HP dx2040 - Microtower PC Operating and maintenance manual

Hardware Reference Guide - dx2040
Microtower Model
HP Compaq Business PC

© Copyright 2009 Hewlett-Packard
Development Company, L.P. The
information contained herein is subject to
change without notice.
Microsoft, Windows, and Windows Vista are
either trademarks or registered trademarks
of Microsoft Corporation in the United States
and/or other countries.
The only warranties for HP products and
services are set forth in the express warranty
statements accompanying such products
and services. Nothing herein should be
construed as constituting an additional
warranty. HP shall not be liable for technical
or editorial errors or omissions contained
herein.
This document contains proprietary
information that is protected by copyright. No
part of this document may be photocopied,
reproduced, or translated to another
language without the prior written consent of
Hewlett-Packard Company.
Hardware Reference Guide
HP Compaq Business PC
dx2040 Microtower Model
First Edition (April 2009)
Document Part Number: 534578-001

About This Book
This guide provides basic information for upgrading this computer model.
WARNING! Text set off in this manner indicates that failure to follow directions could result in bodily
harm or loss of life.
CAUTION: Text set off in this manner indicates that failure to follow directions could result in damage
to equipment or loss of information.
NOTE: Text set off in this manner provides important supplemental information.
ENWW iii

iv About This Book ENWW

Table of contents
1 Product Features
Standard Configuration Features ......................................................................................................... 1
Front Panel Components ..................................................................................................................... 2
Media Card Reader Components ......................................................................................................... 3
Rear Panel Components ...................................................................................................................... 4
Keyboard .............................................................................................................................................. 5
Using the Windows Logo Key .............................................................................................. 6
Serial Number Location ........................................................................................................................ 7
2 Hardware Upgrades
Warnings and Cautions ........................................................................................................................ 8
Removing the Computer Access Panel ................................................................................................ 9
Removing the Front Bezel .................................................................................................................. 10
Removing a 5.25" Drive Bezel Blank ................................................................................................. 11
Removing a 3.5" Drive Bezel Blank ................................................................................................... 12
System Board Device Connections .................................................................................................... 13
Installing Additional Memory .............................................................................................................. 14
DIMMs ............................................................................................................................... 14
DDR2-SDRAM DIMMs ...................................................................................................... 14
Installing DIMMs ................................................................................................................ 15
Installing an Expansion Card .............................................................................................................. 17
Replacing or Upgrading a Drive ......................................................................................................... 20
Locating Drive Positions .................................................................................................... 20
Removing a 5.25" Optical Drive ......................................................................................... 21
Removing a 3.5" Media Card Reader or Diskette Drive .................................................... 22
Removing a 3.5" Hard Drive .............................................................................................. 23
Appendix A Specifications
Appendix B Battery Replacement
Appendix C External Security Devices
Installing a Security Lock .................................................................................................................... 29
ENWW v

Cable Lock ......................................................................................................................... 29
Padlock .............................................................................................................................. 30
Appendix D Electrostatic Discharge
Preventing Electrostatic Damage ....................................................................................................... 31
Grounding Methods ............................................................................................................................ 31
Appendix E Computer Operating Guidelines, Routine Care and Shipping Preparation
Computer Operating Guidelines and Routine Care ............................................................................ 32
Optical Drive Precautions ................................................................................................................... 33
Operation ........................................................................................................................... 33
Cleaning ............................................................................................................................. 33
Safety ................................................................................................................................. 33
Shipping Preparation .......................................................................................................................... 33
Index ................................................................................................................................................................... 34
vi ENWW

1 Product Features
Standard Configuration Features
The HP Compaq Microtower features may vary depending on the model. For a complete listing of the
hardware and software installed in the computer, run the diagnostic utility (included on some computer
models only). Instructions for using the utility are provided in the Troubleshooting Guide.
Figure 1-1 Microtower Configuration
ENWW Standard Configuration Features 1

Front Panel Components
Drive configuration may vary by model.
Figure 1-2 Front Panel Components
Table 1-1 Front Panel Components
15.25-inch Optical Drives
1
6Microphone Connector
2Optical Drive Activity Lights 7Optical Drive Eject Buttons
33.5-inch Media Card Reader (optional)
2
8Power On Light
4Dual-State Power Button 9Headphone Connector
5 Hard Drive Activity Light 10 USB (Universal Serial Bus) 2.0 Ports
1Some models have bezel blanks covering one or both of the 5.25-inch drive bays.
2Some models have a bezel blank covering the 3.5-inch drive bay. An optional diskette drive is available from HP for this drive
bay.
2 Chapter 1 Product Features ENWW

Media Card Reader Components
The media card reader is an optional device available on some models only. Refer to the following
illustration and table to identify the media card reader components.
Figure 1-3 Media Card Reader Components
Table 1-2 Media Card Reader Components
No. Slot Media
1xD ●xD-Picture Card (xD)
2MicroSD ●MicroSD (T-Flash) ●MicroSDHC
3Media Card Reader
Activity Light
4SD/MMC+/miniSD ●Secure Digital (SD)
●Secure Digital High
Capacity (SDHC)
●MiniSD
●MiniSDHC
●MultiMediaCard
(MMC)
●Reduced Size
MultiMediaCard (RS
MMC)
●MultiMediaCard 4.0
(MMC Plus)
●Reduced Size
MultiMediaCard 4.0
(MMC Mobile)
●MMC Micro (adapter
required)
5USB ●USB (Universal Serial
Bus) Port
6CompactFlash I/II ●CompactFlash Card
Type 1
●CompactFlash Card
Type 2
●MicroDrive
7MS PRO/MS PRO DUO ●Memory Stick (MS)
●MagicGate Memory
Stick (MG)
●MagicGate Memory
Duo
●Memory Stick Select
●Memory Stick Duo
(MS Duo)
●Memory Stick PRO
(MS PRO)
●Memory Stick PRO
Duo (MS PRO Duo)
●Memory Stick PRO-
HG Duo
●Memory Stick Micro
(M2) (adapter
required)
ENWW Media Card Reader Components 3

Rear Panel Components
Figure 1-4 Rear Panel Components
Table 1-3 Rear Panel Components
1Power Cord Connector 8Line-Out Connector for powered audio
devices (green)
2Voltage Select Switch 9Line-In Audio Connector (blue)
3PS/2 Keyboard Connector (purple) 10 PS/2 Mouse Connector (green)
4Serial Port (teal) 11 Parallel Port (purple)
5VGA Monitor Connector (blue) 12 RJ-45 Network Connector
6Universal Serial Bus (USB) 13 Optional Serial Port (teal)
7Microphone Connector (pink)
NOTE: Arrangement and number of connectors may vary by model.
The monitor connector on the system board is inactive when a PCI Express x16 graphics card is installed
in the computer.
If a PCI or PCI Express x1 graphics card is installed, the connectors on the card and the system board
may be used at the same time. Some settings may need to be changed in Computer Setup to use both
connectors. For information about setting the boot VGA controller, refer to the Computer Setup (F10)
Utility Guide.
The Line-In, Line-Out, and Microphone audio connectors on the rear panel can be reconfigured to
perform different audio functions using the Realtek Audio Manager. To access the Realtek Audio
Manager, click the Realtek Audio icon on the Windows taskbar, then select the Speaker Configuration
tab to reconfigure the audio connectors.
The following table describes the audio configuration options available in the Realtek Audio Manager.
4 Chapter 1 Product Features ENWW

Audio Connector Color Configuration Option 1 Configuration Option 2 Configuration Option 3
blue Line In Rear Speaker Out Rear Speaker Out
green Front Speaker Out Front Speaker Out Front Speaker Out
pink Microphone In Microphone In Center/Subwoofer
Speaker Out
Keyboard
Figure 1-5 Keyboard Components
Table 1-4 Keyboard Components
1Function Keys Perform special functions depending on the software application being used.
2Editing Keys Includes the following: Insert, Home, Page Up, Delete, End, and Page Down.
3Status Lights Indicate the status of the computer and keyboard settings (Num Lock, Caps Lock,
and Scroll Lock).
4Numeric Keys Work like a calculator keypad.
5Arrow Keys Used to navigate through a document or Web site. These keys allow you to move
left, right, up, and down, using the keyboard instead of the mouse.
6Ctrl Keys Used in combination with another key; their effect depends on the application
software you are using.
7Application Key Used (like the right mouse button) to open pop-up menus in a Microsoft Office
application. May perform other functions in other software applications.
8Windows Logo Keys
1
Used to open the Start menu in Microsoft Windows. Used in combination with other
keys to perform other functions.
9 Alt Keys Used in combination with another key; their effect depends on the application
software you are using.
1Keys available in select geographic regions.
ENWW Keyboard 5

Using the Windows Logo Key
Use the Windows Logo key in combination with other keys to perform certain functions available in the
Windows operating system. Refer to Keyboard on page 5to identify the Windows Logo key.
Table 1-5 Windows Logo Key Functions
The following Windows Logo Key functions are available in Microsoft Windows XP and Microsoft Windows Vista.
Windows Logo Key
Displays or hides the Start menu
Windows Logo Key + dDisplays the Desktop
Windows Logo Key + mMinimizes all open applications
Shift + Windows Logo Key + mUndoes Minimize All
Windows Logo Key + eLaunches My Computer
Windows Logo Key + fLaunches Find Document
Windows Logo Key + Ctrl + fLaunches Find Computer
Windows Logo Key + F1 Launches Windows Help
Windows Logo Key + lLocks the computer if you are connected to a network domain, or
allows you to switch users if you are not connected to a network
domain
Windows Logo Key + rLaunches the Run dialog box
Windows Logo Key + uLaunches the Utility Manager
Windows Logo Key + Pause/Break Launches the System Properties dialog box
Windows Logo Key + Tab Cycles through the Taskbar buttons (Windows XP)
Cycles through programs on the Taskbar using the Windows Flip
3-D (Windows Vista)
In addition to the Windows Logo Key functions described above, the following functions are also available in Microsoft
Windows Vista.
Ctrl + Windows Logo Key + Tab Use the arrow keys to cycle through programs on the Taskbar by
using Windows Flip 3-D
Windows Logo Key + Spacebar Bring all gadgets to the front and select Windows Sidebar
Windows Logo Key + gCycle through Sidebar gadgets
Windows Logo Key + uLaunches Ease of Access Center
Windows Logo Key + any number key Launches the Quick Launch shortcut that is in the position that
corresponds to the number (for example, Windows Logo Key + 1
launches the first shortcut in the Quick Launch menu)
6 Chapter 1 Product Features ENWW

Serial Number Location
Each computer has a unique serial number and product ID number that are located on the top cover of
the computer. Keep these numbers available for use when contacting customer service for assistance.
Figure 1-6 Serial Number and Product ID Location
ENWW Serial Number Location 7

2 Hardware Upgrades
Warnings and Cautions
Before performing upgrades be sure to carefully read all of the applicable instructions, cautions, and
warnings in this guide.
WARNING! To reduce the risk of personal injury from electrical shock, hot surfaces, or fire:
Disconnect the power cord from the wall outlet and allow the internal system components to cool before
touching.
Do not plug telecommunications or telephone connectors into the network interface controller (NIC)
receptacles.
Do not disable the power cord grounding plug. The grounding plug is an important safety feature.
Plug the power cord in a grounded (earthed) outlet that is easily accessible at all times.
To reduce the risk of serious injury, read the Safety & Comfort Guide. It describes proper workstation,
setup, posture, and health and work habits for computer users, and provides important electrical and
mechanical safety information. This guide is located on the Web at http://www.hp.com/ergo.
WARNING! Energized and moving parts inside.
Disconnect power to the equipment before removing the enclosure.
Replace and secure the enclosure before re-energizing the equipment.
CAUTION: Static electricity can damage the electrical components of the computer or optional
equipment. Before beginning these procedures, ensure that you are discharged of static electricity by
briefly touching a grounded metal object. See Appendix D, Electrostatic Discharge on page 31 for
more information.
When the computer is plugged into an AC power source, voltage is always applied to the system board.
You must disconnect the power cord from the power source before opening the computer to prevent
damage to internal components.
8 Chapter 2 Hardware Upgrades ENWW

Removing the Computer Access Panel
1. Remove/disengage any security devices that prohibit opening the computer.
2. Remove all removable media, such as diskettes or compact discs, from the computer.
3. Turn off the computer properly through the operating system, then turn off any external devices.
4. Disconnect the power cord from the power outlet and disconnect any external devices.
CAUTION: Regardless of the power-on state, voltage is always present on the system board as
long as the system is plugged into an active AC outlet. You must disconnect the power cord to
avoid damage to the internal components of the computer.
5. Remove the two screws (1) that secure the access panel to the computer chassis.
6. Slide the access panel back (2) about 1.3 cm (1/2 inch), then lift it off the unit.
NOTE: You may want to lay the computer on its side to install internal parts. Be sure the side
with the access panel is facing up.
Figure 2-1 Removing the Computer Access Panel
NOTE: To replace the access panel. reverse the removal procedure.
ENWW Removing the Computer Access Panel 9

Removing the Front Bezel
1. Remove/disengage any security devices that prohibit opening the computer.
2. Remove all removable media, such as diskettes or compact discs, from the computer.
3. Turn off the computer properly through the operating system, then turn off any external devices.
4. Disconnect the power cord from the power outlet and disconnect any external devices.
CAUTION: Regardless of the power-on state, voltage is always present on the system board as
long as the system is plugged into an active AC outlet. You must disconnect the power cord to
avoid damage to the internal components of the computer.
5. Remove the computer access panel.
6. To remove the front bezel, pull outward on all three tabs on the left side of the bezel (1) then rotate
the bezel off the chassis (2), beginning with the left side then the right side.
Figure 2-2 Removing the Front Bezel
NOTE: To replace the front bezel, insert the three hooks on the right side of the bezel into the
rectangular holes on the chassis then rotate the bezel into place so that the catches on the three tabs
on the left side of the bezel snap into place on the chassis.
10 Chapter 2 Hardware Upgrades ENWW

Removing a 5.25" Drive Bezel Blank
If the computer was not shipped with a drive in the 5.25" option bay, the bay will be covered by a bezel
blank. If you add a drive to the option bay, you must first remove the bezel blank.
1. Remove/disengage any security devices that prohibit opening the computer.
2. Remove all removable media, such as diskettes or compact discs, from the computer.
3. Turn off the computer properly through the operating system, then turn off any external devices.
4. Disconnect the power cord from the power outlet and the computer, and disconnect any external
devices.
CAUTION: Regardless of the power-on state, voltage is always present on the system board as
long as the system is plugged into an active AC outlet. You must disconnect the power cord to
avoid damage to the internal components of the computer.
5. Remove the access panel and front bezel.
6. While facing the inside of the front bezel, press the two retaining tabs on the right towards the outer
edge of the bezel (1) and pull the bezel blank inwards to remove it (2).
Figure 2-3 Removing a 5.25" Bezel Blank
NOTE: To install a 5.25" bezel blank, slide the left side of the blank into the two retainer slots on the
left side of the front bezel then snap the right side of the blank into place.
ENWW Removing a 5.25" Drive Bezel Blank 11

Removing a 3.5" Drive Bezel Blank
If the computer was not shipped with a device in the 3.5" bay, the bay will be covered by a bezel blank.
If you install a device in the 3.5" bay, you must first remove the bezel blank.
1. Remove/disengage any security devices that prohibit opening the computer.
2. Remove all removable media, such as diskettes or compact discs, from the computer.
3. Turn off the computer properly through the operating system, then turn off any external devices.
4. Disconnect the power cord from the power outlet and the computer, and disconnect any external
devices.
CAUTION: Regardless of the power-on state, voltage is always present on the system board as
long as the system is plugged into an active AC outlet. You must disconnect the power cord to
avoid damage to the internal components of the computer.
5. Remove the access panel and front bezel.
6. While facing the inside of the front bezel, press outward on the two retaining tabs on each side of
the bezel blank (1) and pull the bezel blank inwards to remove it (2).
Figure 2-4 Removing a 3.5" Bezel Blank
NOTE: To install a 3.5" bezel blank, press the blank inward from inside the front bezel so that it snaps
into place.
12 Chapter 2 Hardware Upgrades ENWW

System Board Device Connections
Follow the guidelines in the illustration and table below when connecting devices to the system board.
Figure 2-5 System Board Device Connections
Table 2-1 System Board Device Connections
No. System Board Connector System Board Label Color
1PCI Express x16 PCIex16 white
2PCI Express x1 PCIex1 black
3PCI PCI white
4Media Card Reader MEDIA black
5Primary Memory (DIMM) DIMM1 white
6Secondary Memory (DIMM) DIMM2 black
7Diskette Drive FLPY black
8Optical Drive or Secondary Hard
Drive
SATA1 white
9 Primary Hard Drive SATA0 dark blue
ENWW System Board Device Connections 13

Installing Additional Memory
The computer comes with double data rate 2 synchronous dynamic random access memory (DDR2-
SDRAM) dual inline memory modules (DIMMs).
DIMMs
The memory sockets on the system board can be populated with up to two industry-standard DIMMs.
These memory sockets are populated with at least one preinstalled DIMM. The sockets are labeled
DIMM1 and DIMM2. To achieve the maximum memory support, you can populate the system board
with up to 4GB (2 x 2GB) of memory.
DDR2-SDRAM DIMMs
For proper system operation, the DDR2-SDRAM DIMMs must be:
●industry-standard 240-pin
●unbuffered PC2-5300 667 MHz-compliant
●1.8 volt DDR2-SDRAM DIMMs
The DDR2-SDRAM DIMMs must also:
●support CAS latency 4 (CL = 4) for PC2-5300 667 MHz-compliant
●contain the mandatory JEDEC SPD information
In addition, the computer supports:
●256Mbit, 512Mbit, and 1Gbit non-ECC memory technologies
●single-sided and double-sided DIMMs
●DIMMs constructed with x8 and x16 DDR devices; DIMMs constructed with x4 SDRAM are not
supported
NOTE: The system will not start if you install unsupported DIMMs.
14 Chapter 2 Hardware Upgrades ENWW
