Navitar SST300 Guide

ROCHESTER, NEW YORK
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES AND
INCLUDE CHEMICALLY APPLIED
OR PLATED FINISHES
0.0 inch 1.0
0.0 mm 25.0
P/N SUFFIX DEFINITION
-1 CONVERSION COATING
-2 PAINTING
-3 MARKING
-R REWORK
SIZE
REV
TOLERANCES AS FOLLOWS
DEC. .XXX
DEC. .XX
FRACT.
ANGLES
CONCENTRICITY
BREAK ALL SHARP EDGES
.005 MIN. .010 MAX.
MAX. SURF. ROUGHNESS: 32
`.005
`.010
`1/64
`30'
.003 TIR
USED ON:
MATERIAL:
FINISH:
CHAMFER ALL THREADS 30~
TO ROOT DIAMETER
SCALE:
DR:
CH:
APP:
DATE DR:
DO NOT SCALE DRAWING SHEET OF
THE CONTENTS OF THIS
DOCUMENT ARE PROPRIETARY
TO NAVITAR, ITS USE IS
AUTHORIZED ONLY FOR
RESPONDING TO REQUEST FOR
QUOTATION OR PERFORMANCE
OF WORK FOR NAVITAR
1 1 A
1-16789
R. PODLENA
2/28/2005
SST300 SCREENSTAR 3X CONVERSION
LENS
1:1
B
OUTLINE
n3.00 [76.2]
n2.30 [58.4]
n2.74 [69.7]
.75 [19.1] 3.27 [83.1]
.25 [6.4] .22 [5.6]
9.20 [233.7]
5.120
CENTER OF
GRAVITY
WEIGHT = 3.25 LBM
