HP x360 310 G1 PC User instructions

Front, Right
1. WLAN antennas 8. HDMI v1.4 port
2. Microphone 9. USB 3.0 port (closest to HDMI port) and USB 2.0 port
3. HD Webcam 10. Media card reader
4. Webcam LED 11. HDD activity LED
5. Power connector 12. Clickpad
6. AC Adapter/battery light
7. Ethernet port (RJ-45)
QuickSpecs
HP x360 310 G1 PC
Overview
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 1

Tablet
1. Volume + / - button 4. Power button
2. Combo headphone / mic jack 5. Security lock slot
3. USB 2.0 port
Open View
QuickSpecs
HP x360 310 G1 PC
Overview
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 2

Up View
At A Glance
360 Convertible PC combines a super sleek design with key business features and the ability to seamlessly
transition between notebook or tablet with one device.
Windows 8.1 Pro 64, Windows 8.1 Pro for Education 64 or Windows 8.1 SST 64
Intel® Pentium™ or Intel Celeron™ processor
Integrated Intel HD Graphics
11.6" diagonal HD WLED (1366 x 768) TouchscreenChoice of 5400 rpm hard drive (up to 750 GB), 128 GB Solid
State drive, 256 GB Solid State drive SATA-3 TLC or 500 GB Solid State Hybrid drive
0.86 inch (21.9 mm) thin profile
Weight of clamshell starting at 3.08 lbs (1.4 kg)
HP Beats Audio with integrated stereo speakers, integrated microphone, front facing HP HD Webcam
97% scale island-style keyboard
Easily hot dock with one of the optional HP port replicators
2-cell (29 WHr) prismatic battery or 3-cell (43 WHr) prismatic battery
Clickpad w/ multi-touch gesture support image sensor
Security features including a security lock slot and TPM Embedded Security Chip
Wireless connectivity:
Ralink 802.11 b/g/n (1x1) Bluetooth® 4.0 Combo
Qualcomm 802.11b/g/n (1x1) and Bluetooth 4.0 Combo
Realtek 802.11 b/g/n (1x1)
Standard commercial 1 year warranty with upgrade available with HP Care Pack
NOTE: See important legal disclosures for all listed specs in their respective features sections.
QuickSpecs
HP x360 310 G1 PC
Overview
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 3

PRODUCT NAME
HP x360 310 G1 PC
OPERATING SYSTEM
Preinstalled Windows 8.1 Pro 64 *
Windows 8.1 SST 64 *
Windows 8.1 Pro for Education 64*
Office Trial 2013 **
* Not all features are available in all editions of Windows 8.1. Systems may require upgraded and/or separately
purchased hardware, drivers and/or software to take full advantage of Windows 8.1 functionality. See
http://www.microsoft.com/
**Select Windows SST systems include Office Home & Student 2013 with full versions of Word, Excel, PowerPoint
and One Note and is not available in all regions. Office Home & Student 2013 edition software may not be used for
commercial, non-profit or revenue-generating activities.
PROCESSOR
*
Intel® Pentium® N3520 (2.17 GHz, 2 MB L2 cache, 4 cores)*
Intel® Pentium® N3530 (2.58 GHz,2 MB L2 cache, 4 cores)*
Intel® Celeron® N2820 (1.86 GHz, 1 MB L2 cache, 2 cores)*
Intel® Celeron® N2830 (2.42 GHz ,2 MB L2 cache, 2 cores)*
* Multi-Core is designed to improve performance of certain software products. Not all customers or software
applications will necessarily benefit from use of this technology. 64-bit computing on Intel® architecture requires a
computer system with a processor, chipset, BIOS, operating system, device drivers, and applications enabled for
Intel® 64 architecture. Processors will not operate (including 32-bit operation) without an Intel® 64 architecture-
enabled BIOS. Performance will vary depending on your hardware and software configurations. Intel's numbering is
not a measurement of higher performance.
CHIPSET
Integrated SoC PCH
GRAPHICS
Integrated:
Intel HD Graphics
Supports HD playback, streaming, and recording @ 720p 30fps
QuickSpecs
HP x360 310 G1 PC
Features
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 4

DISPLAY
Internal
11.6" diagonal HD* WLED (1366 x 768) SVA Touchscreen
Standard viewing angle flat panel (3.6 mm)
Support LVDS (co-layout with eDP1.3+PSR)
Touchscreen, Multi-touch enabled
External
Up to 32-bit per pixel color depth
VGA
Port supports resolutions up to 1920x1200 external resolution @ 60Hz
HDMI *
1.4 port supports up to 1080p, 1920x1080 at 60Hz
* HD content required to view HD images.
NOTE: Resolutions are dependent upon monitor capability, and resolution and color depth settings.
STORAGE AND DRIVES
Hard Drives
320/500/750 GB 5400 rpm SMART SATA II (7 mm, 7.2 mm for the 750 GB drive)
Solid State Drives
128 GB SATA Solid State Drive
256 GB Solid State Drive SATA-3 TLC
Hybrid Drives
500 GB SATA Solid State Hybrid Drive
NOTE: For hard drives, GB = 1 billion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows 8.1) of
system disk is reserved for the system recovery software.
MEMORY
DDR3L SDRAM 1600 MHz downgraded to 1333 MHz (Pentium) or 1066MHz (Celeron)
1 SODIMM slot On-board
Standard memory up to 8192 MB
NETWORKING/COMMUNICATIONS
Wireless
Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support for the
latest industry standards. Integrated Bluetooth is also available (factory configurable only) and can be combined with
any of the supported wireless LAN and wireless WAN options.
Wireless LAN (WLAN)
Ralink 802.11 b/g/n (1x1) Bluetooth® 4.0 Combo *
Qualcomm 802.11b/g/n (1x1) and Bluetooth 4.0 Combo *
Realtek 802.11 b/g/n (1x1) *
* Wireless access point and internet service required and sold separately. Availability of public wireless access points
limited.
QuickSpecs
HP x360 310 G1 PC
Features
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 5

AUDIO/MULTIMEDIA
Audio
HP Beats Audio™
Dual speakers (front facing)
Single digital microphone with echo cancellation, noise suppression
Formats: MP3, AAC,AAC+, EAAC+ OGG, MIDI
Headphone/Line-out (Beats supported) and Mic-in (combo)
Webcams (Front)
Integrated HP HD * Webcam **
HD* format
720p
2.0MP
Supports videoconferencing and still image capture
High quality fixed focus lens
Video capture at various resolutions up to 1280x720 resolution (720p) and up to 30fps
M-JPEG compression supports higher frame rates for video capture and videoconferencing
Improved low light sensitivity
Improved dynamic range
*HD content required to view HD images.
** Internet access required.
KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS
Keyboard
97% scale backlit -style keyboard features a full-pitch key layout with desktop keyboard features, such as editing keys,
both left and right control and alt keys, and function keys. US and International key layouts are available.
Pointing Devices
Clickpad with image sensor
Touchpad Requirements: Multi-touch gestures enabled, taps enabled as default, and multi-touch capacitive panel
Buttons
Power, Volume Up, Volume Down, Windows Start/Home
SOFTWARE AND SECURITY
Preinstalled Software with Windows Operating System
Browser and Toolbars
Internet Explorer 10
UI Enhancements
HP Utility Center
Baidu Chinese IME (China only)
Productivity
Buy Office
QuickBooks 30-day Trial (NA only)
7-Zip
E-readers and Document Viewers
Kindle
Windows Essentials
QuickSpecs
HP x360 310 G1 PC
Features
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 6

MovieMaker
Photo Gallery
SkyDrive
Photos and Videos
Cyberlink YouCam DE (Windows 8.1 only)
SnapFish URLAdobe® Shockwave Player
HP Connected Photo powered by Snapfish
Music - HP
HP Connected Music powered by Meridian * (includes UMG for Arabic and India) (NA only)
Fingertapps Instruments * Availability of features varies by country. Streaming services may require a paid
subscription. May not be compatible with all music files. Not compatible with DRM tracks. Internet access is required
and not included.
Movies
VUDU Movies (NA only)
Netflix (NA and LA only)
Multimedia Codecs
Dolby
MPEG2
Audio Post processing
Beats Audio™
Games - Microsoft
Solitaire Collection (NA only)
Games - HP
Alawar Game Box for HP
HP Games for Brazil/ Europe / Korea/ ROW/US
Communication
Skype
Pinger (NA and LA only)
App Stores and Content Purchasing
eBay (not available in China)
BestBuy.com (NA only)
Costco.com (NA only)
Amazon (NA only)
Cloud Storage
Box* (Win 8)
HP File Viewer/Connected Drive (US only)
HP Utilities and Support
HP Documentation
Getting Started with Windows 8
HP Registration (Windows 8/8.1 only)
Windows 8.1 Recover Manager Installer
HP Support Assistant**
HP ePrint Driver***
*50 GB Box account available on new 2013 HP Business Desktops, Notebooks, and Tablets. Requires Box
registration. Offer available to new Box users only. Offer subject to change without notice. Box app requires Windows
QuickSpecs
HP x360 310 G1 PC
Features
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 7

8 or 8.1
** Requires Windows and internet access.
*** Requires an Internet connection to HP web-enabled printer and HP ePrint account registration for details, see
www.hpconnected.com .
Standard
McAfee LiveSafe subscription (30 Day Subscription) *
HP SimplePass
Security Lock Slot
TPM Embedded Security Chip
* Internet access required. First 30 days included. Subscription required for live updates afterwards.
Optional
Security Lock
For more information on HP security solutions refer to: http://www.hp.com/go/security .
POWER
Power Supply
External HP 45W Slim Smart AC Adapter *
External 65W EM Smart AC Adapter (PRC, India only)
Power cord included is 3.3-foot (1.0 meter)
*AC adapter uses a 90 degree 4.5mm DC plug
Primary Battery
HP 2-cell prismatic (29 WHr)
HP 3-cell prismatic (43 WHr)
Battery Life*
TBD
System Standby Time
Up to TBD hours
ENVIRONMENTAL
Eco-Label Certifications &
declarations
This product has received or is in the process of being certified to the following approvals
and may be labeled with one or more of these marks:
IT ECO declaration
US ENERGY STAR®
EPEAT <Silver> registered in the United States. See http://www.epeat.net for
registration status in your country.
System Configuration The configuration used for the Energy Consumption and Declared Noise Emissions data for
the Notebook model is based on a "Typically Configured Notebook".
Energy Consumption
(in accordance with US
ENERGY STAR® test
method) 115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation
(Short idle)
8.58 W 9.16 W 8.82 W
QuickSpecs
HP x360 310 G1 PC
Features
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 8

Normal Operation
(Long idle)
6.41 W 6.37 W 6.55 W
Sleep 0.71 W 0.68 W 0.66 W
Off 0.26 W 0.32 W 0.27 W
NOTE:
Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within
the model family. HP computers marked with the ENERGY STAR® Logo are compliant with
the applicable U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications
for computers. If a model family does not offer ENERGY STAR® compliant configurations,
then energy efficiency data listed is for a typically configured PC featuring a hard disk drive,
a high efficiency power supply, and a Microsoft Windows® operating system.
Heat Dissipation * 115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation
(Short idle)
29 BTU/hr 31 BTU/hr 30 BTU/hr
Normal Operation
(Long idle)
22 BTU/hr 22 BTU/hr 22 BTU/hr
Sleep 2 BTU/hr 2 BTU/hr 2 BTU/hr
Off 1 BTU/hr 1 BTU/hr 1 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the service level is
attained for one hour.
Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)
Sound Power
(LWAd, bels)
Sound Pressure
(LpAm, decibels)
Typically Configured - Idle 3.1 24
Fixed Disk - Random writes 3.1 24
Longevity and
Upgrading
This product can be upgraded, possibly extending its useful life by several years.
Upgradeable features and/or components contained in the product may include:
3 USB ports
1 PC card slot (type I/II)
1 ExpressCard/54 slot
1 IEEE 1394 Port
2 SODIMM memory slots
Optional expansion base docking station
1 multi-bay II storage port
Interchangeable HDD
Spare parts are available throughout the warranty period and or for up to "5" years after the
end of production.
Batteries This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the1ppm by weight
Cadmium greater than 20ppm by weight
Battery size: CR2032 (coin cell)
Battery type: Lithium
Battery size: 6-cell high capacity Lithium-Ion battery (optional 8 cell available)
Battery type:
Additional Information This product is in compliance with the Restrictions of Hazardous Substances (RoHS)
directive - 2011/65/EC.
" This HP product is designed to comply with the Waste Electrical and Electronic
Equipment (WEEE) Directive - 2002/96/EC.
QuickSpecs
HP x360 310 G1 PC
Features
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 9

This product is in compliance with California Proposition 65 (State of California; Safe
Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at the <Silver>
level, see www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked per ISO11469
and ISO1043.
This product contains 0% post-consumer recycled plastic (by wt.)
This product is 96.2% recycle-able when properly disposed of at end of life.
Packaging Materials
External:
PAPER/Paper 357 g
Internal:
PLASTIC/Polyethylene low density 13.5 g
PLASTIC/EPE-Expanded Polyethylene 24 g
The plastic packaging material contains at least 75% recycled content.
The paper packaging materials contains at least 75% recycled content.
Material Usage This product does not contain any of the following substances in excess of regulatory limits
(refer to the HP General Specification for the Environment at:
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf ):
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants - may not be used as flame retardants in
plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel - finishes must not be used on the external surface designed to be frequently
handled or carried by the user.
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) - except for wires and cables, and certain retail packaging
has been voluntarily removed from most applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging Usage HP follows these guidelines to decrease the environmental impact of product packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in
packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in packaging materials.
Use readily recyclable packaging materials such as paper and corrugated materials.
Reduce size and weight of packages to improve transportation fuel efficiency.
Plastic packaging materials are marked according to ISO 11469 and DIN 6120
standards.
End-of-life Management and Hewlett-Packard offers end-of-life HP product return and recycling programs in many
QuickSpecs
HP x360 310 G1 PC
Features
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 10

Recycling geographic areas. To recycle your product, please go to: http://www.hp.com/go/reuse-
recycle or contact your nearest HP sales office. Products returned to HP will be recycled,
recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment
information for each product type for use by treatment facilities. This information (product
disassembly instructions) is posted on the Hewlett Packard web site at:
http://www.hp.com/go/recyclers . These instructions may be used by recyclers and other
WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP
equipment.
Hewlett-Packard Corporate
Environmental Information
For more information about HP's commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www8.hp.com/us/en/hp-information/environment/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/PC_GBU_Product_Design_
ISO_14K_Certificate.pdf
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
Low halogen *
RFID support
WEEE compliant (Waste Electric and Electronic Equipment)
RoHS 2 Compliant
MSH/OBL compliant
E-Standby compliant
DLNA certification
Anti-theft **
California Battery Charger Energy Efficiency compliant
Skype Acceptance Test
China CEL label
* External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase
may not be Low Halogen.
**Intel AT security requires a separately purchased Absolute Computrace service subscription and must be activated and
configured. Check with Absolute for availability in your country. Intel and HP assume no liability for lost or stolen data and/or
systems or any other damages resulting therefrom. See http://www.intel.com/technology/anti-theft/
NOTE: This product has received or is in the process of being certified to the following approvals and may be labeled with
one or more of these marks.
WEIGHTS & DIMENSIONS
Weight
Starting at 3.08 lbs (1.4 kg) (weight will vary by configuration)
Dimensions (w x d x h)
12.13 x 8.47 x 0.86 in (308 x 215.1 x 21.9 mm)
NOTE: Height varies depending upon where on the notebook the measurement is made. Weight varies by
configuration and components.
QuickSpecs
HP x360 310 G1 PC
Features
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 11

PORTS/SLOTS
Ports
USB 3.0 - One (right)
USB 2.0 - Two (one right, one left)
HDMI v1.4 - One
VGA - One
Stereo headphone-out/mic-in combo jack - One
RJ-45 (Ethernet) - One
AC adapter Smart Pin plug (4.5mm barrel) - One
Expansion Slots
HP Multi-Format Digital Media Card Reader
Supports SD/SDHC/SDXC
SERVICE AND SUPPORT
HP Services offers a 1 year standard commercial warranty; 1 year limited warranty on primary battery. On-site service
and optional * HP Care Pack Services ** are available to extend your protection beyond the standard warranty. For
more details visit: http://www.hp.com/go/cpc .
*Sold separately or as an optional feature.
** Service levels and response times for HP Care Packs may vary depending on your geographic location. Service
starts on date of hardware purchase. Restrictions and limitations apply. Consult the HP Customer Support Center for
details. http://www.hp.com/go/cpc .
QuickSpecs
HP x360 310 G1 PC
Features
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 12

SYSTEM UNIT
Stand-Alone Power
Requirements (AC
Power)
Nominal Operating
Voltage
19.5 V
Average Operating
Power
TBD W
Max Operating Power < 45 W
Temperature Operating 32° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)
Non-operating -4° to 140° F (-20° to 60° C)
Relative Humidity Operating 10% to 90%, non-condensing
Non-operating 5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature
Shock Operating 40 G, 2 ms, half-sine
Non-operating 200 G, 2 ms, half-sine
Random Vibration Operating 0.75 grms
Non-operating 1.50 grms
Altitude (unpressurized) Operating -50 to 10,000 ft (-15.24 to 3,048 m)
Non-operating -50 to 40,000 ft (-15.24 to 12,192 m)
Planned Industry
Standard
Certifications
UL Yes
CSA Yes
FCC Compliance Yes
ENERGY STAR® TBD models *
EPEAT TBD **
ICES Yes
Australia /
NZ A-Tick Compliance
Yes
CCC Yes
Japan VCCI
Compliance
Yes
KC Yes
BSMI Yes
CE Marking
Compliance
Yes
BNCI or BELUS Yes
CIT Yes
GOST Yes
Saudi Arabian
Compliance (ICCP)
Yes
SABS Yes
UKRSERTCOMPUTER Yes
* Configurations of the HP x360 310 G1 PC that are ENERGY STAR qualified are identified as HP x360 310 G1 PC on HP
websites and on www.energystar.gov .
** EPEAT® registered where applicable. EPEAT registration varies by country. See www.epeat.net for registration status by
country.
For accessibility information on HP products, please visit: http://www.hp.com/accessibility .
QuickSpecs
HP x360 310 G1 PC
Technical Specifications
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 13

DISPLAY
11.6-inch diagonal
WLED HD (1366 x 768)
Active Area 9.88 x 5.67 in (25.61 x 14.40 cm)
Dimensions (W x H) 11.53 x 6.49 in (29.3 x 16.5 cm)
Diagonal Size 11.6 in (29.46 cm)
Contrast Ratio 300:1 (typical)
Refresh Rate 60 Hz
Brightness 200 nit (typical)
Pixel Resolution Format 1366 x 768
Configuration RGB Stripe
Backlight LED
Viewing Angle 40/40/15/30 (Left/Right/Down/Up) (typical)
STORAGE AND DRIVES
750 GB* 5400 rpm
SATA Hard Drive
Drive Weight 0.22 lb (101 g)
Capacity 750 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate Synchronous
(maximum)
300 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 3 ms
Average 13 ms
Maximum 24 ms
Rotational Speed 5400 rpm
Logical Blocks 1,465,149,168
Operating Temperature 32° to 140° F (0° to 60° C) [case temp]
Features ATA Security
QuickSpecs
HP x360 310 G1 PC
Technical Specifications
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 14

500 GB* 5400 rpm
SATA Hard Drive
Drive Weight 0.22 lb (101 g)
Capacity 500 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate Synchronous
(maximum)
150 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 3 ms
Average 13 ms
Maximum 24 ms
Rotational Speed 5400 rpm
Logical Blocks 976,773,168
Operating Temperature 32° to 140° F (0° to 60° C) [case temp]
Features ATA Security
320 GB* 5400 rpm
SATA Hard Drive
Drive Weight 0.22 lb (101 g)
Capacity 320 GB
Height 0.37 in (9.5 mm)
Width 2.75 in (70 mm)
Interface ATA-8, SATA 2.6, 3.0 Gb/s, NCQ
Transfer Rate Synchronous
(maximum)
150 MB/s (Drive Capability)
Seek Time
(typical reads, including
settling)
Single Track 3 ms
Average 13 ms
Maximum 24 ms
Rotational Speed 5400 rpm
Logical Blocks 625,142,448
Operating Temperature 32° to 140° F (0° to 60° C) [case temp]
Features ATA Security
SATA 6 Gb/s 128 GB
Solid State Drive
Drive Weight Up to 10 grams
Capacity 128 GB
Height 0.091 in (2.3 mm)
Width 0.87 in (22 mm)
Interface SATA 3 (6 Gb/s)
Performance Maximum Sequential
Read
Maximum Sequential Write
Up to 510 MB/s Up to 140 MB/s
Logical Blocks 250,069,680
Operating Temperature 32° to 158°F (0° to 70°C) [case temp]
Features ATA Security; ATA-8; SATA 3.0; DIPM; TRIM
* For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36
GB (for Windows 8.1) of system disk is reserved for the system recovery software.
QuickSpecs
HP x360 310 G1 PC
Technical Specifications
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 15

NETWORKING/COMMUNICATIONS
Networking
Integrated Realtek
10/100/1000 NIC
Ethernet Features 10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-
14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses
21-30)
1000 Mbit/s operation (100BASE-T; IEEE 802.3ab; IEEE 802.3 clauses
21-30) ( Support in RTL8161FH-CG only)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and
100 Mbit/s
IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.1q VLAN support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable
Power Management ACPI compliant - multiple power modes
Situation-sensitive features reduce power consumption
Advanced link down power saving for reducing link down power
consumption
Performance Features TCP/IP/UDP Checksum Offload (configurable)
Large send offload and Giant send offload
Receiving Side Scaling
Manageability Wake-on-LAN from standby and hibernation (Magic Packet and
Microsoft Wake-Up Frame); Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB
(802.3x, clause 30))
Comprehensive diagnostic and configuration software suite
Virtual Cable Doctor for Ethernet cable status
Interface PCI Express 1.1 x1 to fully support ASPM L0s/L1 and CLKREQ
NIC Device Driver
Name
Realtek PCIe FE Ethernet Family Controller
Communications
Qualcomm 802.11b/g/n
Bluetooth 4.0 Combo
Card *
Wireless LAN
Standards
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
Interoperability Wi-Fi certified
Cisco Compatible Extensions Program compliant with Microsoft
Windows7 (details at: http://www.hp.com/go/notebooks/WLAN )
Frequency Band 2.402 - 2.482 GHz
Data Rates 802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: 150Mbps for MCS7
Modulation Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, LEAP, EAP-FAST. WAPI
Support for Cisco Security Features (proven compatibility with Cisco
Aironet infrastructure products through the Cisco Compatible
QuickSpecs
HP x360 310 G1 PC
Technical Specifications
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 16

Extensions Program Version 5) with Microsoft Windows Vista and XP
only.
Sub-channels Multinational support with frequency bands and channels compliant to
local regulations.
Media Access Protocol CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming IEEE 802.11 compliant roaming between access points
Output Power
(for CCK)
2
13.5dBm , minimum
Power Consumption Idle associated: 250 mW
Idle unassociated: 150 mW
Transmit: 2.0 W (max)
Receive: 2.0 W (max)
Power Management ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
3
11b:-88dBm@11Mbps,
11g:-74 dBm@54Mbps,
11n:[email protected].
Antenna Type High efficiency dual antenna with spatial diversity, mounted in the
display enclosure
Form Factor PCI-Express Half-MiniCard v1.2
Weight 6 g
Dimensions 3.3 x 26.65 x 29.85 mm
Operating Voltage 3.3v +/- 10%
Temperature Operating
Non-operating
14° to 149° F (-10° to 65° C)
-40° to 176° F (-40° to 80° C)
Humidity Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
LED Activity LED Off - Radio OFF; Solid LED On - RadioON
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation) and
a packet error rate of 10% for 802.11a/g (OFDM modulation).
NOTE: WLAN supplier's client utility is required for Cisco Compatible Extensions support with
Microsoft Windows XP. WLAN may also be compatible with certain third-party software
supplicants. WLAN supplier IHV extensions required for Cisco Compatible Extensions support for
Microsoft Windows Vista and Windows 7.
Bluetooth Specification
V4.0 High Speed, V2.1+EDR, backwards compatible with V1.1, 1.2 and 2.0
Number of Available
Channels
79 (1 MHz) available channels
Data Rates and
Throughput
3 Mbps data rate; throughput up to 2.17 Mbps
Synchronous Connection Oriented links up to 3, 64 kbps, voice
channels
Asynchronous Connection Less links 2178.1 kbps/177.1 kbps
asymmetric or 1306.9 kbps symmetric
Transmit Power -6 dBm to 4 dBm (Bluetooth Class II)
Receiver Sensitivity Better than -80 dBM at 0.1 % raw bit error rate
QuickSpecs
HP x360 310 G1 PC
Technical Specifications
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 17

Power Consumption Peak (Tx) 330 mW
Peak (Rx) 230 mW
Sleep <17 mW
Antenna Internally integrated within module
Range Up to 33 ft (10 m)
Electrical Interface USB 2.0 compliant
Microsoft Windows Plug and Play compliant
Bluetooth Software
Supported
Broadcom Bluetooth for Windows
Microsoft Windows Bluetooth Software
Link Topology Point to Point, Multipoint Pico Nets up to 7 slaves
Security Full support of Bluetooth Security Provisions
Power Management Microsoft Windows ACPI, and USB Bus Support
Self configurable to optimize power conservation in all operating modes,
including Standby, Hold, Park, and Sniff
Certifications All necessary regulatory approvals for supported countries, including:
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Bluetooth Profiles
Supported
Generic Access Profile (GAP)
Service Discovery Application Profile (SDAP)
Serial Port Profile (SPP)
Dial_Up Networking Profile (DUN)
Generic Object Exchange Profile (GOEP)
Object Push Profile (OPP)
File Transfer Profile (FTP)
Synchronization Profile (SYNC)
Hard Copy Cable Replacement (HCRP)
Personal Area Networking Profile (PAN)
Human Interface Device Profile (HID)
Generic Audio/Video Distribution Profile (GAVDP)
Advanced Audio/Video Distribution Profile (A2DP)
FAX Profile (FAX)
Basic Imaging Profile (BIP)
Headset Profile (HSP)
Hands Free Profile (HFP)
Basic Printing Profile (BPP)
VDP (Video Distribution Profile)
AVRCP (Audio Video Remote Control Profile)
* Wireless access point and internet service required. Availability of public wireless access points
limited.
** Sold separately or as an optional add-on feature.
Realtek RTL8188EE
802.11 b/g/n (1x1)
Wireless LAN
Standards
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
Interoperability Wi-Fi certified
Frequency Band 2.402 - 2.482 GHz
Data Rates 802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: card will support rates for NSS=1 for RX and TX for 20 MHz
channels. Short and long guard interval will be supported.
QuickSpecs
HP x360 310 G1 PC
Technical Specifications
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 18

Modulation Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM
Security
1
IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode
only
AES-CCMP: 128 bit in hardware 802.1x authentication types WPA,
WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
WPA2 certification
IEEE 802.11i
Cisco Certified Extensions, all versions through V5
WAPI
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming IEEE 802.11 compliant roaming between access points
Output Power
2
13.5 dBm, nominal
Power Consumption Transmit: 2.0 W (max)
Receive: 1.6 W (max)
Associated to Access Point, Idle: 250 mW nominal
Wireless Button Off: 100 mW nominal
Radio disabled: 75 mW nominal
Power Management ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
3
802.11b:-95 dBm (1 Mbps), -93 dBm (2 Mbps), -91 dBm (5.5 Mbps), -88
dBm (11 Mbps)
802.11g:-90 dBm (6 Mbps), -89 dBm (9 Mbps), -87 dBm (12 Mbps), -85
dBm (18 Mbps), -82 dBm (24 Mbps), -79 dBm (36 Mbps), -76 dBm (48
Mbps), -74 dBm (54 Mbps)
802.11n:-70dBm (72.2 Mbps)
Antenna Connections High efficiency antenna with spatial diversity, mounted in the display
enclosure
Form Factor PCI-Express Half-MiniCard
Dimensions 0.19 x 1.06 x 1.18 in (4.75 x 26.8 x 30 mm)
Operating Voltage 3.3v +/- 9%
Temperature Operating
Non-operating
14° to 158° F (-10° to 70° C)
-40° to 176° F (-40° to 80° C)
Humidity Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
LED Activity LED Off - Radio OFF; Solid LED On - Radio ON
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and
a packet error rate of 10% for 802.11a/g (OFDM modulation).
Ralink RT3290LE
802.11 b/g/n (1x1)
Bluetooth 4.0
Combo * , **
Wireless LAN
Standards
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
Interoperability Wi-Fi certified
Cisco Compatible Extensions Program compliant with Microsoft
Windows7 (details at: http://www.hp.com/go/notebooks/WLAN )
Frequency Band 2.402 - 2.482 GHz
QuickSpecs
HP x360 310 G1 PC
Technical Specifications
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 19

Data Rates 802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: card will support rates for NSS=1 for RX and TX for 20 MHz
channels. Short and long guard intervals shall be supported
Modulation Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, LEAP, EAP-FAST. WAPI
Support for Cisco Security Features (proven compatibility with Cisco
Aironet infrastructure products through the Cisco Compatible
Extensions Program Version 5) with Microsoft Windows Vista and XP
only.
Sub-channels Multinational support with frequency bands and channels compliant to
local regulations.
Media Access Protocol CSMA/CA (Collision Avoidance) with ACK
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming IEEE 802.11 compliant roaming between access points
Output Power
(for CCK)
2
13.5dBm , minimum
Power Consumption Idle associated: 250 mW
Idle unassociated: 150 mW
Transmit: 2.0 W (max)
Receive: 2.0 W (max)
Power Management ACPI compliant power management
802.11 compliant power saving mode
Receiver Sensitivity
3
72.2 Mbps: -70 dBm; 54 Mbps: -74 dBm; 11 Mbps: -88 dBm ; 1 Mbps: -
95 dBm
Antenna Type High efficiency dual antenna with spatial diversity, mounted in the
display enclosure
Form Factor PCI-Express Half-MiniCard
Weight 6 g
Dimensions 3.3 x 26.65 x 29.85 mm
Operating Voltage 3.3v +/- 10%
Temperature Operating
Non-operating
14° to 149° F (-10° to 65° C)
-40° to 176° F (-40° to 80° C)
Humidity Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
LED Activity LED Off - Radio OFF; Solid LED On - RadioON
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation) and
a packet error rate of 10% for 802.11a/g (OFDM modulation).
NOTE: WLAN supplier's client utility is required for Cisco Compatible Extensions support with
Microsoft Windows XP. WLAN may also be compatible with certain third-party software
supplicants. WLAN supplier IHV extensions required for Cisco Compatible Extensions support for
Microsoft Windows Vista and Windows 7.
Bluetooth Specification
QuickSpecs
HP x360 310 G1 PC
Technical Specifications
DA - 14929 Worldwide QuickSpecs — Version 3 — 8.6.2014 Page 20
