HoverCam Pilot User manual
Pilot
Quick Start Guide
For further assistance, please visit www.thehovercam.com/support to download the manual or email us at
1-------------HDMI 7-----------Lightning slot
2-------------21.5" touch screen 8-------------Solo Video booth
3-------------Baffle 9-------------Positioning plate
4-------------Keyboard 10-------------Tray
5-------------Motor lifting lever 11-------------220V power line
6-------------MIC 12-------------Cooling fan
1 ----------MIC 6----------HDMI In2
1 ----------Earphone 7----------Power
3 ----------USB3.0 8----------Reset
4----------USB3.0 9----------HDMI Out
5----------HDMI In1
Motor up button
Lightning switch button
HDMI In2 switch button
HDMI In1 switch button
MIC working indicator light
Speaker working indicator light
Motor down button
Reset
Zoom out
Zoom in Rotate 180° Focus lock
Focus
Electric height-adjustable desk
Height range: 78 cm to 110 cm
High-definition and high-speed exhibition platform featuring 13 million pixels and autofocus
Multi-angle and multidimensional display of objects
The platform includes common operation tools such as a computer, centrally controlled touch screen,
speaker, keyboard, and mobile terminals. The lateral tray can hold computer books, cups, and other
articles. With a 6 m power line connected, the platform can be moved conveniently.
External Computer and Mobile Devices
The platform has multiple interfaces for connecting to a PC, Mac, iPad, and other mobile devices to
display the contents of the connected devices.
HDMI-based Wireless Sending/Receiving Technology
The platform can wirelessly synchronize 1080p high-definition videos with any interactive display, with
support for bidirectional multipoint touch operation.
Installation procedure:
Double-click the installation program . The installation wizard is displayed, as shown in the
following figure. Install KnoteSterSuite step by step according to instructions. To continue installation,
click Next.
The left-side figure shows the
interface for selecting the
installation folder. If you use the
default installation path, click
Next. If you want to use another
installation path, click Browse
and select the desired path. Then
click Next.
1.1 After installation, the KnoteSter Suite shortcut icon is automatically created on the desktop, as
shown in Figure 1.1. Double-click this icon to start KnoteSter.
Click Next. The
installation progress bar
is displayed.
Click Close after
installation is
completed.
Login and registration:
2.1 Click to log in or register a new account.
If you already have an account, enter your account name and password. If you are a new user, register an
account before login.
2.2 Double-click to start KnoteSter. The following figure shows the function menu of KnoteSter.
1. Recording
Click to record classes and upload recordings to the cloud in real time to form
notes. No large files need to be uploaded. The upload process ends when class is over. Teachers can
mark key points and knowledge points for student to review after class.
2. High-definition Exhibition Platform
Click to select the parameters and method of recording and start video recording.
Screen split
Slingshot
The screen split feature supports 2 panes and multi-pane. You can go to multi-pane settings to set the
number of displayed images in transverse and longitudinal directions. You can insert pictures taken by
camera or pictures from other materials for comparison purposes. Screen split enables unified
comparison for scientific experiments or comparative evaluation, as well as local comparison by zooming.
Other recording functions
Click to suspend KnoteSter on top of other software to edit Word documents or paste
pictures.
Click to take a snapshot, start recording, or take consecutive pictures.
Which function to use depends on the data collection method. To take a snapshot, you can also
double-click the target.
Cropping
Click and drag the frame to crop out the desired image collection area.
Description of other cropping functions
: Click to take a picture. You can also double-click the cropped area to take a picture of it.
: Click to take a picture of the selected image collection area and paste the picture to a Word
document or other types of document and software for direct use.
: Click to implement electronic recognition of the text in the selected area by using the OCR
function.
: Click to manually adjust the focal length when a focusing error occurs.
: Click to fine-tune image collection on uneven objects by using the tilt correction function.
: Click to adjust the collection area in transverse and longitudinal directions in a grid.
: Click to exit the cropping function.
3. Interactive Whiteboard
Click to enable the whiteboard function, which supports single-/multi-point touch
and adding/deleting whiteboard.
Description of icons:
Take a picture
Capture a snapshot of the desktop
Load a file or picture
Save as an image or a file
4. Desktop Marker
Click in the middle-right part of the recording screen to start the marker
software, as shown in the following figure.
Click a function button to complete setting.
Description of the buttons of the marker toolbar:
1. Line: Use the mouse for marking information with lines in different colors.
2. Graph: Add different graphs or blocks to the current screen for content marking. The extended
functions include selecting frames, segments, and arrows for lines to select the marked content by
different methods.
3. Clear: Clear unnecessary mark traces on the screen.
4. Subtitle: Add subtitles to the recording area.
5. Select: Move existing marks and identifiers.
6. Undo and redo: Eliminate the impact of misoperation.
5. Student Management
Click to create class information by semester for ease of student information
management.
6. File Management
Click to store the videos and pictures that are generated during
class/microclass recording as well as those generated by the high-definition exhibition platform and
interactive whiteboard. Archive Manager consists of two modules: Lessons/Notes and Files, which
provide an easy way to find desired files.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly
approved by the party.
Responsible for compliance could void the user’s authority to operate this
equipment. (Example- use only shielded interface cables when connecting to
computer or peripheral devices).
This equipment complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
RF warning statement:
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
