Hotpoint Ariston AAQCF81U IT Operating and installation instructions

Indesit Company UK Ltd
© 2010 Reg. Office: Peterborough PE2 9JB Registered in London: 106725
Service
Information
Aqualtis
8 Kg
"A Energy"
CONDENSER
ELECTRONIC
TUMBLE DRYER
with
Refrigerant
Condenser System
Models Comm
Covered Code
AAQCF81U IT 70078
AAQCF81U WE 71832
AAQCF81U UK 71846
5407535 Issue 2 May 2010
..
C00279765

2 of 36
Service Manual UK
Indesit Company
English
SAFETY NOTES & GENERAL SERVICING ADVICE
1. This manual is NOT intended as a comprehensive repair/maintenance guide to the appliance.
2. It should ONLY be used by suitably qualified persons having technical competence applicable
product knowledge and suitable tools and test equipment.
3. Servicing of electrical appliances must be undertaken with the appliance disconnected (unplugged)
from the electrical supply.
4. Servicing must be preceded by Earth Continuity and Insulation Resistance checks.
5. Personal safety precautions must be taken to protect against accidents caused by sharp edges on
metal and plastic parts.
6. After Servicing the appliance must be rechecked for Electrical Safety. In the case of appliances which
are connected to a water supply (i.e.: Washing Machines, Dishwashers & Food Centres etc.) checks
must be made for leaks from seals gaskets and pipe work and rectification carried out where
necessary.
7. It can be dangerous to attempt ‘DIY’ repairs / maintenance on complex equipment and the Company
recommends that any problem with the appliance is referred to its own Service Organisation.
8. Whilst the Company has endeavoured to ensure the accuracy of the data within this publication they
cannot hold themselves responsible for any inconvenience or loss occasioned by any error within.
INDEX
Safety Notes & General Servicing Advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Technical Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Dryer Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 6
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Filter Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Water Drain - Plumbing Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Console Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 12
Component Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 - 16
Special Programmes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Programme Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 - 19
Control Board Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 - 21
Fault Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 - 23
Servicing Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 - 25
Test Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Power Module Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Dismantling Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 - 34
Serial Number Location
The Serial Number is located on the front
panel behind the door - open the door to
see it.

3 of 36
Indesit Company
Service Manual UK English
TECHNICAL SPECIFICATIONS
First Production June 2010
General Model Colour Commercial Code
AAQCF81U IT White / Silver Door 70078
AAQCF81U WE White / Silver Door 71832
AAQCF81U UK White / Silver Door 71846
Features Electronically controlled tumble dryer comprising of an interface
module
fitted into the door and a control module mounted on the plinth,
connected by a serial link cable.
The Condensing Drying System uses an integrated self contained
refrigerant module instead of traditional high wattage heaters.
Country of Origin Great Britain
Dimensions Height 850 mm
Width 595 mm
Depth 584 mm
Weight 48 Kg (Unpacked), 51 Kg (Packed)
Energy Class A
Noise Level 68 dBA approximately
Drum Volume 112 litres
Drying Load Dry weight maximum 8 Kg
Programmes 16 position selector
Drying Sensing Levels Up to 5 depending on programme selected.
Door Operation Lever operated door catch
Electronic Platform EVO2
Drying Controls Variable using electronic control and thermistors
System Thermistor) 25°C = 10 K:10%
50°C = 4.16 K:10%
Front Air Duct Thermistor 25°C = 470 K:15%
100°C = 16.15 K:5%
Motor - Type 360 Single phase capacitor run 2 pole induction motor - 2800 rpm
Motor Capacitor 8.5 uF
Compressor Highly BSD 122DV - H3BD1, 200-240V - 50/60Hz
Compressor Capacitor 17 uF
Cooling Fan 220-240V AC, 50/60Hz, 0.14 Amp
Refrigerant Type R134a
Refrigerant Charge 340 grams
Water Container Capacity 5 Litres
Absorbed Power 1.04 - 1.15 kW (220 - 240 V AC)

4 of 36
Service Manual UK
Indesit Company
English
DRYER FUNCTION
Overview
This is a freestanding tumble dryer with a full width metal door.
The drum is capable of accepting a maximum 8 kg load. The drum is supported at the front by 2
wheels mounted on the front air duct and a single bearing at the rear located in the rear panel. A
shaft fixed to the rear of the drum runs in the rear bearing. The drum is driven by a belt which passes
around its periphery and onto the shaft of a motor secured to the base of the dryer.
The belt is tensioned by a pulley mounted to the motor.
The motor also drives a fan fixed to the end of the rear shaft to recirculate air through the drum.
The drum normally rotates clockwise with the occasional reverse action anticlockwise. This occurs
during the cycles cool down period and for 5 minutes every hour of the cycle duration.
The moisture removed from the recirculating air, by means of a refrigerant module, is pumped to a
removable container mounted in the left hand side of the console. The user can easily withdraw the
container to dispose of the collected condensed water. There is no requirement for venting to
atmosphere on this dryer.
Drying Process
The circulating air flows over the condenser unit causing it to be heated, the air then passes into the
drum via the fan chamber collecting moisture from the clothes enabling them to dry. The moisture
laden air passes through two filters to remove any lint and then passes through the evaporator unit
where the moisture condenses and falls into a channel in the base and flows into the pump reservoir
where it is pumped into the water container. The resulting cooled air aids the cooling of the
refrigerant in the condenser before starting the process again.
Heat Exchange Cycle
The Cycle begins with refrigerant being pumped by the compressor through the condenser unit.
A capillary tube is used to create a restriction to increase the pressure and temperature of the
refrigerant in the condenser, the heat (used to heat the airflow into the dryer) is removed from the
refrigerant converting it from a gas to a liquid.
The liquid refrigerant is then forced through the capillary under pressure into the evaporator unit
where the pressure is removed causing the refrigerant to evaporate into a gas again cooling the
evaporator the refrigerant then returns to the compressor to complete the cycle.
Controls Overview
The user interface controls consist of a Programme selection knob, a Digit display, option buttons;
Start/Pause button and an On/Off button.
The control system consists of a control module, two thermistors and a conductivity sensor.
The conductivity sensor is mounted in the front air duct. A single wire connects the sensor to the
control module. The front thermistor is located in the air duct, and the second thermistor is attached
to the heat exchanger system pipe work.
The control module determines the programme duration and dryness of the load. This is achieved
by the thermistors located in the front air duct and on system pipe work measuring the difference in
temperature / resistance between the two points, the control module then calculates and compares
the values to that of the chosen programme.
As the programme progresses a small DC current is passed from the sensor in the front air through
damp clothes to earth. The resistance of this current is compared to the resistance value of the
chosen programme and when these become equal the load will have reached the required level of
dryness and will then progress through the dry programme and on to the cool down period.

5 of 36
Indesit Company
Service Manual UK English
The control module is located behind the right hand side panel and there is a service port behind the
plinth cover that allows attachment of a computer, Smart Card Reader or Handheld Device to
programme the Control Module.
The control module can be programmed with the relevant settings file if the module is replaced, the
settings file becomes corrupted or if an updated file becomes available.
Each of the sensing programmes has a maximum time of approximately 270 minutes. (Actual time
will vary slightly due to programme selected).
Auto Sensing
After the Automatic cycle has started, the machine’s thermistor and conductivity sensor continually
monitor the dampness of the drying clothes. Once a final dry time has been determined, the display
will update, and the cycle will continue finishing with a 3 minute cool down period. The time taken to
update will vary depending on the Programme set, load and the ambient temperature.
If the display counts down to 3 minutes and the clothes are not at the required dryness level, the
display will hold at 3 minutes, depending on the programme in progress and the material being dried,
the dryer will either wait until the correct dryness level is reached and move to the cool down period,
or wait until the machines sensors are able to recalculate the dryness time and the display will
update accordingly.
If, after the maximum programme time of approximately 270 minutes, the clothes are still not dry,
the programme advances to cool tumble and completes the programme.
Note 1: No fault is indicated if this occurs.
Note 2: The actual time out period will vary slightly depending on the programme and dryness level
set. Under normal drying conditions providing at the start of the cycle the water container is empty,
Gas
Circulated
Calorific Value
(1600W)
Calorific Value
given by
Compressor
(600W)
High Pressure
1.6MPa
Low Pressure
0.3MPa
Compressor Motor
Gas
Dew Condensation
Water
Heat
Exchanger
(Evaporate)
Heat
Exchanger
(Condense)
Low Pressure
0.3MPa 1.6MPa
High Pressure
Liquid
Expansion
Evaporate
Condense
Compress

6 of 36
Service Manual UK
Indesit Company
English
both filters are clean and the clothes have been spun in a washing machine, the clothes should dry
before the time out period occurs.
The module also controls the compressor. The compressor will start running at the start of the
programme and is on continually during the drying cycle.
If the user turns off the power or disconnects the mains cable or there is a power cut, the dryer will
remember its last settings and resume the programme when the start button is pressed, the
compressor will restart after a 5 minute delay period to allow the system to equalise.
Note: If the compressor is switched off, i.e: Programme paused or the door is opened, the
compressor will have an ’OFF’ time of approximately 5 minutes to allow the pressure in the system
to equalise.
The start of a programme can be delayed up to a maximum of 24 hours programmed in 1 hour steps.
Pre-crease care (see page 11) can only be selected if a timed delay has been selected; this option
tumbles the clothes for 3 seconds every 30 minutes for the duration of the time delay.
If selected, the Post crease care option (see page 11) tumbles the clothes after the programme has
finished for 3 seconds every 4 minutes up to a maximum duration of 10 hours.
Installation
If the machine has been transported or laid over, the machine must NOT be started for
2 hours to allow any displaced oil in the system to resettle.
Ventilation
The machine must be installed so it has a minimum air gap of
15mm along each side and 10mm at the top. The machine's rear
air vents must not be blocked.
The machine should be installed on a level surface away from
any appliance which produces flames. i.e: a Gas Hob or Gas
Fire.
Levelling the Tumble Dryer
This dryer must be level for correct
operation.
When the dryer is installed in its final
location check that it is level first side-to-
side, then front to back.
If the dryer is not level, adjust the feet up
or down until the dryer is level.
Rotate the feet to adjust the height.
10 mm
15 mm 15 mm

7 of 36
Indesit Company
Service Manual UK English
Environment
Installing in a cupboard is NOT recommended, but the dryer must not be installed behind a locked
or sliding door, or where a door is hinged on the opposite side to the tumble door.
When in use the dryer must be in an environment that is not damp with proper air circulation.
The dryer will not operate efficiently in an enclosed space or cupboard.
Door Reversal: The Tumble Dryer door cannot be reversed.
Filter Care
This A class Dryer has 2 filters which must be kept clean to ensure efficient and correct operation of
the dryer.
1. Air Duct Filter
Open the machine door (A).
Remove the filter, located just
inside the opened door. (B)
Unclip the filter, and open.
The filter can now be cleaned
and the fluff removed.
Replace the filter after cleaning.
2. Heat Exchanger Filter
B
A
12 3
4
1 Pull the plinth forward
2 Rotate the cover fixing clips
3 Clean the filter
4 Refit the cover and rotate the clips
Filter Cover

8 of 36
Service Manual UK
Indesit Company
English
Water Drain - Plumbing Out
If the Dryer is positioned close to a drain or standpipe, it is possible to
drain the condensed water directly without using the water bottle.
In this case it is no longer necessary to empty the water bottle at the
end of each cycle.
lf the Dryer is positioned above or close to a Washing Machine which
uses a standpipe the same standpipe can be used.
Just disconnect the tube indicated in Figure A and connect it to the
drain.
If the standpipe / drain is further away than the length of the tube it is
possible to buy and connect a tube of the same diameter and the
necessary length in order to reach the standpipe.
To install the new tube just substitute the existing one as indicated in
Figure B inserting it in the same place.
Important Notes:
- The top of the standpipe must be below 1 metre from the bottom of
the Dryer.
- Once the Dryer has been installed, ensure that the drain tube is not
bent, squashed or contorted.
2
H<1m
2

9 of 36
Indesit Company
Service Manual UK English
CONSOLE FUNCTIONS
Option Buttons
ON OFF BUTTON and LIGHT
Push to switch the dryer On and Off.
If the button glows the dryer is turned on and either running or waiting to be started.
PROGRAMME KNOB AND INDICATOR
Used to select the required programme option.
16 timed auto and special programmes are available - see page 17.
Consult the programme chart on pages 18 and 19, to see Programme descriptions.
Stand-by Mode
To comply with current energy saving requirements this product features a Stand-by mode. If the
machine has not been switched off for a period of 30 minutes after the finish of the programme the
controls will go into stand-by mode when the LED's and display will switch off.
To reactivate and remove the controls out of Stand-by mode briefly press the On/Off button, the
LED's and display will illuminate and another programme can then be started or the machine
switched off by pressing the On/Off button.
Display
On/Off Button
& Light Indicator Display Unit Start/Pause Button Child Lock Button
Programme Option Button & Lights Clean Heat Progress
Lights
& Light & Light
Exchange
Empty Water/
Clean Filter Light
Filter Light
Knob
Indicates Current
Dryness Level
Sensor cycles only
(See Sensing Levels)
Active. Auto Cycles
only
Indicates Time Set
Active. Manual Time
Cycles Only
Countdown Timer
Gives Estimated time to
end of delay or cycle
Displays during delay
start, auto, special and
manual programmes.

10 of 36
Service Manual UK
Indesit Company
English
Display Information
Note:
During Sensor Cycles the Centre Timed display screen is blank
During Timed Cycles the left hand Sensor screen is blank
Sensing Levels
After selecting a programme that has a Sensing Dry Option, press and release the button until the
required dryness sensing level is displayed. If the sensing option is not available the display will ash
and the buzzer beeps three times.
Note: ‘Cottons - High Heat’ and ‘Jeans’ programmes are the only programmes which have all ve
dryness level options - all other programmes have only 4 options.
Dryness levels available
Damp Dry: Dries your items ready to be ironed using a machine or rotary ironer.
Iron Dry: Dries you items ready to be ironed with a hand iron.
Hanger Dry: Dries you clothes ready to be hanged for nal drying; Use this program if
you do not need the items to be fully dry as it uses less Energy.
Cupboard Dry: Dries your items ready to be put away.
Ready to Wear / Extra Dry : Dries your clothes ready to be worn.
Timed Dry
After selecting a Programme that has a Timed Dry Option, press the Timed Button and the display will
Note: Timed Dry is only available on the following programmes:
Cottons - High Heat, Cottons - Low Heat, Shirts - High Heat, Shirts - Low Heat, Synthetics, Delicates.
reduce the selected time each time you press and release this button (see Start and Programmes).
Each press decreases the set time , , , , , , , then and then repeats.
If the Timer Dry option is not available the display will ash and the buzzer beeps three times.
The selected time remains displayed after the programme starts and cannot be changed after the after the
Start/Pause Button is Pressed.
Delay Timer
After selecting a Programme that has a Delay Timer Option a delay start time can be selected.
Each press of the Delay button advances the delay setting in 1 hour Increments from to then
and then after ve seconds cancels the delay.
For delays of 10 hours or more the display counts down the time in hours for rst ten hours, then the display
shows and then counts down in minutes. For delays less then 9 hours or less the display shows hours
and minutes and then count down in minutes for all of the delay.
After the Start/Pause Button is pressed the time cannot be changed.
When the delay period nished the symbol is o and the Time to End is displayed
Time to End If the delay icon is o the time displayed is the Time to End of the programme running.
When timed programmes are selected the time displayed throughout the cycle is the actual time
remaining.
When an Automatic programme is selected the time displayed is an estimate of the time remaining.
When the programme is selected the display shows the time required to dry a full load, after around 10
minutes the controller calculates a better estimate of the cycle time
The time to end is displayed in hours and minutes and counts down each minute.
The colons between the hours and minutes display ashes to show that the time is counting down.
The Display also shows if there is a problem with your dryer, if this occurs the display will show F
followed by a fault code number, the four option lights and the pause light will also ash Orange.
