Hozelock EasyClear 3328 User manual

EasyClear
Clearwater, Fountain & Waterfall Pump
INSTALLATION AND OPERATING INSTRUCTIONS. READ INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING
INSTALLATION. KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
3328 UK
The Hozelock Cyprio EasyClear™
Clearwater, Fountain & Waterfall pump
is designed for submersible use in
outdoor ponds. It is an integrated unit
that provides Mechanical & Biological
Filtration with an Ultra Violet Clarifier,
Fountain and Waterfall outlet.
ATTENTION - UV CAUTION
Exposure to Ultra Violet (UV)
radiation can be dangerous and cause
damage to eyes and skin. Under no
circumstances should any attempt be
made to gain access to the lamp
when the unit is switched on. When
switched on, the lamp can be checked
for operation by looking for a bluish
glow from the ball joint outlet (Fig 2-
D).
From 1st January 2005 installing this
product in the garden is classed as
'notifiable' in the revised Building
Regulations for England and Wales.
The Regulations now require you to
tell your local authority building
control department that you intend to
install this product before installation.
Your local authority will let you know
how you can get your installation
approved.
AUTOMATIC CUT-OUT.
To help ensure your EasyClear’s long
life and to prevent damage, it is fitted
with automatic thermal overload
protection on the pump and UVC. This
switches the pump or UVC off if either
overheats. If this occurs, switch off the
power at the mains supply to the unit.
Check for the cause (usually it will be
debris blocking the inlet of the pump
or obstructing the impeller). Remove
the obstruction and wait 15 minutes
for the unit to cool down and
automatically reset. Then switch it on
again.
The UVC lamp will still operate if the
pump automatic thermal overload
protection is activated.
NOTE: YOU MUST SWITCH OFF THE
MAINS SUPPLY BEFORE THE UNIT WILL
RESET.
Pond size
The EasyClear™ can maintain ponds of
up to 4000 litres. However, for best
results, certain conditions may need to
be taken into account. Ponds that are
heavily stocked with fish, or less than
0.5 metres (1’8" feet) deep, or situated
in warm climates or exposed to direct
sunlight for long periods of time will
lead to excessive algae growth and fish
activity. This results in greater demands
on the filtration system. The pond
sizing chart at the end of these
instructions give guidlines on
recommended pond sizes, relating to
these conditions.
Periods of Operation
Keep the filter working 24 hours a day.
Ideally it should run all year round, but
at least throughout the fish feeding
season, ( ie until the water
temperature falls below 10°C and the
fish stop feeding). In winter, operating
the unit will maintain a basic level of
useful bacteria in the Biological Filter
and will help prevent the pond icing
over. However, the unit must not be
allowed to freeze. If you switch the
unit off for winter, wash the unit
thoroughly before resuming filtration
in the spring (see ‘Winter Storage’,
9.0). Never feed your fish when the
unit is not in use.
Maturation
Biological maturation means that the
filter has built up enough nitrifying
bacteria in the Biological Filter to
convert harmful fish waste and other
organic waste (ie Ammonia, Nitrite)
into relatively harmless Nitrate. The
process normally takes 6-8 weeks, but
depends on many factors such as water
temperature, feeding rate and stocking
density.
1.0 IMPORTANT
1.1 WARNING: ALWAYS UNPLUG OR
DISCONNECT ALL APPLIANCES IN THE
POND FROM THE ELECTRICITY
SUPPLY BEFORE PUTTING YOUR
HANDS IN THE WATER WHILST
EQUIPMENT IS BEING INSTALLED,
REPAIRED, MAINTAINED OR
HANDLED.
1.2 Do not use the supply cable to lift the
unit, as this may cause damage. We
recommend fitting a lifting cord to
the hook feature on the base, when
the filter is installed in deep water.
(Fig 2-I).
1.3 Do not operate or leave the unit in
freezing conditions.
1.4 Do not allow the unit to run dry. The
water level should be above the UVC
indicator at the ball joint (Fig 4-L).
1.5 Check that the voltage marked on
the unit corresponds to the mains
supply.
1.6 A 10mA OR 30mA RESIDUAL
CURRENT DEVICE (RCD) MUST BE
FITTED TO THE MAINS SUPPLY.
1.7 DO NOT OPERATE THIS UNIT
WITHOUT THE OUTER CAGE
ATTACHED. USING THE UNIT
WITHOUT THE OUTER CAGE MAY
INVALIDATE YOUR WARRANTY.
1.8 The pump does not use oil or grease
for lubrication and can be used safely
in ponds containing fish or plants.
The motor consists of a sealed stator
and water cooled permanent magnet
rotor. All electrical components are
isolated from the water.
2.0 WARNING: SAFETY AND ELECTRICAL
CONNECTIONS
2.1 The pump is supplied with 10m of 3
core electric cable which is
permanently connected and sealed
to the pump. The supply cable
cannot be replaced. If the cable is
damaged, the unit should be
discarded. This product is designed to
be permanently wired to the mains
supply in a dry weatherproof
enclosure through a Double-Pole
Switched Fused Spur - (Disconnector)
to BS 3676, with a minimum contact
separation of 3mm in each Pole &
Fitted with a 3 or 5 Amp fuse.
The installation must conform to the
national and local wiring regulations
which could include the use of plastic
or metal conduit to protect the cable.
2.2 THIS APPLIANCE MUST BE EARTHED
AND IT IS ESSENTIAL THAT THE
CONNECTIONS ARE MADE USING
THE FOLLOWING CODE;
Brown - Live
Blue - Neutral
Green/Yellow - Earth
TM

2
The BROWN lead should be
connected to the LIVE terminal which
may be marked with an 'L' or
coloured brown or red. The BLUE
lead should be connected to the
NEUTRAL terminal which may be
marked with an 'N' or coloured blue
or black. The GREEN/YELLOW lead
should be connected to the EARTH
terminal which may be marked with
an 'E' or coloured green or
green/yellow.
2.3 If an extension cable is required, this
should be connected to the end of
the unit cable using a weatherproof
connector. The joint must be
positioned in a suitable
weatherproof housing. The extension
cable should be of 3 core 0.75mm2
Polychloroprene rubber insulated
cable (ref: HO5 RN-F) and
permanently wired to the mains
supply with a 3 or 5 Amp fuse.
2.4 The unit cable (and extension cable)
should be positioned and adequately
protected against damage especially
where contact with gardening
equipment (lawn mowers, forks etc.)
children and domestic animals may
occur.
2.5 CONSULT A QUALIFIED ELECTRICIAN
OR LOCAL AUTHORITY IF IN ANY
DOUBT ABOUT WIRING TO THE
MAINS SUPPLY.
2.6 The clear tube inside the unit is made
from quartz glass and care should be
taken during installation and
maintenance. We recommend the
use of eye protection and suitable
gloves.
3.0 ACCESSORY ASSEMBLY
3.1. Bell Fountain (Fig 2).
Locate the Bell Support (E) to the Bell
Main Body (F) and push fully home.
Position the Bell (G) to the Body
Assembly and press into the central
location.
3.2 2 and 3 tier fountain display assembly
(Fig 2-H).
The plastic discs that create the 2 and
3 tier water displays simply snap onto
the fountain stem.
4.0 INSTALLATION
4.1 Place the unit next to the pond and
route the cable back to the mains
supply. Ensure that you allow for
enough cable for positioning the
product in the desired location in the
pond.
Fountain operation. (See Fig 3 for
general installation guide).
4.2 Position - Construct a solid and level
platform on which to place the
EasyClear™. The platform should be
greater than 300 mm (12") below the
water level. For depths between
300mm and 600mm use the fountain
stem extension segments (Fig 11-6),
which simply screw together, to allow
the fountain to be above the water
level. For general installation see Fig
3.
PLEASE NOTE: The product has a water
by-pass to control water flow rates
which means a quantity of water will
always come out of the product just
below the flow control. This is normal in
operation.
4.3 Position the unit in the pond. The 2
and 3 tier fountainheads simply snap
onto the fountain stem (Fig 2). The
fountain angle can be adjusted to be
vertical using the ball joint (Fig 4).
The tightness of the ball joint can be
adjusted (Fig 4-M)
4.4 If required, the 2-Tier Fountainhead
can be used to achieve an alternative
and higher display pattern than the
3-Tier.
4.5 The fountain height can be adjusted
to suit your needs by rotating the
Fountain Flow Adjuster (Fig 5-N).
Rotate the waterfall adjuster to the
‘MIN’ position (Fig 5-P).
4.6 The Bell Fountain creates a
decorative waterbell. The size of the
bell can be adjusted to suit your
needs by rotating the Fountain Flow
Adjuster (Fig 5-N).
Fountain and Waterfall. (See Fig 3 for
general installation guide).
4.7 Position the pump as previously
described.
4.8 Attach a suitable length (3m
maximum) of 25 mm (1”) hose to the
Threaded Hose tail, Fig 5-O), and
secure with a suitable hose clip and
position the outlet end of the hose in
the desired position.
4.9 Screw the Threaded Hose tail onto the
waterfall outlet on the side of the
EasyClear™ (Fig 5-O).
4.10 The combination of waterfall and
fountain will reduce the fountain
height that can be achieved.
4.11 Once the pump is operating the flow
of the waterfall and the height of the
fountain can be independently
adjusted using fountain flowadjuster
(Fig 5-N) and waterfall flow adjuster
(Fig 5-P).
Waterfall Only. (Fig 3 for general
installation guide)
4.12 Screw the blanking plug onto the
fountain outlet (Fig 2-K).
4.13 Position the pump as previously
described.
4.14 Attach a suitable length (3m
maximum) of 25 mm (1”) hose to the
Threaded Hose tail and secure with a
suitable hose clip and position the
outlet end of the hose in the desired
position.
4.15 Screw the Threaded Hose tail to the
waterfall outlet of the EasyClear™ (Fig
5-O) and adjust the flow using the
waterfall flow adjuster, (Fig 5-P), to suit
your needs.
UVC operation
4.16 The UVC will automatically switch
on once the unit has been connected
to the electricity supply.
4.17 The UVC lamp can be checked for
operation by looking for a bluish
glow from ball joint outlet (Fig 2-D).
4.18 See Maintenance section 5.4 for
Lamp replacement.
5.0 MAINTENANCE
The Hozelock Cyprio EasyClear™ has
been designed to allow fast and easy
maintenance. As with all pond
equipment, occasionally it will become
necessary to clean or replace parts. Refer
to section 1 & 2 before attempting any
maintenance.
ALWAYS UNPLUG OR DISCONNECT ALL
APPLIANCES IN THE POND FROM THE
ELECTRICITY SUPPLY BEFORE PUTTING
YOUR HANDS IN THE WATER OR
STARTING MAINTENANCE.
5.1 Fountain Head (Fig 2-J)
a - Place a coin or similar in the slot
and gently lever off the fountain
head.
b - Rinse in clean water and
reassemble.
5.2 Foam
a - Release the Foam Cover by
pushing the two grey buttons (Fig 6-R)
and lift the cover (Fig 7-S).
b - Lift the Foam with the Foam
Support (Fig 8-T). Note :- If the unit is
out of the pond for more then 20
minutes the biological filter action
may stop working.
c - Lift the Foam and stone bags off
the Foam Support, rinse all parts in a
bucket of pond water and
reassemble.
d - The Foam Cover and Base should
also be rinsed.
e - Reassemble the Filter.
5.3 Quartz Tube
a - Remove the bayonet locking
screw (Fig 1-A), twist and lift the
bayonet tube (Fig 1-B).
b - Clean the Quartz Tube. Especially
in hard water areas, the quartz tube
may become covered in limescale,
which will reduce efficiency. Clean
the tube with a soft cloth and a
gentle de-scaler, rinse in water
before refitting.
5.4 Lamp replacement
Change the lamp at the start of the
new season. Even though the lamp
still glows it may not be giving out
any useful UV radiation.
a - How well the EasyClear™
performs is related to the strength of
the UV radiation produced. This will
slowly decline from the day your
lamp is switched on. The UVC lamp
has an effective life of 12 months.
You need to change the lamp when
there is a significant reduction in
water clarity. Make sure this is due to
an expired lamp and not a badly
maintained filter or a dirty/limescaled
quartz sleeve. Both can greatly
reduce UV transmission into the
water.
b - Remove the Bayonet Tube
assembly - ref to section 5.3.
c - Remove the quartz tube, rotating
the plastic moulding anticlockwise
and lifting up and away (Fig 9-U).
d - With the lamp now accessible pull
it out of the holder (Fig 9-V) and
push in a new lamp.
e - Reassemble the filter and switch
back on.
5.5 Biological Filter
Normally, there is no need to remove
the bio-media as any cleaning may
kill the colonies of bacteria that
make toxic waste harmless.
a - Remove the foam – ref to section
5.2.

3
b - Remove the 4 off fixing screws
(Fig 10-X) and lift the base clear.
c - The 12 off pieces of Biomedia (3
off either side of the pump) can be
removed for cleaning. 4 off fit into
the base (Fig 10).
d - Wash in pond water.
e - Reassemble the filter and restart.
5.6 Rotor Assembly
a - Remove the foam – ref to section
5.2.
b - Remove the 4 fixing screws (Fig
10-X) and lift the base & biomedia
clear.
c - Remove the 2 fixing screws (Fig
10-Y) and lift the Pump Assembly
clear.
d - Twist the Pump Chamber anti-
clockwise (Fig 10-Z) and lift clear. The
rotor can now be pulled out for
cleaning or replacement ( Fig 10-AA).
e - Reassemble the pump and 2 off
fixing screws (Fig 10-Y).
f - Reroute the cable(Fig 10-BB).
g - Reassemble the filter, and restart.
6.0 ALL YEAR PUMP CARE
A quick daily check should be carried out
to ensure that the pump is performing
satisfactorily.
Once a week- Remove the outer casing
and Fountain Head in accordance with
the general maintenance notes.
Depending on pond water conditions,
cleaning may be required more
frequently.
Once a year- Completely disassemble the
unit including the Rotor Assembly as
described in the general maintenance
notes, refer to sections 5.1 - 5.6, and
wash all components in clean,
freshwater. Replace worn or broken
parts.
7.0 SPARE PARTS (refer to Fig 11).
Contact the Consumer Services Helpline
on 0870 850 1959.
8.0 HOZELOCK CYPRIO 2 YEAR
GUARANTEE
If this unit, excluding the Rotor
Assembly, Filter Foam & UV Lamp
becomes unserviceable within 2 years of
the date of purchase it will be repaired
or replaced at our option free of charge,
unless in our opinion it has been
damaged or misused. Liability is not
accepted for damage due to accident,
improper installation or use.
Liability is limited to replacement of a
faulty unit. This guarantee is not
transferable. It does not affect your
statutory rights.
To obtain the benefits of the guarantee,
firstly contact Hozelock Cyprio Consumer
Services who may request that the filter
is sent along with proof of purchase
directly to the address provided.
DAMAGE CAUSED BY RUNNING THE
FILTER DRY OR BY FROST INVALIDATES
THE GUARANTEE.
9.0 WINTER STORAGE
When not in use, the unit should be
removed, thoroughly washed and
cleaned, dried and stored in a dry frost
protected area. Always store the unit
with the foam and foam cover off to
ensure adequate ventilation and drying.
Refer to maturation section when
restarting the unit.
10.0 - FISH STOCKING RATE AND
DENSITY
Under normal conditions, the
EasyClear™ will support up to 144cm of
fish. Introduce fish slowly over the first
few weeks, up to 20% of the maximum
recommended level, increasing to 50%
after six months. The balance will allow
for fish growth.
Hozelock Cyprio
Midpoint Park, Birmingham B76 1AB.
England.
Telephone: [phone]
www.hozelock.com
The Aquatics division of Hozelock Group
Item Numbers
1. Foam. 1407
2. UV Lamp. 1520
3. Quartz Tube. 1529
4. Pump chamber & O-Ring. Z13249
5. Pump rotor. 3439
6. Fountain and extension Z31785
segment bagged set.
7. Foam cover. Z13228
8. Foam support. Z13230
FAULT FINDING.
WARNING: ALWAYS UNPLUG OR DISCONNECT ALL APPLIANCES IN THE POND FROM THE
ELECTRICITY SUPPLY BEFORE PUTTING YOUR HANDS IN THE WATER WHILST EQUIPMENT
IS BEING INSTALLED, REPAIRED, MAINTAINED OR HANDLED.
LOW FLOW FROM PUMP a - Ensure the outer cage is clean.
b - Clear any blockages and adjust the flow
controls.
c - Check recoil flap inside pump chamber
moves freely.
POOR FOUNTAIN DISPLAY a - Clean the Fountain Head. (see
maintenance section 5.1)
UV LAMP NOT WORKING a - Check power supply is on.
b - Check fuse and wiring
c - Replace the lamp – refer to section 5.4
PUMP NOT WORKING a - Check power supply is on.
b - Check fuse and wiring.
c - The pump may have over heated as a
result of the rotor getting jammed.
d - Check the rotor assembly – refer to
section 5.6.
e - The AUTOMATIC CUT-OUT may have
operated – see ATTENTION section.
f - Ensure the outer cage is clean.
POND SIZING CHART
Use this chart to ensure that your EasyClear™ is operating in the correct conditions to
guarantee clearwater. Pond depth, location and climate will affect how big a pond
can be.
1.6m
Hmax - 1.6m
POND SIZING CHART
Litres ( Gallons)
Location and Depth Fish type Mild Climate Warm Climate Hot Climate
Shade Goldfish 56” 4000 (880) 3600 (800) 3200 (700)
More than 0.5m deep Goldfish 28” 5000 (1100) 4500 (990) 4000 (880)
Goldfish 0” 6000 (1320) 5400 (1190) 4800 (1060)
Shade Goldfish 56” 3600 (800) 1600 (700) 1400 (600)
Less than 0.5m deep Goldfish 28” 4500 (990) 2000 (880) 1750 (770)
Goldfish 0” 5400 (1190) 2400 (1060) 2100 (920)
Sunlight Goldfish 56” 3600 (800) 1600 (700) 1400 (600)
More than 0.5m deep Goldfish 28” 4500 (990) 2000 (880) 1750 (770)
Goldfish 0” 5400 (1190) 2400 (1060) 2100 (920)
Sunlight Goldfish 56” 3200 (700) 2800 (600) 1200 (250)
Less than 0.5m deep Goldfish 28” 4000 (880) 3500 (770) 1500 (320)
Goldfish 0” 4800 (1060) 4200 (920) 1800 (400)
Mild climate - eg. Northern Europe. Warm climate - eg. Southern Europe. Hot climate - eg.
South Africa

4
Fig. 1
Fig. 2 Fig. 3
Fig. 4
Fig. 5
A
B
C
J
E
D
K
H
F
G
I
L
M
P
O
Q
N

5
Fig. 9
Fig. 7
Fig. 6
Fig. 8
R
S
T
U
V

Fig. 10
6
X
X
X
Y
Y
Z
AA
BB
BB

7
Fig. 11
6
3
2
1
5
8
7
4

Hozelock Cyprio
Midpoint Park, Birmingham B76 1AB. England.
Tel: [phone]
www.hozelock.com
The Aquatics Division of Hozelock Group
33650-002
PLEASE
NOTE:
Do not
dispose of in
household
waste
