QuickSpecs
HP Z230 SFF Workstation
Overview
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 1

1. 1 Audio Line In, 1 Audio Line Out
2. 2 USB 3.0, 2 USB 2.0
3. 1 serial port
4. 3 DisplayPort (DP 1.2) outputs from Intel HD graphics (available on specific processors only)
5. RJ-45 to integrated GBE
6. 2 USB 2.0
7. PS/2 ports (keyboard, mouse)
Form Factor Small Form Factor
Operating Systems Preinstalled:
Windows 7 Ultimate 64-bit
Windows 7 Professional 32/64
Windows 7 Home Premium 32/64
Windows 8 Pro 64-bit
Windows 8 Simplified Chinese Edition 64-bit
Windows 8 Pro Downgrade to Windows 7 Professional 32-bit
Windows 8 Pro Downgrade to Windows 7 Professional 64-bit
Windows 8.1 Pro 64-bit
Windows 8.1 Simplified Chinese Edition 64-bit
Windows 8.1 Pro Downgrade to Windows 7 Professional 32-bit
Windows 8.1 Pro Downgrade to Windows 7 Professional 64-bit
QuickSpecs
HP Z230 SFF Workstation
Overview
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 2

Windows 8.1 Pro Downgrade to Windows 7 Professional 32-bit (National Academic)
Windows 8.1 Pro Downgrade to Windows 7 Professional 64-bit (National Academic)
HP Installer Kit for Linux [includes drivers for 64-bit OS versions of Red Hat Enterprise Linux 6 and
SUSE Linux Enterprise Desktop (SLED) 11]
SUSE Linux Enterprise Desktop 11 64-bit (90 day license)
Red Hat Enterprise Linux Workstation (1 year paper license available; Preinstall not available)
Supported:
Genuine Windows® 7 Enterprise 32/64
Notes: For detailed OS/hardware support information for Linux, see:
http://www.hp.com/support/linux_hardware_matrix
Name Cores
Clock
Speed
(GHz)
Intel® Turbo
Boost
Technology
1
Cache
(MB)
Memory
Speed
(MHz)
Hyper-
Threading
Integrated
Graphics
Featuring
Intel®
vPro™
Technology
TDP
(W)
Intel® Xeon® processor E3-1280v3 4 3.6 4.0 8 1600 Y N/A Y 80W
Intel® Xeon® processor E3-1270v3 4 3.5 3.9 8 1600 Y N/A Y 80W
Intel® Xeon® processor E3-1245v3
4 3.4 3.8 8 1600 Y
Intel HD
Graphics
P4600
Y 84W
Intel® Xeon® processor E3-1240v3 4 3.4 3.8 8 1600 Y N/A Y 80W
Intel® Xeon® processor E3-1230v3 4 3.3 3.7 8 1600 Y N/A Y 80W
Intel® Xeon® processor E3-1225v3
4 3.2 3.6 8 1600 N
Intel HD
Graphics
P4600
Y 84W
Intel® Core
TM
i7-4771 processor 4 3.5 3.9 8 1600 Y
Intel HD
Graphics
4600
Y 84W
Intel® Core
TM
i7-4770 processor 4 3.4 3.9 8 1600 Y
Intel HD
Graphics
4600
Y 84W
Intel® Core
TM
i5-4670 processor 4 3.4 3.8 6 1600 N
Intel HD
Graphics
4600
Y 84W
Intel® Core
TM
i5-4570 processor 4 3.2 3.6 6 1600 N
Intel HD
Graphics
4600
Y 84W
Intel® Core
TM
i3-4330 processor 2 3.5 NA 4 1600 Y
Intel HD
Graphics
4600
N 54W
Intel® Core
TM
i3-4130 processor 2 3.4 NA 3 1600 Y
Intel HD
Graphics
4400
N 54W
Intel® Pentium® G3220 processor 2 3.0 NA 3 1333 N
Intel HD
Graphics
N 54W
1
The specifications shown in this column represent the maximum turbo frequency with one core active. Turbo boost stepping occurs
in 100MHz increments. Processors that do not have turbo functionality are denoted as N/A.
QuickSpecs
HP Z230 SFF Workstation
Overview
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 3

Available Processor
Disclaimers
Integrated Intel® HD graphics is not supported on the Intel® Xeon Processor E3-1230v3, E3-1240v3, E3-
1270v3 or E3-1280v3.
Intel® Xeon E3, Intel Core i3 and Intel Pentium processors can support either ECC or non-ECC memory;
Intel® Core i5/i7 processors only support non-ECC memory.
Intel's numbering is not a measurement of higher performance. Processor numbers differentiate features
within each processor family, not across different processor families. See:
http://www.intel.com/products/processor_number/ for details.
64-bit computing on Intel® 64 architecture requires a computer system with a processor, chipset, BIOS,
operating system, device drivers and applications enabled for Intel 64 architecture. Processor will not
operate (including 32-bit operation) without an Intel 64 architecture-enabled BIOS. Performance will vary
depending on your hardware and software configurations. See: http://www.intel.com/info/em64t for more
information.
Dual-Core and Quad-Core technologies are designed to improve performance of multithreaded software
products and hardware-aware multitasking operating systems and may require appropriate operating
system software for full benefits; check with software provider to determine suitability; Not all customers
or software applications will necessarily benefit from use of these technologies.
Color Jack Black
Convertibility The Z230 SFF can either be placed flat on the desktop or made to stand on the desk with the optional
tower stand.
Expansion Slots (see
system board section for
more details)
1 PCIe Gen3 x16 slot
1 PCIe Gen2 x4 slot /x16 connector
1 PCIe Gen2 x1 slot/x4 connector
1 PCIe Gen2 x1 slot
(all slots are Low Profile)
Note: In the PCIe Gen3 x16 slot, if it is not being used for a graphics card, only cards certified as After
Market Options for this platform are supported.
Expansion Bays (see
storage section for more
details)
1 external Half Height 5.25" bay
1 shared internal/external 3.5" bay
1 internal 3.5" bay
1 internal 2.5" bay (for SSD only)
Front I/O 2 USB 3.0, 2 USB 2.0, 1 Headphone, and 1 Microphone
Internal I/O 1 USB 3.0 and 3 USB 2.0 ports available as 2 separate 2x10(3.0 x1, 2.0 x1) and 2x5(2.0 x2) header:
supports one HP Internal USB 2.0 Port Kit and one USB 3.0 Media Card Reader.
Rear I/O 3 DisplayPort (DP 1.2) outputs from Intel HD graphics (available on specific processors only); 2 USB 3.0
ports, 4 USB 2.0 ports, 2 serial ports (1 standard, 1 optional), 1 parallel port (optional), 2 PS/2, RJ-45 (LoM),
1 Audio Line-in, and 1 Audio Line-out; 2 IEEE 1394b ports (optional).
Interfaces Supported 14-in-1 Media Card Reader (optional)
Chassis Dimensions
(H x W x D)
Standard desktop orientation: 100 x 337 x 384 mm (3.95 x 13.3 x 15.1 in); Optional SFF Tower orientation
(excluding stand dimension): 337 x 100 x 384 mm (13.3 x 3.95 x 15.1 in)
QuickSpecs
HP Z230 SFF Workstation
Overview
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 4

Weight Exact weights depend upon configuration;
Typical Weight* 7.2 kg (15.87 lbs)
Shipping Weight* 9.8 kg (21.6 lbs)
Max Supported Weight (desktop orientation) 35 kg (77 lb)
Note*: Configured with 2 3.5" hard drives, 1 optical drive, 2 DIMMs and 1 NVIDIA Quadro K600 graphics card
Temperature Operating: 5° to 35°C (40° to 95°F)
Non-operating: -40° to 60°C ( -40° to 140°F)
Notes: Derate the maximum operating temperature by one degree C (1.8 degrees F) for every 305m (1,000
ft) altitude over 1,524m (5,000 ft).
Humidity Operating: 8% to 85%
Non-operating: 8% to 90%
Maximum Altitude
(non-pressurized)
Operating: 3,000 m; 10,000 ft
Non-operating: 9,100 m; 30,000 ft
Power Supply 240W 92% Efficiency wide-ranging, active Power Factor Correction (PFC)
240W Standard Efficiency wide-ranging, active PFC Power Supply option available in some countries.
The Power Supply Efficiency Report for the 240W, 92% efficiency power supply may be found at these
links:
http://www.plugloadsolutions.com/psu_reports/HEWLETT-PACKARD%20COMPANY_PS-4241-
1HA_240W_ECOS%203449_Report.pdf
http://www.plugloadsolutions.com/psu_reports/HEWLETT-PACKARD_D12-
240P2A_240W_ECOS%203384_Report.pdf
http://www.plugloadsolutions.com/psu_reports/Hewlett-Packard%20Company_DPS-240AB-
3%20A_240W_ECOS%203416_Report.pdf
http://www.plugloadsolutions.com/psu_reports/HEWLETT-PACKARD%20COMPANY_PCC002-
020H2_240W_ECOS%203440_Report.pdf
Backup Devices For a complete listing of compatible DAT tape drives, LTO tape drives and RDX Removable Disk Backup
System offerings, please visit http://www.hp.com/go/connect
Chipset Intel® C226 chipset
Memory 4 DIMM slots, supporting up to 32GB ECC/non-ECC, DDR3 1600 MHz
Memory disclaimers The CPUs determine the speed at which the memory is clocked. If a 1333 MHz capable CPU is used in the
system, the maximum speed the memory will run at is 1333 MHz regardless of the specified speed of the
memory.
Workstation ISV
Certifications
See the latest list of certifications at
http://www.hp.com/united-states/campaigns/workstations/partnerships.html
QuickSpecs
HP Z230 SFF Workstation
Overview
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 5

Processors Factory
Configured
Option
Kit
Support
Notes
Intel® Xeon® processor E3-1200 v3 family (Z230)
Intel® Xeon® processor E3-1280v3, Quad-Core, 8 MB cache, 3.6 GHz, up
to 4.0 GHz with Intel Turbo Boost Technology
Y N
See Note
2
Intel® Xeon® processor E3-1270v3, Quad-Core, 8 MB cache, 3.5 GHz, up
to 3.9 GHz with Intel Turbo Boost Technology
Y N
See Note
2
Intel® Xeon® processor E3-1245v3, Quad-Core, 8 MB cache, 3.4 GHz, up
to 3.8 GHz with Intel Turbo Boost Technology
Y N
See Note
2
Intel® Xeon® processor E3-1240v3, Quad-Core, 8 MB cache, 3.4 GHz, up
to 3.8 GHz with Intel Turbo Boost Technology
Y N
See Note
2
Intel® Xeon® processor E3-1230v3, Quad-Core, 8 MB cache, 3.3 GHz, up
to 3.7 GHz with Intel Turbo Boost Technology
Y N
See Note
2
Intel® Xeon® processor E3-1225v3, Quad-Core, 8 MB cache, 3.2 GHz, up
to 3.6 GHz with Intel Turbo Boost Technology
Y N
See Note
2
4th generation Intel® Core™ processor family
Intel® Core™ i7-4771 processor, Quad-Core, 8 MB cache, 3.5 GHz, up to
3.9 GHz with Intel Turbo Boost Technology
Y N
See Note
3
Intel® Core™ i7-4770 processor, Quad-Core, 8 MB cache, 3.4 GHz, up to
3.9 GHz with Intel Turbo Boost Technology
Y N
See Note
3
Intel® Core™ i5-4670 processor, Quad-Core, 6 MB cache, 3.4 GHz, up to
3.8 GHz with Intel Turbo Boost Technology
Y N
See Note
3
Intel® Core™ i5-4570 processor, Quad-Core, 6 MB cache, 3.2 GHz, up to
3.6 GHz with Intel Turbo Boost Technology
Y N
See Note
3
Intel® Core™ i3-4330 processor, Dual-Core, 4 MB cache, 3.5 GHz
Y N
See Note
2
Intel® Core™ i3-4130 processor, Dual-Core, 4 MB cache, 3.4 GHz
Y N
See Note
2
Dual Core Intel® Pentium® Processors (Z230)
Intel® Pentium® G3220 processor, Dual-Core, 3 MB cache, 3.0 GHz
Y N
See Note
2
NOTE 1: Intel HD Graphics P4600 supports workstation-specific graphics drivers for improved
compatibility and performance on select professional applications, compared to Intel HD Graphics 4600.
NOTE 2: These processors support either ECC or non-ECC memory
NOTE 3: These processors support only non-ECC memory
QuickSpecs
HP Z230 SFF Workstation
Supported Components
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 6

Monitors / Displays
Factory
Configured
Option
Kit
Option
Kit Part
Number
Support
Notes
HP DreamColor LP2480zx Professional Display
HP Z Display Z30i 30-inch IPS LED Backlit Monitor
HP Z Display Z27i 27-inch IPS LED Backlit Monitor
HP Z Display Z24i 24-inch IPS LED Backlit Monitor
HP Z Display Z23i 23-inch IPS LED Backlit Monitor
HP Z Display Z22i 21.5-inch IPS LED Backlit Monitor
HP ZR2740w 27-inch LED Backlit IPS Monitor
HP ZR2440w 24-inch LED Backlit IPS Monitor
HP ZR2330w 23-inch IPS LED Backlit Monitor
Supported by all Operating Systems available from HP
Screen Size Diagonally Measured
Hard Drives
SATA Hard Drives
Factory
Configured
Option
Kit
Option
Kit Part
Number
Support
Notes
SATA (Serial ATA) Hard Drives for HP Workstations
500GB SATA 7200 rpm 6Gb/s 3.5" HDD Y Y LQ036AA
1TB SATA 7200 rpm 6Gb/s 3.5" HDD Y Y LQ037AA
2.0TB SATA 7200 rpm 6Gb/s 3.5" HDD Y Y QB576AA
3.0TB SATA 7200 rpm 6Gb/s 3.5" HDD Y Y QF298AA
250GB SATA 10K rpm SFF HDD Y Y B8X18AA
500GB SATA 10K rpm SFF HDD Y Y B8X19AA
1TB SATA 10K rpm SFF HDD Y Y B8X20AA
500GB SATA 7.2K SED SFF HDD Y N (not
available
today as
After
Market
Option)
Sub-Section
Description/Notes
Note: The 2.5" internal drive bay on the Z230 SFF only supports a Solid State Drive, and not a 10K rpm
HDD.
SATA Solid State Drives HP Solid State Drives (SSDs) for Workstations
HP 128GB SATA 6Gb/s SSD Y Y A3D25AA
HP 256GB SATA 6Gb/s SSD Y Y A3D26AA
QuickSpecs
HP Z230 SFF Workstation
Supported Components
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 7

HP 256GB SATA 6Gb/s SED SSD Y Y (not
available
as After
Market
Option)
Intel Pro 1500 180GB SATA SSD Y Y F5Z70AA
Samsung SM843T 240GB SATA SSD Y Y F0W94AA
Samsung SM843T 480GB SATA SSD Y Y TBD
Intelligent Disk Caching Intelligent Disk Caching
64GB SSD Disk Cache Module Y N (not
available
today as
After
Market
Option)
Hard Drive Controllers Factory
Configured Option Kit
Support
Notes
Integrated SATA Controller (Z230)
Integrated SATA Controller, RAID 0,1 supported: 5x 6 Gb/s ports Y N
Factory integrated RAID on motherboard for SATA drives
RAID 0 Configuration – Striped Array Y N
RAID 1 Configuration – Mirrored Array Y N
NOTE 1 : Windows OS only; Supported only with two drives of identical type and capacity.
SATA hardware RAID is not supported on Linux systems. The Linux kernel, with built-in software RAID,
provides excellent functionality and performance. It is a good alternative to hardware-based RAID. Please
visit http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00060684/c00060684.pdf for RAID
capabilities with Linux.
Graphics
Factory
Configured
Option
Kit
Option
Kit Part
Number
Support
Notes
Supported
# of
cards Mixed
Integrated Intel HD Graphics Media Accelerators (Z230)
Intel HD Graphics P4600 Y N Available
on Intel®
Xeon® E3-
12x5 v3
processors
only. See
Note 1.
1 NO
Intel HD Graphics 4600 Y N Available
on Intel
1 NO
QuickSpecs
HP Z230 SFF Workstation
Supported Components
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 8

CoreTM i7-
4xxx/ Core
i5-4xxx/
Core i3-
4330
processors.
See Note
1.Available
on Intel
CoreTM i7-
4xxx/ Core
i5-4xxx/
Core i3-
4330
processors.
See Note 1.
Intel HD Graphics 4400 Y N Available
on Intel
Core i3-
4130
processor.
See Note 1.
1 NO
Intel HD Graphics Y N Available
on Intel
Pentium®
3220
processor.
See Note 1
1 NO
Professional 2D
NVIDIA NVS 310 512MB Graphics Y Y A7U59AA Can be
mixed with
one NVS
510
2 YES
NVIDIA NVS 315 1GB Graphics Y Y E1U66AA 2 NO
NVIDIA NVS 510 2GB Graphics Y Y C2J98AA Can be
mixed with
one NVS
310
1 YES
Graphics Cable Adapters
HP DisplayPort To DVI-D Adapter Y Y FH973AA 1
HP DisplayPort To DVI-D Adapter (2-
Pack)
Y N 1
HP DisplayPort To DVI-D Adapter (4-
Pack)
Y N 1
HP DisplayPort To VGA Adapter Y Y AS615AA 1
QuickSpecs
HP Z230 SFF Workstation
Supported Components
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 9

HP DisplayPort to Dual Link DVI
Adapter
Y Y NR078AA 1
Entry 3D
AMD FirePro V3900 1GB Graphics Y Y A6R69AA 1 NO
NVIDIA Quadro 410 512MB Graphics Y Y A7U60AA 1 NO
NVIDIA Quadro K600 1GB Graphics Y Y C2J92AA 1 NO
Note 1: Intermixing integrated Intel HD graphics and discrete graphics cards in order to drive more than
three displays can be enabled using the Computer (F10) Setup Utility. However, HP recommends using only
discrete graphics when four or more displays are required to be supported. Utility. However, HP
recommends using only discrete graphics cards when four or more displays are required to be supported.
Memory Sub-Section Description/Notes
Intel® Xeon E3, Intel Core i3 and Intel Pentium processors can support either ECC or non-ECC memory;
Intel® Core i5/i7 processors only support non-ECC memory.
CTO Support Notes
DDR3-1600 nECC Unbuffered DIMMs CTO
HP 32GB (4x8GB) DDR3-1600 nECC RAM
HP 16GB (2x8GB) DDR3-1600 nECC RAM
HP 16GB (4x4GB) DDR3-1600 nECC RAM
HP 8GB (2x4GB) DDR3-1600 nECC RAM
HP 4GB (1x4GB) DDR3-1600 nECC RAM
DDR3-1600 ECC Unbuffered DIMMs - CTO
HP 32GB (4x8GB) DDR3-1600 ECC RAM
HP 16GB (2x8GB) DDR3-1600 ECC RAM
HP 16GB (4x4GB) DDR3-1600 ECC RAM
HP 8GB (2x4GB) DDR3-1600 ECC RAM
HP 8GB (1x8GB) DDR3-1600 ECC RAM
HP 4GB (2x2GB) DDR3-1600 ECC RAM
HP 4GB (1x4GB) DDR3-1600 ECC RAM
Sub-Section Description/Notes
Two channels of DDR3 memory are supported. To realize full performance at least one DIMM must be
inserted into each channel.
The CPUs determine the speed at which the memory is clocked. If a 1333 MHz capable CPU is used in the
system, the maximum speed the memory will run at is 1333 MHz regardless of the specified speed of the
memory.
AMO Option Kit Part
Number
Support Notes
DDR3-1600 nECC Unbuffered DIMMs AMO
HP 8GB (1x8GB) DDR3-1600 non-ECC RAM B1S54AA
HP 4GB (1x4GB) DDR3-1600 nECC RAM B1S53AA
DDR3-1600 ECC Unbuffered DIMMs - AMO
QuickSpecs
HP Z230 SFF Workstation
Supported Components
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 10

HP 8GB (1x8GB) DDR3-1600 ECC RAM A2Z50AA
HP 4GB (1x4GB) DDR3-1600 ECC RAM A2Z48AA
NOTE: Only unbuffered DDR3 DIMMs are supported.
Multimedia and Audio
Devices Factory
Configured Option Kit
Option Kit
Part
Number
Support
Notes
HP Thin USB Powered Speakers, Low Halogen Y Y KK912AA
Integrated Realtek HD ALC221 Audio Y N
Optical and Removable
Storage Factory
Configured
Option
Kit
Option
Kit Part
Number
Support
Notes
HP 16X DVD-ROM SATA Drive (non Lightscribe) Y Y AR629AA
HP 16X DVD+/-RW SuperMulti SATA Drive Y Y QS208AA
HP Blu-ray Writer Y Y AR482AA
HP 14-in-1 Media Card Reader Y Y E5G19AA
Actual speeds may vary. Does not permit copying of commercially available DVD movies or other copyright
protected materials. Intended for creation and storage of your original material and other lawful uses.
Double Layer discs can store more data than single layer discs. However, double-layer discs burned with
this drive may not be compatible with many existing single-layer DVD drives and players.
As Blu-ray is a new format containing new technologies, certain disc, digital connection, compatibility
and/or performance issues may arise, and do not constitute defects in the product. Flawless playback on
all systems is not guaranteed. In order for some Blu-ray titles to play, they may require a DVI or HDMI
digital connection and your display may require HDCP support. HD-DVD movies cannot be played on this
workstation.
Controller Cards
Factory
Configured
Option
Kit
Option
Kit Part
Number
Support
Notes
HP IEEE 1394b FireWire PCIe Card Y Y NK653AA See Note
1
HP Thunderbolt-2 PCIe 1-port I/O Card Y Y F3F43AA See Note
2
NOTE 1: : Four USB 3.0 ports are available integrated on the motherboard (2 front, 2 rear). Integrated USB
3.0 ports are supported under Microsoft Windows 7 or Microsoft Windows 8 operating systems only.
NOTE 2: Thunderbolt™ 2 is available via an optional add-in card. Thunderbolt is new technology.
Thunderbolt cable and Thunderbolt device (sold separately) must be compatible with Windows. To
determine whether your device is Thunderbolt Certified for Windows, see
https://thunderbolttechnology.net/products
QuickSpecs
HP Z230 SFF Workstation
Supported Components
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 11

Networking and
Communications Factory
Configured
Option
Kit
Option
Kit Part
Number
Support
Notes
Integrated Intel I217LM PCIe GbE Controller Y N N See Notes
1, 2, 3
Intel Ethernet I210-T1 PCIe NIC Y Y E0X95AA See Notes
3, 4
Intel 6205 802.11 a/b/g/n PCIe x1 WLAN Card N Y E0X93AA
NOTE 1 : The integrated network connection is required to support Intel vPro Technology.
NOTE 2 : If AMT is enabled network teaming with the integrated LAN port is not possible.
NOTE 3 : "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does
not connote actual operating speed of 1 Gb/sec. For high speed transmission, connection to a Gigabit
Ethernet server and network infrastructure is required.
NOTE 4 : The Intel Ethernet I210-T1 PCIe NIC is supported on the following operating systems:
Microsoft Windows 7 and Windows 8 32-bit and 64-bit versions
Red Hat Enterprise Linux(RHEL)
SLED 11.
Racking and Physical
Security Factory
Configured Option Kit
Option Kit
Part
Number
Support
Notes
HP Solenoid Lock and Hood (SFF) Sensor Y Y E0X97AA
HP Business PC Security Lock Kit N Y PV606AA The HP
Business
PC
Security
Lock Kit
does not
work with
the
Integrated
Work
Center
stand.
HP UltraSlim Cable Lock Kit N Y H4D73AA
QuickSpecs
HP Z230 SFF Workstation
Supported Components
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 12

Input Devices
Factory
Configured Option Kit
Option Kit
Part
Number
Support
Notes
HP SpacePilot Pro 3D USB Intelligent Controller N Y WH343AA
HP SpaceMouse Pro USB 3D Input Device N Y B4A20AA
HP USB 1000dpi Laser Mouse Y Y QY778AA
HP USB Optical 3-Button Mouse Y Y DY651A
HP USB Optical Mouse Y Y QY777AA
HP PS/2 Mouse Y Y QY775AA
HP 2.4GHz Wireless Keyboard & Mouse N Y NB896AA
HP USB CCID SmartCard Keyboard Y Y BV813AA
HP USB Keyboard Y Y QY776AA
HP PS/2 Keyboard Y Y QY774AA
Other Hardware
Factory
Configured Option Kit
Option Kit
Part
Number
Support
Notes
HP Power Cord Kit N Y DM293A
HP Workstation Mouse Pad Y N Japan
only
HP Serial Port Adapter Y Y PA716A
HP ENERGY STAR Qualified Configuration Y N
HP Parallel Port Adapter Kit N Y KD061AA
HP Internal USB Port Kit N Y EM165AA
HP eSATA PCI Cable Kit Y Y FH966AA
HP (SFF) Tower Stand Y Y VN569AA
Software Factory
Configured Option Kit Support Notes
HP Performance Advisor Y N See Note 1
HP Remote Graphics Software (RGS) 6.0 Y N See Note 2
PDF Complete - Corporate Edition Y N
MS Office Home & Business 2013 Y N
Cyberlink PowerDVD and Power2Go Y N
HP PC Hardware Diagnostics UEFI Y N Windows OS only
NOTE 1 : Supports, and preinstalled with, Windows 7 and Windows 8 only. Also available as a free
download from www.hp.com/go/performanceadvisor
NOTE 2 : Supported Operating Systems:
Windows 7 Professional
Windows 8 Pro
RHEL v5.2 - v6.3
QuickSpecs
HP Z230 SFF Workstation
Supported Components
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 13

SLED 11 SP2
Operating Systems Support Notes
Genuine Windows® 7 Ultimate 64-bit
Genuine Windows® 7 Professional 32-bit See http://www.microsoft.com/windows/windows-7/
for support details.
Genuine Windows® 7 Professional 64-bit See http://www.microsoft.com/windows/windows-7/
for support details.
Genuine Windows® 7 Home Premium 32-bit See http://www.microsoft.com/windows/windows-7/
for support details.
Genuine Windows® 7 Home Premium 64-bit See http://www.microsoft.com/windows/windows-7/
for support details.
Windows 8.1 Pro 64-bit
Windows 8.1 Simplified Chinese Edition 64-bit
Windows 8.1 Pro Downgrade to Windows 7
Professional 32-bit
Windows 8.1 Pro Downgrade to Windows 7
Professional 64-bit
Windows 8.1 Pro Downgrade to Windows 7
Professional 32-bit (National Academic)
Windows 8.1 Pro Downgrade to Windows 7
Professional 64-bit (National Academic)
HP Linux Installer Kit See http://h20331.www2.hp.com/hpsub/cache/537200-0-
0-225-121.html
Red Hat Enterprise Linux (RHEL) Workstation -
Paper License (1yr)
See http://www.redhat.com/rhel/desktop/
SUSE Linux Enterprise Desktop 11 See http://www.suse.com/products/desktop/
QuickSpecs
HP Z230 SFF Workstation
Supported Components
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 14

System Board
System Board Form Factor ATX 24.38 x 24.38 mm (9.6 x 9.6 inches)
Processor Socket Single LGA 1150
CPU Bus Speed DMI
Chipset Intel® PCH C226
Memory Expansion Slots 4 DDR3 memory slots
Memory Type Supported DDR3, UDIMM (Unbuffered), ECC& non-ECC
Memory Modes Non-Interleaved for single channel. Interleaved when both channels are populated.
Memory Speed Supported 1600MHz DDR3
Memory Protection ECC available on data
Maximum Memory 32GB
Memory Configuration
(Supported)
4GB and 8GB non-ECC/ 2GB, 4GB and 8GB ECC unbuffered DIMMs are supported.
ECC and non-ECC memory DIMMs cannot be mixed on the same system.
NOTE: * Maximum memory capacities assume 64-bit operating systems, such as Genuine Windows® 7
Professional 64-Bit or Red Hat Linux 64-bit. 32-bit Windows Operating Systems support up to 4 GB.
PCI Express Connectors 1 PCI Express Gen3 x16 LP slot (x16 electrical/x16 mechanical)
1 PCI Express Gen2 x16 LP slot (x4 electrical/x16 mechanical)
1 PCI Express Gen2 x1 LP slot (x1 electrical/x4 mechanical)
1 PCI Express Gen2 x1 LP slots (x1 electrical/x1 mechanical)
NOTE: LP = Low Profile
NOTE: In the PCIe Gen3 slot (x16 electrical/x16 mechanical) slot, if it is not being used for a graphics card,
only cards certified as After Market Options for this platform are supported.
Supported Drive
Interfaces
SATA Integrated (5) Serial ATA interfaces (6Gb/s SATA). One port can
optionally be used for eSATA.
RAID 0 and 1 supported. Factory integrated RAID is Microsoft
Windows only.
Serial Attached SCSI None
Integrated RAID NOTE: Requires identical hard drives (speeds, capacity,
interface)
Integrated Graphics Integrated Intel HD Graphics 4600 (on Core i5/i7-4xxx
processors); Integrated Intel HD Graphics P4600 (on Intel Xeon
E3-12x5v3 processors).
Based on Unified Memory Architecture (UMA)- A region of
system memory is reserved and dedicated to the graphics
display.
Support for Microsoft DirectX 11, OpenGL 4.0 and OpenCL 1.2
on Intel HD Graphics P4600;
3 DP 1.2 graphics ports integrated in motherboard; Supports up
to three simultaneous displays across DP outputs. Max.
resolution supported: 3840x2160 @60Hz
QuickSpecs
HP Z230 SFF Workstation
System Technical Specifications
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 15

Network Controller Integrated Ethernet PHY Connection I217LM. Management
capabilities: WOL, PXE 2.1 and AMT 9.0
External SATA (eSATA) 1 port eSATA capable with optional eSATA After-Market Option
cable kit.
IDE connector No
Floppy connector No
Serial 1 rear port
2nd Serial Yes- requires optional Serial Port Adapter Kit
Parallel 1 internal header (optional Parallel Port Adapter required)
CD-ROM input (Audio) No
AUX input (Audio) No
IEEE 1394 Connector(s) Rear 2 IEEE 1394b (requires optional PCIe 1394b card)
Internal No
USB Connector(s) Front 2 USB 3.0, 2 USB 2.0
Rear 2 USB 3.0, 4 USB 2.0
Internal 1 USB 3.0, 2 USB 2.0
HD Integrated Audio Yes
Flash ROM Yes, 16MB
Chassis Fan Header Not applicable
Front Control
Panel/Speaker Header
Yes
CMOS Battery Holder -
Lithium
Yes
Integrated Trusted
Platform Module
Integrated TPM 1.2.
Power Supply Headers Yes
Power Switch, Power LED
& Hard Drive LED Header
Yes
Clear Password Jumper Yes
Keyboard/Mouse USB or PS/2
240W, 92% efficiency, wide-ranging, active PFC Power Supply;
(Note: 240W Standard Efficiency wide-ranging, active PFC Power Supply option available in some
countries).
The Z230 SFF 92% PSU Efficiency Report can be found at these links:
http://www.plugloadsolutions.com/psu_reports/HEWLETT-PACKARD%20COMPANY_PS-4241-
1HA_240W_ECOS%203449_Report.pdf
http://www.plugloadsolutions.com/psu_reports/HEWLETT-PACKARD_D12-
240P2A_240W_ECOS%203384_Report.pdf
http://www.plugloadsolutions.com/psu_reports/Hewlett-Packard%20Company_DPS-240AB-
QuickSpecs
HP Z230 SFF Workstation
System Technical Specifications
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 16

3%20A_240W_ECOS%203416_Report.pdf
http://www.plugloadsolutions.com/psu_reports/HEWLETT-PACKARD%20COMPANY_PCC002-
020H2_240W_ECOS%203440_Report.pdf
Operating Voltage Range 90-269 VAC
Rated Voltage Range 100-240 VAC
Rated Line Frequency 50-60 Hz
Operating Line Frequency
Range
47-63 Hz
Rated Input Current 4A @ 100-240V
Heat Dissipation Typical: 444 btu/hr (112 kcal/hr)
Maximum: 890 btu/hr (224 kcal/hr)
Power Supply Fan 70x25 mm variable speed
ENERGY STAR® qualified
(Config Dependent)
Yes
FEMP Standby Power
Compliant
Yes, with Wake-on-LAN disabled: <2W in S5- Power Off
Built-in Self Test (BIST)
LED
No
Surge Tolerant Full
Ranging Power Supply
(withstands power surges
up to 2000V)
Yes
Hood Lock Header Yes
ErP Lot 6- Tier 1
Compliance @ 230V (<1W
in S5- Power Off)
Yes
ErP Lot 6- Tier 2
Compliance @ 230V
(<0.5W in S5- Power Off)
Yes
QuickSpecs
HP Z230 SFF Workstation
System Technical Specifications
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 17

System Configurations
Z230 SFF Configuration
#1
Processor Info 1x Intel Core i3-4xxx 3.x xMB 2C HT xxW GT1 CPU
Memory Info 4GB (1x 4GB) 1600 MHz DDR3 non-ECC
Graphics Info Intel Integrated Graphics
Disks/Optical/Floppy 1x SATA 500 GB 7.2k rpm/ 1x DVD-RW
PSU 240W 92%
OS /BIOS --
Energy Consumption
(Watts)
115 VAC 230 VAC 100 VAC
LAN Enabled LAN Disabled LAN Enabled LAN Disabled LAN Enabled LAN Disabled
Windows Idle (S0)
Windows Busy Typ (S0)
Windows Busy Max (S0)
Sleep (S3)
Off (S5)
Zero Power Mode (EuP)
Heat Dissipation
(Btu/hr)
115 VAC 230 VAC 100 VAC
LAN Enabled LAN Disabled LAN Enabled LAN Disabled LAN Enabled LAN Disabled
Windows Idle (S0)
Windows Busy Typ (S0)
Windows Busy Max (S0)
Sleep (S3)
Off (S5)
Zero Power Mode (EuP)
Z230 SFF Configuration
#2
Processor Info 1x Intel Xeon E3-1280v3 3.6 8MB 4C HT 84W GT0 CPU
Memory Info 8GB (2x 4GB) 1600 MHz DDR3 ECC
Graphics Info 1x NVIDIA Quadro K600 1GB Graphics
Disks/Optical/Floppy 1x SATA 2 TB 7.2k rpm/ 1xDVD-RW
PSU 240W 92%
OS /BIOS --
QuickSpecs
HP Z230 SFF Workstation
System Technical Specifications
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 18

Energy Consumption
(Watts)
115 VAC 230 VAC 100 VAC
LAN Enabled LAN Disabled LAN Enabled LAN Disabled LAN Enabled LAN Disabled
Windows Idle (S0) 32.7 W 32.7 W 32.6 W
Windows Busy Typ (S0) 131 W 130 W 130 W
Windows Busy Max (S0) 154 W 151 W 155 W
Sleep (S3) 2.05 W 1.95 W 2.18 W 2.08 W 2.03 W 1.93 W
Off (S5) 0.83 W 0.76 W 0.95 W 0.88 W 0.82 W 0.75 W
Zero Power Mode (EuP) 0.23 W 0.34 W 0.22 W
Heat Dissipation
(Btu/hr)
115 VAC 230 VAC 100 VAC
LAN Enabled LAN Disabled LAN Enabled LAN Disabled LAN Enabled LAN Disabled
Windows Idle (S0) 112 btu/hr 112 btu/hr 111 btu/hr
Windows Busy Typ (S0) 447 btu/hr 444 btu/hr 444 btu/hr
Windows Busy Max (S0) 525 btu/hr 515 btu/hr 529 btu/hr
Sleep (S3)
6.99 btu/hr 6.65 btu/hr 7.44 btu/hr 7.10 btu/hr 6.93 btu/hr 6.95 btu/hr
Off (S5)
2.83 btu/hr 2.59 btu/hr 3.24 btu/hr 3.00 btu/hr 2.80 btu/hr 2.56 btu/hr
Zero Power Mode (EuP) 0.78 btu/hr 1.16 btu/hr 0.75 btu/hr
Z230 SFF Configuration
#3
Processor Info 1x Intel Xeon E3-1280v3 3.6 8MB 4C HT 84W GT0 CPU
Memory Info 32GB (4x 8GB) 1600 MHz DDR3 ECC
Graphics Info 1x NVIDIA Quadro K600 1GB Graphics
Disks/Optical/Floppy 2x SATA 2 TB 7.2k rpm/ 1xDVD-RW
PSU 240W 92%
OS /BIOS --
Energy Consumption
(Watts)
115 VAC 230 VAC 100 VAC
LAN Enabled LAN Disabled LAN Enabled LAN Disabled LAN Enabled LAN Disabled
Windows Idle (S0) 38.8 W 38.7 W 38.9 W
Windows Busy Typ (S0) 142 W 140 W 141 W
Windows Busy Max (S0) 164 W 161 W 165 W
Sleep (S3) 2.87 W 2.75 W 3.01 W 2.90 W 2.86 W 2.75 W
Off (S5) 0.83 W 0.76 W 0.95 W 0.88 W 0.82 W 0.75 W
Zero Power Mode (EuP) 0.23 W 0.34 W 0.22 W
Heat Dissipation
(Btu/hr)
115 VAC 230 VAC 100 VAC
LAN Enabled LAN Disabled LAN Enabled LAN Disabled LAN Enabled LAN Disabled
Windows Idle (S0) 132 btu/hr 132 btu/hr 133 btu/hr
Windows Busy Typ (S0) 485 btu/hr 478 btu/hr 481 btu/hr
Windows Busy Max (S0) 560 btu/hr 549 btu/hr 563 btu/hr
Sleep (S3)
9.79 btu/hr 9.38 btu/hr 10.3 btu/hr 9.90 btu/hr 9.76 btu/hr 9.38 btu/hr
Off (S5)
2.83 btu/hr 2.59 btu/hr 3.24 btu/hr 3.00 btu/hr 2.80 btu/hr 2.56 btu/hr
Zero Power Mode (EuP) 0.78 btu/hr 1.16 btu/hr 0.75 btu/hr
QuickSpecs
HP Z230 SFF Workstation
System Technical Specifications
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 19

Declared Noise Emissions (Entry-level and High-end configurations)
System Configuration
(Entry level)
Processor Info Intel Core i3-4130
Memory Info 4GB (2x2GB) 1600 MHz
Graphics Info Integrated Intel HD Graphics 4400
Disks/Optical 1x 500 GB 7200 RPM SATA HDD;
DVD-RW SuperMulti ODD
Declared Noise Emissions
(in accordance with ISO
7779 and ISO 9296)
Sound Power (LWAd, bels) Deskside Sound Pressure
(LpAm, decibels)
Idle 3.3
Hard drive Operating
(random reads)
3.3
DVD-ROM Operating
(sequential reads)
System Configuration
(High-end)
Processor Info Intel Xeon E3-1280v3 3.6 GHz
Memory Info 4 x 4GB DDR3 1600 MHz
Graphics Info NVIDIA Quadro K600 graphics
Disks/Optical 2x 500GB 10K rpm SATA HDDs;
SATA Blu-ray ODD
Declared Noise Emissions
(in accordance with ISO
7779 and ISO 9296)
Sound Power (LWAd, bels) Deskside Sound Pressure
(LpAm, decibels)
Idle 3.4
Hard drive Operating
(random reads)
3.5
DVD-ROM Operating
(sequential reads)
QuickSpecs
HP Z230 SFF Workstation
System Technical Specifications
DA - 14630 Worldwide — Version 14 — April 1, 2014 Page 20
