hp pavilion home pc
warranty and
support guide
what’s inside:
where to get help
warranty and license
information
declaration of
conformity
operating specifications
regulatory and safety
information
Before contacting HP Customer Support
Center, it’s important to have the following
information handy. Please take a moment
to write down your product information for
future reference.
Product Name: ____________________________________
Model Name: _____________________________________
System or
Product #: ________________________________________
Serial #: __________________________________________
Purchase Date: ____________________________________
Operating
System: ___________________________________________
Type &
Revision: __________________________________________

2
Where to Get Help
Follow these steps when you need help from HP:
1 Check the setup poster and the User’s Guide for help
with setting up and using your PC.
2 For faster help, be sure to register your HP Pavilion
home PC on the Web at
www.hp.com/apac/register
3 Use Help on your PC to get help with your hardware
and software. Click Start and then click Help and
Support.
4 For help online, go to the HP Customer Care Center
Web site at
http://www.hp.com/support
for technical information or to get software updates.
5 If you have not solved the problem, call the HP Customer
Care Center at the appropriate number below.
Australia: 1300 721 147
New Zealand: 0 800 441 147
Mon.–Fri. 10–9, Sat.–Sun. 10–4 (local time)
India: 1-600-114772
Mon.–Sat. 9–9
Hours are subject to change without notice.
HP Support Web site:
http://www.hp.com/support
HP Registration Web site:
http://www.hp.com/apac/register
Software Support
If you have questions about your software or ISP (Internet
Service Provider), call or visit your software or ISP vendor’s
Web site. The appropriate number or Web address is listed
below. Some of these Web addresses may be listed in the
Favorites list found in your Internet Explorer browser. Phone
and e-mail support may not exist if no information is given.
For software not listed, the HP Customer Care Center
provides 30-day limited support. All software titles, below,
may not be included with your PC.
OzEmail (Australia)
132 884
[email protected]
www.ozemail.com.au/info/frameset_techsupport.html
Xtra (New Zealand)
0800 22 55 98
[email protected]
www.xtra.co.nz
Acrobat Reader by Adobe
www.pacific.adobe.com/support/main.html
Britannica 2003 Deluxe (India only)
www.britannica.com
GameChannel by WildTangent
(Australia/New Zealand only)
[email protected]
www.wildtangent.com
InterVideo
http://www.intervideo.com/home
MusicMatch Jukebox
[email protected]
www.musicmatch.com/form/support/tech
Norton AntiVirus 2004 by Symantec
www.symantec.com/region/reg_ap/servsupp.html
Norton Personal Firewall by Symantec
www.symantec.com/region/reg_ap/servsupp.html
RecordNow! by Sonic
(with CD-RW or DVD+RW/+R option only)
support.sonic.com/default.htm
Simple Backup for My Pictures by Sonic
www.sonic.com/products/
simplebackup/default.asp

3
Warranty and License Information
To Our Valued Customer
Congratulations on your decision to purchase an HP Pavilion
home PC! During development, the HP Pavilion must pass
extensive quality tests to meet the rigorous standards that
have made HP famous for quality and reliability.
All HP Pavilions go through a comprehensive quality test to
ensure the PC is working correctly before it leaves our
factory. In addition, we have placed a security seal on your
PC to indicate that it has not been tampered with since it left
our factory.
We know that expanding and upgrading are key benefits
for all customers. We are proud to make this a key
differentiator for our HP Pavilion and understand that you
may wish to upgrade your PC to meet your specific needs.
Any hardware upgrades that you intend to do should only
be done after you have completely set up your new
HP Pavilion. Refer to the setup poster included with your
system for help with setting up. If you have any problems
setting up your system and turning it on, immediately contact
the HP Customer Care Center listed earlier in this Warranty
and Support Guide, and an HP Customer Representative will
assist you. This must be done first before attempting to
upgrade your system.
By breaking the security seal on the back of the HP Pavilion,
you are confirming that the HP Pavilion was working
properly before you attempted to upgrade your system.
Once the security seal has been broken, your HP Pavilion is
then, to the extent allowed by local law, covered under the
terms and conditions listed in the following pages.
Thank you for choosing the HP Pavilion. We hope you enjoy
discovering the exciting things you can do with it!
HP Customer Care
Easy to reach. Easy to use. Award-winning HP Customer
Care is our promise to help you get the most from your
HP Pavilion. Whether with tools located on your PC, from
information on the Web, by phone, or through your local
retailer, you’ll find what you need.
Problems? HP Will Help
Your new HP Pavilion computer is built to work right now —
and for many years to come. But it is a complex, powerful
machine, and sometimes things go wrong. If that happens to
your computer, Hewlett-Packard is ready to help.
Getting Started
Follow the setup poster and the User’s Guide for help with
setting up and using your PC.
Register Your PC
It is always best to register your PC. This allows for quicker
help when you need it. You can register your PC on the
Web at http://register.hp.com
See What You Can Do
There’s lots of helpful information included with your
HP Pavilion. First look at Help on your Windows®desktop
(to access it, click Start on the taskbar). It contains more
detailed help and will give you suggestions on how to fix
the problem.
Within the Help and Support Center, you can get the latest
news from HP about your PC. Be sure to also check the
updates from HP that are sent to your desktop from time
to time.
Next, try a little surfing! The HP Web site has updated
software, tips and tricks, answers for common problems,
and other information. Go to the Support Web site listed
earlier in this document and search for your HP Pavilion
model.
Call HP Customer Care Center
Finally, if these steps don’t help, you can reach a real,
knowledgeable person by calling the HP Customer Care
Center in your area. Phone assistance to get you up and
running is free for 30 days from the time you purchased
your computer. After 30 days, there may be a charge, but
the helpful support is still available.
And, if Necessary: Get Repair
If your computer needs to be repaired or to have parts
replaced, you have two choices.
1 You can easily replace many of your HP Pavilion parts
that are considered consumer replaceable. This is the
fastest method of repair, as many times we can send the
part directly to your home or business in a few days.
2 If a repair is necessary, the HP Customer Care Center will
make arrangements to fix your computer.
These services are free during the warranty period.
There are a few limitations and exclusions to this warranty
(as well as some important details), which are described in
the following section.

4
The Legal Language
Hewlett-Packard Limited Warranty
Statement
HP PRODUCT DURATION OF LIMITED WARRANTY
Hardware — Parts and Labor: 1 Year
Phone assistance to get you up-and-running: 30 days
HP warrants to you, the end-user customer, that HP
hardware, accessories, and supplies will be free from
defects in materials and workmanship after the date of
purchase, for the period specified above. If HP receives
notice of such defects during the warranty period, HP will, at
its option, either repair or replace products which prove to
be defective. Replacement products may be either new or
equivalent in performance to new.
HP warrants to you that HP software will not fail to execute
its programming instructions after the date of purchase, for
the period specified above, due to defects in material and
workmanship when properly installed and used. If HP
receives notice of such defects during the warranty period,
HP will replace software which does not execute its
programming instructions due to such defects.
HP does not warrant that the operation of HP products will
be uninterrupted or error free. If HP is unable, within a
reasonable time, to repair or replace any product to a
condition as warranted, you will be entitled to a refund of
the purchase price on a prorated basis upon prompt return
of the product.
HP products may contain remanufactured parts equivalent to
new in performance or may have been subject to
incidental use.
Warranty does not apply to defects resulting from
(a) improper or inadequate maintenance or calibration,
(b) software, interfacing, parts, or supplies not supplied by
HP, (c) unauthorized modification or misuse, (d) computer
viruses of any origin, (e) operation outside of the published
environmental specifications for the product, (f) improper site
preparation or maintenance, or (g) unplanned acts of
nature, such as floods, tornadoes, lightning strikes,
hurricanes, or earthquakes. TO THE EXTENT ALLOWED BY
LOCAL LAW, THE ABOVE WARRANTIES ARE EXCLUSIVE
AND NO OTHER WARRANTY OR CONDITION, WHETHER
WRITTEN OR ORAL, IS EXPRESSED OR IMPLIED AND HP
SPECIFICALLY DISCLAIMS ANY IMPLIED WARRANTIES OR
CONDITIONS OF MERCHANTABILITY, SATISFACTORY
QUALITY, AND FITNESS FOR A PARTICULAR PURPOSE.
Some countries/regions, states, or provinces do not allow
limitations on the duration of an implied warranty, so the
above limitation or exclusion might not apply to you. This
warranty gives you specific legal rights and you might also
have other rights that vary from country/region to
country/region, state to state, or province to province.
HP’s limited warranty is valid in any country/region or
locality where HP has a support presence for this product
and where HP has marketed this product. The level of
warranty service you receive may vary according to local
standards. HP will not alter form, fit, or function of the
product to make it operate in a country/region for which it
was never intended to function for legal or regulatory
reasons.
TO THE EXTENT ALLOWED BY LOCAL LAW, THE REMEDIES
IN THIS WARRANTY STATEMENT ARE YOUR SOLE AND
EXCLUSIVE REMEDIES. EXCEPT AS INDICATED ABOVE, IN
NO EVENT WILL HP OR ITS SUPPLIERS BE LIABLE FOR
LOSS OF DATA OR FOR DIRECT, SPECIAL, INCIDENTAL,
CONSEQUENTIAL (INCLUDING LOST PROFIT OR DATA),
OR OTHER DAMAGE, WHETHER BASED IN CONTRACT,
TORT, OR OTHERWISE. Some countries/regions, states, or
provinces do not allow the exclusion or limitation of
incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
THE WARRANTY TERMS CONTAINED IN THIS STATEMENT,
EXCEPT TO THE EXTENT LAWFULLY PERMITTED, DO NOT
EXCLUDE, RESTRICT, OR MODIFY AND ARE IN ADDITION
TO THE MANDATORY STATUTORY RIGHTS APPLICABLE TO
THE SALE OF THIS PRODUCT TO YOU.
Network Interface Cards
HP warrants the operation on a network interface card
(NIC), only if factory preinstalled by HP, as follows: HP will
make sure the correct drivers are installed; HP will make
sure that the HP Pavilion recognizes the NIC. NO
CONNECTIVITY ISSUES ARE SUPPORTED.
DVD Country/Region Codes
DVD players utilize country/region codes to limit playing
DVDs designed for that country/region. You may change the
country/region setting of a DVD player only five times. After
changing this setting five times, the setting becomes
permanent and cannot be changed.
Software Media (CDs)
The software CDs that come with your system are warranted
to be free from defects for one year. Any claims for missing
CDs need to be made within 30 days. Any claims for
defective CDs may require the exchange of the CDs.
Customer Responsibilities
You may be required to run HP-supplied diagnostic
programs before an in-home visit will be scheduled or a
replacement part will be dispatched.

5
You are responsible for the security of your proprietary and
confidential information and for maintaining a procedure
external to the products for reconstruction of lost or altered
files, data, or programs. You should back up all data on
your system before calling the HP Customer Care Center.
For In-home service, you must provide: Access to the
product; adequate working space and facilities within a
reasonable distance of the product; access to and use of all
information and facilities determined necessary by HP to
service the product; and operating supplies and
consumables such as you would use during normal
operation.
When service is being performed in-home, you or your
representative, 18 years of age or older, must be present at
all times. You must state if the product is being used in an
environment which poses a potential health hazard to repair
personnel; HP may require that the product be maintained
by customer personnel under direct HP supervision. HP may
also refuse to provide In-home service in special
circumstances and will provide an alternative repair method
such as Carry-in repair.
Obtaining Hardware Warranty Repair
Service
For the duration of the one-year parts and labor warranty,
repair service includes Customer-replaceable Parts services,
Carry-in services, and In-home services as described below.
To obtain hardware warranty service, call the HP Customer
Care Center. You must be prepared to supply the
proof-of-purchase date.
The time it takes to repair your computer will vary based
upon location and circumstances. The phone agent can
supply more details.
Customer-Replaceable Parts Services
Customer-replaceable components — such as the keyboard,
mouse, speakers, and monitor — may be serviced through
expedited part shipment. In this event, HP will send you the
component and, if necessary, telephone assistance on
replacement of the component. In some cases, HP will ask
for a credit card as collateral for the part (such as monitors)
and will charge you for the retail price of the part if the
failed product is not returned within 30 days.
Carry-In Services
Hardware service during the one-year warranty period is
provided by bringing or mailing your PC to an HP Pavilion
authorized service provider. The HP Customer Care Center
can provide you with details on the location nearest you.
In-Home Services
In-home service is available for certain products sold and
serviced within Australia, India, and New Zealand only. The
HP Customer Care Center can give you more information.
HP Software Product License Agreement
ATTENTION: USE OF THE SOFTWARE IS SUBJECT TO THE
HP SOFTWARE LICENSE TERMS SET FORTH BELOW;
USING THE SOFTWARE INDICATES YOUR ACCEPTANCE
OF THESE LICENSE TERMS. IF YOU DO NOT ACCEPT
THESE LICENSE TERMS, YOU MAY RETURN THE
SOFTWARE FOR A FULL REFUND. IF THE SOFTWARE IS
BUNDLED WITH ANOTHER PRODUCT, YOU MAY RETURN
THE ENTIRE UNUSED PRODUCT FOR A FULL REFUND.
The HP Software Product License Agreement will govern all
Software which is provided to you with the exception of
Microsoft®Software. Microsoft Products are licensed to you
under the Microsoft End User License Agreement (EULA)
contained in the Microsoft documentation online.
The following License Terms govern your use of the
accompanying Software unless you have a separate signed
agreement with HP.
License
GRANT — HP grants you a license to use one copy of the
Software. “Use” means storing, loading, installing,
executing, or displaying the Software. You may not modify
the Software or disable any licensing or control features of
the Software. If the Software is licensed for “concurrent use,”
you may not allow more than the maximum number of
authorized users to Use the Software concurrently.
OWNERSHIP — The Software is owned and copyrighted by
HP, its subsidiaries, or its third-party suppliers. Your license
confers no title to, or ownership in, the Software and is not a
sale of any rights in the Software. HP’s third-party suppliers
may protect their rights in the event of any violation of these
License Terms.
Copies
ADAPTATIONS — You may only make copies or
adaptations of the Software for archival purposes or when
copying or adaptation is an essential step in the authorized
Use of the Software. You must reproduce all copyright
notices in the original Software on all copies or adaptations.
You may not copy the Software onto any public network.

6
If your computer was shipped with a Recovery CD, (i) the
Recovery CD and/or Support Utility software may be used
only for restoring the hard disk of the HP computer system
with which the Recovery CD originally was provided, and
(ii) if separate EULA(s) are included with your computer for
any other Microsoft products which are included on the
Recovery CD, those Microsoft products are subject to the
terms of their respective EULA(s).
No Disassembly
DECRYPTION — You may not disassemble or decompile the
Software unless HP’s prior written consent is obtained. In
some jurisdictions, HP’s consent may not be required for
limited disassembly or decompilation. Upon request, you
will provide HP with reasonably detailed information
regarding any disassembly or decompilation. You may not
decrypt the Software unless decryption is a necessary part
of the operation of the Software.
TRANSFER — Your license will automatically terminate upon
any transfer of the Software. Upon transfer, you must deliver
the Software, including any copies and related
documentation, to the transferee. The transferee must accept
these License Terms as a condition to the transfer.
TERMINATION — HP may terminate your license upon
notice for failure to comply with any of these License Terms.
Upon termination, you must immediately destroy the
Software, together with all copies, adaptations, and merged
portions in any form.
EXPORT REQUIREMENTS — You may not export or re-
export the Software or any copy or adaptation in violation
of any applicable laws or regulations.
(REV. 090502)
Declaration of Conformity
According to ISO/IEC Guide 22 and EN 45014
Manufacturer’s
Name:
Hewlett-Packard Company
Manufacturer’s
Address:
10500 Ridgeview Ct.
Cupertino, CA 95015-4010
USA
declares that the product
Product Name: HP Pavilion Multimedia Personal
Computer System
Model Number(s): 100 series, 300 series, 400
series, 500 series, 600 series,
700 series, a000 series, t000
series, and m000 series
Product Options: All
conforms to the following Product Specifications:
Safety: IEC 60950:1991 + A1, A2, A3, A4
EN 60950:1992 + A1, A2, A3, A4, A11
IEC 60825-1:1993 + A1/E 60825-1:1994 +
A11 Class 1 (Laser/LED)
EMC: CISPR 22:1997/EN 55022:1998 Class B1)
CISPR 24:1997/EN 55024:1998
IEC 61000-3-2:1995/EN61000-3-2:1995 +
A14 — Harmonics
IEC 61000-3-3:1994/EN61000-3-3:1995 —
Flicker
FCC Title 47 CFR, Part 15 Class B2)/ICES-003,
Issue 2
AS/NZS 3548:1995 + A1 + A2:1997/CISPR
22:1993 + A1 + A2:1996 Class B1)
Telecom: TBR 21:1998, EG201 121:1998
Supplementary Information:
The product herewith complies with the requirements of the
following Directives and carries the CE marking accordingly.
— the R&TTE Directive 1999/5/EC
1) The Product was tested in a typical configuration with
Hewlett-Packard Personal Computer and peripherals.
2) This Device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Hardware Quality Engineering Manager
Cupertino, CA, USA February, 2004
For Regulatory Compliance Information ONLY,
contact:
Australian Contact: Product Regulations Manager
Hewlett-Packard Australia Ltd.
31-41 Joseph Street
Blackburn, Victoria 3130,
Australia

7
Operating Specifications
Electrical ratings: 100–127 V/200–240 V,
4/2 A, 50/60 Hz
Operating temperature: 5° to 35° C
(On models with DVD+RW/+R
drives, the operating
temperature is 5° to 30° C.)
Storage temperature: –40° to 70° C
Operating humidity: 15 to 80% @ 26° C
Storage humidity: 90% @ 65° C (non-condensing)
Operating altitude: 0–2286 m
Storage altitude: 0–4572 m
Batteries are delivered with this product. When empty, do
not throw them away but collect as small chemical waste.
Regulatory and Safety Information
WARNING: The HP Pavilion is heavy; be sure to
use ergonomically correct lifting procedures
when moving the computer.
WARNING: Please read the “Additional Safety
Information” located later in this document
before installing and connecting your system to
the electrical power system.
ENERGY STAR Compliance
Hewlett-Packard Pavilion PCs and Monitors
marked with the ENERGY STAR®logo on
the packaging box qualify with the
U.S. Environmental Protection Agency’s
ENERGY STAR guidelines for energy efficiency.
Products with the ENERGY STAR label are designed to use
less energy, help you save money on utility bills, and help
protect the environment.
ENERGY STAR®is a registered trademark owned by the U.S.
government.
Australia Telecom Statement
The computer must be connected to the Telecommunication
Network through a line cord that meets the requirements of
ACA Technical Standard TS008.
WARNING: Modems without integral RJ-11 that
are shipped with this computer must be installed
only in devices displaying the A-tick.
New Zealand Telecom Statement
The grant of a Telepermit for any item of terminal equipment
indicates only that Telecom has accepted that the item
complies with minimum conditions for connection to its
network. It indicates no endorsement of the product by
Telecom, nor does it provide any sort of warranty. Above
all, it provides no assurance that any item will work correctly
in all respects with another item of Telepermitted equipment
of a different make or model, nor does it imply that any
product is compatible with all of Telecom’s network services.
Some parameters required for compliance with Telecom’s
Telepermit requirements are dependent on the equipment
(PC) associated with this modem. The associated equipment
shall be set to operate within the following limits for
compliance with Telecom’s specification:
• For automatically initiated calls to the same
number:
(a) There shall be no more than 10 call attempts to the
same number within any 30-minute period for a single
manual call initiation.
and
(b) The equipment shall be on the hook for a period of
not less than 30 seconds between the end of one attempt
and the beginning of the next attempt.
• For automatically initiated calls to different
numbers: The equipment shall be on-hook for a period
of not less than 5 seconds between the end of one
attempt and the beginning of the next attempt.
• For automatically answered incoming calls:
Incoming calls shall be answered between 3 and 30
seconds of the first ring.
For correct operation of the ringers in each device, the total
of the RNs (ringer number) of all devices connected to a
single line at any time should not exceed 5. The RN can be
found printed on the Telepermit Label.

8
WARNING: When using this device, basic safety
precautions should always be followed to reduce
the risk of fire, electric shock, and injury to
persons, including the following:
• Do not use this product near water; for
example, near a bathtub, wash bowl, kitchen
sink, or laundry tub, in a wet basement, or
near a swimming pool.
• Avoid using this product during an electrical
storm. There may be a remote risk of electric
shock from lightening.
• Do not use this product to report a gas leak in
the vicinity of the leak.
• Always disconnect the modem cable before
opening the equipment enclosure or touching
an uninsulated modem cable, jack, or internal
components.
• If this product was not provided with a
telephone line cord, use only No. 26 AWG or
larger telecommunication line cord in order to
reduce the risk of fire.
• Do not plug a modem or telephone cable into
the Network Interface Card (NIC) receptacle.
SAVE THESE INSTRUCTIONS
Additional Safety Information
This product has not been evaluated for connection to an
“IT” power system (an AC distribution system with no direct
connection to earth, according to IEC 60950).
AC Power Safety Warning
WARNING: Install the computer near an
AC outlet. The AC power cord is your
HP Pavilion’s main AC disconnecting device and
must be easily accessible at all times. For your
safety, the power cord provided with your
system has a grounded plug. Always use the
power cord with a properly grounded wall
outlet, to avoid the risk of electrical shock.
WARNING: Your system is provided with a
voltage select switch for use in a 115 or 230 VAC
power system. The voltage select switch has
been pre-set to the correct voltage setting for use
in the particular country/region where it was
initially sold. Changing the voltage select switch
to the incorrect position can damage your
PC and void any implied warranty.
W
ARNING: To reduce the possibility of an electric
shock from the telephone network, plug your
computer into the AC outlet before connecting it
to the telephone line. Also, disconnect the
telephone line before unplugging your computer
from the AC power outlet.
WARNING: Always disconnect the modem cord
from the telephone system before installing or
removing your computer cover.
W
ARNING: Do not operate the computer with the
cover removed.
WARNING: Electrostatic discharge (ESD) can
damage disk drives, add-in cards, and other
components. If an ESD station is not available,
wear a wrist strap attached to a metal part of
the computer. Place cards on a conductive foam
pad or inside the card wrapper, if possible, but
never on the card wrapper.
WARNING: For your safety, always unplug the
system from its power source and from any
telecommunications systems (such as phone
lines), networks, or modems before performing
any of the procedures described in this guide.
Failure to do so may result in personal injury or
equipment damage. Hazardous voltage levels
are inside the power supply and modem of this
product.
Lithium Battery Caution
WARNING: The PC uses a lithium battery, type
CR2032. There is danger of an explosion if the
battery is incorrectly replaced. Replace only with
the same, or equivalent, type recommended by
the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions.
Laser Safety Statement
Class 1 LED Product
The CD-ROM and DVD-ROM drives contain a laser system
and are classified as a “Class 1 Laser Product” under a
U.S. Department of Health and Human Services (DHHS)
Radiation Performance standard according to the Radiation
Control for Health and Safety Act of 1968.

9
Should the unit ever require maintenance, contact an
authorized service location.
WARNING: Use of controls, adjustments, or
performance procedures other than those
specified in the User’s Guide may result in
hazardous radiation exposure. To prevent direct
exposure to laser beam, do not try to open the
enclosure of the CD-ROM or DVD-ROM.
Laser Product Label
The following label or equivalent is located on the surface of
HP laser products:
This label indicates that the
product is classified as a
CLASS 1 LASER PRODUCT.
This label appears on a laser
device installed in your
product.
TV Antenna Connectors Protection
External Television Antenna Grounding
If an outside antenna or cable system is connected to the
product, be sure the antenna or cable system is electrically
grounded so as to provide some protection against voltage
surges and built-up static charges. Article 810 of the
National Electrical Code, ANSI/NFPA 70, provides
information with regard to proper electrical grounding of the
mast and supporting structure, grounding of the lead-in wire
to an antenna-discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
Lightning Protection
For added protection of any Hewlett-Packard product during
a lightning storm, or when it is left unattended and unused
for long periods of time, unplug the product from the wall
outlet and disconnect the antenna or cable system. This will
prevent damage to the product from lightning and power
line surges.
2
1
1
2
3
4
5
6
7
3
4
5
6
7
Antenna Grounding
Antenna Grounding
Grounding Component
Electric Service Equipment
Ground Clamps
Ground Clamp
Grounding Conductors (NEC Section 810-21)
Antenna Discharge Unit (NEC Section 810-20)
Antenna Lead in Wire
Power Service Grounding Electrode System
(NEC Art 250, Part H)
Reference
Power Lines
An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light or
power circuits, or where it can fall into such power lines or
circuits.
WARNING: When installing an outside antenna
system, extreme care should be taken to keep
from touching such power lines or circuits as
contact with them could be fatal.

© 2003 Hewlett-Packard Development Company, L.P.
Printed in
