Technical Reference Manual
HP 9000 B Class Workstations
April 96 Edition
Hewlett–Packard Company
3404 East Harmony Road, Fort Collins, CO 80525

Hewlett–Packard Preliminary and Confidential
    
______________________________________________________________________________
Notices
Information in this document is subject to change without notice.
Hewlett–Packard makes no warranty of any kind about this manual, including, but not limited to, the
implied warranties of merchantablility and fitness for a particular purpose. Hewlett–Packard shall not
beliableforerrorscontainedhereinordirect,indirect,special,incidentalorconsequentialdamagesabout
the furnishing, performance, or use of this material.
Warranty. PleasecarefullyreadtheenclosedHewlett–PackardSoftwareProductLicenseAgreementand
Limited Warranty before operating this product. Rights in the software are offered only on the condition
that the customer accepts all terms and conditions of the License Agreement.
Operating the product indicates your acceptance of these terms and conditions. If you do not agree to
the License Agreement, you may return the unused product for a full refund.
Acopy ofthe specificwarranty termsapplicable toyour Hewlett–Packardproduct andreplacement parts
can be obtained from your local Sales and Service Office.
Copyright Hewlett–Packard Company 1996
This document contains information that is protected by copyright. All rights are reserved.
Reproduction, adaptation, or translation without prior written permission is prohibited, except as
allowed under the copyright laws.
Restricted Right Legend
Use, duplication, or disclosure by the U.S. Government Department of Defense is subject to
restrictions as set forth in paragraph (b)(3)(ii) of the Rights in Technical Data and Software clause in
FAR 52.227–7013.
Copyright EAT & T, Inc. 1980, 1984
Copyright EThe Regents of the University of California 1979, 1980, 1983
This software and documentation is based in part on the Fourth Berkeley Software Distribution under
licence from the Regents of the University of California.

Hewlett–Packard Preliminary and Confidential

   
Printing History
New Editions of this manual incorporate all material updated since the previous edition. Update
packages may be issued between editions and contain replacement and additional pages to be merged
into the manual by the user.
The manual printing date and part number indicate its current edition. The printing date changes
when a new edition is printed. (Minor corrections and updates which are incorporated at reprint do
not cause the date to change.) The manual part number changes when extensive technical changes are
incorporated.
April 1996 ... Edition 1
Electrostatic Discharge (ESD) Precautions
Electrostatic charges can damage the integrated circuits on printed circuit boards. To prevent such
damage from occurring, observe the following precautions when unpacking and installing the board.
•Stand on a static–free mat.
•Wear a static strap to ensure that any accumulated electrostatic charge discharges from your body
to ground.
•Connect all equipment together, including the static–free mat, static straps, routing nodes, and
peripheral units.
•Keep uninstalled printed circuit boards in their protective antistatic bags.
•Once you have removed the printed circuit boards from their protective antistatic bags, handle
them by their edges.

Hewlett–Packard Preliminary and Confidential
    

For:root
Printed on:Wed, Sep 4, 1996 12:48:44
From book:MerlinTechRef
Document:chap_1
Last saved on:Thu, Apr 25, 1996 09:11:20

Hewlett–Packard Preliminary and Confidential

B Class Technical Reference General Information
1
General Information
This chapter describes the general features and gives an overview of the B Class workstation.
Features
Hewlett–Packard’s Model B132L/B160L Workstations are based on a PA7300 central processing unit
(CPU) that provides a variety of interfaces, graphics, and mass storage.
The following table lists the features of the Model B132L/B160L workstations.
Table 1–1. Features
Features Functionality
Operating system HP–UX 10.2
CPU Frequency
Performance
PA–RISC PA7300
Performance information may be obtained from HP Sales
(NOTE: Performance figures are OS and compiler version re-
lated.)
External Cache
Size
Bus Width
Speed
1MB (Two 512KB DIMMs)
128 bits with 16 bit for error detection and correction
83 MHz
Time source Battery–backed Real–Time Clock
Memory
Memory Management Unit
Virtual memory address
Instruction TLB and
data TLB
6 slots
32MB minimum required
Upgradeable to 384 MB
48 bit
Unified 120 page entries, additional single–entry instruction
TLB lookaside, 16block entries, fully associative
(continued)

Hewlett–Packard Preliminary and Confidential
1-2   
General Information
Table1–1. Features (Continued)
Optional Graphics HP VISUALIZE 24Z or 24–plane graphics
HP VISUALIZE–8/24Z Accelerated 8–plane or 24–plane 3D
graphics
HP VISUALIZE–48Z 24/24 image planes, 8 overlay planes,
24–bit Z buffer 3D graphics
Graphics Performance Performance information may be obtained from HP Sales
(NOTE: Performance figures are OS and compiler version re-
lated.)
200–Watt Power supply Four DC output voltages (+12V, +5V, –12V, and +3.3V)
Mass storage Up to two of the following:
3.5–inch, 4GB, low–profile, SE SCSI hard disk drive
3.5–inch, 2GB, low–profile, SE SCSI hard disk drive
3.5–inch, 1GB, low–profile, SE SCSI hard disk drive
3.5–inch, 4GB, low–profile, FW SCSI hard disk drive
3.5–inch, 2GB, low–profile, FW SCSI hard disk drive
Network IEEE 802.3 AUI connection
Supports connections to 10BASE2 (ThinNet), 10BASE5 (Thick-
Net), and 10BASE–T (EtherTwist) networks with the use of an
external transceiver.
I/O Two 9–pin Serial ports
One 25–pin HP parallel port
8–bit Single–Ended SCSI interface
16–bit Fast Wide SCSI interface (optional)
2 PS/2 ports for Keyboard and Mouse
CD–quality audio and speaker output
CD–quality microphone or audio input

Hewlett–Packard Preliminary and Confidential
1-3
B Class Technical Reference General Information
Memory
Standard memory is 32 MB of 60 ns 4 Mbit or 16 Mbit DRAMs. 32 MB is the minimum required for
the HP–UX operating system. Each workstation has 8 memory slots, labeled 0A, 0B through 2A, 2B.
There are several possible memory configurations:all 32 MB to 96 MB installed in pairs of
16 MB SIMM cards; or, 128 MB to 384 MB installed in pairs of 64 MB SIMM cards. The SIMM
pairs may be mixed for memory sizes between 32MB and 384MB, in all configurations memory
SIMMS must be installed in pairs of equal size.
Memory upgrades include:
HP A3026A 32 MB DRAM Upgrade, two 16 MB DRAM boards.
HP A3027A 128 MB DRAM Upgrade, two 64 MB DRAM boards.
Internal Storage Devices
The B132L/B160L workstation can have up to two fixed disk drives, one removable media drive
(DDS–tape or CD–ROM), and a floppy drive.
Fixed Disk drives
3.5–inch, 4GB, low–profile, single ended SCSI hard disk drive
3.5–inch, 2GB, low–profile, single ended SCSI hard disk drive
3.5–inch, 1GB, low–profile, single ended SCSI hard disk drive
3.5–inch, 4GB, low–profile, fast, wide differential SCSI hard disk drive
3.5–inch, 2GB, low–profile, fast, wide differential SCSI hard disk drive
Removable Media drives
The B Class workstation supports the following types of removable media devices:
CD–ROM drive
HP A4325A CD–ROM dive(4X speed)
DDS Tape drive
3.5–inch, DDS1 tape drive
3.5–inch, DDS2 tape drive
HP92283A Box of five 60–meter DDS data cassettes
HP92283B Box of five 90–meter DDS data cassettes
HP92283K Package of two cleaning cassettes
Floppy Disk drive
HP A4283A 96mm, slimline 1.44MB floppy drive
HP92192X High–Density Micro Flexible Disks (1.44MB Formatted Capacity) – box of ten diskettes

Hewlett–Packard Preliminary and Confidential
1-4   
General Information
System Graphics
The B132L/B160L workstation comes with built–in 8–bit color and high resolution graphics. The
supported monitors are:
A4330A 17–inch, multimode, 1280x1024 color monitor
A4331A 20–inch, multimode, 1280x1024 color monitor
AxxxxA 21–inch, multimode, 1600x1200 color monitor
The supported graphics boards are:
•HP VISUALIZE 24Z or 24–plane graphics
•HP VISUALIZE–8/24Z Accelerated 8–plane or 24–plane 3D graphics
•HP VISUALIZE–48Z 24/24 image planes, 8 overlay planes, 24–bit Z buffer 3D graphics

Hewlett–Packard Preliminary and Confidential
1-5
B Class Technical Reference General Information
System Unit Interfaces
The system board’s built–in interfaces have ports on the workstation rear panel and front panel, as
shown in Figures 1–1 and 1–2. Chapter 5 lists the pinouts of these external connectors.
Power Switch
Power LED
System Leds
Mic
Headset
Volume
Mute
Figure 1–1. System Front Panel Connectors

Hewlett–Packard Preliminary and Confidential
1-6   
General Information
Parallel
Built–in Video
PS/2 Keyboard
PS/2 Mouse
LAN–TP
LAN AUI
Serial
Power Cord
Optional FW SCSI
SE SCSI
Figure 1–2. System Rear Panel Connectors

Hewlett–Packard Preliminary and Confidential
1-7
B Class Technical Reference General Information
Audio Interfaces
The Model B132L/B160L workstation has audio input and output capability through external input
and output connectors on the rear panel, Headphones (headphone–out) and Microphone
(Microphone–in) connectors on the front panel plus a built–in speaker. The rear panel contains the
Line–IN (Stereo line–in) and Mic , and Audio OUT (Stereo line–out) and Headphones connectors.
Additional controls for audio include a MUTE button and a VOLUME CONTROL knob located on
the front panel.
The audio connectors are standard audio mini–jacks. Hewlett–Packard recommends using
gold–plated plugs available through audio retailers for best quality recording and playback through
the external connectors. The following is a summary of the workstation audio features:
•Audio Features Programmable sample rates:
8kHz, 16kHz, 32kHz, 48kHz, 11.025kHz, 22.05kHz, and 44.1kHz.
Programmable output attenuation:
0 to –96dB in –1.5dB steps
Programmable input gain:
0 to 22.5dB in 1.5dB steps.
Input monitoring:
16–bit linear, 8–bit u–law, or A–law coding
•Audio Inputs Line–in Mono microphone with 1.5V phantom supply
CD–ROM audio (if internal CD–ROM is installed)
•Audio Outputs Line–out
Headphone
Mono speaker jacks
Built–in mono speaker
•Audio CODEC Crystal CS4215
The audio electrical specifications for this workstation are summarized in Table 1–2.

Hewlett–Packard Preliminary and Confidential
1-8   
General Information
Table 1–2. Audio Electrical Specifications
Frequency Response 25–20,000Hz
Input Sensitivity/Impedance
Line in 2.0Vpk/47kohm
Line Out 2.8Vpp/47kohm
Headphone 2.75Vpp/50ohm
Speaker (internal) 5.88Vpp/48ohm
Speaker (external jack) 4.2Vpp/8ohm
Max Output Level/Impedance
Output Impedence
Line Out
Headphone
Speaker
Line in
Microphone
Speaker (external jack)
Line Out
Headphone
Speaker
Line in
Microphone
Line Out
Headphone
619ohm
118ohm
11ohm
Signal to Noise* 65dB
61dB
63dB
61dB
57dB
THD (w nominal load) –73dB
–70dB
–68dB
–75dB
–73dB
* To convert from dB to number of significant bits use the formula:
n = dB
20 log10
dB
6.
For example, for 61dB S/N then n= 61/6
significant bits, or in other words, about 6 bits of noise.
10


Microphone 22mVpk/1kohm
PS/2 Keyboard and Mouse Interfaces
The PS/2 connectors provide an interface for the PS/2 style keyboard and mouse to the system.
HP Parallel I/O Interface
The 25–pin HP Parallel I/O interface uses Centronics interface protocols to support peripheral
devices such as printers and plotters. Consult the documentation that accompanies each peripheral
device for specific information concerning its use.

Hewlett–Packard Preliminary and Confidential
1-9
B Class Technical Reference General Information
Network Interface
The Model B132L/B160L has built–in ThickNet LAN AUI and TP (Twisted Pair) connectors for the
802.3 (ETHERNET) network. Connections to ThinLAN networks require an external transceiver.
Your workstation will autoselect the correct network setting.
The IEEE 802.3 Ethernet Local Area Network (LAN) circuit provides both the AUI interface for
conventional coaxial Ethernet and a direct interface to a twisted pair (TP) 10BASE–T network. Only
one interface can be used at a time, the system auto–selects the correct port that is being used.
Ethernet is a 10 Mbit/s packet–switched serial interface employing Carrier Sense Multiple
Access/Collision Detection (CSMA/CD). Table 1–3 lists the supported LAN adapters and other
network devices.
Table 1–3. Supported AUI LAN Adapters and Devices
LAN Adaptor Network Devices
HP 28641B ThinLAN Transceiver
HP 30241A 10Base4 ThickLAN MAU
HP 28692A ThinLAN Hub Plus
HP 28673A 10:10 LAN Bridge
HP 28683A Fiber Optic Transceiver
Serial I/O Interfaces
The Serial I/O (SIO) ports on the B132L/B160L accept a variety of pointing devices or peripheral
devices. Peripheral devices include printers, plotters, modems, and scanners. Consult the
documentation that accompanies each peripheral device for specific information concerning its use.
The SIO ports are programmable, allowing the setting of such functions as bit rate, character length,
parity, and stop bits. SIO Ports are used as interfaces for serial asynchronous devices to the CPU. The
ports operate at up to a 460.8 K baud rate.
Chapter 5 lists the SIO connector pin listings. The serial connectors are 9–pin D–sub connectors.
Signal names are those specified in the EIA RS–232 standard.

Hewlett–Packard Preliminary and Confidential
1-10   
General Information
Small Computer Systems (SCSI) Interface
Use the SCSI connectors to connect external SCSI devices such as DDS–format tape drives and
CD–ROM drives. Consult the documentation that accompanies each SCSI device for specific
information concerning its use. Refer to Appendix C of the B Class Owner’s Guide for information
about connecting SCSI devices to the workstation.
Single–Ended (SE) SCSI
The built–in SE SCSI port is implemented using an NCR710 macrocell inside the I/O ASIC chip.
This 8–bit single ended implementation is compatible with the current 700 series products and
supports 5 MB/sec data transfer rates.
The SE SCSI bus is terminated to 3.3 volts through 127kΩresistors on the CPU board. Terminators
must be removed or disabled from internal devices. If an external device is used an active terminator
must be used on the drive at the end of the SE SCSI chain.
The external SE SCSI connector must always have a terminator when no external devices are
connected.
Fast Wide (FW) SCSI (Optional)
Fast Wide SCSI is an extension to the existing 8–bit, single–ended SCSI. “Fast” indicates that
signals on the SCSI bus are differentially driven and terminated and capable of a 10 MHz clock rate.
“Wide” indicates that there are 16 data bits on the SCSI bus.
The FW SCSI bus is terminated to 3.3 volts through 127kΩresistors on the FW SCSI controller
board. Terminators must be removed or disabled from internal devices. If an external device is used
an active terminator must be used on the drive at the end of the FW SCSI chain.
The external FW SCSI connector must always have a terminator when no external devices are
connected.
The Fast Wide SCSI bus is specified at a peak synchronous transfer rate of 20 MB/sec. The
architecture of the Fast Wide SCSI port on the workstation has been designed to allow a 20 MB/sec
sustained transfer rate for long data streams.
Power Cord Connector
Plug the workstation’s power cord into the power cord connector to provide ac power to the system.

Hewlett–Packard Preliminary and Confidential

B Class Technical Reference General Information
Hardware Architecture
The Model B132L/B160L is a desktop or desk–side system designed to be easy to operate and
upgrade. The features in this package are designed for user access to the majority of system
upgradeable parts (disks, memory SIMMs, and processors) by removing the main tray.
Figure 1–3 shows the front view of the system. There is a Power LED that indicates that the system
is on when lit and LEDs that inform the user of the system’s status. In case of failure the status LEDs
indicate a failure code.
Power LED System Status Leds
Figure 1–3. System Status LEDs

Hewlett–Packard Preliminary and Confidential
1-12   
General Information
Operating System
HP–UX
HP–UX 10.2 is supported on the Model B132L/B160L workstations. HP–UX is booted from an
internal hard disk drive factory installed with Instant Ignition. HP–UX can also be installed from
external DDS or CD–ROM drives. If the workstation is a client on a LAN, HP–UX can be booted
over the LAN. Table 1–4 lists the HP–UX operating systems and languages for the workstation.
Table 1–4. HP–UX Operating Systems and Languages
Operating systems: HP–UX 10.2
HP–UX 10.2 complies with IEEE POSIX 1993.1 and
1003.1 FIPS 151–2 ANS X3.159–1989, System V Inter-
face Definition (SVID) Issue III (Base System and all Ex-
tensions, with exceptions), X/Open Portability Guide Issue
IV (XPG4) (Base Branding), and OSF/Motif 1.2.
HP–UX 10.2 also complies with IS 9945/1 and Base Com-
ponent and all Optional Components except XTI only.
X Window System Version 11 Release 5 (X11R5), OSF/Motif 1.2
Languages C/ANSI C, C++
FORTRAN 9000
Pascal
PA–RISC 1.1 Assembler
COBOL
User Interface and Graphics Libraries HP VUE 3.0
X11R5, PEX, PHIGS
Starbase capabilities
HP PowerShade
Product Identification
On the back of the B132L/B160L workstation, a pullout card lists the product’s serial number. The
information can be interpreted as shown below for an example serial number 6247A00001:
6247 A 00001 5–digit sequential identifying number.
Country of Manufacture Code:
A = U.S.A.
J = Japan
G = Germany
Introduction Date Code:
First 2 digits + 60 = last 2 digits of year.
Last 2 digits = number of week in year.
Figure 1–4. Product Serial Number Label Interpretation

Hewlett–Packard Preliminary and Confidential
1-13
B Class Technical Reference General Information
Board Exchange Part Numbers
A4190–66513 CPU Module, 132MHz
A4190–66516 CPU Module, 160MHz
A4200–66540 512MB Cache
A2759–69001 32MB DIMM
A2580–69001 64MB DIMM
A4072–69512 HCRX Z–Accelerator Board
A4070–69504 HCRX–8
A4071–69507 HCRX–24
A4081–69009 Color Graphics Card
Board Nonexchange Part Numbers
A4190–60501 Optional Fast Wide SCSI PCA
A4190–66500 PCI Backplane
A4452–66501 SGRAM Daughter Card
Support Documentation
Tables 1–5, and 1–6 list the service and support documentation.
Table 1–5. Service Documentation
Manual Title Part Number
Model B132L/B160L Service Handbook
HP A4032/A4033 Color Monitors CE Handbook A4190–90039 A4033–90099
Table 1–6. System Installation and Getting Started Documentation
Manual Title Part Number
Model B132L/B160L Owner’s Guide
Model B132L/B160L Hardware Installation Guide
Installing the B132L/B160L CPU Upgrade
SCSI Tech Data
HP–UX Device Driver Manual
SCSI Tech Reference Manual
A4190–90014
A4190–90010
A4190–90012
5951–7100
98577–9014
98265–90010

For:root
Printed on:Wed, Sep 4, 1996 12:48:49
From book:MerlinTechRef
Document:chap_2
Last saved on:Thu, Apr 25, 1996 09:11:51
