Hotpoint GD64 User manual

InstructionsforInstallationandUse
GasHob
Models GD74, GD74 CH,GD64, GF740, GE740TCX
TotheInstaller
Before installation fill in the product details on the back cover of this book.
Theinformationcan be found ontherating plate.
TotheUser
Youmust read theinstructionsprior to installing and using the appliance and
thenretainthemforfuturereference.

2
CONTENTS
Introduction
For Your Safety
Know your Hob
How to use your Hob
Practical Advice
Care and Cleaning
Troubleshooting
Installation
Electrical Connection
Characteristics of Burners and Nozzels
After Sales Service
Hotpoint Guarantee
Key Contacts
3
4
5
5
6
6
7
8-10
11
12
14
15
Back Cover
Retention of this Instruction Book
ThisInstructionBookmustbekepthandyforreferenceasitcontainsimportantdetailsonthesafeandproperuseofthe
appliance.
Ifyou sell or passthe appliance to someoneelse, or movehouse and leave itbehind, make sure thisBook is also
providedso the new ownercan become familiar withthe appliance andsafety warnings.
If the Book is lost or damaged a copy may be obtained from:
INDESIT Company UK LTD, MorleyWay, Peterborough, PE2 9JB

3
Your new hob is guaranteed* and will give lasting service. This guarantee is only applicable if the appliance has been
installedinaccordance with theinstallationinstructionsdetailedinthis booklet.
Tohelpmakebestuse of your cooking equipment, pleasereadthisbookletcarefully.
Thehobisdesigned specifically for domestic useandresponsibilitywill not be accepted for useinanyother installation.
Introduction
* The guarantee is subject to the provisions that the appliance:
(a) Has been used solely in accordance with this booklet.
(b) Has been properly connected to a suitable supply voltage as stated on the rating plate, attached to the
appliance.
(c) Has not been subjected to misuse or accident or been modified or repaired by any person other than the
manufacturersauthorisedemployeeoragent.
(d) Has been correctly installed.
Thisapplianceconformswiththe following European Economic Community directives:
- 73/23/EEC of19/02/73 (Low Voltage) andsubsequentmodifications;
- 89/336/EECof03/05/89(ElectromagneticCompatibility)and subsequent modifications;
- 90/396/EEC of29/06/90(Gas)and subsequent modifications;
- 93/68/EEC of22/07/93and subsequent modifications.

4
For Your Safety
ALWAYS:
-makesureyouremoveallpackagingand disposeofsafely.
- check the soundness of the appliance after it has been
unpacked.
- make sure you understand the controls before using the
appliance.
-keepchildren away from theapplianceduring use.
- take care to avoid heat/steam burns when operating the
controls.
-makesurethecontrolsareturnedoffwhenyouhavefinished
cookingand when notin use.
- take care to avoid heat/steam burns when operating the
controls.
-disconnectfromthepowersupply,andallow tocool,before
cleaningorperformingmaintenance.
-referservicing to a qualifiedapplianceserviceengineer.
- keep the hob clean as a build up of grease or fat from
cookingcancausea fire.
-followthebasicprinciplesoffoodhandlingandhygieneto
preventthepossibilityofbacterialgrowth.
-dry foodthoroughlybeforefryingandloweritslowlyintothe
hotoilorfat. Frozenfoodinparticular,willcausefrothingand
spittingifaddedtoo quickly.
-keep outside ofpans clean andfree from streaksof oil or
fat.
-placepanscentrallyovertheburner making sure handles
are kept away from the edge of the hob and cannot be
heatedby other burners/pans.
-keepanyventilationslotsclearof obstructions.
NEVER:
- attempt to install or repair the appliance without the
assistanceofqualifiedpersonnel.
-storeitemsabovethe appliance that children may attempt
toreach.
-heatup unopened food containers, aspressurecan build
upcausingthecontainertoburst.
-use the appliance to heatup anything other than food.
-use the appliance as aroom heater.
- dry any items on the hob.
-installtheappliancenexttocurtainsorothersoftfurnishings.
-allowchildren to play with ortamperwith the controls.
-leavechildrenunsupervised where cookingappliancesare
installedasallthecookingsurfacesgethotduring and after
use.
-storechemicals,foodstuffsorpressurisedcontainersinor
ontheappliance, or in cabinetsimmediatelyabove or next
totheappliance.
-useflammable or plastic itemsonor near the hob.
-useadapters, multiple sockets and/or extensionleads.
-filla deep fatfryingpanmorethan1/3 fullofoil,orusealid.
DO NOT LEAVE UNATTENDED WHILE COOKING.
- fry too much food at a time, especially frozen food. This
onlylowersthetemperatureortheoilorfattoomuch,resulting
ingreasyfood.
- pull on the appliance or the supply able to unplug it from
theelectricaloutlet.
-allowpowercablesofotherappliancestocomeintocontact.
- with hot parts of this appliance.
- expose the appliance to atmospheric agents, such as
rainorsunlight.
- operate the appliance with wet hands.
-allow anyone to sit or stand on any partof the appliance.
- use misshapen pans which may be unstable.
- use round base woks directly on the pan supports.
-usefishkettlesorlargepreservingpansacrosstwoburners.
- operate the appliance with wet parts of the body.
-operate the appliancewhen barefoot.
When used properly your appliance is completely safe but as with any electrical product there are certain
precautions that must be observed.
PLEASE READ THE BELOW PRECAUTIONS BEFORE USING YOUR APPLIANCE.
Tomaintaintheefficiency and safety of thisappliance,werecommend you do the following:
-onlycalltheServiceCentresauthorisedbythemanufacturer.
- always use genuine spare parts.
SAFETY ADVICE
IMPORTANT-Aswithanycookingappliancetherecould be some fire risk attached to the heating of oil, particularly for
deepfatfrying. Cookingutensilscontainingoilmustnotbe left unattended (eg. to answer the telephone) on or in close
proximityto thecookingareas.
IN THE EVENT OF A CHIP PAN OR ANY OTHER PAN FIRE:
1.Turnofftheburners.
2.Coverthepanwithafireblanketordampcloth,thiswillsmother the flames and extinguish the fire.
3.Leavethe pan to coolforat least 60 minutesbeforemoving it. Injuries areoftencaused by picking upahot pan and
rushingoutside withit.
NEVERUSE A FIRE EXTINGUISHERTOPUT OUT A PANFIRE as the forceof the extinguisher islikelyto tip thepan
over.Neverusewater to extinguish oilorfatfires.

5
D
F
B. Pan Support for Cookware
C. ControlKnobsforGasBurners
D. IgnitorforGasBurners
F. FlameFailure Device- Activatesiftheflameaccidentally
goesout (spills, drafts, etc.),interruptingthe delivery of
gastotheburner.
How To Use Your Hob
Know your Hob
Thepositionofthecorrespondinggasburner isindicatedon
eachcontrol knob.
The burners differ in size and power. Choose the most
appropriateoneforthediameterofthecookwarebeingused.
Theburner can be regulatedwiththe corresonding control
knobby using one ofthefollowing settings:
• Off
High
Low
Tolight a burner, simply press the corresponding knob all
thewayinand then turn itinthecounter-clockwisedirection
tothe "High" setting, keeping it pressed in until theburner
lights.
Caution: Ifthe burner accidently goesout,turn off the gas
withthecontrol knob and trytolight it again afterwaitingat
least1minute.
These models are fitted with a safety device (F), the
knobmust bepressedinforabout6secondsuntilthedevice
thatkeeps the flame lightedwarmsup.
Toturn off aburner, turntheknobintheclockwisedirection
untilitstops (it should beonthe “•” setting).
A. AuxilliaryBurner
R RapidBurner
S. Semi Rapid Burner
RR. Reduced Rapid Burner
TC. TripleCrownBurner(WokBurner)
Model GD74, GD74 CH
A
B
C
A
B
C
A
B
C
Model GD64 Model GF740, GE740TCX
RR
TC
S
S
S
RR
S
S
R

6
PracticalAdviseon Using the Burners
For best performance, follow these general guidelines:
• Use the appropriate cookware for each burner (see
table) in order to prevent the flame from reaching the
sides of the pot or pan;
• Alwasy use cookware with a flat bottom and keep the
lidon;
• When the contents come to a boil, turn the knob to
"Low".
Practical Advice
Burner Cookware Diameter
(cm)
Rapid (R) 24 - 26
Reduced Rapid (RR) 22 - 24
Semi-Rapid (S) 16 - 20
Auxilliary(A) 10 - 14
TripleCrown(TC) 24 - 26
Toidentifythetypeofburner,referto the 'BurnerandNozzle
Specifications'section.
Care and Cleaning
Before cleaning or performing maintenance on your hob,
disconnectitfromthepowersupply.
To extend the life of the hob, it should be cleaned
carefullyand thoroughly onafrequent basis,keepingin
mindthefollowing:
• Theenamelled parts must bewashed with warm water
withoutusingabrasive powdersorcorrosivesubstances
whichcouldruinthem.
• Theremovable parts of the burners should be washed
frequently with warm water and soap, making sure to
removecaked-onsubstances.
• Onhobswithautomaticignition,theend oftheelectronic
ignitiondevicemust be cleanedcarefullyandfrequently,
makingsurethatthe gas holes are notclogged.
• Thetop must becleaned with glasscleaning products.
Avoid using abrasive products and abrasive sponges
thatcouldscratchtheglass.
• The glass surfaces should be cleaned regularly with a
solution of warm water and a non-abrasive detergent.
First,removeall food build up orgreasewith a cleaning
scraper(Fig.A).
• Stainless steel can be stained if it remains in contact
withhighly calcareous water or aggressive detergents
(containingphosphorous) foranextendedperiodoftime.
Itisrecommendedthatthese parts be rinsed thoroughly
with water and then dried well. It is also a good idea to
clean up any spills.
Clean the cooking surface when it is still warm with a
suitablecleaningproduct,rubwithacleandampcloth
and dry. Sugarorfoodswith a high sugar content that
havemeltedontothesurface must be removed
immediatelywithascraperwhilethesurfacrisstillhot.DO
NOTuseabrasivespongesorcleaningproducts under
anycircumstances.Thisholdstrueforchemically
aggressivecleaners,likeovenspraysandstainremovers.
Greasing the Gas Valves
Over time, the gas valves may stick or become difficult to
turn. If this is the case, the must be cleaned on the inside
andtheregreased.
N.B.:This proceduremustbe performedbya technician
authorizedbythe manufacturer.
Fig.A
Do not place anything, e.g. flame tamer,
asbestos mat, between pan and pan
support as serious damage to the
appliance may result.
Do not remove the pan support and
enclose the burner with a work stand as
this will concentrate and deflect the heat
onto the hotplate.
Do not use large pots or heavy weights
which can bend the pan support or
deflect the flame onto the hotplate.
diffuser,

7
Troubleshooting
If the burner does not remain on when set to "Low".
Check to make sure that:
• Thegasholesare not clogged.
• Therearenodraughts near the cookingsurface.
• Theminimumhasbeenadjustedcorrectly(seeInstallation
section,"MinimumRegulation").
If the cookware is not stable.
Check to make sure that:
• Thebottomofthecookwareisperfectlyflat.
• Thecookwareis centered correctlyontheburner.
• Thesupportgridshave not been inverted.
If, despite all of these checks, the hob does not function
properly and problem persists, call Hotpoint Service (see
KEYCONTACTS,backpage), informing them of:
-Thetypeof problem.
- The abbreviation used to identify the model (Mod. ...) as
indicatedonthewarranty.
IMPORTANT:
Never call upon technicians not authorized by the
manufacturer,andrefusetoacceptsparepartsthatarenot
original.
Before calling service for assistance, check through the
followinglist,theremaybenothingwrong.
Firstofall, check toseethatthereareno interruptionsinthe
gasand electrical supplies,and, in particular,that the gas
valvesfor the mainsare open.
If the burner does not light or the flame is not uniform
aroundthe burner.
Check to make sure that:
• Thegasholeson the burner are notclogged.
• All of the movable parts that make up the burner are
mountedcorrectly.
• Thereareno draughts around thecookingsurface.
If the flame does not stay lit on a model with the
FlameFailuredevice.
Check to make sure that:
• You press the knob all the way in.
• You keep the knob pressed in long enough to activate
theflame failuredevice.
• Thegas holesarenotclogged intheareacorresponding
totheflamefailuredevice.

8
Installation
Thefollowinginstructionsareintendedfortheinstallersothatthe
installationandmaintenanceproceduresmaybefollowedinthe
most professional and expert manner possible. Important:
Disconnecttheappliancefromtheelectricalsupplybefore
performinganymaintenanceorrepair.
PositioningtheHob
Important: this unit may be installed and used only in
permanently ventilated rooms in accordance with British
Standard Codes Of Practice:B.S. 6172 / B.S. 5440, Par.2 and
B.S.6891CurrentEditions.Thefollowingrequirementsmustbe
observed:
a) Theroommustbefittedwithaventilationsystemwhichvents
smokeandgasesfromcombustiontotheoutside.Thismust
be done by means of a hood or electric ventilator that turns
onautomaticallyeachtimethehobisoperated.
Ina chimneystackorbranchedflue. Directlytothe Outside
(exclusively forcookingappliances)
b) Theroommusthaveanairflowtoallowforpropercombustion.
Thismustbe2m3³/hperkWofinstalledpower.Theairflowcan
becreatedusinganenclosedventwithaninnercrosssection
ofatleast100cm²whichmustnotbeabletobeblocked.Ithe
appliancedoesnothaveaflamefailuredevice,theventmust
haveaninternalcrosssectionof200cm3³ (Fig. A). Alternatively
theroominwhichthehobissituatedcanbeventedindirectly
throughventilation ducts as specifiedabove, as long asthe
adjacentroomisnotasharedarea,abedroomorpresentany
risk of fire (Fig. B).
DetailA Adjacent Room to be
Room Vented
A
Examples of ventilation holes Enlarging the ventilation slot
forcomburantair. between window and floor.
Fig.A Fig.B
c) Intensiveandprolongeduseoftheappliancemaynecessitate
supplementalventilation,e.g.openingawindoworincreasing
thepoweroftheairintakesystem(ifpresent).
d) Liquidifiedpetroleumgasesareheavierthanairand,asaresult,
settledownwards. Rooms in which LPG tanks are installed
mustbefittedwithventilationopeningstotheoutsideinorderto
allowthegastoescapeintheeventofaleak.Therefore,LPG
tanks,whetheremptyorpartiallyfull,mustnotbeinstalledor
storedinroomsorspacesbelowgroundlevel(cellars,ect.).Itis
alsoagoodideatokeeponlythetankcurrentlybeingusedin
theroom,makingsurethatitisnotnearsourcesofheat(ovens,
fireplaces,stoves,etc.)thatcouldraisetheinternaltemperature
ofthetankabove50°C.
InstallationofBuilt-inHobs
Thegas hob is equippedwithtype X degree protectionagainst
overheating. Therefore, the appliance can be installed next to
cabinets,providedtheheightofthecabinetdoesnotexceedthatof
thehob.Forproperinstallationofthehob,thefollowingguidlines
mustbefollowed:
a) Ifthecabinet(s)locatednexttothehobarehigherthanthehob
itself,thecabinet(s)mustbeinstalledatleast110mmfromthe
hobedge.
b) Hoodsmustbeinstalledinaccordancewiththeinstructions
containedintheinstallationmanualforthehoodsthemselves,
andnolessthan650mmfromthehob.
c) In the case of the 600 mm cooker hoods, besides following
the recommendations in point b), the cabinets should be
positioned next to the hood at a height of at least 540 mm
from the top since this will make it possible to install the lid
andmoveitcorrectly.Thecabinetshouldalwaysbeinstalled
at a height from the top which allows easy use of pots and
pans on the cooker.
d) Shouldthehobbeinstalleddirectlyunderacupboard,thelatter
shouldbeatleast700mm(millimetres)fromthetop,asshown
inFigureC.
Fig.C
e) Thedimensionsofthecutoutfortheappliancemustbethose
indicatedinthefigureD.Clampsareprovidedtofastenthehob
tocountersmeasuringfrom20to40mminthickness.Tofasten
the hob securely, it is recommended that all the clamps be
used.
Fig.D
HOOD
420
Min.
min.
650
mm. with hood
min.
700
mm. without hood
mm.
600
Min. mm.
420
Min. mm.
555 mm.
55 mm.
475 mm.

9
When installing the hob above a built-in oven without forced
ventilation,ensurethatthereareairinletsandoutletsforventilating
theinteriorofthecabinetadequately.
GasConnectionfortheHob
Thehobshouldbeconnectedtothegassupplybyanauthorized
installer.During installation of this product it is essential tofit an
approvedgastaptoisolatethesupplyfromtheapplianceforthe
convenienceofanysubsequentremovalorservicing.Connection
of the appliance to the gas mains or liquid gas tanks must be
carriedoutaccordingtothesafetystandardscurrentlyinforce,and
onlyafteritisascertainedthatitissuitableforthetypeofgastobe
used.Ifnot,followtheinstructionsindicatedinthesectionentitled,
“AdaptingtheHobforDifferentTypesofGas”.Ifthehobistobe
connectedtotankscontainingliquidgas,usepressureregulators
thatcomplywithcurrentsafetystandards.
Important:Toinsurethattheapplianceoperatessafety,thegas
is regulated correctly and your appliance lasts over time, make
surethatgaspressurelevelscomplywiththeindicationsgivenin
Table1,“NozzleandBurnerSpecifications”.
GasConnectionto Non-flexiblePipe
(copper or steel)
Connectiontothegassourcemustbedoneinsuchawayasto
not create any stress points at any part of the appliance.
Theapplianceisfittedwithanadjustable,"L"shapedconnector
and a gasket for the attachment to the gas supply.Should this
connector have to be turned, the gasket must be replaced
(suppliedwiththeappliance).
Thegasfeedconnectortotheapplianceisathreaded,male 1/2"
connectorforroundgaspipe.
Gas Connection to Flexible Steel Pipe
Thegasfeedconnectortotheapplianceisathreaded,male1/2"
connectorforroundgaspipe.Onlyusepipes,tubesandgaskets
thatcomplywithcurrentsafetycodes. Themaximumlengthofthe
flexiblepipesmustnot exceed 2000 mm. Oncetheconnection
hasbeenmade,ensurethattheflexiblemetaltubedoesnottouch
anymovingpartsandisnotcrushed.
Check the Seal
Oncethehobhasbeeninstalled,makesurealltheconnections
areproperly sealed, usinga soapy water solution.Never use a
flame.
Before fastening the hob in place, position the seal
(supplied)alongtheperimeterof the worktop, as shown
inthefigure.
Clamps are provided to fasten the hob to counters
measuringfrom20to 40 mm in thickness.Tofastenthe
hobsecurely, it is recommended that all the clamps be
used.
FasteningClamps-AssemblyDiagram
ClampPositionfor ClampPositionfor
H=30mmtop H=40mmtop
Front
ClampPositionfor
H=20mmtop Back
N.B:Usetheclampscontainedinthe"accessorykit."
f) In the event the hob is not installed above a built-in oven, a
woodpanelmustbeinsertedasinsulation.Thispanelmustbe
placedatleast20mmfromthebottomofthehobitself.
Important:Wheninstallingthehobaboveabuilt-inoven,theoven
should be placed on two wooden strips; in the case of a joining
cabinetsurface,remembertoleaveaspaceofatleast45x560
mmattheback.
560 mm.
45 mm.
Installation

10
Adaptingthe Hobfor DifferentTypes ofGas
To adapt the hob to a different type of gas than that for which it
wasdesigned,(seethestickerunderthehoboronthepackaging),
theburnernozzlesmustbechanged,asfollows:
•Remove the pan supports and slide the burners out of the
cooktop.
•Unscrew the nozzles using a 7mm socket wrench and
replacethemwiththoseforthenewtypeofgas.(Seetable1,
“BurnerandNozzleSpecifications”).
•Reassemblethepartsfollowingtheinstructionsinreverseorder.
•Oncompletingtheoperation,replacetheoldratinglabelwith
theoneshowingthenewtypeofgas;thestickerisavailable
fromHotpointService(seeKEYCONTACTS,backpage).
If the gas pressure is different than that prescribed, a pressure
regulatormustbeinstalledatthesource,incompliancewithnational
standardsgoverningtheuseof pipedgasregulators.
RegulationofAirSupplytotheBurner
Theburnersdonotneedaprimaryairregulator.
MinimumRegulation
•Turn the gas valve to minimum.
• Remove the knob and turn the regulator screw (positioned
either on the side of the top or inside the shaft) clockwise
untiltheflamebecomessmallbutregular.
N.B.: Inthecaseofliquid gas, the regulation screw must be
fullyscrewedin(clockwise).
•Makesurethat,whentheknobisturnedrapidlyhightolow,the
flamedoesnotgoout.
•Intheeventofamalfunctiononapplianceswiththesecurity
device(thermocouple)whenthegassupplyissetatminimum,
increasetheminimumsupplylevelsusingtheregulatorscrew.
Once the adjustment has been made, apply sealing wax, or a
suitablesubstitute,totheoldsealsontheby-pass.
Installation

11
Electrical Connection
Electricalconnection
WARNING: THIS APPLIANCE MUST BE EARTHED.
The hob is designed to work with alternating current, the
supplyvoltage and frequencyindicated on the ratingplate
(situated under the hob). Make sure that the local supply
voltagecorresponds to the voltage indicatedon the rating
plate.
Connecting the supply cable to the mains electricity
supply
For models supplied without a plug, fit a standard plug
suitable for the load indicated on the rating plate, onto a
cableand connect to asuitable socket.
Toconnectdirecttothemainssupply,adoublepoleswitch
with a contact separation of at least 3mm suitable for the
loadandcomplyingwithcurrent standards and regulations
mustbefittedbetweentheapplianceand the mains supply
outlet.
Thegreen-yellowearthwire must not be interruptedbythe
switch.
The supply cable must be positioned so that no part of it
reaches atemperatureof50°Caboveroomtemperature.
For installation above a built-under oven, the hob and the
ovenmustbe connectedseparatelytotheelectricity supply,
both for safetly reasons and for easy removal of the oven
forrepair,maintenanceetc.
DONOT use adapters astheycould cause overheating or
burning.
Beforeconnectingtothepower supply, make sure that:
• thelimiterswitchandthedomesticsystemcan
withstandthe load fromthe appliance (see rating
plate).
• thesupplysystemisefficientlyearthedaccordingto
standardsand laws in force.
• thesocketor double-pole switch are easilyaccessible
whenthe appliance is installed.
Important: the wires in the mains lead are coloured in
accordancewiththefollowing code:
Green& Yellow - Earth
Blue - Neutral
Brown - Live
As the colours of the wires in the mains lead may not
correspondwiththecolouredmarkingsidentifyingtheterminals
inyourplug, proceed as follows:
ConnecttheGreen&Yellowwireto terminal marked “E”or
orcolouredGreenorGreen&Yellow.
ConnecttheBrownwiretotheterminalmarked“L”orcoloured
Redor Brown.
ConnecttheBluewiretotheterminalmarked“N”orcoloured
BlackorBlue.
FAILURE TO OBSERVE THE ACCIDENT-
PREVENTIONREGULATIONS RELIEVES THE
MANUFACTUREROFALLLIABILITY.
Replacing the cable
Use a rubber cable of the type H05RR-F with a suitable
crosssection 3x0.75mm².
Theyellow-greenearthwiremustbe2-3cmlongerthan
theotherwires.

12
Characteristic of the burners and nozzles
Table 1 Liquid Gas Natural Gas
Burner Diameter
(mm) Thermal Power kW (p.c.s.*) By-pass 1/100
(mm)
Nozzle
1/100 Flow* g/h Nozzler 1/100 Flow* l/h
Nom. Red. (1) (mm) *** ** (mm)
Fast
(Large) (R) 100 3.00 0.7 41 39 86 218 214 116 286
Reduced Fast
(RR) 100 2.60 0.70 41 39 80 189 186 110 248
Semi Fast
(Medium) (S) 75 1.65 0.4 30 28 64 120 118 96 157
Auxiliary
(Small) (A) 55 1.00 0.4 30 28 50 73 71 71 95
Triple Crown
(TC) 130 3.25 1.3 60 57 91 236 232 133 309
Supply
pressures
Nominal (mbar)
Minimum (mbar)
Maximum (mbar)
28-30
20
35
37
25
45
20
17
25
* At 15°C and 1013 mbar-dry gas
** Propane P.C.S.= 50.37MJ/kg.
*** Butane P.C.S.=49.47MJ/kg.
Natural P.C.S.= 37.78 MJ/m3
(1) re.Models withthesecurity device(Ref. F).
Rapid
(Large)(R)
Reduced
Rapid (RR)
SemiRapid
(Medium)(S)

13
Notes

GB 14
"No company is better positioned to offer an after sales service on a
Hotpoint appliance than us - the manufacturer"
As part of our commitment to you, all Hotpoint appliances have the added benefit of a fully inclusive parts
and labour guarantee for the first 12 months. In addition to this you also have the advantage of free
replacement parts for the first 5 years when fitted by a Hotpoint
engineer. When the 12 months parts and labour guarantee expires we offer the following after sales
serviceoptions:
Repair Service and Information Help Desk
UK:08709 066066
www.theservicecentre.co.uk
Republicof Ireland: 1850 302 200
Note: Our operators will require the Model number and the Serial number of your appliance
Available 364 days a year with a fast, effective and value for money service. We have the largest white
goods repair service in the UK with over 1200 of our own fully trained engineers. All repairs include a parts
and labour guarantee for 12 months from the date of the repair.
If you require any information or have any questions about your appliance, our operators are on hand with
helpandadvice.
Allthisensuresthatyouwill receive the best available after sales service possible.
Extended Warranties
UK:08709088088
www.theservicecentre.co.uk
Republicof Ireland: 1850 502 200
Whether you have just one or a number of Hotpoint appliances in your kitchen, we offer two service cover
plans to give you total peace of mind.
l RepairProtectionPlan - FREEservice repairs for asingleHotpoint appliance during theperiod
of cover.
l Kitchen Cover - FREEservice repairsforall your Hotpointappliancesless than 8
yearsold.
Genuine Parts and AccessoriesUK: 08709 077 077
www.theservicecentre.co.uk
Republicof Ireland: [phone]
A wide range of genuine parts and accessories are available from our hotline or through our web site.
Genuine parts and accessories, extended warranties and service repairs are all
available on our web-site at:
www.theservicecentre.co.uk

GB
15
Guarantee
"Satisfaction guaranteed or your money back"
We give you a unique 'satisfaction guaranteed' promise - valid for 90 days - after you have
purchasedyourHotpointappliance. Ifthereisa technical problem simply call Hotpoint Repair service or
visit our web-site at www.theservicecentre.co.uk and where necessary, we will arrange for an
engineer to call. If the technical problem is not resolved under this guarantee, we will replace your
machine or, if you prefer, give you your money back.
All Hotpoint appliances carry a fully inclusive 12 month parts and labour guarantee as well as free
replacement parts for the first 5 years (except microwaves, selected integrated appliances and cooker
hoods, which have a one year guarantee) provided that they are fitted by a Hotpoint engineer.
Guarantee terms and conditions
Your guarantee is only applicable in the United Kingdom or Republic of Ireland and is subject to the
following provisions that your appliance:
lHas been installed and used correctly in accordance with this instruction booklet.
lHasbeenused solely for domestic purposes and is locatedondomesticpremises(ie.not for
commercialortrade use).
lHas been properly connected to a suitable electrical supply voltage as stated on the appliance
rating plate.
lHas not been subject to misuse, accident, modified or repaired by anyone other than one of our
ownservice engineers.
For pre purchase information on any other Hotpoint product call: 08701 50 60 70
or visit: www.hotpoint.co.uk
Recycling&DisposalInformation
As part of Hotpoint's continued commitment to helping the environment, Hotpoint reserves the right to
use quality recycled components to keep down customer costs and minimise material wastage.
Pleasedispose of packaging andoldappliances carefully.
To minimise risk of injury to children, remove the plug and cut mains cable off flush with the appliance.
Dispose of these parts separately to ensure that the appliance can no longer be plugged into a mains
socket.

Key Contacts
After Sales Service
02/2005-195036406.03
Over 1200 trained specialists, directly employed by us, ensure that you can have complete confidence in
both the appliances and services we offer.
Repair Service and Information Desk
UK: 08709 066 066
(Open 8 to 8 Mon - Fri, 8 to 6 Sat, 10 to 4 Sun & Bank Holidays)
www.theservicecentre.co.uk
Republic of Ireland: 1850 302 200
Note: Our operators will require the following information:
Modelnumber:
Serialnumber:
Extended Warranties
UK: 08709 088 088
(Open 8 to 8 Mon - Sun)
www.theservicecentre.co.uk
Republic of Ireland: 1850 502 200
Genuine Parts and Accessories
UK: 08709 077 077
(Open 8-30 to 5-30 Mon - Fri & 9 to 12 Sat)
www.theservicecentre.co.uk
Republic of Ireland: [phone]
Indesit Company UK Ltd.Morley Way, Peterborough, PE2 9JB.
