The HP Z600 packs eight-core compute and
visualization power into a small, quiet package—
for the ideal workstation when every inch, watt,
and decibel make a difference.
Innovation that transforms the way you work
The HP Z600’s sleek new industrial design—
brushed aluminum side panels, tool-less access
chassis, integrated handles, and visually cable-
less engineering—creates new standards for
ease of service, lowered acoustics, and energy
efciency.
• Enhance your work area with HP’s quietest
workstation, designed to t where space is at a
premium
• Minimize power and cooling costs with
ENERGY STAR® qualied congurations
featuring 85% efcient power supplies
• Help save energy with HP WattSaver which,
when activated, lowers energy consumption to
less than 1 Watt in off mode
Performance to help you do more every minute
The HP Z600 optimizes the way processor,
memory, graphics, OS and software technology
work together to deliver massive, whole-system
computational power.
• Tackle bigger problems faster and process
more tasks and threads in parallel with new
Intel® QuickPath Technology and Intel® Xeon®
processors1with integrated memory controllers
• Get maximum I/O bandwidth and
expandability from a range of Gen2 PCI
Express slots and optical drives and up to 5
storage bays
• Choose the simplied HP Installer Kit for
Linux or a breadth of Microsoft® Windows®
selections
• Drive up to 8 displays with new dual graphics
support and the latest NVIDIA and ATI graphics
cards
Reliability from our legendary, condence-
inspiring quality
• Close ISV relationships help ensure full
certication for your applications
• In-depth testing and quality assurance keep you
up-and-running
• HP Performance Tuning Framework helps ease
conguration and updates and maximizes a
range of applications
• Quickly capture system conguration data and
share it with IT personnel with HP Vision Field
Diagnostics, an easy-to-use system diagnostics
tool that runs outside the OS
• Comprehensive, lifetime HP Total Care options
provide personal attention, convenient tools,
and reliable service
Maximum
computing
power in
minimal space
HP z600 Workstation
HP recommends Windows Vista® Business

HP z600 Workstation
Form factor Rackable minitower
Operating systems Genuine Windows Vista® Business 32-bit with downgrade to Windows® XP Professional 32-bit custom installed*
Genuine Windows Vista® Business 64-bit with downgrade to Windows® XP Professional x64 custom installed*
Genuine Windows Vista® Business 32-bit**
Genuine Windows Vista® Business 64-bit**
HP Installer Kit for Linux (includes drivers for both 32-bit and 64-bit OS versions of Red Hat Enterprise Linux WS4 and WS5)
(expected availability 05/09)
Available processors Intel® Xeon® processor1,2 E55043, 2.00 GHz, 4 MB cache, 800 MHz memory, Quad-Core
Intel Xeon processor1,2 E55063, 2.13 GHz, 4 MB cache, 800 MHz memory, Quad-Core
Intel Xeon processor1,2 E55203, 2.26 GHz, 8 MB cache, 1066 MHz memory, Quad-Core
Intel Xeon processor1,2 E55303, 2.40 GHz, 8 MB cache, 1066 MHz memory, Quad-Core
Intel Xeon processor1,2 E55403, 2.53 GHz, 8 MB cache, 1066 MHz memory, Quad-Core
Intel Xeon processor1,2 X55503, 2.66 GHz, 8 MB cache, 1333 MHz memory, Quad-Core
Intel Xeon processor1,2 X55603, 2.80 GHz, 8 MB cache, 1333 MHz memory, Quad-Core
Intel Xeon processor1,2 X55703, 2.93 GHz, 8 MB cache, 1333 MHz memory, Quad-Core
Chipset Intel® 5520
Memory46 DIMM slots, up to 24 GB (expected availability 05/09), 6-channel DDR3 1333 MHz**, 3 channels per CPU (**actual memory
speed dependent on processor capability)
Drive controllers5Integrated SATA 3 GB/s controller, RAID 0, 1, 5, 10 capable; Optional SAS controller, LSI 3041E 4-port SAS/SATA, RAID 0,
1, 10 capable
Hard drive(s)6Up to (3) 3.5-inch 7200 rpm SATA drives: 160, 250, 320, 500 GB, 1, 1.5* TB, 4.5 TB max*; Up to (4) 2.5-inch 10K rpm
SATA drives: 160, 300 GB SFF, 1.2 TB max; Up to (3) 3.5-inch 15K rpm SAS drives: 146, 300, 450 GB, 1.35 TB max (*1.5
TB SATA drive expected availability 9/09). Note: Third and fourth drives occupy one external optical bay.
Optical drives7,8 DVD-ROM, DVD+/-RW, Slot-load DVD+/-RW, Blu-Ray Writer (expected availability 05/09)
Drive bays 2 external 5.25-inch bays, 2 internal 3.5-inch HDD bays, Up to 4 eSATA. Note: Third and fourth HDDs occupy one external bay.
Slots 2 PCI Express Gen2 x16, 1 PCI Express Gen2 x8 mechanical/x4 electrical, 1 PCI Express Gen1 x8 mechanical/x4
electrical, 2 PCI
Graphics
(dual graphics on selected
cards)
Professional 2D: NVIDIA Quadro NVS 295 (256 MB), NVIDIA Quadro NVS 450 (512 MB)
Entry 3D: NVIDIA Quadro FX 380 (256 MB), ATI FirePro V3700 (256 MB), NVIDIA Quadro FX 580 (512 MB)
Midrange 3D: NVIDIA Quadro FX 1800 (768 MB), ATI FirePro V5700 (512 MB)
High-end 3D: NVIDIA Quadro FX 3800 (1 GB) (available 06/09), ATI FirePro V7750 (1 GB), NVIDIA Quadro FX
4800 (1.5 GB), NVIDIA Quadro CX
Audio High Denition Integrated RealTek ALC262 Audio, optional Creative X-Fi Titanium PCIe Audio Card, optional HP Thin USB
Powered Speakers
Network Integrated Broadcom 5764 LAN, Inneon TPM 1.2 Controller, Optional Broadcom NIC, Optional Intel NIC
Ports Front: 3 USB 2.0, 1 IEEE 1394a (optional), 1 microphone in, 1 headphone out
Rear: 6 USB 2.0, 1 audio in, 1 audio out, 1 microphone in, 2 PS/2, 1 RJ-45 to integrated Gb LAN, 1 serial (optional)
Internal: 3 USB 2.0
Input devices PS/2 standard keyboard, USB standard keyboard, USB Smart Card Keyboard, PS/2 optical scroll mouse, USB 2-button
optical scroll mouse, USB 3-button optical mouse, USB SpaceExplorer, USB SpacePilot, USB Laser Scroll Mouse
Dimensions (H x W x D) 17.5 x 6.5 x 17.3 in (44.51 x 16.53 x 44 cm)
Power supply 650 Watt 85% efcient power supply, direct connection power supplies
Monitors (screen size
diagonally measured)
HP LP1965 19-inch LCD Monitor, HP LP2275w 22-inch Widescreen LCD Monitor, HP LP2475w 24-inch Widescreen LCD
Monitor, HP DreamColor LP2480zx Professional Display (24-inch diagonal widescreen), HP LP3065 30-inch Widescreen LCD
Monitor
Warranty Limited three-year next business day9, parts, labor and 8x5 phone support; Terms and conditions may vary.
*Windows Vista Business disk may also be included for future upgrade if desired. To qualify for this downgrade an end user must be a business (including governmental or educational institutions) and is expected to
order at least 25 customer systems with the same custom image.
**Certain Windows Vista product features require advanced or additional hardware. See www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and
www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade Advisor can help you determine which features of Windows Vista will run on your computer. To download the tool,
visit www.windowsvista.com/upgradeadvisor.
1 Quad-Core technologies are designed to improve performance of multithreaded software products and hardware-aware multitasking operating systems and may require appropriate operating system software for full
benets; check with software provider to determine suitability; Not all customers or software applications will necessarily benet from use of these technologies.
2 64-bit computing on Intel architecture requires a computer system with a processor, chipset, BIOS, operating system, device drivers and applications enabled for Intel® 64 architecture. Processors will not operate
(including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary depending on your hardware and software congurations. See www.intel.com/info/em64t for more information.
3Intel’s numbering is not a measurement of higher performance.
4 Each processor supports up to 3 channels of DDR3 memory. To realize full performance at least 1 DIMM must be inserted into each channel. To get full 6 channel support, 2 processors MUST be installed.
5 SATA hardware RAID is not supported on Linux systems. The Linux kernel, with built-in software RAID, provides excellent functionality and performance. It is a good alternative to hardware-based RAID. Please visit
http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00060684/c00060684.pdf for RAID capabilities with Linux.
6 For hard drives, 1 GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 12 GB of hard drive (or system disk) is reserved for the system recovery software (XP and XP Pro). Up to 3 GB of
system disk is reserved for system recovery software. (Vista).
7 Actual speeds may vary. Does not permit copying of commercially available DVD movies or other copyright protected materials. Intended for creation and storage of your original material and other lawful uses. Double Layer
discs can store more data than single layer discs. However, double-layer discs burned with this drive may not be compatible with many existing single-layer DVD drives and players.
8 As Blu-Ray is a new format containing new technologies, certain disc, digital connection, compatibility and/or performance issues may arise, and do not constitute defects in the product. Flawless playback on all systems is
not guaranteed. In order for some Blu-ray titles to play, they may require a DVI or HDMI digital connection and your display may require HDCP support. HD-DVD movies cannot be played on this workstation.
9 HP Care Pack Services extend service contracts beyond the standard warranties. Service starts from date of hardware purchase. To choose the right level of service for your HP product, use the HP Care Pack Services
Lookup Tool at www.hp.com/go/lookuptool. Additional HP Care Pack Services information by product is available at www.hp.com/hps/carepack. Service levels and response times for HP Care Packs may vary
depending on your geographic location.
