HP Compaq LE2002xi User instructions

NOTE: Shown with fixed stand (not included). Comes with IWC stand (not shown).
1. Menu Opens, selects or exits the OSD menu. 4. OK/auto If the OSD menu is on, press to select the
highlighted menu item.
If the OSD menu is inactive, press to
activate the auto adjustment feature to
optimize the screen image.
2. Minus If the OSD menu is on, press to navigate
backward through the OSD menu and
decrease adjustment levels.
5. Power Turns the monitor on or off.
3. Plus/source If the OSD menu is on, press to navigate
forward through the OSD menu and
increase adjustment levels. If the OSD
menu is inactive, press to activate the
source button that chooses the video signal
input (VGA or DVI).
6. Power LED Blue = Fully powered.
Amber = Sleep mode.
Flashing Amber = Sleep Timer mode.
Model
QC841AA
QuickSpecs
HP Compaq LE2002xi 20-inch LCD Monitor with IWC
Stand
Overview - HP Compaq LE2002xi 20-inch LCD Monitor
DA - 14140 North America — Version 6 — April 26, 2013 Page 1

Introduction
The HP Compaq LE2002xi 20-inch LCD Monitor with IWC Stand allows you to easily attach an HP Compaq Ultra-slim Desktop PC or HP
Thin Client1 onto the back of the monitor stand for the convenience of an "all-in-one" form factor.
Key features and benefits
Integrates your HP Compaq Ultra-slim Desktop PC or HP Thin Client
1
and an HP Compaq LE2002xi 20-inch LCD Monitor with IWC
Stand, allowing you to conveniently put the entire compact system configuration at your fingertips, saving valuable desktop
space and making the most efficient use of space-constrained office environments
Cable management solution keeps the PC and monitor cables together and hidden from view
Vertical height adjustment allows the monitor to be adjusted for maximum user comfort
Entire unit swivels left to right with the touch of a finger which allows easy adjustability to accommodate multiple viewers
1
With the exception of HP gt7720 and HP gt7225 Thin Clients.
QuickSpecs
HP Compaq LE2002xi 20-inch LCD Monitor with IWC
Stand
Overview - HP Compaq LE2002xi 20-inch LCD Monitor
DA - 14140 North America — Version 6 — April 26, 2013 Page 2

Panel Type TN (Twisted Nematic) LED Backlit LCD
Viewable Image Area
(diagonal)
50,8 cm (20 in.) widescreen; diagonally measured
Screen Opening
(W x H)
44,28 x 24,91 cm (17.43 x 9.81 in.)
Aspect Ratio 16:9
Viewing Angle (typical) Up to 170° horizontal/160° vertical (10:1 minimum contrast ratio)
Brightness (typical) * 250 nits (cd/m
2
)
Contrast Ratio (typical) * 1000:1
Dynamic Contrast Ratio
(typical) *
3,000,000:1
Response Time (typical) * 5 ms (on/off)
Pixel Pitch 0.2768 mm
Backlight Lamp Life
(to half brightness)
30,000 hours (min)
Color Gamut (typical) 72%
Color Support ** Can display up to 16.7 million colors
*All performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
** With the use of FRC technology.
On Screen Display
(OSD) Controls
Buttons or Switches Menu, Minus ("-"), Plus/Source ("+"), "OK/Auto" and Power
Languages German, Simplified Chinese, Traditional Chinese, Japanese, English, Spanish,
French, Italian, Netherlands, Portuguese
User Controls Brightness, Contrast, Color(Standard/Warm/Cool/Custom), Image
Control(Clock/Clock Phase/Horizontal Position/Vertical Position/Custom
Scaling/Sharpness/Dynamic Contrast Ratio),OSD Control(Horizontal OSD
Position/Vertical OSD Position/OSD Transparency/OSD Timeout), monitor
Management, Language, Information, Factory Reset, Source Control
Signal Interface/
Performance
Horizontal Frequency 24 to 83 kHz
Vertical Frequency 50 to 76 Hz
Native Resolution 1600 x 900 @ 60 Hz
Preset VESA Graphic
Modes (non-interlaced)
640 x 480 @ 60 Hz
720 x 400 @ 70 Hz
800 x 600 @ 60 Hz
1024 x 768 @ 60 Hz
1280 x 720 @ 60 Hz
1280 x 1024 @ 60 Hz
1440 x 900 @ 60 Hz
1600 x 900 @ 60Hz
Text Mode 720 x 400 @ 70 Hz
QuickSpecs
HP Compaq LE2002xi 20-inch LCD Monitor with IWC
Stand
Technical Specifications - HP Compaq LE2002xi 20-inch LCD Monitor
DA - 14140 North America — Version 6 — April 26, 2013 Page 3

Maximum Pixel Clock
Speed
170 MHz
User Programmable
Modes
Yes (10 user modes)
Anti-Glare Yes
Default Color
Temperature
6500 K
Video/Other Inputs Plug and Play Yes
Input Connectors VGA (analog), DVI-D w/ HDCP
Input Impedance 75 Ohms
Sync Input TTL separate synch
Video Cable One 15-pin D-sub (VGA)
Video Cable Lengths 70 cm (27.56 in.)
Audio No
Audio Cable Length N/A
Power Power Supply Internal power adapter
Input Power 100 -240 VAC, 50 or 60 Hz
Typical Power
Consumption
22 W
Maximum 26 W
Power Saving < 0.5 W
Power Cable Length 1,9 m (6.2 ft.)
Mechanical Dimensions (W x D x H) Unpacked w/stand 48,20 x 25,03 x 36,18 to 48,63 cm
(18.98 x 9.85 x 14.24 to 19.14 in.)
Unpacked w/o stand
(head only)
48,20 x 4,75 x 29,41 cm
(18.98 x 1.87 x 11.58 in.)
Packaged 55,2 x 12,8 x 42,2 cm
(21.73 x 5.04 x 16.61 in.)
Base area (footprint) 23,63 x 15,11cm
(9.30 x 5.95 in.)
Weight Head Only 2,7 kg (5.95 lb.)
Unpacked 5,8 kg (12.76 lb.)
Packaged 8,5 kg (18.7 lb.)
Tilt Range -3 to +20 degrees
Swivel Range 360°
Height Adjustable Yes
Pivot Rotation No
Base Attachable, ships detached
Environmental Temperature - Operating 5° to 35° C (41° to 95° F)
Temperature - Non-
operating
-20° to 60° C (-4° to 140° F)
QuickSpecs
HP Compaq LE2002xi 20-inch LCD Monitor with IWC
Stand
Technical Specifications - HP Compaq LE2002xi 20-inch LCD Monitor
DA - 14140 North America — Version 6 — April 26, 2013 Page 4

Humidity - Operating 20% to 80% non-condensing
Humidity - Non-operating 5% to 95%, 38.7° C max wet-bulb
Altitude - Operating 0 to 5,000 m (16,404 ft)
Altitude - Non-operating 0 to 12,192 m (0 to 40,000 ft)
White LED Backlights Yes
CCFL Panel No
Arsenic-Free Display
Glass
Yes
Low Halogen
2
Yes (everything except external cables)
Mercury-Free Display
Backlighting
Yes
Environmental Data Eco-Label Certifications
& declarations
This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
IT ECO declaration
Energy Consumption 115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation 18.5 W 18.5 W 18.6 W
Sleep 0.2 W 0.2 W 0.2 W
Off 0.1 W 0.1 W 0.1 W
Heat Dissipation * 115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation 63.27 BTU/hr 63.27 BTU/hr 64 BTU/hr
Sleep 0.6 BTU/hr 0.6 BTU/hr 0.6 BTU/hr
Off 0.34 BTU/hr 0.34 BTU/hr 0.34 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one
hour.
Additional Information This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) directive - 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive - 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
Plastics parts weighing over 25 grams used in the product are marked
per ISO 11469 and ISO1043.
This product contains 0% post-consumer recycled plastic (by wt.)
This product is 97.8% recycle-able when properly disposed of at end of
life.
Packaging Materials External: Corrugated carton 1200 gm
Internal: Polyethylene low density 35 gm
Polystyrene foam 500 gm
RoHS Compliance Hewlett-Packard is committed to compliance with all applicable environmental
laws and regulations, including the European Union Restriction of Hazardous
Substances (RoHS) Directive. HP's goal is to exceed compliance obligations by
meeting the requirements of the RoHS Directive on a worldwide basis. By July
QuickSpecs
HP Compaq LE2002xi 20-inch LCD Monitor with IWC
Stand
Technical Specifications - HP Compaq LE2002xi 20-inch LCD Monitor
DA - 14140 North America — Version 6 — April 26, 2013 Page 5

1, 2006, RoHS substances will be virtually eliminated (virtually = to levels
below legal limits) for all HP electronic products subject to the RoHS Directive,
except where it is widely recognized that there is no technically feasible
alternative (as indicated by an exemption under the EU RoHS Directive).
Material Usage This product does not contain any of the following substances in excess of
regulatory limits (refer to the HP General Specification for the Environment at:
http://www.hp.com/hpinfo/globalcitizenship/environment/
supplychain/gen_specifications.html ):
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants - may not be used as flame
retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel - finishes must not be used on the external surface designed to be
frequently handled or carried by the user.
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) - except for wires and cables, and certain retail
packaging has been voluntarily removed from most applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging HP follows these guidelines to decrease the environmental impact of product
packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury and
cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging
materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
packaging materials.
Use readily recyclable packaging materials such as paper and corrugated
materials.
Reduce size and weight of packages to improve transportation fuel
efficiency.
Plastic packaging materials are marked according to ISO 11469 and DIN
6120 standards.
End-of-life Management Hewlett-Packard offers end-of-life HP product return and recycling programs
QuickSpecs
HP Compaq LE2002xi 20-inch LCD Monitor with IWC
Stand
Technical Specifications - HP Compaq LE2002xi 20-inch LCD Monitor
DA - 14140 North America — Version 6 — April 26, 2013 Page 6

and Recycling
in many geographic areas. To recycle your product, please go to:
http://www.hp.com/go/reuse-recycle or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a
responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide
treatment information for each product type for use by treatment facilities.
This information (product disassembly instructions) is posted on the Hewlett
Packard web site at: http://www.hp.com/go/recyclers . These instructions may
be used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
Hewlett-Packard
Corporate Environmental
Information
For more information about HP's commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/
ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/operations/
envmanagement.html
Options
(sold separately)
HP USB Graphics Adapter-
Part number NL571AA
Enables connection of up to six simultaneous displays to help you boost
productivity and multi-task across several open applications. Use one Adapter
to bridge between a notebook or desktop PC and second monitor or use
multiple Adapters to connect several displays to each other.
HP Business PC Security
Lock Kit-Part number
PV606AA
Attaches to the rear of the PC with a six-foot steel cable that can be used to
secure a PC or peripherals such as mice, keyboards, monitors or USB security
devices to protect them against unauthorized removal by physically connecting
the system to an anchor point.
HP LCD Speaker Bar-Part
number NQ576AA
Powered directly by the connected PC, the Speaker Bar seamlessly attaches to
the monitor's lower bezel to bring full audio support to select HP flat panel
monitors. Features include dual speakers with full sound range and dual
external headphone jacks. Sold separately. For more information, refer to the
product's QuickSpecs.
Other Accessories Included VGA cable and AC Power cable
Software Yes - HP Display Assistant
User Guide Languages English, French, Spanish (Int'l), Brazilian Portuguese, Danish, Dutch, Finnish,
French, German, Italian, Norwegian, Spanish, Swedish, Czech, Hungarian,
Polish, Russian, Greek, Slovenian, Turkish, Arabic, Bahasa Indonesian, S.
Chinese, T. Chinese, Korean and Japanese.
Warranty Languages English, LA Spanish, Brazilian Portuguese, German, French, Italian, Turkish,
Greek, Arabic, Russian, Hungarian, Czech, Polish, Japanese, Dutch, Danish,
Finnish, Norwegian, Swedish, S. Chinese, T. Chinese, Korean, Slovenain, Bahasa
Indonesia, Serbian
Color Black
VESA External Mounting Yes (one set of standard 4-hole pattern, 100 mm).
Security Lock-Ready Yes
QuickSpecs
HP Compaq LE2002xi 20-inch LCD Monitor with IWC
Stand
Technical Specifications - HP Compaq LE2002xi 20-inch LCD Monitor
DA - 14140 North America — Version 6 — April 26, 2013 Page 7

Certification and
Compliance
TCO 5.0, VCCI, KC, CECP, FCC, CE, BSMI, ISC, C-Tick, Gost, E-Standy, RoHS, WEEE, ETL, CCC, NOM, KCC, BSMI,
TUV, Microsoft WHQL, China Energy Label Grade 1
Compatibility Compatible with platforms using the VESA standard video modes. Recommended for use with HP products.
Service and Warranty Protected by HP, including a 3 year standard limited warranty. Optional Care Pack Services are extended
service contracts which go beyond your standard warranties.1
QuickSpecs
HP Compaq LE2002xi 20-inch LCD Monitor with IWC
Stand
Technical Specifications - HP Compaq LE2002xi 20-inch LCD Monitor
DA - 14140 North America — Version 6 — April 26, 2013 Page 8

HP Integrated Work Center Stand - USDT / Thin Clients
1. HP Quick Release mounting latch 5. Mounting bracket security thumb-screw
2. Integrated HP Quick Release 6. USDT PC and Thin Client mounting bracket
3. Height-adjustable monitor mount 7. Rear cable management clips
4. Integrated cable management slot 8. Spring-loaded power supply tray
Model
Part Number: LH526AA
QuickSpecs
HP Compaq LE2002xi 20-inch LCD Monitor with IWC
Stand
Overview - HP Integrated Work Center Stand – USDT / Thin Clients
DA - 14140 North America — Version 6 — April 26, 2013 Page 9

Introduction
The HP Integrated Work Center Stand is designed to help maximize the use of limited desk space without compromising performance
or productivity by accommodating an HP Compaq 6005 Pro, or 8000 Series Elite HP Ultra-slim Desktop PC or an HP Thin Client
1
and
most HP 17 to 24-inch * ,
2
diagonal LCD monitors (please refer to compatibility list below) with VESA standard mounting brackets.
Simply mount the USDT or Thin Client on to the back plate with four simple screws, and then attach the monitor to the front of the
stand with the included HP Quick Release. Next, neatly route the cords into the cable management clip and insert the power supply into
the secure spring-loaded drawer to enable the monitor and PC to be combined into a complete system, creating a convenient "all-in-
one" form factor.
* Not all 24-inch monitors supported, please refer to compatibility list below
Key features and benefits
Integrates your HP Compaq 6005 Pro, or 8000 Series Elite HP Ultra-slim Desktop PC or an HP Thin Client
1
and most HP 17 to 24-
inch * ,
2
diagonal LCD monitors, allowing you to conveniently put the entire compact system configuration at your fingertips,
saving valuable desktop space and making the most efficient use of space-constrained office environments
Cable management clips help keep cables neatly dressed and concealed behind the stand
Industry-standard VESA mounting holes enable high or low positioning of the USDT or Thin Client
An adjustable stand with tilt, height and swivel lets you change positions throughout the day, helping you stay comfortable and
productive
Built-in HP Quick Release enables easy installation and removal of monitor
Spring loaded retention drawer securely holds power supplies of many sizes
Cable pass-through design simplifies cable routing and enables a clutter free workspace
* Not all 24-inch monitors supported, please refer to compatibility list below
Compatibility
The Integrated Work Center Stand USDT / Thin Clients is designed to exclusively accommodate the HP Compaq 6005 Pro, or 8000
Series Elite Ultra-slim Desktop PC or HP Thin Client
1
and the HP LCD monitors shown below (each sold separately).
Monitor Monitor Part Number(s) Monitor Monitor Part Number(s)
ESSENTIAL SERIES ADVANTAGE SERIES
LE1711 EM886AA LA1751g EM889AA (available in select
regions)
LE1851w NK022AA LA1905wg NM360AA, NM360A2 (TAA
compliant/US only)
LE1851wl XL867AA (available in select
regions)
LA1951g EM890AA, EM890A2 (TAA
compliant/US only)
LE19f VV081AA LA1951gl XL875AA (available in select
regions)
LE1901w NK570AA LA2006x XN374AA
LE1901wl XL877AA (available in select
regions)
LA22f VU893AA
LE1901wm NP446A LA2205wg NM274AA, NM274A2 (TAA
compliant/US only)
LE1911 EM887AA LA2206x XN376AA
LE2001w NK128AA LA2306x XN375AA
QuickSpecs
HP Compaq LE2002xi 20-inch LCD Monitor with IWC
Stand
Overview - HP Integrated Work Center Stand – USDT / Thin Clients
DA - 14140 North America — Version 6 — April 26, 2013 Page 10

LE2001wl XL866AA (available in select
regions)
LA2405wg NL773AA (Product must be used
in conjunction with a USDT or
Thin Client to be supported.)
LE2001wm VN692AA (available in select
regions)
PERFORMANCE SERIES
LE2201w NK571AA ZR22w VM626A4
TOUCH SERIES
L2105tm EM891AA
QuickSpecs
HP Compaq LE2002xi 20-inch LCD Monitor with IWC
Stand
Overview - HP Integrated Work Center Stand – USDT / Thin Clients
DA - 14140 North America — Version 6 — April 26, 2013 Page 11

Mechanical Tilt range -3 to +20 degrees vertical tilt
Swivel range -180° to + 180°
Height adjustable Yes, range: 13,5 cm (5.3 in)
Pivot rotation No
Dimensions
(H x W x D)
Unpackaged 36,19 x 37,35 x 25,05 cm
(14.25 x 14.7 x 9.93 in)
Packaged 32,0 x 49,0 x 43,8 cm
(12.6 x 19.3 x 17.2 in)
Weight Unpackaged 3,1 kg (6.8 lbs)
Packaged 4,9 kg (10.8 lbs)
Supported weight
capacity
2
The Integrated Work Center Stand has been designed to support 17 to 24-inch diagonal HP LCD monitors
from 3,4 kg to 4,8 kg (7.5 lbs to 10.5 lbs).
Other Accessories included Exclusive Integrated Work Center VGA video cable, HP Compaq Ultra-slim
Desktop cable cover (rear port cover), PC mounting bracket, HP Quick Release,
documentation kit.
Quick Start Guide
languages
English, Spanish, Dutch, French, German, Italian, S. Chinese and Japanese
Warranty languages English, French, German, Italian, Spanish, Japanese, T. Chinese, S. Chinese,
Korean, Indonesian, Brazilian Portuguese and LA Spanish
Color Black/Silver
VESA external mounting Yes (Standard 4 hole pattern, two separate 100 mm patterns on the mounting
bracket)
Option kit contents Integrated Work Center Stand and PC mounting bracket, Integrated Work
Center VGA video cable, HP Compaq Ultra-slim Desktop cable cover (rear port
cover), Quick Release bracket (to attach to back of monitor)
Limited Warranty The Integrated Work Center Stand carries a one-year limited warranty. Technical support is available
seven days a week, 24 hours a day, by phone, as well as online support forums. Certain restrictions and
exclusions apply.
NOTES:
1 With the exception of HP gt7720 and HP gt7225 Thin Clients.
2
HP monitors weighing 3,4 kg to 4,8 kg (7.5 lbs to 10.5 lbs).
QuickSpecs
HP Compaq LE2002xi 20-inch LCD Monitor with IWC
Stand
Technical Specifications - HP Integrated Work Center Stand – USDT / Thin Clients
DA - 14140 North America — Version 6 — April 26, 2013 Page 12

© Copyright 2013 Hewlett-Packard Development Company, L.P.
1
HP Care Pack Services extend service contracts beyond the standard warranties. Service levels and response times for HP Care Packs
may vary depending on your geographic location. Service starts from date of hardware purchase. To choose the right level of service
for your HP product, use the HP Care Pack Services Lookup Tool at http:// www.hp.com/go/lookuptool . Additional HP Care Pack
Services information by product is available at http://www.hp.com/hps/carepack .
2
External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be
Low Halogen.
All specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either
higher or lower. The only warranties for HP products and services are set forth in the express warranty statements accompanying such
products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or
editorial errors or omissions contained herein.
QuickSpecs
HP Compaq LE2002xi 20-inch LCD Monitor with IWC
Stand
Technical Specifications - HP Integrated Work Center Stand – USDT / Thin Clients
DA - 14140 North America — Version 6 — April 26, 2013 Page 13
