HP TFT7600 User manual

HP TFT7600 G2 Rackmount Keyboard Monitor
KVM Console
User Guide
Part Number 615930-001
June 2010 (First Edition)

© Copyright 2010 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the
express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional
warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
ENERGY STAR and ENERGY STAR mark are registered U.S. trademarks.
Intended audience
This document is for the person who installs racks and rack products. This procedure is performed only by trained personnel. HP assumes you are
qualified in performing installations and trained in recognizing hazards in rack products.

Contents
Introduction.................................................................................................................................. 5
HP TFT7600 KVM Console features ...............................................................................................................5
ENERGY STAR compliant....................................................................................................................6
Main components.........................................................................................................................................6
Rear components .........................................................................................................................................7
Installation ................................................................................................................................... 8
Kit contents..................................................................................................................................................8
Installing the HP TFT7600 G2 Rackmount Keyboard Monitor KVM Console .......................................................8
Connecting and routing cables....................................................................................................................12
Accessing the HP TFT7600 KVM Console.....................................................................................................13
Removing the HP TFT7600 KVM Console .....................................................................................................14
Removing the HP 1U Adjustable Toolless Rails...............................................................................................14
Removing PS2 cables with cable-locking mechanism......................................................................................14
Enabling the native display resolution of 1440x900 in HP-UX ........................................................................15
Operational overview ................................................................................................................. 16
On-screen display ......................................................................................................................................16
Launching OSD menu.................................................................................................................................16
Navigating OSD........................................................................................................................................16
OSD menu ................................................................................................................................................17
Brightness/Contrast..........................................................................................................................17
Image control ..................................................................................................................................17
Advanced .......................................................................................................................................18
Auto Configuration...........................................................................................................................19
Factory settings ................................................................................................................................19
Language........................................................................................................................................19
Information......................................................................................................................................
19
Maintenance.............................................................................................................................. 20
Maintenance guidelines..............................................................................................................................20
Cleaning the monitor........................................................................................................................20
Shipping instructions...................................................................................................................................21
Moving a rack with the HP TFT7600 KVM Console installed...........................................................................21
Specifications............................................................................................................................. 22
HP TFT7600 KVM Console specifications .....................................................................................................22
Environmental requirements...............................................................................................................22
Regulatory compliance notices ..................................................................................................... 23
Regulatory compliance identification numbers ...............................................................................................23
Federal Communications Commission notice.................................................................................................23
FCC rating label ..............................................................................................................................23
Class A equipment ...........................................................................................................................23
Class B equipment............................................................................................................................23
Declaration of conformity for products marked with the FCC logo, United States only..............................24
Modifications...................................................................................................................................24
Cables............................................................................................................................................24

Canadian notice (Avis Canadien)................................................................................................................24
European Union regulatory notice................................................................................................................25
Japanese notice .........................................................................................................................................26
BSMI notice...............................................................................................................................................26
Korean notice ............................................................................................................................................26
Chinese notice...........................................................................................................................................27
China energy regulations............................................................................................................................27
Disposal of waste equipment by users in private households in the European Union..........................................27
Power cord requirement..............................................................................................................................27
Power cord statement for Japan...................................................................................................................28
Electrostatic discharge................................................................................................................. 29
Preventing electrostatic discharge ................................................................................................................29
Grounding methods to prevent electrostatic discharge....................................................................................29
Technical support........................................................................................................................ 30
HP contact information................................................................................................................................30
Acronyms and abbreviations........................................................................................................ 31
Index......................................................................................................................................... 32

Introduction 5
Introduction
HP TFT7600 KVM Console features
The HP TFT7600 KVM Console is a rack-mountable 1U integrated flat-panel monitor and keyboard with
touchpad.
NOTE: 1U = 1.75 inches or 44.45 cm
The HP TFT7600 KVM Console is mounted on rails with space available to add a 1U KVM switch box
behind the unit. The console can be used with all HP racks.
The HP TFT7600 KVM Console uses a 43.9-cm (17.3-inch) color-active matrix TFT LCD ("Main
components" on page 6).
Feature Description
Display 43.9-cm (17.3-inch) viewable area display
Resolution 640 x 480 (VGA) through 1280 x 1024 (SXGA), 1440 x 900
(WXGA+), and 1600 x 900 (WXGA+)
Monitor
input Plugs into a standard VGA connector; does not require a special graphics adapter card
Plug and
Play
Plug-and-Play capability if supported by your system
OSD Available in seven languages:
•
English
•
French
•
German
•
Italian
•
Japanese
•
Simple Chinese
•
Spanish
Keyboard
with
touchpad
Three-button touchpad with scroll bar
Power supply 12v DC/36 Watt
Scroll keys Four scroll keys (inverted T)

Introduction 6
ENERGY STAR compliant
The HP TFT7600 KVM Console is ENERGY STAR® qualified.
For more information about the ENERGY STAR® qualifications, see the HP website
(http://www.hp.com/hpinfo/globalcitizenship/environment/products/ecolabels.html).
Main components
Callout Component Function
1 Display release latch Pushes down to unlatch the display
assembly
2 Blue LED
•
Turns on when the display is closed
•
Helps identify the HP TFT7600 KVM
Console in a rack
3 OSD activation button
•
Launches OSD menus
•
Selects
•
Exits menus and OSD
4 OSD scroll up and
down button Used to scroll in the OSD menu and adjust functions
5 Scroll lock LED Lights when Scroll lock is on
6 Cap lock LED Lights when Cap lock is on
7 Number lock LED Lights when Number lock is on

Introduction 7
Callout Component Function
8 USB connection Pass-through to the rear USB port
9 Scroll bar Used to scroll on the monitor
10 Right pick button Used to select the option on the right
11 Middle pick button Used to select the option in the middle
12 Left pick button Used to select the option on the left
13 Touchpad Used to move the mouse on the monitor
Rear components
Callout Component
1 USB pass-through
2 USB keyboard and mouse port
3 PS2 keyboard port
4 PS2 mouse port
5 VGA input port
6 Power connection port
7 Serial firmware port

Installation 8
Installation
Kit contents
Item Quantity
HP TFT7600 KVM Console 1
M6 screws 4
6-32 screws 5
HP Adjustable Toolless Rails 2
Cable management arm, power adapter with brace rail 1
Lock plates 2
USB cables 2
PS2 cables 2
Video cable 1
Power cords 2
USB cable labels 2
This kit might contain extra hardware.
Installing the HP TFT7600 G2 Rackmount Keyboard
Monitor KVM Console
1. Align the HP 1U Adjustable Toolless Rails with the holes marked on the rack, and snap them into
place.
a. Snap one end of the HP 1U Adjustable Toolless Rails into the retna rails.
b. Extend the other half of the HP 1U Adjustable Toolless Rails to meet the appropriate rack depth,
and snap them into place.
NOTE: If the HP 1U Adjustable Toolless Rails do not snap into place, be sure that they align
with the holes marked on the rack. The holes marked on the rack must be in the same location
for the front and rear of the rack.

Installation 9
2. Extend the inner slides until they lock into place.
3. Align the unit with the extended inner slides, and then insert the unit into the rack.

Installation 10
4. From the rear of the rack, slide the brace rail assembly in between the HP 1U Adjustable Toolless
Rails.
5. Align the screw holes on the brace rail with the screw holes on the HP 1U Adjustable Toolless Rails.
6. Using two 6-32 screws, secure the brace rail to the HP 1U Adjustable Toolless Rails.

Installation 11
7. Remove and discard the two shipping screws from the rear of the unit.
8. Attach the cable management arm to the rear of the unit with two 6-32 screws.

Installation 12
9. Connect and route the cables through the cable management arm and unit opening.
Installation is complete.
Connecting and routing cables
When connecting and routing the cables through the cable management arm and cable tray to the HP
TFT7600 KVM Console, use the following cable-routing method to ensure that the cables fit into the tray.
IMPORTANT: Use either the PS/2 cables or USB keyboard/mouse cable when connecting the
unit to a device. Do not use both.
NOTE: The PS/2 cables use the same cable-routing method as the USB keyboard/mouse
cable.
To connect and route the cables:
1. Connect and route the power cable (1).
2. Connect and route the VGA cable (2).
3. Connect and route the USB keyboard/mouse cable (3).
4. Connect and route the USB pass-through cable (4).

Installation 13
The following figure illustrates where the cables connect and how to route the cables in the tray.
Item Description
1 Power cable
2 VGA cable
3 USB keyboard/mouse cable
4 USB pass-through cable
Accessing the HP TFT7600 KVM Console
1. Gently extend the HP TFT7600 KVM Console until the slides lock.
2. Push the display release latch, and then lift the display.

Installation 14
Removing the HP TFT7600 KVM Console
To remove the HP TFT7600 KVM Console, reverse the order of the steps listed in Installing the HP
TFT7600 G2 Rackmount Keyboard Monitor KVM Console (on page 8).
Removing the HP 1U Adjustable Toolless Rails
1. Locate the spring release.
2. Place your hand on the outside of the HP 1U Adjustable Toolless Rails so that you can move the
spring release.
3. Gently move the spring release toward the inside of the rack (1) while moving the HP 1U Adjustable
Toolless Rails out toward you and away from the rack (2).
NOTE: If you cannot gain access to the spring release from the outside of the HP 1U
Adjustable Toolless Rails, a tool might be required to unlock the spring release from the inside
of the HP 1U Adjustable Toolless Rails.
4. Repeat the previous steps for the other HP 1U Adjustable Toolless Rail.
Removing PS2 cables with cable-locking mechanism
PS2 cables have a locking mechanism to provide a secure cable connection. You must use proper
procedures when disconnecting these cables.
CAUTION: Failure to follow proper disconnect procedures could result in damage to the
cable or to your unit.
To properly disconnect a PS2 cable:
1. Grasp the housing.

Installation 15
2. Slide it back to release the locking mechanism and gently pull to remove the cable.
Enabling the native display resolution of 1440x900
in HP-UX
To fix issues related to wide screen panels, verify that you have at least one of the following server
patches (or newer) installed:
•PHSS_40809 (11.31)
•PHSS_40810 (11.23)
For more information about setting resolutions in HP-UX, see the Graphics Administration Guide for HP-UX
11.x servers on the HP website (http://www.docs.hp.com/en/5900-0585/5900-0585.pdf).

Operational overview 16
Operational overview
On-screen display
The OSD buttons are used to operate the HP TFT7600 KVM Console OSD menus.
Callout Component Function
1 OSD activation button
•
Launches OSD menus
•
Selects menu options
•
Exits menus and OSD
2 OSD scroll up and down button Used to scroll in the OSD menu
and adjust the function
Launching OSD menu
To launch the OSD menu:
1. Press the OSD activation button on the front panel. The main menu displays on the screen.
2. To select a menu item, scroll up or down by pressing OSD scroll up and down button.
3. Press the OSD activation button again to select your choice. A second level will expand menu items.
Navigating OSD
To navigate through the OSD menus and functions:
•Use the Up (+) or Down (-) button to scroll through the OSD menu or an OSD sub-menu. The Up (+)
and Down (-) button are also used to adjust or change a function setting.

Operational overview 17
•Use the OSD activation button to select a sub-menu or a function.
Example:
To exit the OSD menu:
1. Press the Down (-) button to scroll to the Exit function.
2. Press the OSD activation button to select the Exit function and exit the OSD menu.
OSD menu
The OSD menu provides access to display settings and functions, enabling the user to customize the HP
TFT7600 KVM Console display settings.
Brightness/Contrast
The Brightness/Contrast option contains the following options:
•Brightness
•Contrast
•Exit sub-menu
Brightness
The Brightness option displays a slider bar to enable the adjustment of the back light brightness.
Contrast
The Contrast option displays a slider bar to enable the adjustment of the screen contrast. Contrast
adjustments are more discernable when the background is white.
Image control
The Image control option contains the following sub-menu:
•Horizontal position
•Vertical position
•Clock
•Phase
•Exit sub-menu
Horizontal position
The H position option displays a slider bar to enable the adjustment of the screen's horizontal position.
The center of the bar is obtained from the factory-preset value for Horizontal Position. At value=MIN, the
selection of + positioning response might vary between XGA and SXGA panels. This is caused by
physical limitations at MIN OSD placement.

Operational overview 18
Vertical position
The V position option displays a slider bar to enable the adjustment of the screen's vertical position.
The center of the bar is obtained from the factory-preset value for Vertical Position.
Clock
The Clock option displays a slider bar to enable the adjustment of the Horizontal Clocks.
Phase
The Phase option displays a slider bar to enable the adjustment of the analog signals phase.
Advanced
The Advanced option provides access to the following options:
•OSD settings menu
•Exit sub-menu
OSD settings
The OSD settings option provides access to the following options:
•Lock OSD settings
oYes
oNo
•Timeout
•V position
•H position
•Exit sub-menu
Lock OSD settings
The Lock OSD settings option locks or unlocks the OSD settings.
Timeout
The Timeout option displays a slider bar at the right side of the OSD display to enable the adjustment of
OSD timeout. The timeout ranges from 5 to 60 seconds with 1-second intervals. The default setting is 10
seconds.
Vertical position
The V position option enables the location of the OSD window to move up or down on the screen.
Horizontal position
The H position option enables the location of the OSD window to move left or right on the screen.

Operational overview 19
Auto Configuration
The Auto Configuration option performs four functions automatically:
•Auto Level—Automatically adjusts the black and white levels of the screen
•Auto Position—Automatically adjusts the position of the screen
•Auto Phase—Automatically adjusts the phase
•Auto Clock—Automatically adjusts the output clock per line to match the input
Factory settings
The Factory settings option enables the user to set the HP TFT7600 back to its original factory settings. The
following options are available in the Factory settings menu list:
•Yes
•No
•Exit sub-menu
Language
The Language option allows the user to change the language in which the menu options are displayed.
The following languages are available:
•English
•French
•German
•Italian
•Japanese
•Simple Chinese
•Spanish
Information
The Information option provides the following unit information:
•Current mode
•Recommended mode
•SW version
•Exit sub-menu

Maintenance 20
Maintenance
Maintenance guidelines
To protect your unit from overheating and other types of damage:
•Use only a power source and connection appropriate for this unit, as indicated on the marking label
and back plate.
•If an extension cord or power strip is used, be sure that the cord or strip is rated for the product.
Also, be sure that the total ampere ratings of all products plugged into the extension cord or power
strip do not exceed 80% of the extension cord or power strip ampere ratings limit.
•Do not overload an electrical outlet, power strip, or convenience receptacle. The overall system load
must not exceed 80% of the branch circuit rating. If power strips are used, do not allow the load to
exceed 80% of the power strip input rating.
•Install the unit near an outlet that you can reach easily. Disconnect the unit by grasping the plug
firmly and pulling it from the outlet. Do not disconnect the plug by pulling the cord.
•Disconnect the unit from the wall before cleaning. Do not use liquid or aerosol cleaners.
•Slots and openings in the monitor are provided for ventilation. These openings must not be blocked
or covered. Do not push objects of any kind into these slots or openings.
•Do not drop the unit or place it on an unstable surface.
•Do not allow anything to rest on the power cord. Do not step on the cord.
•Keep the unit in a well-ventilated area, away from excessive light, heat, and moisture. Keep the
monitor away from high-capacity transformers, electric motors, and other strong magnetic fields.
•Do not attempt to service this product yourself. Adjust only those controls that are covered by the
operating instructions. If the unit is not operating properly or has been dropped or damaged, contact
your HP authorized dealer, reseller, or service provider.
Cleaning the monitor
To clean the display:
1. Turn off and unplug the unit.
2. Dust the panel by wiping the screen with a soft, clean cloth.
If the screen requires additional cleaning, use any anti-static LCD screen cleaner.
CAUTION: Do not use benzene, thinner, ammonia, or any volatile substance to clean the
monitor screen or cabinet. These chemicals might damage the monitor. Never use water to
clean an LCD screen.
