Hp Kayak xa Product manual

Technical Reference Manual

Hardware and BIOS

HP KAYAK XA PC WORKSTATION

Notice

The information contained in this document is subject to change without notice.

Hewlett-Packard makes no warranty of any kind with regard to this

material, including, but not limited to, the implied warranties of

merchantability and fitness for a particular purpose.

Hewlett-Packard shall not be liable for errors contained herein or for incidental

or consequential damages in connection with the furnishing, performance, or use

of this material.

Hewlett-Packard assumes no responsibility for the use or reliability of its

software on equipment that is not furnished by Hewlett-Packard.

This document contains proprietary information that is protected by copyright.

All rights are reserved. No part of this document may be photocopied,

reproduced, or translated to another language without the prior written consent

of Hewlett-Packard Company.

AdobeTM is a trademark of Adobe Systems Incorporated which may be registered

in certain jurisdictions.

Microsoft®, Windows® and MS-DOS® are U.S. registered trademarks of

Microsoft Corporation.

MMXTM is a U.S. trademark of Intel Corporation.

NetscapeTM is a U.S. trademark of Netscape Communications Corporation.

Pentium® is a U.S. registered trademark of Intel Corporation.

SoundBlasterTM is a trademark of Creative Technology Limited.

Windows NT® is a registered trademark of Microsoft Corporation.

Hewlett-Packard France

38053 Grenoble Cedex 9

France

Preface

This manual is a technical reference and BIOS document for engineers and

technicians providing system level support. It is assumed that the reader

possesses a detailed understanding of AT-compatible microprocessor

functions and digital addressing techniques.

Technical information that is readily available from other sources, such as

manufacturer’s proprietary publications, has not been reproduced.

This manual contains summary information only. For additional reference

material, refer to the bibliography, on the next page.

Conventions

The following conventions are used throughout this manual to identify

specific numeric elements:

❒Hexadecimal numbers are identified by a lower case h.

For example, 0FFFFFFFh or 32F5h

❒Binary numbers and bit patterns are identified by a lower case b.

For example, 1101b or 10011011b

Bibliography

❒HP Kayak XA PC Workstation DT User’s Guide manual (D4790-90001).

❒HP Kayak XA PC Workstation MT User’s Guide manual (D4800-90001).

❒HP Kayak XA PC Workstation (Desktop and Minitower) Familiarization

Guide (online - D4790-90901).

❒HP Network Administrator’s Guide (online).

❒HP Kayak XA PC Workstation Service Handbook -

1st edition (5966-8261).

❒HP Support Assistant CD-ROM (by subscription).

Data sheets can be obtained at:

❒Analog AD1816 (sound card controller)

http:\\www.analog.com\products\sheets\ad1816a.html.

❒Cirrus 5465 (graphic controller)

http:\\www.cirus.com\products\categories\graphicsvid.html.

❒Intel Chipsets. 440LX AGPSet (82443LX) and,

PIIX4 PCI/ISA Bridge Chip (82371SB)

http:\\www.intel.com\pcisets\datashts\index.html.

❒Memory

http:\\www.chips.ibm.com\products\memory\sdamart\sdramart.html.

❒Pentium II Processor

http:\\www.intel.com\design\pcisets\datashts\index.html.

❒SCSI Chips

http:\\www.symbios.com\products\scsichps.html.

❒Super I/O

http:\\www.national.com\catalog\personal_superi_desktop.html.

For further information about the availability and where to find the different

documentation, refer to page 21.

How to use this online guide

Click the Go Back button in the toolbar to go back to your previous place in

the guide.

Click the Next Page button in the toolbar to go to the next page in the

guide.

Click the Previous Page button in the toolbar to go to the previous page

in the guide.

Click the First Page button in the toolbar to go to the opening screen of

the guide.

Click a bookmark name (to the left of the screen) to go to the topic

corresponding to that bookmark. Clicking a right-pointing triangle,

for example, will reveal the subordinate bookmarks. Clicking a

downward pointing triangle will hide the subordinate bookmarks.

Click underlined red text to go to the topic indicated. Underlined red

text is text that is “linked” to another topic in the guide.

AAAA

AAA

AAAA

AAA

AAAA

AAA

AAAA

AAA

AAAA

System Overview

External Features

Specifications

Hardware Control Panel

Documentation

Topic

Contents

Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Bibliography. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

How to use this online guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1 System Overview

Package for the Desktop Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Package for the Minitower Models. . . . . . . . . . . . . . . . . . . . . . . . . . . 13

HP Kayak XA PC Workstation Overview . . . . . . . . . . . . . . . . . . . . . . 14

Hardware Control Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Specifications and Characteristic Data . . . . . . . . . . . . . . . . . . . . . . . 16

Physical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Environmental Specifications (Desktop and Minitower) . . . . . . . . . . . . 20

Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Where to Find the Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

2 System Board

System Board and Backplane Boards . . . . . . . . . . . . . . . . . . . . . . . . 26

Architectural View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Chip-Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

The PAC Chip (440LX). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

The PIIX4, PCI/ISA Bridge Chip (82371AB) . . . . . . . . . . . . . . . . . . . . . . 32

Contents

Cache Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Devices on the Processor-Local Bus. . . . . . . . . . . . . . . . . . . . . . . . . . 35

Intel Pentium II Microprocessor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Main Memory Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Devices on the PCI Bus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Integrated Drive Electronics (IDE). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Universal Serial Bus (USB) Controller . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Other PCI Accessory Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Accelerated Graphics Port (AGP) Controller . . . . . . . . . . . . . . . . . . 41

Devices on the SM Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Serial EEPROM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

LM75 Chip. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Main PLL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Devices on the ISA Bus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

The Super I/O Controller (NS 82317) . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Audio Controller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Flash EEPROM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

System Board Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Little Ben . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Other ISA Accessory Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

3 Interface Devices and Mass-Storage Drives

Cirrus 5465 Graphics Controller Chip. . . . . . . . . . . . . . . . . . . . . . . . . 54

Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Video Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Available Video Resolutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

SCSI / LAN Combo Board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Contents

PCI Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

SCSI Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

SCSI / PCI LAN Combo Board Features . . . . . . . . . . . . . . . . . . . . . . . . . 60

10BT/100TX LAN Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

10BT/100TX LAN Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Remote Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Mass-Storage Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Hard Disk Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Flexible Disk Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

CD-ROM Drives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Connectors and Sockets. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

4 HP BIOS

HP/Phoenix BIOS Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Using the HP Setup Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Advanced Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Boot Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Power Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Symbios Logic SCSI Configuration Utility. . . . . . . . . . . . . . . . . . . . . 77

Default Settings You Can Change. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Starting the SCSI Configuration Utility . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Power Saving and Ergonometry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Power-On from Space-Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Soft Power Down. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

BIOS Addresses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

System Memory Map. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Contents

HP I/O Port Map (I/O Addresses Used by the System) . . . . . . . . . . . . . 81

DMA Channel Controllers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Interrupt Controllers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

PCI Interrupt Request Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

5 Power-On Self-Test and Error Messages

Order in Which the Tests are Performed . . . . . . . . . . . . . . . . . . . . . . 86

Error Message Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Beep Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Lights on the Hardware Control Panel . . . . . . . . . . . . . . . . . . . . . . . . 98

Appendix

Video Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Standard VGA Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Extended Video Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

Maximum Refresh Rates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

BIOS Modes Supported . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

System Overview

This manual describes the HP Kayak XA PC Workstation, and provides

detailed system specifications.

This chapter introduces the external features, and lists the specifications

and characteristic data of the system. It also summarizes the documentation

which is available.

1 System Overview

Package for the Desktop Models

Front view

(Multimedia models only)

Front view with

cover removed

Four accessory

board slots

Video memory

Main memory

modules

Hard disk drive

(below power

supply unit)

24X CD-ROM drive

Flexible disk drive

Rear view

USB Serial AParallel

(All icons

shown here are

for informa-

tion, and do not

necessarily

appear on the

PC). KeyboardDisplay Mouse

1 System Overview

Package for the Minitower Models

Front view with

cover removed

Hard disk drive

Main memory Modules

Video Memory Upgrade

Six accessory board slots

24X CD-ROM drive

Serial

Parallel

Mouse

Keyboard

Display

Rear view

USB (All icons shown here are for

information, and do not nec-

essarily appear on the PC).

1 System Overview

HP Kayak XA PC Workstation Overview

1. Models with a LAN or LAN/SCSI board only have one internal mass storage shelf.

2. Models with a LAN or LAN/SCSI board only have one PCI slot.

Component Desktop Minitower

Microprocessor 233, 266 or 300 MHz Pentium II MMX processor with 512 KB cache memory

Main memory

Three DIMM sockets using:

32 MB, 64 MB or 128 MB ECC SDRAM to a maximum of 384 MB, or

16 MB, 32 MB, or 64 MB non-ECC SDRAM to a maximum of 192 MB

Graphics controller

Integrated AGP video controller with 2 MB of built-in video memory and 2 MB of removable video memory

(Rev. A).

Or, an on-board 4 MB (soldered onto the system board) video module (Rev B).

Communications 2 USB connectors, 1 serial port, 1 parallel port

Mass storage 2.5 GB IDE, or 2.1 or 4.5 GB SCSI

5 shelves (3 front-access, 2 internal1)

2.5 or 4.3 GB IDE, or 4.5 GB SCSI

6 shelves (4 front access, 2 internal)

Accessory board slots 5 slots

(1 ISA, 2 PCI2, 2 combination ISA/PCI)

6 slots

(2 ISA, 2 PCI, 2 combination ISA/PCI)

SCSI connectors

(SCSI models only)

Ultra-wide internal SCSI connector and Ultra-narrow external SCSI connector

Audio Integrated 16-bit hi-fi audio processor with music synthesizer and mixer

CD-ROM drive 24X speed IDE CD-ROM on all models

Flexible disk drive New version without bezel New version without bezel

Power supply

Input voltage: 100-127, 200-240V ~

Input frequency: 50/60Hz

Maximum output power: 120W continuous

Input voltage: 100-127, 200-240V ~

Input frequency: 50/60Hz

Maximum output power: 160W continuous

Power saving

On (idle - no file transfer) - Windows 95: 32W (115V/60Hz), 35W (230V/50Hz)

On (idle - no file transfer) - Windows NT 4.0: 45W (115V/60Hz), 45W (230V/50Hz)

Sleep/Suspend mode - Windows 95: 25.5W (115V/60Hz), 29W (230V/50Hz)

Off: 1.6W (115V/60Hz), 3W (230V/50Hz)

1 System Overview

Hardware Control Panel

Desktop Hardware

Control Panel

Power On Status Light

Hard Disk Activity

Light

Volume Control Speaker Out for Headset Microphone connector

Power On/Off Button

Network Activity

Light

PC Lock Activity

Light Reset

Button

PC Lock Button

Minitower Hardware

Control Panel

Power on Status

Light

Hard Disk Activity

Light

Volume Control Speaker Out for Headset Microphone connector

Power On/Off Button

Network Activity

Light PC Lock Activity

Light

Reset Button

PC Lock Button

1 System Overview

Specifications and Characteristic Data

Physical Characteristics

Electrical Specifications

Desktop Characteristic Description

Weight

(excluding display and keyboard)

9 kg (20 pounds)

Dimensions Width: 43.5 cm (17.1 inches)

Height: 13.2 cm (5.2 inches)

Depth: 44.6 cm (17.5 inches)

Footprint 0.194 m2 (2.08 ft2)

Keyboard 18 inches (W) by 7 inches (D) by 1.3 inches (H), when flat, or

18 inches (W) by 7 inches (D) by 2 inches (H), when standing

Minitower Characteristic Description

Weight

(excluding display and keyboard)

15 kg (33 pounds)

Dimensions Width: 19.2 cm (7.56 inches)

Height: 43.8 cm (17.24 inches)

Depth: 44 cm (17.32 inches)

Footprint 0.085 m2 (0.91 ft2)

Keyboard 18 inches (W) by 7 inches (D) by 1.3 inches (H), when flat, or

18 inches (W) by 7 inches (D) by 2 inches (H), when standing

Desktop Parameter Total Rating Notes

Typical per

PCI

Accessory

Slot

Typical per

ISA

Accessory

Slot

Input voltage 100-127

Vac

200-240

Vac

Selected

automatically1

Power 120 W

Voltage range 90 to 264 VAC

Frequency range 45 Hz to 66 Hz

Input Surge Current Protection Maximum of 90A

Safety Ground Leakage Current > 3.5mA

1 System Overview

Specifications and Characteristic Data

Efficiency 70% at maximum power output

Output Voltage Regulation Min Nom Max

11.0 12.0 13.0

4.8 5.0 5.25

3.15 3.3 3.6

-4.5 -5.0 -5.5

-10.8 -12.0 -13.2

4.7 5.0 5.3 (5 VStd By)

Overvoltage Protection Not more than 6.5V for 5V output

Not more than 16V for 12V output

Isolation Voltage 3000Vac primary/secondary

1500Vac primary/ground

Safety Standard IEC950/UL 1950/CSA950/EN60950

Maximum input current 3 A

Current at +5 V 14 A 2.5 A 1 A

Current at +3.3 V 8 A ——

Total cumulated current on

+3.3 V and +5 V

20 A ——

Current at -5 V 0.1 A —0.2 A

Current at +5V standby 0.3 A —0.2 A

Current at +12 V 4 A 0.2 A 0.2 A

Current at -12 V 0.3 A 0.2 A 0.5 A

Minitower Parameter Total Rating Notes

Typical per

PCI

Accessory

Slot

Typical per

ISA

Accessory

Slot

Input voltage 100-127

Vac

200-240

Vac

Manual Switch2

Desktop Parameter Total Rating Notes

Typical per

PCI

Accessory

Slot

Typical per

ISA

Accessory

Slot

1 System Overview

Specifications and Characteristic Data

Power 160 W

(200 W peak)

Voltage range 90-140

Vac

180-264

Vac

Frequency range 45 Hz to 66 Hz

Maximum input current 5 A

Input Surge Current Protection Maximum of 90A

Safety Ground Leakage Current > 3.5mA

Efficiency 75% at maximum power output

Output Voltage Regulation Min Nom Max

11.0 12.0 13.0

4.8 5.0 5.25

3.15 3.3 3.6

-4.5 -5.0 -5.5

-10.8 -12.0 -13.2

4.7 5.0 5.3 (5 VStd By)

Overvoltage Protection Not more than 6.5V for 5V output

Not more than 16V for 12V output

Isolation Voltage 3000Vac primary/secondary

1500Vac primary/ground

Safety Standard IEC950/UL 1950/CSA950/EN60950

Output Voltage Regulation Min Nom Max

Current at +5 V 20 A 2.5 A 1 A

Current at +3.3 V 12 A —

Total cumulated current on

+3.3 V and +5 V

20 A —

Current at -5 V 0.2 A —0.2 A

Current at +5V standby 0.3 A —1 A

Desktop Parameter Total Rating Notes

Typical per

PCI

Accessory

Slot

Typical per

ISA

Accessory

Slot

1 System Overview

Specifications and Characteristic Data

An attempt to draw too much current (such as a short circuit across edge-

connector pins, or an accessory board that is not suitable for these PC

Workstations), will cause the overload protection in the power supply to be

triggered, and the PC Workstation could fail to boot.

Both power supplied on the desktop and minitower models are new

compare to the ones used on previous platforms (Vectra VL 6/xxx and XA 6/

xxx). The difference is at the V standby level, which has been extended to

deliver 300mA instead of 100mA. This extra current is required by the

100TX hardware layer so it can perform a remote power-on at reception of a

magic frame. Using an older power supply for a repair will prevent a remote

power-on at reception of a magic frame.

NOTE When the PC Workstation is turned off with the power button on the front

panel, the power consumption falls below 5 Watts, but is not zero. The special

on/off method used by this PC Workstation extends the lifetime of the power

supply. To reach zero power consumption in “off” mode, either unplug the PC

Workstation from the power outlet or use a power block with a switch. You

should be aware that the PC Workstation will lose its time settings within a

few days if you unplug the PC, or switch off the PC Workstation at the power

block.

1.Note that even though the desktop power supply is autoselect, it is not a full range power supply.

It works in 2 input voltage range and not in one big 90 V to 240 V range.

2.On minitower models, always check the voltage switch position at first power-on.

Current at +12 V 4.4 A —0.2 A 0.2 A

Current at -12 V 0.5 A —0.2 A 0.5 A

Desktop Parameter Total Rating Notes

Typical per

PCI

Accessory

Slot

Typical per

ISA

Accessory

Slot

1 System Overview

Specifications and Characteristic Data

Environmental Specifications (Desktop and Minitower)

Operating temperature and humidity ranges may vary depending upon the

mass storage devices installed. High humidity levels can cause improper

operation of disk drives. Low humidity levels can aggravate static electricity

problems and cause excessive wear of the disk surface.

Environmental Specifications (System Processing Unit, with Hard Disk)

Operating Temperature +5°C to +40°C (+ 40°F to 104° F)

Recommended Operating

Temperature

+15°C to +70°C (+59°F to +158°F)

Storage Temperature -40°F to +158°F (-40°C to +70°C)

Over Temperature Shutdown +50°C (+122°F)

Operating Humidity 15% to 80% (relative)

Storage Humidity 8% to 80% (relative)

Acoustic noise emission:

Sound power

Sound pressure

(as defined ISO 7779)

LwA ≤42 db

LpA ≤37 db

Operating Altitude 10000 ft (3100m) max

Storage Altitude 15000ft (4600m) max
