Hoshizaki HUF40A-D User manual

Hoshizaki
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshiza i.com
HHUUFF4400AA--DD DDIIMMEENNSSIIOONNSS
W x D x H
HUF40/68A-D
5/08
Item # 13188
UNDERCOUNTER FREEZERS ITH DRA ERS
arranty
Valid in Unit d Stat s, Canada, Pu rto Rico, & U.S. T rritori s. Contact factory for warranty in
oth r countri s.
Two Year - Parts & Labor on ntir machin .
Five Year - Parts on: Compr ssor.
HUF40/68A-D
HHUUFF6688AA--DD DDIIMMEENNSSIIOONNSS
W x D x H
68 x 32.3 x 33.9*
*with 4" cast rs
Item #
Project:
Qty:
Hoshizaki r s rv s th right to chang sp cifications without notic .
40.25 x 32.3 x 33.9*
*with 4" cast rs
HUF68A-D
Shown
TEMPGUARD®Self-Contained Undercounter Freezers with EverCheck®Controls
*AutoCad availabl on KCL
HUF40A-D
Shown
• Stainless steel interior and exterior top, front, sides and ottom with galvanized steel ack for long life,
dura ility and easy maintenance
•Ca inet drawer perimeter heater provides condensation control in high humidity environments and is
equipped with a ack-up should the primary heater fail
• Ca inet and drawer mullion are insulated with 23/8" CFC free, foamed-in-place polyurethane
• Each drawer accommodates (2) 12" x 20" x 6" deep pans (pans not included) and features full extension
drawer slides
• Drawer fronts are constructed of high-grade 300 series stainless steel inside and out
• The drawer module frame and drawer slides are constructed of 14 gauge stainless steel for superior dura ility
• Snap-in magnetic drawer gaskets are dura le and easily removed for cleaning
• Delrin rollers, used in com ination with the stainless steel slides, provide for smooth, quiet drawer operation
without metal to metal contact
• Drawers have a 250 l . dynamic load rating
• Lifetime warranty on drawer slides
• 4" heavy duty casters (2 with rakes) are standard
•High-efficiency refrigeration system is designed with a large capacity condenser and evaporator
resulting in lower overall power consumption
• TempGuard's®EverCheck® controls monitor high and low temperatures, high pressure, clean filter and
ca inet temperature functions and provide visual alarms to alert operator to possi le pro lems
• Cartridge-style refrigeration system is easily remova le from the main unit for ease of service
• Evaporator coil is coated for extended life
• Refrigeration system is equipped with solid state digital controls (Fahrenheit or Celsius display)
• Refrigeration system is designed to maintain proper temperatures with "zero" clearance on ends and at rear
•Defrost cycles are time initiated - temperature terminated and can e set to cycle from one to twelve
hours to prevent ice formation and maintain optimum ca inet temperatures
• Remova le, cleana le air filter protects condenser and reduces cleaning requirements
• Hot gas condensate evaporator is standard
• Units equipped with 8' - 6" cord and plug
• R-404A Refrigerant with capillary tu e controls

115/60/1
5.5
15.0
5 - 15P
8.9
1267
1378 (3/8HP)
104 - 126
45° - 100°F
-13° to +19°
R-404A
Hoshizaki
DDIIMMEENNSSIIOONNSS
W x D x H
HUF40A-D
40.25 x 32.3 x 33.9*
HUF68A-D
68 x 32.3 x 33.9*
*with 4" cast rs
U N D E R C O U N T E R F R E E Z E R S
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshiza i.com Printed in U.S.A.
HUF40/68A-D
UNDERCOUNTER FREEZERS ITH DRA ERS
• 1 section undercounter freezer
• 2 section undercounter freezer
OPTIONS
• 1 door in lieu of 2 drawers • Drawer adaptor ars
• 6" Legs • Bullnose top (front & rear)
• 6" Casters • Doors
• Stainless steel ack
TOP VIEW
DIMENSIONS/CAPACITY
Mo el #
Interior Storage
Capacity (CF)
Overall Wi th
Overall Depth
Height (including 4" casters)
Drawer Fully Open (in)
Drawer Opening Wi th
Drawer Height
A justable Shelves
Pan Capacity
(12" x 20" x 6" DP Pans)
Crate Shipping Weight
Crate Height
Crate Wi th
Crate Depth
HUF40A-D
ELECTRICAL & REFRIGERATION DATA
Mo el #
Voltage
Amperage
HACR Breaker
Electrical Connection(NEMA)
*Energy Consumption(kwh/day)
* Heat Rejection(BTU/Hr.)
Approximate Nominal
Compressor BTU/Hr.(HP)
Voltage Range
Ambient Temp. Range
Control Setpoint Range
*Refrigerant
8.5 ft3
40.25"
32.3"
33.9"
58.1"
N/A
9.9"
N/A
4
375 lb
35.5"
44.25"
35.5"
18.8 ft3
68"
32.3"
33.9"
58.1"
N/A
9.9"
N/A
8
553 lb
35.5"
72"
35.5"
HUF68A-D
115/60/1
10.0
15.0
5 - 15P
12.6
1791
2592 (1/2HP)
104 - 126
45° - 100°F
-13° to +19°
R-404A
HUF40A-D HUF68A-D
PLAN VIEW
SIDE VIEW (BOTH UNIT )
HUF40A
HUF68A
58.1"
(1476.7 mm)
* Based on 100°F ambient cycling at setpoint
28.2"
(715.9 mm)
27.0"
(686.7 mm)
12.0"
(304.8 mm)
25.1"
(637 mm)
CABINET
FRONT
58.1"
(1476.7 mm)
28.2"
(715.9 mm) 27.0"
(686.7 mm)
12.0"
(304.8 mm)
25.1"
(637 mm)
CABINET
FRONT
20.2"
(513.5 mm)
20.2"
(513.5 mm)
40.25"
(1022.4 mm) 68"
(1727.6 mm)
32.3"
(821 mm)
32.3"
(821 mm)
30"
(760.8 mm)
32.3"
(821 mm)
2.1"
(52.4 mm)
3.2"
(82 mm)
25.8"
(654.2 mm)
13.1"
(333 mm)
13.1"
(333 mm)
.4"
(9.5 mm)
.7"
(19 mm)
40.3"
(1022.6 mm)
22.5"
(570.2 mm)
33.9"
(860.8 mm)
30"
(762.4 mm)
3.9"
(98.4 mm)
24.3"
(616.2 mm)
654.2"
(25.8 mm)
654.2"
(25.8 mm)
13.1"
(333 mm)
13.1"
(333 mm)
.4"
(9.5 mm)
.7"
(19 mm)
