HP Compaq Presario Manual

3-4 Volume One
Presario 500
System Boards Assembly Spare Part System
System Board w/o Processor,
4 MB 003831-101 177067-001 CDS520, CDTV520
System Board w/o Processor,
4 MB (Outside NA) 004126-101 004205-101 177066-001 DISCONTINUED CDS520, CDTV520
System Board w/o Processor,
4 MB 004663-102 210262-001 CDS522, 524, 526, CDTV528
System Board w/o Modem &
Processor, 4 MB (INT’L) 004664-102 004205-102 210263-001 DISCONTINUED CDS522, 524, 526, CDTV528
Jumper Settings (Assembly 003831, 004126, 004205, 004663, 004664)
Jumper Function Pins Function
P1 Speed Select 1,2 Select processor speed (25 or 50 MHz)
2,3 Select processor speed (33 or 66 MHz)
P2 SX Processor Select 1,2 486 SX Installed
2,3 Other than 486SX installed
P5 CMOS Erase Remove and replace jumper P5 to clear
CMOS and Password
J11 Replacement
Battery Connector Use only 4.5v Alkaline computer battery.
Memory SIMMs Spare Part System
4 MB Memory Module 160033-001 All
8 MB Memory Module 160034-001 All
16 MB Memory Module 177122-001
DISCONTINUED All
32 MB Memory Module 177123-001
DISCONTINUED All
Microprocessors Spare Part System
486DX2/50 Processor 194394-001 Option
486SX2/66 Processor 189388-001
DISCONTINUED CDS520, CDTV 520, 522
486DX2/66 Processor 171752-001
DISCONTINUED CDS524, 526, CDTV528
486SX/331164563-001 CDS510
1Outside U.S.
Miscellaneous Assembly Spare Part System
Monitor Assembly, NA (P)
Monitor Assembly, NA (S) 171866-001 171866-001 177018-001 177018-101* All All
Monitor Assembly, NH (P)
Monitor Assembly, NH (S) 171866-002 171866-002 177018-002 177018-102* All All
Monitor Assembly, SH (P)
Monitor Assembly, SH (S) 171866-003 171866-003 177018-003 177018-103* All All
Speaker 171851-001 177070-001
DISCONTINUED All
Backplane 004215-001 177014-001
DISCONTINUED All
TV Tuner Controller Board
(U.S.) 171095-001 171090-001 All
TV Tuner Controller Board
(Europe) 004846-002 214765-001 DISCONTINUED All
* Outside U.S.

Volume One 3-5
Presario 500
Hard Drive Type Cable Select* Spare Part System
270 MB 65/66 171011-001 CDS520,
CDTV520
270 MB Yes 172778-001 CDS522, 524,
526, CDTV528
420 MB 65 172193-001 CDS520,
CDTV520
420 MB Yes 172780-001 CDS522, 524,
526, CDTV528
540 MB 188666-001 CDS522, 524,
526, CDTV528
* “Hard Drive Select”cable required.
CD-ROM Drives Assembly Spare Part System
CD-ROM, IDE 172159-001
DISCONTINUED CDS520, 524*,
CDTV520
CD-ROM, IDE, 4 Speed 172854-
001 172864-001 DISCONTINUED CDS522, 524**, 526,
CDTV528
* Configuration Code HQQ2. ** Configuration Code HQS2.
Diskette Drives Spare Part System
1.44 MB (Three-mode) 160788-201 All
2400/9600-Baud
Modem, D/F/TAM Assembly Spare Part Cable Spare Part System
Australia 165231-011 165220-011 165224-011 All
Austria 165232-041 165220-341 165224-341 All
Belgium 165232-181 165220-181 165224-181 All
Denmark 165232-081 165220-081 165224-081 All
France 165232-051 165220-051 135716-001 All
Germany 165232-041 165220-041 165224-041 All
Italy 165232-061 165220-061 165224-061 All
Japan, Korea,
Singapore,
Thailand
165231-192 165220-192 165224-001 All
Netherlands 165232-331 165220-331 165224-331 All
New Zealand 165231-361 165220-361 165221-001 All
Sweden 165232-101 165220-101 165224-101 All
Switzerland 165232-111 165220-111 165224-111 All
United Kingdom 165231-031 165220-031 165221-001 All
14.4K bps Modem, D/F/TAM Assembly Spare Part System
U.S. 003993-001 176501-001 486 Models
U.S. 003993-002 176501-002 586 Models
Cables Spare Part System
TV Audio Cable 177131-001 All
TV VGA Cable 177132-001
DISCONTINUED All
TV Cable Adapter 171615-001 All
Diskette Data/Power Cables 177071-001 All
CD ROM Power, Data, Audio Cables 177073-001
DISCONTINUED All
Hard Drive Select/CD ROM Cables 177073-001
DISCONTINUED All

3-6 Volume One
Presario 500
System/Video ROM
Revision Number on ROM Location Spare Part System
177032-001 XU23 177185-001
DISCONTINUED All
101394 177032-011 XU23 177185-001
DISCONTINUED All
122894 177032-012 XU23 177185-001
DISCONTINUED All
System Modem ROM
Number on ROM Location Spare Part System
177033-005 XU24 176508-001 All
Power Supply/Battery Spare Part System
Real-Time Clock Battery 4.5 Volts, 600 mA 160274-001 All

Volume One 3-7
Presario 500
Memory Upgrade Chart
PROCESSOR BOARD
4 MB MEMORY
(003831, 004126, 004205, 004663, 004664)
4-MB MEMORY MODULE (70ns) OPTION PN 147522-001
8-MB MEMORY MODULE (70ns) OPTION PN 147523-001
16-MB MEMORY MODULE (70ns) OPTION PN 147524-001
32-MB MEMORY MODULE (70ns) OPTION PN 147525-001
ADD ANY OF THE FOLLOWING
UP TO 64-MB TOTAL SYSTEM MEMORY
