to the TC300 Commercial Thermostat User Guide - 31-00644 or follow the
steps below.
To connect thermostat via BACnet MS/TP
1. Swipe left from the Home page.
2. On the Quick access page, tap > Connection.
The Connection page appears.
Fig 1. BACnet MS/TP connection
3. Tap the BACnet MS/TP.
The BACnet MS/TP page appears.
Fig 2. BACnet MS/TP
4. Tap BACnet MS/TP and enable it.
The BACnet MS/TP configuration page appears.

14 Setting up BACnet MS/TP
Fig 3. BACnet MS/TP
5. The device automatically adapts to the baud rate of the MS/TP network. You can also
manually select the baud rate.
6. Enter a unique Device ID for the thermostat. It should be different from other TC300
thermostats.
7. Auto MAC addressing is enabled by default. The installer can also manually set a unique
MAC address for the TC300.
8. To do manual configuration, tap Manual.
A text box appears below to enter the MAC address.
9. Tap Baud Rate, to select a desired baud rate from the list.

Setting up BACnet MS/TP 15
Fig 4. Baud Rate
10. Tap the back arrow button to navigate back to BACnet MS/TP setting page.
11. Tap BACnet MS/TP Setting.
The BACnet MS/TP setting page appears.
Fig 5. BACnet MS/TP Setting

16 Setting up BACnet MS/TP
12. Set the desired parameters and tap the back arrow button to navigate back to the
connection page.
Note: The TC300 will attempt to adapt to the baud rate of the MS/TP network in the first
four minutes after startup or when MS/TP is enabled. If the baud rate could not be
determined, for example, there is a single device on the network, then the TC300 will
choose the default baud rate of 76,800 Kbps. The installer can manually change the
baud rate to another value if desired.

Adding a thermostat to the BACnet network 17
Adding a thermostat to the BACnet network
The following procedure explains adding the TC300 thermostat to a Bacnet net-
work using the Niagara 4 workbench.
1. In the Niagara 4 workbench, create a new Station.
2. To configure the BACnet device, click Station > Config > Drivers >
BacnetNetwork > Local Device in the Nav view.
The property sheet of the local BACnet device appears in the right view.
Fig 6. Local Device Property Sheet
3. On the property sheet, change the Object Id to any other number instead of -1
and click Save.
4. In the Nav view seen on the left, click BACnet Comm > Network > MstpPort >
Link.
The property sheet of the MSTP port page appears.

18 Adding a thermostat to the BACnet network
Fig 7. Selecting the Adapter Type
5. Select Network Number.
6. Select the Baud rate from the drop-down list.
7. Select the Enabled field to True.
8. Click Save.
9. In the Nav view, double click the BacnetNetwork.
The BacnetNetwork discovery page appears.

Adding a thermostat to the BACnet network 19
Fig 8. Device Discovery Page
10. Click Discover.
The Configure Device Discovery page appears.
Fig 9. Configure Device Discovery
11. Select the Send Global checkbox and click OK.
The thermostat appears on the Discovered view page.

20 Adding a thermostat to the BACnet network
Fig 10. Adding the Discovered Device
12. Select the thermostat > click Add > then select the Type as BACnet Device from
the drop-down list.
The added thermostat appears on the Nav view under BacnetNetwork.
