Hoover HLXV9TG Installation and operation manual

EN

!
2

!
EN
3
Thank you for choosing this product.
We are proud to offer the ideal product for
you and the best complete range of home
appliances for your daily routine.
Please read and follow these
instructions carefully and operate the
machine accordingly. This booklet provides
important guidelines for safe use,
installation, maintenance and some useful
advice for best results when using your
machine. Keep all documentation in a safe
place for future reference or for any future
owners.
Please check that the following items are
delivered with the appliance:
•Instruction manual
•Guarantee card
•Energy label
Check that no damage has occurred to the
machine during transit. If it as, call for
service by Customer Service Centre.
Failure to comply with the above can
compromise the safety of the appliance.
You may be charged for a service call if a
problem with your machine is caused by
misuse or by incorrect installation.
To contact the Service, ensure that you
have the unique 16-character code
available, also called the "serial number".
This code is a unique code for your
product, printed on the sticker that can be
found inside the door opening.
WEEE contains both polluting substances (which
can cause negative consequences for the
environment) and basic components (which can
be re-used). It is important to have WEEE
subjected to specific treatments, in order to
remove and dispose properly all pollutants, and
recover and recycle all materials. Individuals can
play an important role in ensuring that WEEE
does not become an environmental issue; it is
essential to follow some basic rules:
!WEEE should not be treated as household
waste;
!WEEE should be handed over to the relevant
collection points managed by the municipality or
by registered companies. In many countries, for
large WEEE, home collection could be present.
In many countries, when you buy a new
appliance, the old one may be returned to the
retailer who has to collect it free of charge on a
one-to-one basis, as long as the equipment is of
equivalent type and has the same functions as
the supplied equipment.
1. GENERAL SAFETY RULES
2. WATER CONTAINERS
3. DOOR, FILTER AND CONDENSER
4. PRACTICAL HINTS
5. REMOTE CONTROL (WI-FI)
6. QUICK USER GUIDE
7. CONTROLS AND PROGRAMMES
8. TROUBLESHOOTING AND WARRANTY
This appliance is marked according to
the European directive 2012/19/EU
on Waste Electrical and Electronic
Equipment (WEEE).
Contents
Environmental conditions

!
4
1. GENERAL SAFETY
RULES
!This appliance is intended to
be used in household and
similar applications such as:
- Staff kitchen areas in shops, offices
and other working environments;
- Farm houses;
- By clients in hotels, motels and
other residential type environments;
- Bed and breakfast type environments.
A different use of this appliance
from household environment
or from typical housekeeping
functions, as commercial use by
expert or trained users, is excluded
even in the above applications. If
the appliance is used in a manner
inconsistent with this it may reduce
the life of the appliance and may
void the manufacturer’s warranty.
Any damage to the appliance or
other damage or loss arising
through use that is not consistent
with domestic or household use
(even if located in a domestic or
household environment) shall not
be accepted by the manufacturer to
the fullest extent permitted by law.
!This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.
Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made
by children without supervision.
!Children should be supervised
to ensure that they do not play
with the appliance.
!Children of less than 3 years
should be kept away unless
continuously supervised.
!This machine is solely for
domestic use, i.e. to dry
household textiles and garments.
!Ensure that the instructions for
installation and use are fully
understood before operating
the appliance.
!Do not touch the appliance
when hands or feet are damp
or wet.
!Do not lean on the door when
loading the machine or use the
door to lift or move the machine.
WARNING
Misuse of a tumble dryer may
create a fire hazard.

!
EN
5
!Do not continue to use this
machine if it appears to be faulty.
!The tumble dryer is not to be
used if industrial chemicals
have been used for cleaning.
! Lint and fluff must not be allowed
to collect on the floor around the
outside of the machine.
!Always remove the plug before
cleaning the appliance.
!The drum inside may be very
hot. Always allow the dryer to
complete the cool down period
before removing the laundry.
!The final part of a tumble dryer
cycle occurs without heat (cool
down cycle) to ensure that the
items are left at a temperature
that ensures that the items will
not be damaged.
!Do not install the product in a
low temperature room or in a
room where there is a risk of
frost occurring. At temperature
around freezing point the
product may not be able to
operate properly: there is a risk
of damage if the water is
allowed to freeze in the
hydraulic circuit (valves, hoses,
pumps). For a better product
performance the ambient room
temperature must be between
5-35°C. Please note that
operating in cold condition
(between +2 and +5°C) might
simply some water condensation
and water drops on floor.
WARNING
Do not use the product if the
fluff filter is not in position or
is damaged; fluff could be
ignited.
WARNING
Where the hot surface
symbol is located the
temperature rise during
operation of the tumble
dryer may be in excess of 60
degrees C.
WARNING
Never stop a tumble dryer
before the end of the drying
cycle unless all items are
quickly removed and spread
out so that the heat is
dissipated.
Installation

!
6
!In cases where the dryer is
installed on top of a washing
machine, a suitable stacking kit
must be used according to the
configuration of your appliance:
− Stacking kit "standard size":
for washing machine with
minimum depth of 44 cm;
−Stacking kit "slim size": for
washing machine with
minimum depth of 40 cm.
−Universal stacking kit with
sliding: for washing machine
with minimum depth of
47 cm.
The stacking kit shall be
obtainable from service. The
instructions for installation and
any fixing attachments, are
provided with the stacking kit.
!NEVER install the dryer up
near curtains.
!The appliance must not be
installed behind a lockable
door, a sliding door or a door
with a hinge on the opposite
side to that of the tumble dryer.
!For your safety, the appliance
must be correctly installed. If
there is any doubt about installation,
call Service for advice.
!Once the machine is in place
the feet should be adjusted to
ensure that the machine is
level.
!The technical details (supply
voltage and power input) are
indicated on the product rating
plate.
!Make sure that the electrical
system is earthed, complies
with all applicable law and that
the (electricity) socket is
compatible with the plug of the
appliance. Otherwise, seek
qualified professional assistance.
Electrical connections and
safety instructions
WARNING
The appliance must not be
supplied through an external
switching device, such as a
timer, or connected to a circuit
that is regularly switched on
and off by a utility.

!
EN
7
!Do not use adapters, multiple
connectors and/or extensions.
!The plug should be accessible
for disconnection after the
appliance has been installed.
!Do not plug the machine in and
switch it on at the mains until
the installation is completed.
!If the supply cord is damaged,
it must be replaced by the
manufacturer, its service agent
or similarly qualified persons in
order to avoid a hazard.
!Adequate ventilation must be
provided in the room where the
tumble dryer is located to
prevent gases from appliances
burning other fuels, including
open fires, being drawn into
the room during operation of
the tumble dryer.
!Install the rear of the appliance
close to a wall or vertical surface.
!There should be a gap of at
least 12 mm between the
machine and any obstrubtions.
The inlet and outlet air should
be kept clear of obstruction.
!Make sure carpets or rugs
do not obstruct the base or any
of the ventilation openings.
!Prevent items from falling or
collecting behind the dryer as
these may obstruct the air inlet
and outlet.
!Exhaust air must not be
discharged into a flue which is
used for exhausting fumes
from appliances burning gas or
other fuels.
!Check regularly that the air
flowing around the dryer is not
restricted, avoiding accumulation
of dust and lint.
!Check frequently the fluff filter
after use, and clean, if necessary.
*
**
* Air inlet.
**Air outlet.
!Always refer to the laundry
care labels for directions on
suitability for drying.
Ventilation
The Laundry

!
8
!Fabric softeners, or similar
products, should be used as
specified by the fabric softener
instructions.
!Do not dry unwashed items in
the tumble dryer.
!Clothes should be spin dried or
thoroughly wrung before they
are put into the tumble dryer.
!Clothes that are dripping wet
should not be put into the dryer.
!Glass fibre curtains should
NEVER be put in this machine.
Skin irritation may occur if other
garments are contaminated with
the glass fibres.
!Items that have been soiled
with substances such as cooking
oil, acetone, alcohol, petrol,
kerosene, spot removers,
turpentine, waxes and wax
removers should be washed in
hot water with an extra amount
of detergent before being dried
in the tumble dryer.
! Remove all objects from pockets
such as lighters and matches.
!Lighters and matches must not
be left in pockets and NEVER
use flammable liquids near the
machine.
!Maximum load drying weight:
see energy label.
! To consult the product technical
specification please refer to the
manufacturer website.
WARNING
Foam rubber materials can ,
under certain circumstances,
when heated become ignited
by spontaneous combustion.
Items such as foam rubber
(latex foam), shower caps,
waterproof textiles, rubber
backed articles and clothes
or pillows fitted with foam
rubber pads MUST NOT be
dried in the tumble dryer.
WARNING
Do not tumble dry fabrics
treated with dry cleaning fluids.

!
EN
9
2. WATER CONTAINERS
The water removed from the laundry during
the drying cycle is collected in a container.
When the container is full the relevant
indicator light on the control panel will light,
and the container MUST be emptied.
However, we recommend that the container is
emptied after each drying cycle.
1. Gently pull out the water container
holding the handle (A).
When it is full the water container will
weigh about 6 kg.
2. Tilt the water container to empty the
water out through the spout (B).
When empty, replace the water container
back as shown; (C) first insert the base of
the container into position as shown (1)
then gentle push the top into position (2).
3. Press the programme start button to
restart the cycle.
AB
1C
*Depending on model
1. Gently pull the bottom of the kickplate so
that it unclips from the dryer. The top
section can then be unhinged allowing
the kickplate to be completely removed (A).
2. Pull firmly on the handgrip and slide the
water container out of the dryer (B).
Support the container with both hands
(C). When full, the water container will
weigh about 4 kg.
3. Open the lid located on the top of the
container and empty the water (D).
4. Refit the lid and slide the water container
back into position (D). PUSH FIRMLY
INTO PLACE.
5. Refit the kickplate by engaging the
hinges at the top and 'snapping' the lower
clips into place.
AB
CD
*Depending on model
Very little water will collect during the
first few cycles of a new machine as an
internal reservoir is filled first.
To remove the container tank in
door drawer *
ONLY FOR MODELS WITH DRAIN
HOSE KIT
If you have the option of drainage
near to the dryer you can use the
discharge kit to provide a permanent
drainage for the water collected in the
container of the dryer. This means
that you don't have to empty the water
container.
To remove the container bottom
water drawer *

!
10
3. DOOR, FILTER AND
CONDENSER
!Pull on handle to open the door.
!To restart the appliance, close the door
and press the programme start button.
Filter cleaning indicator light
It lights up when the cleaning of the filter is
requested: check the filter and eventually
clean it.
If the laundry is not drying check that the
filter is not clogged.
1. Pull the filter upwards.
2. Open filter as shown.
3. Gently remove lint using a soft brush or
your fingertips.
4. Snap the filter together and push back
into place.
1
2
Door
WARNING
When the tumble dryer is in use the
drum and door may be VERY HOT.
WARNING
If you open the door mid cycle, before
the cool-down cycle has completed,
the handle may be hot. Please use
extreme caution when attempting to
empty the water reservoir during the
cycle.
Filter
Clogged filters could increase the
drying time and cause damages and
expensive cleaning operation.
To maintain the efficiency of the dryer
check that all filters are clean before
each drying cycle.
WARNING
Do not use the tumble dryer without
the filters.
.
.
If you clean filter under water, remember
to dry it.
WARNING
Clean the filter before every cycle.
To clean the lint filter
