Honeywell 69-1776EFS-01 User manual

Operating
Manual
PRO TH3000 Series
Non-Programmable Digital Thermostat
69-1776EFS-01

ENGLISH
Read and save these instructions.
® U.S. Registered Trademark. Patents pending.
Copyright © 2009 Honeywell International Inc. All rights reserved.
Need Help?
For assistance with this product please visit http://yourhome.honeywell.com
or call Honeywell Customer Care toll-free at 1-800-468-1502
CAUTION: EQUIPMENT DAMAGE HAZARD.
To prevent possible compressor damage, do not operate cooling system when outdoor
temperature is below 50°F (10°C).
This manual covers the following models:
TH3110D: For 1 Heat/1 Cool systems
TH3210D: For 2 Heat/1 Cool heat pump systems only
(Pull thermostat from wallplate and turn over to find model number.)
M29416

1 69-1776EFS—01
PRO TH3110D / TH3210D
ENGLISH
Table of contents
About your new thermostat
Thermostat features...................................2
Quick reference to controls.......................3
Quick reference to display ........................4
Thermostat Operation
System switch (Heat/Cool)........................5
Fan switch (Auto/On) ................................. 6
Temperature controls.................................7
Compressor protection..............................8
Appendices
Battery replacement ..................................9
In case of difficulty...................................10
Customer assistance ............................... 12
Accessories............................................. .12
5-year limited warranty............................13

69-1776EFS—01 2
Operating Manual
ENGLISH
Your new Honeywell thermostat has been designed to give you many years of reliable
service and easy-to-use, push-button climate control.
Features
• Large,clear,backlitdisplayiseasytoread,eveninthedark.
• Displaysbothroomtemperatureandtemperaturesetting.
• Built-incompressorprotection.
About your new thermostat

3 69-1776EFS—01
PRO TH3110D / TH3210D
About your new thermostat
ENGLISH
M29417
Temperature adjustment
(see page 7)
Fan Switch (see page 6)
On: Fan runs continuously.
Auto: Fan runs only when heating or
cooling system is on.
Quick reference to controls
System switch (see page 5)
• Cool: Cooling system control.
• Off: All systems off.
• Heat: Heating system control.
• Em Heat: Emergency & Auxiliary
Heat control. Compressor is locked
out. (Select models only.)
Digital display screen

69-1776EFS—01 4
Operating Manual
ENGLISH
Em Aux
Heat On
Set ToInside
75
75
Replace Batt
M29418
System Status
•Cool On: Cooling system is on.
•Heat On: Heating system is on.
•Em: Emergency heat is on. **
•Aux: Auxiliary heat is on. **
Quick reference to display screen
Current inside temperature Temperature setting
If “Heat On” or “Cool
On” is flashing, com-
pressor protection is
engaged (see page 8).
Low battery warning
(see page 9)
** Only for heat pumps with this capability
(select models only).

5 69-1776EFS—01
PRO TH3110D / TH3210D
ENGLISH
M29417
The SYSTEM switch can be set to control
your heating or cooling system, depending
on the season.
• Cool: Cooling system control.
• Off: All systems are off.
• Heat: Heating system control.
• Em Heat: Emergency & Auxiliary Heat
control. Compressor is locked out.
(Select models only.)
System switch
Set SYSTEM switch to control the
heating or cooling system.
CAUTION: EQUIPMENT DAMAGE HAZARD.
Do not operate cooling system when outdoor
temperature is below 50°F (10°C).

69-1776EFS—01 6
Operating Manual
ENGLISH
M29417
Fan switch
Set the FAN switch to Auto or On.
In “Auto” mode (the most commonly used
setting), the fan runs only when the heat-
ing or cooling system is on.
If set to “On,” the fan runs continuously.
Set FAN switch to choose whether the fan
runs continuously or only as needed.

7 69-1776EFS—01
PRO TH3110D / TH3210D
About your new thermostat
ENGLISH
M29419
Cool On
Set To
78
Inside
75
Temperature controls
Press the temperature adjustment
buttons until the temperature you want
is displayed in the upper right portion of
the screen.
Note: Make sure the SYSTEM switch is set
to the system you want to control (Heat or
Cool).
Desired
temperature.
Temperature
adjustment buttons.

69-1776EFS—01 8
Operating Manual
ENGLISH
M29420
Cool On
Set ToInside
75
75
This feature helps prevent damage to the
compressor in your air conditioning or heat
pump system.
Damage can occur if the compressor is
restarted too soon after shutdown. This fea-
ture forces the compressor to wait 5 minutes
before restarting.
During the wait time, the display will flash
the message Cool On (or Heat On if you have
a heat pump). When the safe wait time has
elapsed, the message stops flashing and the
compressor turns on.
Message flashes until safe restart
time has elapsed.
Built-in compressor protection

9 69-1776EFS—01
PRO TH3110D / TH3210D
ENGLISH
M29421
M29422
Batteries are optional (for backup
power) if your thermostat was wired to
run on AC power when installed.
Install fresh batteries when the REPLACE
BATT warning begins flashing. The
warning flashes about two months
before the batteries are depleted.
Replace batteries once a year, or
before leaving home for more than a
month. Batteries provide backup power
to the display during power interrup-
tions. All settings are permanently
stored in memory, and do not require
battery power.
Pull at bottom to
remove thermostat
from wallplate.
Turn thermostat
over, insert fresh AA
alkaline batteries,
then reinstall ther-
mostat.
Battery replacement

69-1776EFS—01 10
Operating Manual
ENGLISH
If you have difficulty with your thermostat, please try the following suggestions.
Most problems can be corrected quickly and easily.
Display is blank • Checkcircuitbreakerandresetifnecessary.
• Makesurepowerswitchatheating&coolingsystemison.
• Makesurefurnacedoorisclosedsecurely.
• MakesurefreshAAalkalinebatteriesarecorrectlyinstalled(seepage9).
Heating or
cooling system
does not respond
• SetsystemswitchtoHeat (see page 5). Make sure the temperature is
set higher than the Inside temperature.
• SetsystemswitchtoCool (see page 5). Make sure the temperature is
set lower than the Inside temperature.
• Wait5minutesforthesystemtorespond.
In case of difficulty

11 69-1776EFS—01
PRO TH3110D / TH3210D
ENGLISH
Temperature
settings do not
change
Make sure heating and cooling temperatures are set to acceptable ranges:
• Heat:40°to90°F(4.5°to32°C).
• Cool:50°to99°F(10°to37°C).
“Cool On” or
“Heat On” is
flashing
•Compressor protection feature is engaged. Wait 5 minutes for the system
to restart safely, without damage to the compressor (see page 8).
“Heat On” is not
displayed
•Set the System switch to Heat, and set the temperature level above the
current room temperature (see page 7).
“Cool On” is not
displayed
•Set the System switch to Cool, and set the temperature level below the
current room temperature (see page 7).
In case of difficulty

69-1776EFS—01 12
Operating Manual
ENGLISH
M29423
M29421
For assistance with this product, please visit
http://yourhome.honeywell.com.
Or call Honeywell Customer Care toll-free at
1-800-468-1502.
To save time, please note your model number
and date code before calling.
Accessories/replacement parts
To order, please call Honeywell Customer Care
toll-free at 1-800-468-1502.
Cover plate assembly*........ Part No. 50002883-001
*Use to cover marks left by old thermostats.
Customer assistance
Turn thermostat over
to find model number
and date code.
Pull at bottom to
remove thermostat
from wallplate.

13 69-1776EFS—01
PRO TH3110D / TH3210D
ENGLISH
Honeywell warrants this product, excluding battery, to be free from defects in the workmanship
or materials, under normal use and service, for a period of five (5) years from the date of pur-
chase by the consumer. If at any time during the warranty period the product is determined to
be defective or malfunctions, Honeywell shall repair or replace it (at Honeywell’s option).
If the product is defective,
(i) return it, with a bill of sale or other dated proof of purchase, to the place from which you pur-
chased it; or
(ii) call Honeywell Customer Care at 1-800-468-1502. Customer Care will make the determination
whether the product should be returned to the following address:
Honeywell Return Goods, Dock 4 MN10-3860, 1885 Douglas Dr. N., Golden Valley, MN 55422, or
whether a replacement product can be sent to you.
This warranty does not cover removal or reinstallation costs. This warranty shall not apply if it
is shown by Honeywell that the defect or malfunction was caused by damage which occurred
while the product was in the possession of a consumer.
Honeywell’s sole responsibility shall be to repair or replace the product within the terms stated
above.HONEYWELLSHALLNOTBELIABLEFORANYLOSSORDAMAGEOFANYKIND,
5-year limited warranty

69-1776EFS—01 14
Operating Manual
ENGLISH
5-year limited warranty
INCLUDINGANYINCIDENTALORCONSEQUENTIALDAMAGESRESULTING,DIRECTLYOR
INDIRECTLY,FROMANYBREACHOFANYWARRANTY,EXPRESSORIMPLIED,ORANY
OTHERFAILUREOFTHISPRODUCT.Somestatesdonotallowtheexclusionorlimitationof
incidental or consequential damages, so this limitation may not apply to you.
THISWARRANTYISTHEONLYEXPRESSWARRANTYHONEYWELLMAKESONTHIS
PRODUCT.THEDURATIONOFANYIMPLIEDWARRANTIES,INCLUDINGTHEWARRANTIES
OFMERCHANTABILITYANDFITNESSFORAPARTICULARPURPOSE,ISHEREBYLIMITEDTO
THE FIVE-YEAR DURATION OF THIS WARRANTY.
Some states do not allow limitations on how long an implied warranty lasts, so the above limita-
tion may not apply to you. This warranty gives you specific legal rights, and you may have other
rights which vary from state to state.
If you have any questions concerning this warranty, please write Honeywell Customer Relations,
1985 Douglas Dr, Golden Valley, MN 55422 or call 1-800-468-1502. In Canada, write Retail
ProductsON15-02H,HoneywellLimited/HoneywellLimitée,35DynamicDrive,Toronto,Ontario
M1V4Z9.

Honeywell International Inc.
1985 Douglas Drive North
Golden Valley, MN 55422
http://yourhome.honeywell.com
HoneywellLimited-HoneywellLimitée
35 Dynamic Drive
Toronto, Ontario M1V 4Z9
® U.S. Registered Trademark.
© 2009 Honeywell International Inc.
69-1776EFS—01 M.S. 05-09
Automation and Control Solutions
Printed in U.S.A. on recycled
paper containing at least 10%
post-consumer paper fibers.

Mode
d’emploi
Série PRO TH3000
Thermostatnumériquenonprogrammable

FRANÇAIS
Veuillez lire le mode d’emploi et le conserver en lieu sûr.
®MarquedecommerceenregistréeauxÉtats-Unis.Brevetseninstance
Copyright©2009HoneywellInternationalInc.Tousdroitsréservés
Besoin d’aide?
Pour obtenir de l’aide sur ce produit Honeywell, veuillez consulter le site Web
http://yourhome.honeywell.com ou adressez-vous au Service à la clientèle
de Honeywell en composant sans frais le 1-800-468-1502
MISE EN GARDE : RISQUE DE DOMMAGE MATÉRIEL
Pouréviterd’endommagerlecompresseur,nefaitespasfonctionnerlesystèmede
refroidissementlorsquelatempératureextérieureestinférieureà10°C(50°F).
Le présent mode d’emploi porte sur les modèles suivants :
TH3110D :Poursystèmesà1étagedechauffage/1étagede
refroidissement
TH3210D :Pourthermopompesà2étagesdechauffage/1étagede
refroidissement seulement
(Retirer le thermostat de la plaque murale et le retourner pour trouver le
numérodemodèle.)
M29416
