HP Compaq d240 MT Manual

System Unit
1 Front bezel (1 carbonite and 1 silver) with diskette
drive bezel. (See Miscellaneous plastics kit for con-
tents) for d240 model
337555-001
2 Front bezel (cmbined carbonite and silver) with dis-
kette drive bezel. (See Miscellaneous plastics kit for
contents) for d248 model
354696-001
4 Access panel (left or right side) (See Miscellaneous
plastics kit for contents) could be 1 of 2 kits
5 Chassis not spared
3 Power supply, PFC 351071-001
*Power supply, non-PFC 351070-001
* Not shown
Mass Storage Devices
1 Diskette drive, 3.5-inch with mounting screws 347233-001
240-GB\5400 RPM hard drive 335176-001
*40-GB\7200 RPM hard drive 335392-001
*80-GB\5400 RPM hard drive 335177-001
*80-GB\7200 RPM hard drive 337027-001
348X CD-ROM drive 335389-001
* CD RW drive, 48X/24X 335391-001
* 16X DVD drive 335390-001
* 48X/24X/48X+16X CD-RW/DVD-ROM drive 336783-001
*Not shown
Cables
1 Diskette drive cable 335190-001
2 Hard drive cable, primary ATA (2 devices) 335188-001
* Optical drive cable, secondary ATA (2 devices) 335189-001
3 Audio cable 335191-001
* Front USB cable 351073-001
*Not shown
Keyboards (not illustrated)
Keyboard, PS2 335192-xxx
Brazil -201 Latin American Spanish -161
French Canadian -121 Peoples Republic of China -AA1
International -B31 Taiwanese -AB1
Japanese -291 Thai -281
Korean -AD1 U.S. -001
Standard and Optional Boards
Memory modules
1 128 MB PC3200 335697-001
* 256 MB PC3200 335698-001
* 512 MB PC3200 335699-001
* 1 GB PC3200 335700-001
Intel Processors with alcohol pad and thermal grease
2 Celeron 2.5 GHz processor 344056-001
* Celeron 2.6 GHz processor 344057-001
* Pentium 2.6 GHz processor 333863-001
* Pentium 2.8 GHz processor 333864-001
* Pentium 3.0 GHz processor 333865-001
* Pentium 3.2 GHz processor 335813-001
3 Front I/O PCA with cable 342725-001
System board with alcohol pad and thermal grease
4 System board without AGP socket 351067-001
Other boards
* Lucent 56K PCI Win modem 239411-001
* Not shown
Miscellaneous Parts
Front bezel kit, (1 carbonite and 1 silver) for d240 model,
includes: 337555-001
1 Front bezel (also ships in solid silver
5 5.25” drive bezel with metal shield
6 Diskette drive bezel
7 3.5” drive bezel blank with metal shield
* Side access panel
* Thumb screw for side access panel
Front bezel kit as described above except only front bezel
#3 (carbonite and silver) for d248 model 354696-001
2 Chassis fan 351068-001
4 Heatsink with alcohol pad and thermal grease 351072-001
8 Power switch/LED with switch mounting bracket 342724-001
* Mouse, PS2, scroll type 335181-001
* Battery, real-time clock 153099-001
* Internal speaker with mounting pins 345979-001
Miscellaneous screw kit, includes: 337552-001
*#6-32 x .025 lg pan head (262508-001) (6 ea)
*#6-32 x .187 lg hi top (262508-003) (6 ea)
* M3 x 5mm lg pan head (263585-001) (8 ea)
* M3 x 6.5mm lg pan head (263585-002) (8 ea)
* Drive Key, 128 MB 349988-001
* Drive Key, 256 MB 344249-001
*Not shown
© 2003 Hewlett-Packard Development Company, L.P.
HP and the HP logo are trademarks of Hewlett-Packard
Development Company, L.P.
Intel and Celeron are US registered trademarks of Intel
Corporation. All other product names mentioned herein
may be trademarks of their respective companies.
HP shall not be liable for technical or editorial errors or
omissions contained herein. The information in this
document is provided “as is” without warranty of any kind
and is subject to change without notice. The warranties for
HP products are set forth in the express limited warranty
statements accompanying such products. Nothing herein
should be construed as constituting an additional
warranty.
December 2003
Document Part Number 349336-001
HP Compaq Business Desktop
d240/d248 Microtower Models
Illustrated Parts Map
Celeron and Pentium Processors

System Board Connectors and Jumpers (position of some untitled components may vary in location)
BAT1 RTC Battery J28 DIMM Socket 4
J11 CD IN header J29 Chassis intrusion header
J12 System fan header J30 ATX Power connector
J13 AUX line in header J31 Secondray IDE connector
J14 + 12 V Connector J33 Primary IDE connector
J15 PCI connector 3 J34 Diskette drive connector
J16 PCI connector 2 J35 Front panel header
J17 PCI connector 1 J36 CPU fan
J21 Front USB header J38 Mono out connector
J22 Chassis fan header JP1* BIOS configuration
J23 DIMM Socket 1 JP2* FWH lock
J24 DIMM Socket 2 JP3* CMOS clear
J25 DIMM Socket 3 U16 CPU socket
*See table below
JP1 BIOS Configuration JP2 FWH Lock JP3 CMOS Clear
Status Jumper Setting Notes Status Jumper Setting Notes Status Jumper
Setting Notes
Normal 1-2 Default Lock 1-2 Normal 1-2 Default
Safe 2-3 Configure Unlock 2-3 Default Clear 2-3
Fan Sensor 3
System Hardware Interrupts
IRQ System Function IRQ System Function
0Timer Interrupt 8 Real-Time Clock
1Keyboard 9 Unused
2Interrupt Controller Cascade 10 Unused, available for PCI
3Serial Port (COM B) 11 Unused, available for PCI
4Serial Port (COM A) 12 Mouse
5Unused, available for PCI 13 Coprocessor
6Diskette Drive 14 Primary ATA (IDE) Controller
7Parallel Port (LPT 1) 15 Secondary ATA (IDE) Controller
Establishing a Password
1. Turn on or restart the computer. If you are in Windows, click Start > Shut Down >
Restart the computer.
2. When the F10 Setup message appears in the lower-right corner of the screen, press the F10 key. Press Enter to
bypass the title screen, if necessary. If you do not press F10 when prompted, a restart will be necessary.
3. Select Password Option, then select Change Supervisor Password and follow the instructions on the screen. You
may also want to establish the Password check at this time. This will allow you to specify when the password will
be required.
4. Before exiting, click Save Settings and Exit.
Changing a Password
1. Turn on or restart the computer. If you are in Windows, click Start > Shut Down > Restart the Computer. To change
the setup password, run Computer Setup.
2. When the key icon appears, type your current password, a slash (/) or alternate de-limiter character, your new
password, another slash (/) or alternate delimiter character, and your new password again as shown:
current password/new password/new password.
NOTE: Type the new password carefully since the actual characters do not appear on the screen.
3. Press the enter key.
4. The new password will take effect the next time the computer is restarted.
Deleting a Password
1. Turn on or restart the computer. If you are in Windows, click Start > Shut Down > Restart the Computer. To delete
the setup password, run Computer Setup (F10).
2. When the key icon appears, type your current password followed by a slash (/) or alternate delimiter character as
shown. Example: currentpassword/
3. Press the Enter key.
Clearing CMOS
The computer's configuration (CMOS) may occasionally be corrupted. If it is, it is necessary to clear the CMOS
memory using by performing the following procedure:
ÄCAUTION: The power cord must be disconnected from the power source before changing the jumper
setting. (NOTE: All LEDs on the board should be OFF). Failure to do so may damage the system board
1. Turn off the computer and any external devices, then disconnect the power cord from the power outlet.
2. Remove the access panel.
3. Locate the JP3 CMOS jumper and move the jumper from pins 1-2 to pins 2-3. Keep the jumper there for 5 seconds.
4. Replace the jumper on pins 1-2.
5. Replace the access panel.
6. Connect the power cord to the power outlet.
7. Turn on the computer, allow it to start. Run the Computer Setup Utility to reconfigure the system.
NOTE: Clearing CMOS clears all passwords.
Diagnostic LEDs
LED Color LED Activity State/Message
Power Green On (S0) Computer on
Power Green 1 blink every 2 seconds (S1) Normal Suspend Mode
Power Green 1 blink every 2 seconds (S3) Suspend to RAM
Power Clear Off (S4) Suspend to Disk (if applicable)
Power Clear Off (S5) Computer off
Power Red/Green Red when flashing ROM;
Green 1 blink every second
when user can restart
Boot block recovery w/Embedded Video
Power Red 1 blink every second for 2
seconds CPU thermal shutdown
Power Red 1 blink every second for 5
seconds, then 2 second pause.
5 beeps.
No memory installed
Power Red 1 blink every second for 6 sec-
onds, then 2 second pause.
6 beeps.
Graphics card error
Power Red 1 blink every second for 7
seconds, then 2 second pause.
7 beeps.
System board failure
Hard Drive Green Blinking Hard drive activity
Computer Setup (F10) Utility Features (not all features may be available)
System
Information
Product Name
System Chipset Type
BIOS Version
BIOS Release Date
Processor Type
Processor Speed
CPU ID
L1 Cache Size
L2 Cache Size
Memory Bank 0
Memory Bank 1
Total Memory
FSB Speed
Ratio Status
Rastio CMOS Setting
DDR Frequency
MAC Address
Standard
CMOS Setup
Set Time
System Date
Set Floppy
Auto Detect Primary IDE Master drive
Auto Detect Primary IDE Slave drive
Auto Detect Secondary IDE Master drive
Auto Detect Secondary IDE Slave drive
Advanced
CMOS Setup
Boot Device Priority
POST Delay Time (in seconds)
System Keyboard
APIC ACPI SCI IRQ
Hyper-Threading Technology
Internal Graphics Mode Select
Power
Management
Setup
ACPI Standby State
Restore on AC/Power Loss
Resume on Ring
Resume on PME
Peripheral
Setup
OnBoard LAN
OnBoard LAN Chip Boot ROM
Init. Graphics Adapter Priority
USB Controller
USB 1.1 Device Legacy Support
OnBoard Serial Port
OnBoard Parallel Port
Hardware
Monitor
CPU Warning Temperature
CPU Shutdown Temperature
System Warning Temperature
System Shutdown Temperature
CPU Temperature
System Temperature
CPU FAN Speed
Chassis FAN Speed
CPU VID
Vccp
+1.5V
+2.5V
+3.3V
+5.0V
+12.0V
HVcc (+3.3VSB)
Password
Option Change Supervisor Password
Password Status Password Check
Load Default
Settings
Save Settings
and Exit
Exit Without
Saving
Note: See Computer Setup (F10) Utility Guide on the Documentation Library CD.
