SLAVE CLOCK CONTROL BOARD 7406RC
7406RC Slave Clock Control Board for System 7001RC - V02.03 7 / 27
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: [email protected]
1 Slave Clock Control Board 7406RC
RC Function Board 7406RC is a Slave Clock Control Board for controlling two lines (clock
chains) with clocks operating on a pole-changing pulse basis or DCF77 time code
clocks.
It is designed for the central
hopf clock System 7001RC in eurocard size with a 4HP/3U
front panel.
After the once-only set-up of the clock equipment the system operates
maintenance-free.
The pulse output of the two lines is monitored so that, in the event of a fault or pulse
failure, an error message can be transmitted.
In the event of a fault in pole-changing mode, the current time of the slave clocks
is stored, such that after the fault has been removed or when the equipment is re-
started, the last-transmitted time is available and the slave clocks are re-set
independently.
The pulse lengths are adjustable in pole-changing operational mode.
A constant voltage supply source external to the system 7001RC can be
connected to RC Function Board 7406RC, to control and supply power to the slave
clocks (see Chapter 9 Technical Data).
RC Function Board 7406RC can synchronise self-setting DCF77 time code clocks
with the DCF77 data telegram via the line cables. If these clocks have a power
supply independently from the System 7001RC they continue to run whilst there is a
fault (DCF77 data telegram failure).
The summertime/wintertime changeover points are executed in conjunction with
RC Function Board 7406RC.
The time basis of the lines can be transmitted in local time or UTC time.
Due to its hot-plug capability, the Board can be removed from and re-connected to
the running 7001RC system at any time and at any point, without affecting the
function of other system boards. However, to provide the power supply to slave
lines, it can be fixed to a connection slot in system 7001RC by means of additional
internal wiring.
Slave Clock Control Board 7406RC is configured via the
hopf System 7001RC
display / keyboard or via
hopf _RC remote software.
Monitoring for insufficient line voltage

CLOCKS IN POLE-CHANGING PULSE OPERATION
8 / 27 7406RC Slave Clock Control Board for System 7001RC - V02.03
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: [email protected]
2 Clocks in Pole-Changing Pulse Operation
In pole-changing operation, lines transmit every second for second lines and every minute
for minute lines, alternately a positive or negative voltage pulse with the set pulse length.
Uhren im polwechselnden Betrieb
-Uext
+Uext
0V
gerade Sekunde
ungerade Sekunde
-Uext
+Uext
0V
gerade Minute
ungerade Minute
Sekundenlinie
Minutenlinie
0.2 - 3.1 sec
0.2 - 3.1 sec
1min 1min 1min 1min 1min
1sec 1sec 1sec 1sec 1sec

DCF77 TIME CODE CLOCKS
7406RC Slave Clock Control Board for System 7001RC - V02.03 9 / 27
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: [email protected]
3 DCF77 Time Code Clocks
In DCF77 time code operation, lines transmit a DCF77 time code signal, changing pole on
every second change. The DCF77 time code signal is coded according to the period of the
zero volt position, 100msec (= logic 0) and 200msec (= logic 1).
Pulse form for DCF77 time code clocks
1 sec 1 sec 1 sec 1 sec 1 sec
100 msec 200 msec
+U
ext
-U
ext
0V

RC-FUNCTION BOARD 7406RC DESIGN
10 / 27 7406RC Slave Clock Control Board for System 7001RC - V02.03
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: [email protected]
4 RC-Function Board 7406RC Design
Board 7406RC has a 3U/4HP front panel for 19” systems with the following components:
4.1 Front Panel Components
ERROR
line1 line2
Send
X1
7406RC
12
11
10
9
8
7
6
5
4
3
2
1
24
23
22
21
20
19
18
17
16
15
14
13
4.1.1 LED Status
Description Function
line1 Fault LED for line 1
line2 Fault LED for line 2
send Bus communication LED
4.1.2 Pin Assignment of the 24-pin Delta-Ribbon
Socket
Pin No.: Function
1, 13 * +Uext, external line voltage supply source
9, 21 * +U, additional external line voltage supply source
2,10,14,15,22 GND, external line voltage supply source (GND_LU)
3 Relay (normally open contact)
4 Relay (normally closed contact)
16 Relay (common contact)
5 / 17 Monitoring inputs line 1: positive / negative
6 / 18 Pulse outputs line 1: positive / negative
7 / 19 Monitoring inputs line 2: positive / negative
8 / 20 Pulse outputs line 2: positive / negative
11 RxD, serial interface reception line
12 GND, serial interface
23 Not in use
24 TxD, serial interface transmission line
* An external line voltage supply source must not be connected if an internal
line voltage supply source is already connected to the slot.
4.1.3 LED Functions
SEND LED Description
Flashing Normal case indicating access to the internal bus. Board 7406RC
is correctly integrated into the system 7001RC.
Permanently on Fault on Board 7406RC.
Permanently off Board 7406RC is not ready for operation.

RC-FUNCTION BOARD 7406RC DESIGN
7406RC Slave Clock Control Board for System 7001RC - V02.03 11 / 27
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: [email protected]
ERROR line 1 / 2 Description
Permanently on Fault detected in the line
(see Chapter 7 Faults and Causes of Faults).
Permanently off Line is ready for operation.
4.2 VG-Ledge 64-pin (DIN 41612)
ca
32
1
20
10
C
o
nn
e
c
t
o
r,
D
IN4
1
6
1
2, 64-pin
V
G
m
a
l
e
Connector, DIN 41612,
64-pin VG male
Pin c a Pin
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
10 XOUT 10
11 R1CC 11
12 R1CNC 12
13 R1CNO 13
14 OERR 14
15 1ERR 15
16 2ERR 16
17 1SCK 17
18 XTST 18
19 GND_LU GND_LU 19
20 VG20 VG20 20
21 RES / System reset 21
22 22
23 SERI / System bus SCLK / Bus pulse 23
24 KHZB / regulated
1kHz pulse PPS / regulated 1Hz pulse 24
25 FROUT FRIN 25
26 26
27 AR0UT ARIN 27
28 28
29 29
30 30
31 GND GND 31
32 +5V DC VCC / 5Volt 32

RC-FUNCTION BOARD 7406RC DESIGN
12 / 27 7406RC Slave Clock Control Board for System 7001RC - V02.03
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: [email protected]
4.3 7406RC Board Assembly Overview
DS1 - DS2 : standard ex works (Standardeinstellung ab Werk)
X2
J1
J14
MB3
J5
J2
J4
J6
60V
48V
24V
J11
J12
J13
60V
48V
24V
J8
J9
J10
12345678
on
DS2
12345678
on
DS1
ST3
1
1
Delta Ribbon 24-pole female
VG-ledge 64 pole male
Description Function
ST3 Service connector
X2 Diagnosis connector
J14, J6 Service jumper
MB3, J1 Operating voltage measuring points (5 V DC)
J8, J9, J10 Voltage monitoring setting for line 1
J11, J12, J13 Voltage monitoring setting for line 2
J2, J3 Diagnosis jumper line 1
J4, J5 Diagnosis jumper line 2
4.3.1 Line Voltage and Monitoring Device Configuration
The lines of RC Function Board 7406RC can be operated with various voltages. For this
purpose, jumpers 8-13 (see imprint) must be pre-set for voltage monitoring.
Jumper setting
Line 1 Line 2 Line voltage Monitoring voltage
Line fault on insufficient voltage
J13 J10 24 V 18 V
J12 J9 48 V 36 V
J11 J8 60 V 45 V

IMPLEMENTATION OF THE BOARD 7406RC IN THE SYSTEM 7001RC
7406RC Slave Clock Control Board for System 7001RC - V02.03 13 / 27
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: [email protected]
5 Implementation of the Board 7406RC in the
System 7001RC
All RC function boards are individually parameterized from the system 7001RC.
Every RC function board is uniquely identified via the board type and an
assigned board number (1-31)
The following steps are necessary for implementation:
Identification of the board numbers available
Setting up of the board number with the DIP switch on the board 7406RC
Installation of the board 7406RC in the system 7001RC
Parameterization of the board 7406RC
Activation of the board 7406RC via the system 7001RC
5.1 Identification of the Board Numbers available
The board numbers allocated so far can be displayed via the SHOW ALL ADDED SYSTEM-
BOARDS menu. The board numbers that are not listed for this board type are available for
the new board.
Boards that are available in terms of hardware, but which have not yet been
activated via the system menu, are not listed in the SHOW ALL ADDED
SYSTEM-BOARDS menu. (The "SEND" LED of these boards does not
flash when in operation.)
In order to identify the set board number, these boards must be made
available externally, in order to identify the set board number from the DIP
switch setting.
5.2 Set the Board Number
In order to clearly identify the board in the system 7001RC, the board number must be
defined via the DS1 DIP switch bank. The board number is set as Hex code on DS1. Switch
8 is the lowest value bit and switch 1 the highest value bit. The inscription on the DIP switch
housing serves to identify switches 1-8. Board numbers from 1 to 31 can be setup, board
numbers outside this range are not recognized by the system 7001RC.
Under no circumstances may two boards of the same type with the same
board number be embedded in one system 7001RC. This leads to
undefined errors on both boards.

IMPLEMENTATION OF THE BOARD 7406RC IN THE SYSTEM 7001RC
14 / 27 7406RC Slave Clock Control Board for System 7001RC - V02.03
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: [email protected]
J1
DS1
Board 01
DS1 DS1 DS1 DS1 DS1 Board number
Pos 4 Pos 5 Pos 6 Pos 7 Pos 8 in the system 7001RC
off off off off on 1
off off off on off 2
off off off on on 3
off off on off off 4
off off on off on 5
off off on on off 6
off off on on on 7
off on off off off 8
off on off off on 9
off on off on off 10
off on off on on 11
off on on off off 12
off on on off on 13
off on on on off 14
off on on on on 15
on off off off off 16
on off off off on 17
on off off on off 18
on off off on on 19
on off on off off 20
on off on off on 21
on off on on off 22
on off on on on 23
on on off off off 24
on on off off on 25
on on off on off 26
on on off on on 27
on on on off off 28
on on on off on 29
on on on on off 30
on on on on on 31
5.3 Installation of a new Board 7406RC in the System 7001RC
In order to install a new board 7406RC, a free extension slot (slot with board connectors and
VG strip installed in the system bus) must be available. This information can be obtained
from the associated specific system drawing.
If no free extension slot is available, this can usually be retrofitted. Please contact
hopf
Elektronik GmbH.

IMPLEMENTATION OF THE BOARD 7406RC IN THE SYSTEM 7001RC
7406RC Slave Clock Control Board for System 7001RC - V02.03 15 / 27
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: [email protected]
5.4 Parametrize / Activating the Board 7406RC in the
System 7001RC
The following steps are required to activate the board:
To avoid undesirable output behaviour of the board it is first parameterized
and then activated by switching it into the monitoring system.
In the BOARD-SETUP menu, sub-heading ADD SYSTEM-BOARDS, log on the
newly installed board.
In the BOARD-SETUP menu, sub-heading SET SYSTEM BOARDS PARAMETER
parameterize the board. (Chapter 6 Administration of the Board 7406RC)
In the BOARD-SETUP menu, sub-heading SET SYSTEM BOARDS TO
MONITORING-MODE OR IDLE-MODE integrate the newly installed board into the
monitoring system.
The menus:
ADD SYSTEM-BOARDS and
SET SYSTEM BOARDS TO MONITORING-MODE OR IDLE-
MODE
can be consulted in the technical specification of the system 7001RC.

ADMINISTRATION OF THE BOARD 7406RC
16 / 27 7406RC Slave Clock Control Board for System 7001RC - V02.03
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: [email protected]
6 Administration of the Board 7406RC
The 7001RC base system manual serves as the basis for configuration. The following will
cover only the inputting of the values that can be found under the BOARD-SETUP:4 menu
heading.
In order for the system 7001RC to accept the newly configured parameters,
is the configured menu and the following parameter menu of SET SYSTEM-
BOARDS PARAMETER menu be confirmed by pressing the ENT key.
6.1 Input Functions for the Board 7406RC in the System 7001RC
The input and display functions of the board parameters are polled in the menu heading
BOARD-SETUP:4
with ENT key Main menu
with 4 key Board setup
with N key Scroll to menu heading:
S
E
T
S
Y
S
T
E
M
-
B
O
A
R
D
S
P
A
R
A
M
E
T
E
R
Y
/
N
Select with key Y
Search for board to be parameterized with key N and select with key Y .
Example:
P
A
R
A
M
E
T
E
R
B
O
A
R
D
0
3
O
F
2
5
7
4
0
6
N
O
.
:
0
4
S
T
A
T
U
S
:
M
/
-
B
O
A
R
D
N
A
M
E
:
"
L
I
N
I
E
"
S
E
T
>
Y
/
N
N
PARAMETER BOARD 03 OF 25 board 03 of 25 implemented
7406 NR.: 04 board type 7406RC with board number 04
STATUS: M (I)/- (E) Mor I= monitoring or no monitoring
– or E = without error operating or board error
BOARDNAME:"LINIE" LINIE board name freely selected by customer

ADMINISTRATION OF THE BOARD 7406RC
7406RC Slave Clock Control Board for System 7001RC - V02.03 17 / 27
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: [email protected]
6.2 Input Parameter Byte 01
Parameter Byte 01 is shown on the top line with the currently set values.
B
.
7
4
0
6
N
O
.
:
0
3
O
L
D
:
B
Y
T
E
0
1
>
0
1
1
0
0
0
0
0
<
B
Y
T
E
=
B
I
T
7
.
.
0
N
E
W
:
B
Y
T
E
0
1
>
~
~
~
~
~
~
~
~
<
For the purposes of manipulation, the individual bits of the new byte are to be entered on the
second line using "0" and "1". The complete Parameter Byte must always be recorded and
confirmed with the ENT key.
The bits of the Parameter Byte are numbered in descending order:
Bit 7 Hour Mode Slave Line 1
0 12 hour operation
1 24 hour operation
Bit 6 Slave Lines (SL) 2 as minute or second lines
0 Minutes (SL1) + Seconds (SL2)
1 Minutes (SL1) + Minutes (SL2)
Bit 5 Summertime/ Wintertime changeover
0 Stop (1h)
1 Update display
Bit 4 Hour Mode Slave Line 2
0 12 hour operation
1 24 hour operation
Bit 3
Bit 2
Bit 1
Bit 0
No function at present
For compatibility reasons these bits should always be set to 0.
6.2.1 Bit7/Bit4 - Slave Line 1/2 in 12 or 24 Hour Operation
For pole-changing pulse operation.
With this function, the two lines can control different clocks for pole-changing pulse operation
in 12 or 24 hour operation.
Analogue clocks usually 12 hour operation
Digital clocks usually 24 hour operation
Slave Line 1:
Bit 7 = 0 12 hour operation
Bit 7 = 1 24 hour operation
Slave Line 2:
Bit 4 = 0 12 hour operation
Bit 4 = 1 24 hour operation

ADMINISTRATION OF THE BOARD 7406RC
18 / 27 7406RC Slave Clock Control Board for System 7001RC - V02.03
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: [email protected]
6.2.2 Bit 6 – Slave Line 2 as Minute or Second Line
For pole-changing pulse operation.
In this mode the two lines of Board 7406RC are controlled as either:
2 separate minute lines or
1 minute and 1 second lines (for clocks with separate second line)
Bit 6 = 1 2 independent minute slave lines
Both lines are used to control minute slave clock chains.
The Board occupies two line numbers in the system.
Bit 6 = 0 1 minute line and 1 second line
The 2nd line of the Board is used to control the seconds’ line.
With this setting Board 7406RC occupies only one common line number in
the system.
6.2.3 Bit 5 - Summertime/Wintertime Changeover
For pole-changing pulse operation.
This function defines the behaviour of the lines on ST/WT changeover.
Bit 5 = 0 1 hour - stop (1h) on ST WT changeover
The minute lines wait 1 hour after the changeover from summertime to wintertime.
The line is re-set on changeover from wintertime to summertime.
In order to prevent a data overrun, this function is automatically activated for
the minute lines in 24 hour operation, irrespective of the parameter byte
settings.
Bit 5 = 1 Updating (11/23 h forerun) on ST WT
The minute lines are always re-set after the ST/WT changeover.

ADMINISTRATION OF THE BOARD 7406RC
7406RC Slave Clock Control Board for System 7001RC - V02.03 19 / 27
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: [email protected]
6.3 Input Parameter Byte 02
Parameter Byte 02 is accessed by pressing the ENT key after setting Parameter Byte 01.
Parameter Byte 02 is shown on the top line with the currently set values.
B
.
7
4
0
6
N
O
.
:
0
3
O
L
D
:
B
Y
T
E
0
2
>
1
1
1
0
0
0
0
0
<
B
Y
T
E
=
B
I
T
7
.
.
0
N
E
W
:
B
Y
T
E
0
2
>
~
~
~
~
~
~
~
~
<
For the purposes of manipulation, the individual bits of the new byte are to be entered on the
second line using "0" and "1". The complete Parameter Byte must always be recorded and
confirmed with the ENT key.
The bits of the Parameter Byte are numbered in descending order:
B
Y
T
E
0
2
>
7 6 5 4 3
2
1
0
<
Bit 7 Radio status fault signal
0 In common signal
1 No radio status fault signal
Bit 6 Pole-changing pulse operation / DCF77 time code
0 DCF77 time code line
1 Clocks with pole-changing pulse operation
Bit 5 Time basis of the line output
0 UTC
1 Local time
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
No function at present
For compatibility reasons these bits should always be set to 0.
6.3.1 Bit 7 – Fault Signal with Synchronisation Status System 7001RC
Faults are signalled via the drop-out of the alarm relay and transmitted as a common signal.
If no faults / errors are present the alarm relay is re-activated.
All faults are signalled via the 24-pin delta-ribbon socket (see Chapter 4.1 Front Panel
Components):
See Chapter 7 Faults and Causes of Faults for possible error messages.
The common signal can be extended with the fault signal "No synchronisation of the
complete system" with Parameter Byte 02; Bit 7.
Bit 7 = 0 Radio synchronisation included in common fault signal
Bit 7 = 1 Radio synchronisation not included in common fault signal

ADMINISTRATION OF THE BOARD 7406RC
20 / 27 7406RC Slave Clock Control Board for System 7001RC - V02.03
hopf Elektronik GmbH
Nottebohmstr. 41 • D-58511 Lüdenscheid • Tel.: [phone] • Fax: [phone] • Internet: http://www.hopf.com • E-Mail: [email protected]
6.3.2 Bit 6 – Line Operating Modes
Function Board 7406RC can be configured to operate clocks with pole-changing pulse
operation or DCF77 time code clocks.
Bit 6 = 1 For pole-changing pulse operation
Bit 6 = 0 For DCF77 time code clocks
In DCF77 time code mode 2 lines are available for the slave clocks.
6.3.3 Bit 5 – Line Time Basis
For pole-changing pulse operation and DCF77 time code mode.
The line output time for clocks is set up with the following function:
Bit 5 = 1 Local time output with any ST/WT changeover points
Bit 5 = 0 UTC time output without ST/WT changeover points
6.4 Input Parameter Byte 03
Parameter Byte 03 is shown on the top line with the currently set values.
B
.
7
4
0
6
N
O
.
:
0
3
O
L
D
:
B
Y
T
E
0
3
>
0
0
0
0
0
0
0
0
<
B
Y
T
E
=
B
I
T
7
.
.
0
N
E
W
:
B
Y
T
E
0
3
>
_
<
For the purposes of manipulation, the individual bits of the new byte are to be entered on the
second line using "0" and "1". The complete Parameter Byte must always be recorded and
confirmed with the ENT key.
The bits of the Parameter Byte are numbered in descending order:
B
Y
T
E
0
3
>
<
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
No function at present
For compatibility reasons these bits should always be set to 0.
