Hoover HV-LHP8 User manual

Welcome to your new Hoover heat pump dryer! We hope that this product brings you many years of
enjoyment.
When unpacking the dryer, make sure to remove both pieces of packaging foam from the drum.
Position your new heat pump dryer in a clean and dry, well ventilated area. The floor must be firm, flat and
stable. Adjust the leveling feet if your floor is slightly uneven. Don’t place the dryer on carpet or other soft
surfaces, which could block the air intake. Leave sufficient room at the back for air dissipation.
The dryer produces condensate water which is by default collected in the in-built water container and needs
to be emptied. You can also drain the condensate water directly into a sink, using the external drain hose.
NOTE: Before you use the dryer for the first time, place some clean, damp rags into the drum and run a
complete cycle on the Gentle-Light program for 30 minutes following the instructions in the manual.
For detailed installation instructions, please consult the supplied instruction manual, which also has
comprehensive usage instructions and important safety advice.
Let’s get your washing
machine up and running!
Instructions
• Rotate the dial on the control panel to switch on the dryer
and select the desired program (Fig. 1).
• The display screen (Fig. 2) will show the settings, time
remaining, options, codes, etc.
• When using the Gentle-Light program, press the Duration
button to extend the default drying time in 10 minute steps.
• Press the Dry Level button to select the drying level (if the
program allows).
• Press the Anti-Crease button to extend the duration of the
anti-crease phase.
• Press the Delay Start button to set the delay start time
(from 1 to 24 hours).
• Press the Start/Pause button to start or pause a drying
program.
• Optionally, you can also press and hold the Duration and
Dry Level buttons at the same time to set/cancel the child
lock, and/or press and hold the Anti-Crease and Delay Start
buttons at the same time to mute the buzzer.
Version #:
After Sales Support
Model #:
V1.1
1300 886 649
HV-LHP8
8 kg Heat Pump
Dryer
Hoover’s quick
& snappy start
up guide.
For details about all drying programs, please
refer to the table on page 16 of the supplied
instruction manual.
1
2
8 kg Heat Pump
Dryer
HV-LHP8

Cleaning the Filter Drawer
• Lint and fibres that could not be captured by the lint
filter are blocked in the filter drawer, which should also be
cleaned after each drying process. It is located behind the
maintenance cover and contains a two-level filter: a filter
drawer sponge and a filter cloth.
• Push down the locking latch to the maintenance cover
(Fig. 4a).
• Unlock the fixer (Fig. 4b).
• Pull out the filter drawer (Fig. 4c).
• Remove any lint, fibres and textile threads from the filter
cloth by hand or with a soft brush or cloth (Fig. 4d). When
you notice a layer of lint or debris that may lead to clogging
of the filter cloth, clean off the layer by washing the filter
in warm water. Let the filter cloth dry thoroughly before
installing it back in the filter drawer.
• Wash the filter drawer sponge by hand to remove any fibres
and lint from the surface. After washing the sponge, squeeze
it by hand and remove the excess water. Thoroughly dry the
sponge before reinstalling it.
• Close the maintenance cover.
Afterwards
• At the end of the drying program, when the drum has stopped
rotating, unplug the machine, open the door and take out your
washing.
• When the drum has cooled, take the lint filter case out of the
door opening (Fig. 3a) and wipe or brush it clean. If required,
wash the filter in warm water, rinse and let dry. When it is
completely dry, refit the filter into the door opening.
• Unless you have the drain hose connected, you will also have
to empty the water container after every drying cycle (Fig. 3b).
• Hold the container with both hands and pull it out of the dryer
housing. Tilt it over a sink and pour out the water (Fig. 3c).
• Wipe the container dry, then reinsert it into its space in the
dryer housing.
3A
4A
4C
Water
container
3B
4B
4D
3C
Hope you enjoy your new Hoover
washing machine.
8 kg Heat Pump
Dryer
HV-LHP8
