Hotpoint S130E User manual

Instructions
S130E

Contents
1
Introduction 2
Safety Information 3
Features 5
Controls 6
Oven Timer Operation 7
Grill Pan and Handle 13
Using the Top Oven for Grilling 14
Operation when using Top Oven for Grilling 15
Guide to Grilling 16
Using the Top Oven as a Convection Oven 17
Operation when using the Top Oven as a Convection Oven 18
Using the Main Oven for Fan Cooking 19
Using the Main Oven for Other Functions 20
Temperature Conversion Chart 22
Oven Temperature Charts 23
Cooking Results Not Satisfactory? 25
Care and Cleaning 26
Installation 29
Something Wrong? 33
Key Contacts Back Cover
You must read these instructions prior to using the
appliance and retain them for future reference.

Introduction
2
Your new appliance is guaranteed* and will give lasting service. This guarantee is only applicable
if the appliance has been installed in accordance with the installation instructions detailed in
this booklet.
To help make best use of your cooking equipment, please read this booklet carefully.
The cooker is designed specifically for domestic use and responsibility will not be accepted for
use in any other installation.
When first using the cooker ensure that the room is well ventilated (e.g. open a window or use
an extractor fan) and that persons who may be sensitive to the odour avoid any fumes.
It is suggested that any pets be removed from the room until the smell has ceased. This odour is
due to temporary finish on oven liners and elements and also any moisture absorbed by the
insulation.
When the cooker is first used an odour may be emitted,
this will cease after a period of use
* The guarantee is subject to the provisions that the appliance:
(a) Has been used solely in accordance with the Users Instruction Book.
(b) Has been properly connected to a suitable supply voltage as stated on the
rating plate attached to this equipment.
(c) Has not been subjected to misuse or accident or been modified or repaired by
any person other than the authorised employee or agent.
(d) Has been correctly installed.
This appliance conforms to the following EEC Directives:
Low Voltage Equipment
73/23/EEC
93/68/EEC
Electromagnetic Compatibility
89/336/EEC
92/31/EEC
93/68/EEC
To minimise the risk of injury to children please dispose of your product carefully and safely.
Remove all doors and lids. Remove the mains cable (where fitted) by cutting off flush with the
appliance and always ensure that no plug is left in a condition where it could be connected to
the electricity supply.
To help the environment, Local Authority instructions should be followed for the disposal of
you product.
Disposal of your product

Always
●Always make sure you remove all packaging and literature from inside the oven
and grill compartments before switching on for the first time.
●Always make sure you understand the controls prior to using the appliance.
●Always keep children away from the appliance when in use as the surfaces will
get extremely hot during and after cooking.
●Always make sure all controls are turned off when you have finished cooking
and when not in use.
●Always stand back when opening an oven door to allow any build up of steam or
heat to disperse.
●Always use dry, good quality oven gloves when removing items from the
oven/grill.
●Always take care to avoid heat/steam burns when operating the controls.
●Always turn off the electricity supply at the wall switch before cleaning and
allow the appliance to cool.
●Always make sure the shelves are in the correct position before switching on the
oven.
●Always keep the oven and grill doors closed when the appliance is not in use.
●Always take care when removing utensils from the top oven when the main oven
is in use as the contents may be hot.
●Always keep the appliance clean as a build up of grease or fat from cooking can
cause a fire.
●Always follow the basic principles of food handling and hygiene to prevent the
possibility of bacterial growth.
●Always keep ventilation slots clear of obstructions.
●Always refer servicing to a qualified appliance service engineer.
●During use the oven becomes hot. Care should be taken to avoid touching
heating elements inside the oven,
SAFETY ADVICE
IN THE EVENT OF A CHIP PAN OR ANY OTHER PAN FIRE:
1. TURN OFF THE COOKER APPLIANCE AT THE WALL SWITCH.
2. COVER THE PAN WITH A FIRE BLANKET OR DAMP CLOTH, this will smother the
flames and extinguish the fire.
3. LEAVE THE PAN TO COOL FOR AT LEAST 60 MINUTES BEFORE MOVING IT.
Injuries are often caused by picking up a hot pan and rushing outside with it.
NEVER USE A FIRE EXTINGUISHER TO PUT OUT A PAN FIRE as the force of
the extinguisher is likely to tip the pan over. Never use water to extinguish
oil or fat fires.
3
Safety Information
When used properly your appliance is completely safe but as with any electrical product
there are certain precautions that must be observed.
PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR APPLIANCE.

Never
●Never leave children unsupervised where a cooking appliance is installed as all
cooking surfaces will be hot during and after use.
●Never allow anyone to sit or stand on any part of the appliance.
●Never store items above the appliance that children may attempt to reach.
●Never remove the oven shelves whilst the oven is hot.
●Never heat up unopened food containers as pressure can build up causing the
container to burst.
●Never store chemicals, food stuffs or pressurised containers in or on the
appliance, or in cabinets immediately above or next to the appliance.
●Never operate the grill with the door closed as this will cause the appliance to
overheat.
●Never use the appliance as a room heater.
●Never use the grill to warm plates.
●Never dry any items on the oven doors.
●Never install the appliance next to curtains or other soft furnishings.
●Never allow children to play with the appliance controls.
●Never use ‘steam cleaners’.
4
Safety Information

Features
5
TOP OVEN
TEMPERATURE CONTROL
/ GRILL SELECT
MAIN OVEN
TEMPERATURE
SELECTOR
TIMER
OVEN LIGHT
GRILL PAN,
FOOD SUPPORT
TOP OVEN
DOOR OVEN LIGHT
OVEN SHELF
RATING PLATE
GRILL
CONTROL
GRILL
ELEMENT
OVEN FAN
STAY CLEAN
LINER
STAY CLEAN
LINER
INNER
DOORGLASS
INNER DOOR
GLASS
MAIN OVEN
DOOR
❍❍❍

TOP OVEN
TEMPERATURE CONTROL
/ GRILL SELECT
MAIN OVEN
TEMPERATURE
SELECTOR
TIMER
GRILL
CONTROL ❍❍❍
Cooling Fan: A gentle flow of air will be blown below the control panel when any selector
switch is used.
Note: Whenever the appliance has been used, the cooling fan may run on or
restart itself after all the controls have been turned off.
This indicates that the appliance is still warm.
Oven Interior The oven lights are operated when their respective oven control is
Lights used. (N.B. Not all models have a top oven interior light).
The main oven has a light only position.
Slow Cooking ‘S’ The main oven has a “Slow Cook Setting”, ‘S’, this can be used for slow
cooking, keeping food warm and warming plates for a short period.
Controls
Control Markings
Note: It is advisable to check that all oven controls have been switched off when you have
finished using the appliance.
6
Control Knob Description
Grill Setting Control
Top Oven Temperature &
Grill Selection Control
Main Oven Temperature &
Function Control
A
ACB
B
C
Function
Selects the heat at which the grill will cook the
food. 1 – 6 Grill Settings Control:
1 = Low, 6 = High
Note: To grill you must first select a grill
function using control (B).
Selects the cooking temperature
(Degrees Centigrade) when using the top
oven as a conventional oven.
Switches the top oven to “Half Grill”
mode.
Switches the top oven to “Full Grill”
mode.
Fan Only Setting
- This is used to decrease the amount
of time required to defrost food items.
Oven Light Only
- Switches on the Main Oven Interior
Light Only.
Main Oven Temperature Scale (In
Degrees Centigrade).
- When cooking select the required
cooking temperature.
100 -
220
Half
Grill
Full
Grill
Fan
Only
Oven
Light
80 -
230

Oven Timer Operation
7
The oven timer offers you the following features:
1. Time of Day
2. Automatic Cooking
3. Minute Minder
The Main Oven (only) can be controlled by the automatic timer.
Never operate the grill or top oven when the main oven is set to cook
automatically because the oven cavity can become warm and this may cause
bacterial growth in food.
1. Select foods which will take the same time to cook and require
approximately the same temperature.
2. Set the oven timer so that the food has just finished or about to
finish cooking on your return to the oven. This will ensure the
food has not cooled down and does not require reheating
before serving.
3. Food should be as cold as possible when it goes into the oven,
ideally straight from the refrigerator. Frozen meat and poultry
should be thawed thoroughly before it is put in the oven.
4. We advise that warm food should never be placed in the oven if
there is to be a delay period. Stews prepared by frying the meat
and vegetables should be cooked as soon as possible.
5. We advise dishes containing left-over cooked poultry or meat,
for example Shepherds Pie, should not be cooked automatically
if there is to be a delay period.
6. Stews and joints should be cooked by the long slow method, so
that the delay period is kept to a minimum.
7. On warm days, to prevent harmful bacterial growth in certain
foods (ie poultry, joints, etc) the delayed start should be kept to
a minimum.
8. Wine or beer may ferment and cream may curdle during the
delay period, so it is best to add these ingredients just before
serving.
9. Foods which discolour should be protected by coating in fat or
tossing in water to which lemon juice has been added, prior to
placing food in the oven.
10. Dishes containing liquid should not be filled too full to prevent
boiling over.
11. Food should be well sealed (but not airtight) in a container to
prevent the loss of liquid during cooking. Aluminium foil gives a
good seal.
12. Ensure food is cooked thoroughly before serving.
1. Make sure all oven controls are turned Off.
2. Check that the electricity supply to the oven is turned On.
3. Check that the oven clock is at the right time of day.
Automatic Cooking
Hints on
Automatic
Cooking
Timer
Operation

8
Know Your Timer
CLOCKFACE
The timer incorporates a 24 hour clock.
Ensure the correct time of day is always set, before using your cooker.
SYMBOLS
A ‘bell’ symbol will light up when you select a Minute Minder Period and will
remain lit for the period set.
At the end of the Minute Minder Period, the timer will emit an audible tone and
the ‘bell’ symbol will disappear.
The ‘cookpot’ symbol will light up either:–
– When the timer is in manual mode, or
– During the actual Cook Period.
‘AUTO’ will light up:–
– When the timer is first turned on it will flash. It will go out when a time of day
is set or when the timer is set to manual.
The ‘AUTO’ symbol will flash at the end of an Auto Cooking programme to
indicate that the programme has finished.
(When the ‘AUTO’ symbol is flashing, to return the oven to Manual operation,
turn the oven controls off, ensure that the correct time of day is set, and press
the “Manual” button – The ‘AUTO’ symbol will go out).
Here you can set a time period of up to 23 hours 59 minutes, that will count down.
When it reaches zero, the timer will emit an audible tone.
For Example: If you set 20 minutes, the audible tone will occur 20 minutes later.
Cook Period is the actual length of time for which, the timer will switch the oven(s)
on as part of an “Auto Cooking” programme.
(e.g. If you set 2 hours, the food will be cooked for 2 hours).
The time of day at which you want an “Auto Cooking” programme to end.
For Example: If you set a “Cook Period” for 2 hours, and “End Time” of 11:00. The
timer will switch the oven(s) on at 9:00 and turn the oven(s) off at 11:00. You will hear
a audible tone at 11:00, to indicate that the Auto Cooking Programme has finished.
Notes:
- When setting an Auto Cooking programme you will need to set the oven
control(s) to the required temperature(s) when you set the timer.
- If an Auto Cooking programme has been set the oven(s) will only operate during
the pre-programmed time.
Needs to be pressed to cancel an Auto Cooking programme and return the oven(s) to
Manual operation.
Used to adjust the various timer function settings.
Minute Minder
Button
Cook Period Button
End Time Button
Manual Button
“+” and “–” Buttons
TIMER FUNCTION BUTTONS
AUTO COOKING PROGRAMME

Electronic Clock and Automatic Oven Timer Operation
9
SETTING THE TIME OF DAY
Step 1 Make sure all oven controls are turned Off.
Step 2 Check the electricity supply to the cooker is turned on.
Step 3 When switched on the display will show 0.00 and the Auto symbol,
flashing intermittently.
Step 4 Press & hold in both the Cook Period & End Time buttons together.
Step 5 With the Cook Period & End Time buttons still held in, press either the “+”
or “–” buttons to set the correct time of day.
Step 6 Release all the buttons simultaneously.
THE TIME OF DAY IS NOW SET.
To change the time of day repeat Steps 4, 5 & 6 above.
Note: You cannot adjust the time of day if the timer has been set for an
Auto Cooking Programme.
SETTING THE MINUTE MINDER
Step 1 Ensure the time of day is set correctly.
Step 2 Press and hold the Minute Minder button.
Step 3 With the Minute Minder button held in, set the required Minute Minder
period using the “+” and “–” buttons. A ‘bell’ symbol will light up.
Release all buttons and the timer display will revert back to the time of day.
The ‘bell’ symbol will remain lit to signify that a Minute Minder period has been
set.
At the end of the set time an audible tone will be heard, and the ‘bell’ symbol will
disappear.
Step 4 To cancel the audible tone press the Minute Minder button.
Note 1 When the Minute Minder has been set, the time remaining can be checked at any
time by simply pressing the Minute Minder button.
Note 2 If necessary the Minute Minder can be cancelled before the tone sounds by press
ing and holding the Minute Minder button and then at the same time pressing the
“–” button until 0.00 appears in the display window.

Electronic Clock and Automatic Oven Timer Operation
10
Step 3 Press and hold in the Cook Period button.
The display will read 0.00 with the ‘cookpot’ symbol lit.
Step 4 With the Cook Period button still held in, set the required Cook Period
using the “+” and “–” buttons.
Release the buttons and the timer display will revert to the time of day with the
‘Auto’ symbol and ‘cookpot’ symbol lit.
Step 5 Press and hold in the End Time button.
The display will read the earliest possible end time for the Cook Period
that you have set above.
The ‘Auto’ symbol and ‘cookpot’ symbol will be lit.
Step 6 With the End Time button still held in, use the “+” and “–” buttons to set
the ‘End Time’ (i.e. The time you require the oven to switch off).
Release all the buttons and the timer will revert back to the time of day.
The ‘Auto’ symbol will remain lit to signify that an Auto Cooking Programme has
been set. The ‘cookpot’ symbol will go out.
Step 7 Turn the oven control(s) to the required temperature, and if necessary
select the appropriate oven function.
At the end of the Automatic Cook Period the Auto Symbol will flash and an
intermittent bleeping sound will be heard.
The audible tone will continue unless cancelled.
The ‘Auto’ symbol will continue to flash until the timer is returned to Manual
operation (see below).
Step 8 Press the Manual button, the audible tone will be cancelled and the
oven(s) will be returned to Manual.
Step 9 Turn the oven control(s) to the OFF position.
AUTO COOKING PROGRAMMES
There are two Auto Cooking programmes that can be selected using your timer:–
(a) To set the timer to switch the oven(s) On and Off Automatically
(b) To set timer to switch on immediately and OFF automatically after a set cook period.
a) TO SET THE TIMER TO SWITCH THE OVEN(S) ON AND OFF AUTOMATICALLY
This allows you to cook at a specified time for a chosen period before the oven switches
off Automatically.
Step 1 Check that the correct time of day is set, if not follow instructions for setting the time of day.
Step 2 Place food onto the correct shelf position in the oven and close the oven door(s).

Electronic Clock and Automatic Oven Timer Operation
11
Step 4 Press & hold in the Cook Period button, the display will read 0.00 and the
‘cookpot’ symbol will light up.
With the Cook Period button still held in set the required Cook Period using the
“+” and “–” buttons. Example: 1hr 30 minutes (as shown).
Note: Cook Period is the length of time the food requires to cook.
Step 5 Release all buttons.
The timer display will revert to the time of day with the ‘Auto’ symbol lit &
‘cookpot‘ symbol remaining lit.
At the end of the Cook Period the ‘Auto’ symbol will flash and an intermittent
audible tone will be heard.
The audible tone will continue to flash until the timer is returned to Manual
operation (see below).
Step 6 Press the Manual button. The audible tone will be cancelled and the
oven(s) will be returned to Manual.
Step 7 Turn the oven control(s) to the OFF position.
b) TO SET TIMER TO SWITCH ON IMMEDIATELY AND OFF AUTOMATICALLY AFTER A SET COOK
PERIOD
Step 1 Check that the correct time of day is set, if not follow instructions for setting the time of day.
Step 2 Place food onto the correct shelf position in the oven and close the oven door(s).
Step 3 Turn the oven control(s) to the required temperature, and if necessary select the appropriate oven
function.
Note 1 When cooking automatically the Cook Period can be checked at any time by simply
pressing the Cook Period button.
Note 2 When cooking automatically the End Time can be checked at any time by simply
pressing the End Time button.
NOTE: The Cookpot symbol disappears

Electronic Clock and Automatic Oven Timer Operation
12
OTHER NOTES ON TIMER OPERATION
1. When cooking Automatically the Cook Period can be checked at any time simply by pressing the Cook
Period button.
2. When cooking Automatically the End Time can be checked at any time by simply pressing the End Time
button.
3. Having set a Cook Period and End Time an electronic device stores the information. The device within the
timer will switch the oven(s) on and off at the required times.
4. When setting an Auto Cooking Programme and a mistake is made, to clear:–
(d) Press & release the Manual button.
(e) Start the sequence again.
5. If at any time the display shows three flashing zero’s 0.00 and ‘Auto’, it is likely that the electricity supply to
the oven has been interrupted. Reset the timer to the correct time of day.
Food in the oven may, therefore, not have been cooked, before serving check food is thoroughly heated
and completely cooked.
6. To set each function always press and hold the required function button and at the same time press “+” or
“–” buttons.
TO CANCEL AN AUTO COOKING PROGRAMME BEFORE
THE COOK PERIOD HAS FINISHED.
Step 1 Turn the oven control(s) to the OFF position.
Step 2 Press the Manual button to return the oven(s) to “Manual” operation.
The ‘Auto’ symbol will go out.
Note 1 When cooking automatically the Cook Period can be checked at any time by simply pressing
the Cook Period button.

The grill pan handle is detachable from the pan, to facilitate cleaning and storage.
The grill pan handle can be fixed as follows:
Step 1 Remove the screw and washers from the grill pan bracket (a).
Step 2 Tilt the handle over the recess (b).
Step 3 Slide it towards the centre of the pan (c).
Step 4 Locate the handle over the bracket (d).
For a fixed handle, replace the screw and washers and ensure they are fully
tightened up. If a detachable handle is required, do not replace the screw and
washers.
Grill Pan & Food Support
Top Oven Shelf Positioning for Grilling
Grill Pan and Handle
13
Note: If a fixed handle is required, the grill pan cannot be kept in the main oven with the
door closed but may be stored in the top oven with the door closed, when the top oven is
not in use..
Always clean the grill pan and
food support after each use.
Step 1 Step 2 Step 3 Step 4
GRILL PAN
FOOD SUPPORT
(a)
(b) (c)
(d)
NOTE: Preheat the grill if indicated on grill chart.
The grill pan must be placed on the correct shelf and positioned centrally under the grill
element.
Leave the control at 6 for toast, and for fast cooking of foods.
For thicker foods requiring longer cooking, turn the switch to a lower setting after the
initial sealing on both sides at 6. The thicker the food, the lower the control should be set.
DO NOT line the grill pan with aluminium foil, as this increases the amount of fat spitting
which can cause a fire.
After use always return both controls to their OFF (0) position.
ENSURE SHELVES ARE FITTED CORRECT WAY UP.
DO NOT PLACE FOOD/UTENSILS DIRECTLY ON THE OVEN FLOOR
3
2
1
3
2
1

CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN
SHOULD BE KEPT AWAY. GRILLING SHOULD NEVER BE UNDERTAKEN WITH THE
GRILL/TOP OVEN DOOR CLOSED.
The grill control is designed to provide variable heat control of either the twin grill elements
on together or the single left hand grill element only, depending upon which direction the
control knob is rotated. With the control rotated clockwise the numbers will show 1through
to 6the twin elements will come on together. With the control turned anti-clockwise the
numbers will show 1through to 6and the single left hand element will come on only.
The control is Off at O.
Note: The grill will not operate unless the top oven control is in the OFF position.
Food which requires browning only should be placed under the hot grill, directly on the shelf
in the first or second runner from the bottom of the oven, according to the depth of the dish.
Open the Grill door to the grilling position. i.e. fully.
With the grill door in the grilling position, heating the grill is achieved by turning the control
clockwise to the desired ‘grill setting’ on the control panel, as described under ‘setting the grill’.
Never: line the grill pan with aluminium foil.
Note: When the door is open, air will be blown from beneath the controls by the cooling fan,
and when controls are in the Off position. Preheat the grill at setting 6for approximately 5
minutes. The grill pan is placed on the shelf and should be correctly positioned under the grill
element. Leave the control at 6for toast, sealing and fast cooking of foods. For thicker foods
requiring longer cooking, turn the switch to a lower setting after the initial sealing on both
sides at 6. The thicker the food the lower the control should be set.
14
Using the Top Oven for Grilling

Step 1 Ensure that the timer is set to manual.
Step 2 Place the rod shelf in the correct position (see Grilling Guide).
Position the grill pan on the rod shelf, centrally under the grill element.
Leave the door fully open.
Step 3 Turn knob (B) clockwise to select grill function setting:
Set to: For Half Grill (Left hand side only).
For Full Grill.
Step 4 Turn knob (A) clockwise to select the Grill Setting (1–6). (1=Low, 6=High).
Grill Controls Example:
= Full Grill Function
= Maximum Grill Setting
NOTE: Do not grill with the grill/top
oven door closed.
Step 5 After use, turn both controls A & B
anti clockwise to their off (●) position.
Operation when using the Top Oven for Grilling
15
NOTE: As you turn past the end of the oven temperature scale you will feel resistance on the
knob – continue turning clockwise until the grill setting position is selected.
Half
Grill
Full
Grill
Full
Grill
6
DO NOT allow young children near to the appliance when the grill is in use as the surfaces
get extremely hot.
TOP OVEN
TEMPERATURE CONTROL
/ GRILL SELECT
TIMER
GRILL
CONTROL ❍❍❍
AB
DOOR POSITION
FOR GRILLING.
6Full
Grill

Guide to Grilling
16
Food Preheat for 5
minutes on: Shelf Position from
base of oven. Setting Approximate
Cooking Time Notes:
3-10 minutes
10-20 minutes
25-30 minutes
10-30 minutes
10-30 minutes
10-30 minutes
10-20 minutes
8-15 minutes
5-10 minutes
Setting 6
Setting 6 for 4 minutes
then reduce to Setting 3
Setting 6 for 6-8 minutes
then reduce to Setting
3
Setting 6
Setting 3
Setting 3
Setting 6
Toasting of Bread
Products
Small cuts of meat,
Sausage, Bacon
Chops etc.
Gammon steaks
Fish Whole
Fillets
Fingers
Pre-cooked Potato
products
Pizzas
Browning of food
eg. Cauliflower
Cheese
2 or 3
2 or 3
2
2
3
3
2 or 3
2 or 3
1 or 2
Setting 6
Setting 6
Setting 6
Setting 6
Setting 6
Setting 6
Setting 6
Cooked on base of
pan
preheat pan first

The top oven should be used to cook small quantities of food. The oven is designed so
that the grill element operates at a reduced heat output, this is combined with a
heating element situated underneath the floor of the oven. To ensure even cooking of
the food it is important that cooking utensils are positioned correctly on the oven
shelf so that the element is directly above. As a guide, the front of the utensil should
be approx. 100mm (4”) from the front of the shelf.
Shelf Positioning
There should always be at least 25mm (1 inch) between the top of the food and
the grill element.
DO NOT PLACE FOOD/UTENSILS DIRECTLY ON THE OVEN FLOOR
3
2
1
ENSURE SHELVES ARE FITTED THE CORRECT WAY UP
Using the Top Oven as a Convection Oven
Note: Charts are a guide only, to suit personal taste and requirements, it may be
necessary to increase or decrease temperatures by 10˚C. It may also be necessary to increase
or decrease cooking times.
WARNING: Items stored in the top oven will get hot when the main oven is in use.
DO NOT allow young children near to the appliance when the top oven is in use as the
surfaces get extremely hot.
17

Step 1 Ensure that the timer is set to manual.
Step 2 Place the shelf in the correct position (see Oven Temperature Charts).
Step 3 Select the required cooking temperature (100–220˚C) using control (B)
(see Top Oven Temperature Charts).
The pilot light will immediately come on, and remain on until the oven
reaches the required temperature. The light will then automatically go off and
on during cooking as the oven thermostat maintains the correct temperature.
Step 4 Place the food on the shelf directly below the element ensuring the oven door is
closed.
Plate Warming
Place the plates/dishes on shelf position 1 from the base of the top oven, and turn top
oven temperature and grill selection control (B) to 100˚C for 10-15 minutes.
Never use the grill setting control (A) when warming plates.
Top Oven Utensils
Do Not use: Meat Pans and Baking Trays larger than – 225mm x 300mm (9”x12”)
Operation when using the Top Oven as a Convection
Oven
DO NOT use the grill pan as a meat pan in the top oven, as the air
circulation will be seriously restricted.
18
NOTE: At the end of your cooking, always return control (B) to the OFF (●) position.
TOP OVEN
TEMPERATURE CONTROL
/ GRILL SELECT
TIMER
GRILL
CONTROL ❍❍❍
AB

Step 1 Check that the timer is in manual.
Step 2 Place the shelf/shelves in the correct position (see Main Oven Temperature
Charts.
Step 3 Place the food centrally on the shelf ensuring the oven door is fully closed.
Step 4 Select the required cooking temperature (80 to 230˚C) by turning control (C)
clockwise. The pilot light will immediately come on, and remain on until the
oven reaches the required temperature. The light will then automatically go
off and on during cooking as the oven thermostat maintains the correct
temperature.
Using the Main Oven for Fan Cooking
Since a circulaire fan oven heats up more quickly and generally cooks food at a
lower temperature than a conventional oven, pre-heating is often unnecessary.
For “Oven Temperature Charts” later in book.
Main Oven Shelf Positioning for Fan Oven
Most foods will cook satisfactorily on any shelf position, due to even distribution of heat in the
main oven, but the shelves must be evenly spaced.
The top oven rod shelf can be used in the main oven when cooking large quantities of food.
(N.B. Maximum 2 shelves in the main oven).
Food or utensils should never be placed directly on the floor of the oven
for cooking.
Main Oven Utensils
Do Not Use: Meat Pans larger than – 375mm x 300mm (15”x12”)
Baking Trays larger than – 325mm x 250mm (13”x10”)
Temperature & Time
When all three shelves are in use to cook large quantities of food, it may be necessary to
increase the cooking times given in the temperature charts by a few minutes, to allow for
the loss of heat due to extra time taken to load the oven, and the larger mass of food.
Baking trays should have an even gap around the oven.
Main Fan Oven Operation
Note: Charts are a guide only, to suit personal taste and requirements, it may be necessary to
increase or decrease temperatures by 10oC. It may also be necessary to increase or decrease
cooking times.
DO NOT allow young children near to the appliance when the main oven is in use as the surfaces
get extremely hot.
Note: When you have finished using your cooker, always return the controls to their OFF (●)
position. At the end of the cooking period there may be a momentary puff of steam when the door is
opened. This will disperse in a few seconds and is a perfectly normal characteristic of an oven with a good
door seal.
19
C
MAIN OVEN
TEMPERATURE
SELECTOR
TIMER
❍❍❍
