Hoshizaki HWF40A User manual

Hoshizaki
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Pea htree City, GA 30269 TEL [phone] FAX [phone] www.hoshizaki. om
HHWWFF4400AA DDIIMMEENNSSIIOONNSS
W x D x H
HWF40/68A
5/08
Item # 13169
WORK OP FREEZERS
Warranty
Valid in Unit d Stat s, Canada, Pu rto Rico, & U.S. T rritori s. Contact factory for warranty in
oth r countri s.
Two Year - Parts & Labor on ntir machin .
Five Year - Parts on: Compr ssor.
HWF40/68A
HHWWFF6688AA DDIIMMEENNSSIIOONNSS
W x D x H
68 x 32.3 x 39.9*
*with 6" cast rs
Item #
Project:
Qty:
Hoshizaki r s rv s th right to chang sp cifications without notic .
HWF40A
Shown
40.25 x 32.3 x 39.9*
*with 6" cast rs
EMPGUARD®Self-Contained Worktop Freezers with EverCheck®Controls
HWF68A
Shown
*AutoCad availabl on KCL
*
•Stainless steel interior and exterior top, front, sides and bottom with galvanized steel back for long life,
durability and easy maintenance. The stainless steel top includes a 4" backsplash
•(2) heavy duty epoxy shelves per section are standard, mounted on stainless steel pilasters, shelves are
adjustable in 1" increments
•Cabinet door perimeter heater provides condensation control in high humidity environments and is
equipped with a back-up heater should the primary heater fail
•Cabinet and doors are insulated with 21/4" CFC free, foamed-in-place polyurethane
•6" heavy duty casters (2 with brakes) are standard
•Doors are constructed of high-grade 300 series stainless steel inside and out
•Doors are self-closing with a stay open feature at 105°
•Stepped door design protects door gasket when product is removed from the cabinet; Snap in
magnetic door gaskets are durable and easily removed
•Door hinging is reversible at the factory
•High-efficiency refrigeration system is designed with a large capacity condenser and evaporator
resulting in lower overall power consumption; Evaporator coil is coated for extended life
•TempGuard's®EverCheck® controls monitor high and low temperatures, high pressure, clean filter and
cabinet temperature functions and provide visual alarms to alert operator to possible problems
•Cartridge-style refrigeration system is easily removable from the main unit for ease of service
•Refrigeration system is equipped with solid state digital controls (Fahrenheit or Celsius display)
•Refrigeration system is designed to maintain proper temperatures with "zero" clearance on ends and at rear
•Defrost cycles are time initiated - temperature terminated and can be set to cycle from one to twelve
hours to prevent ice formation and maintain optimum cabinet temperatures
•Removable, cleanable air filter protects condenser and reduces cleaning requirements
•Hot gas condensate evaporator is standard
•nits equipped with 8' - 6" cord and plug
•Refrigerant: R-404A with capillary tube controls
* The HWF68A worktop freezer is ENERGY STAR ertified.

115/60/1
5.5
15.0
5 - 15P
8.0
1133
1378 (3/8HP)
104 - 126
45° - 100°F
-13° to +19°F
R-404A
Hoshizaki
DDIIMMEENNSSIIOONNSS
W x D x H
HWF40A
40.25 x 32.3 x 39.9
*with 6" cast rs
HWF68A
68 x 32.3 x 39.9
*with 6" cast rs
WO R K TO P F R E E Z E R S
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Pea htree City, GA 30269 TEL [phone] FAX [phone] www.hoshizaki. om Printed in U.S.A.
HWF40/68A
WORK OP FREEZERS
• 1 section worktop freezer
• 2 section worktop freezer
O P I O N S
• 6" Legs • Bullnose top (front & rear)
• 6" Casters • Foot pedal
• Doors • Reversible hinging
• Stainless steel back
5.6"
DOOR SWING
DIMENSIONS/CAPACI Y
Model #
Interior Storage Capacity (CF)
Overall Width
Overall Depth
Height (including 6" casters)
Depth with Door Open 90°
Door Opening Width
Drawer Opening Height
Adjusta le Shelves
Shelf Dimensions (W x D)
Crated Shipping Weight
Crated Height
Crated Width
Crated Depth
HWF40A
ELEC RICAL & REFRIGERA ION DA A
Model #
Voltage
Amperage
HACR Breaker
Electrical Connection(NEMA)
*Energy Consumption(kwh/day)
* Heat Rejection(B U/Hr.)
Approximate Nominal
Compressor B U/Hr.(HP)
Voltage Range
Am ient Temp. Range
Control Setpoint Range
*Refrigerant
8.5 ft3
40.25"
32.3"
39.9"
56.8"
22.5
24.3"
2
22.4" x 24.6"
322 lb
40.5"
44.25"
35.5"
18.8 ft3
68"
32.3"
39.9"
56.8"
22.5"
24.3"
4
25" x 24.6"
450 lb
40.5"
72"
35.5"
HWF68A
115/60/1
10.0
15.0
5 - 15P
12.0
1708
2592 (1/2HP)
104 - 126
45° - 100°F
-13° to +19°F
R-404A
HWF40A HWF68A
PLAN VIEW
SIDE VIEW (BO H UNI S)
HWF40A
HWF68A
56.8"
40.25"
32.3"
66.3"
68"
56.8"
24.5" 24.5"
5.6"
7.4"
32.3"
30"
30" 24.3"
35.9"
5.9"
27"
32.3"
1.9"
35.9"
30"
* Based on 100°F ambient cycling at setpoint
22.5"
40.25"
4"
2"
39.9"
25.6"
