HP ProCurve Radio Port 210 User manual

http://www.procure.com
ProCurve Radio Port 230
P r o C u r v e R a d i o P o r t 2 1 0
Radio Port Install Guide
December 2005
DRAFTv.12

© Copyright 2005 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without
notice.
This document contains proprietary information, which is
protected by copyright. No part of this document may be
photocopied, reproduced, or translated into another
language without the prior written consent of Hewlett-
Packard.
Publication Number 5991 3780
Applicable Products
Trademark Credits
Windows NT®, Windows®, and MS Windows® are US
registered trademarks of Microsoft Corporation.
Disclaimer
HEWLETT-PACKARD COMPANY MAKES NO WARRANTY
OF ANY KIND WITH REGARD TO THIS MATERIAL,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. Hewlett-Packard shall not
be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing,
performance, or use of this material.
The only warranties for HP products and services are set
forth in the express warranty statements accompanying
such products and services. Nothing herein should be
construed as constituting an additional warranty. HP shall
not be liable for technical or editorial errors or omissions
contained herein.
Hewlett-Packard assumes no responsibility for the use or
reliability of its software on equipment that is not furnished
by Hewlett-Packard.
Warranty
See the Customer Support/Warranty booklet included with
the product.
A copy of the specific warranty terms applicable to your
Hewlett-Packard products and replacement parts can be
obtained from your HP Sales and Service Office or
authorized dealer.
HP ProCurve Radio Port 230
HP ProCurve Radio Port 210
J9006A
J9004A

3
Introduction
The ProCurve Radio Port 230 and ProCurve Radio Port 210, components of the ProCurve Wireless LAN System, link
wireless 802.11a/b/g devices to the Ethernet network through a wireless services-enabled switch. These devices are
to be used with the HP ProCurve Switch 5300xl with a ProCurve Wireless EDGE Services xl Module or other
compatible wireless services-enabled switch products. These Radio Ports are designed to be simple plug-and-play
devices that require no individual device configuration before being installed into a network. All Radio port
configurations, including country-specific settings, radio channels, radio power, SSID settings, security settings,
management information, and Radio Port firmware is provided through the wireless services-enabled switch.
NOTE: Before installing Radio Ports, a ProCurve wireless services-enabled switch (such as the ProCurve Switch
5300xl with Wireless EDGE Services xl Module installed) should be deployed, configured and operating in a Normal
mode. See the “ProCurve Wireless EDGE Services xl Module Getting Started Guide” for details.
ProCurve Radio Port 230 and 210 Package Contents
• ProCurve Radio Port 230 or Radio Port 210
• Two wall mount screws
• Two wall anchors
• Radio Port Install Guide
• Customer Support/Warranty booklet
Description
The ProCurve Radio Port 230 is a dual-radio IEEE 802.11-compliant device supporting simultaneous 802.11a and b/g
wireless Ethernet connections. It contains two embedded 802.11 b/g (2.4 GHz) omni directional diversity antennas,
and two embedded 802.11a (5.4 GHz) omni directional diversity antennas.
The ProCurve Radio Port 210 is a single radio IEEE 802.11-compliant device supporting 802.11 b/g wireless Ethernet
connections. It contains two embedded 802.11 b/g (2.4 GHz) omni directional diversity antennas.
Both Radio Ports are designed for installation in office environments, either using the wall mount or suspended-
ceiling T-Bar mountings built into the underside of the plastic case. Each Radio Port has one RJ-45 connector
supporting 10/100 Ethernet and requires power from any UL-listed, 802.3af-compatible Power over Ethernet (PoE)
switch or power injector.
Technical Specifications
Dimensions & Weight
Features
• High-performance 802.11-compliant radios
Operating Voltage 48VDC (from 802.3af-compliant power source)
Operating Current 148mA (typical)
Power 7W (typical)
Operating Temperature 32 to 104° F (0 to 40° C)
Non-Operating/Storage Temperature -40°F to 158°F (-40 to 70°C )
Operating Humidity 5 to 95% (non-condensing)
Non-Operating/Storage Humidity 5 to 95% (non-condensing)
Operating Altitude (max) 10,000 ft (3,048 m)
Non-Operating/Storage Altitude 15,000ft.(4,572 m)
Length 249.2mm (9.81in.)
Width 174.9mm (56.88in.)
Height 42.4mm (1.67in.)
Radio Port 230 Weight 0.55kg (1.214lbs)
Radio Port 210 Weight 0.50kg (1.096lbs)

4
• Embedded omni directional diversity antennas
• Integrated 10/100 Base TX RJ-45 port
• Two LED indicators
• Safety wire tie point
• Lap-style lock port
• Slots for wall mounting
• Clips for mounting on a suspended ceiling T-Bar
Radio Characteristics
The ProCurve Radio Port 230 comprises two 802.11 radios: (1) a 802.11 b/g radio operating in the 2.4 to 2.5 GHz band
and (2) an 802.11a radio operating in the 4.9 to 5.875 GHz band. The ProCurve Radio Port 210 has a single 802.11b/
g radio. Both units contain two embedded 2.4-2.5GHz omni-directional diversity antennas and the Radio Port 230 also
contains two embedded 4.9-5.875 GHz omni-directional diversity antennas.
The following table lists the 802.11-compliant operating modes. The three supported 802.11g modes are
simultaneous CCK and OFDM, CCK only, or OFDM only.
Integrated RJ-45 Port
The ProCurve Radio Port 230 and 210 has one RJ-45 connector supporting a full-duplex 10/100 Base-TX Ethernet port
and requires IEEE 802.3af-compliant Power-over-Ethernet (PoE) from an external source such as a PoE switch or
power injector. This Ethernet port is configured as an MDI port and can be connected to any MDIX switch port using
standard straight-through CAT-5 Ethernet cables. For details on cable pinouts, see the Appendices of the 'Installation
and Getting Started Guide' for your ProCurve switch. Installers can use a single CAT-5 cable to supply both Ethernet
connectivity and power to the Radio Port allowing these Radio Ports to be installed up to 100 m (300 ft.) from a PoE-
compliant 10/100 Ethernet port. There is no additional power supply required.
LED Indicators
Each Radio Port has LED indicators on the front of the case that visually display the status of the device. The LED
indicators display connection status and error conditions, as well as network activity for the individual radios in the
Radio Port.
Radio Port 230 LED Indicators
Device Mbps Data Rate Support Utilizing Diversity GHz
802.11a 6, 9, 12, 18, 24, 36, 48, 54 OFDM Transmit and receive 4.9 to 5.875 range
802.11b/g 1, 2, 5.5, 11 CCK
6, 9, 12, 18, 24, 36, 48, 54 OFDM
Transmit and receive 2.4 to 2.5 ISM range
LEDs

5
The Radio Port 230 has two LEDs indicators displaying connection status, error conditions, and networking
activity for each of the two radios. Operation is as follows:
Startup:
Radio Port Startup occurs immediately following the application of PoE power, or following a power or
software reset.
1. Both GREEN and AMBER LEDs light steadily for several seconds, while the Radio Port performs an
internal self-test.
2. The AMBER LED then flashes 3 times per second, while the GREEN LED is off. This indicates that the
Radio POrt is attempting to communicate to a compatible wireless services-enabled switch.
3. Both LEDs then go off for a moment, followed by both LEDs lighting steadily for a few seconds.
4. After this sequence, assuming no error conditions have occurred, the Radio Port will enter Normal
operation mode. This means that the Radio Port has successfully communicated with and been
adopted by a wireless services-enabled switch. If this startup sequence repeats itself, then it is likely
that the Radio Port is unable to contact a compatible wireless services-enabled switch, and the
installer should review the Troubleshooting section below.
Normal Operation:
Once the Radio Port has established a connection to a compatible wireless services-enabled switch, the
Radio Port will begin normal operation. During normal operation, the GREEN LED indicates status of the
802.11 b/g radio, and the AMBER LED indicates status of the 802.11a radio.
•Without Wireless Traffic: Each LED will briefly flash once every 5 seconds, to indicate that power is
on, and the Radio Port is communicating normally to its wireless services-enabled switch. The flashing
may not be synchronous between the two LED indicators.
•With Wireless Traffic: Each LED will briefly flash more frequently than once every 5 seconds, and in an
irregular fashion, to represent wireless traffic on that radio.
Radio Error Mode:
• The GREEN LED flashes on and off steadily once per second if an error prevents the 802.11b/g radio
from operating normally.
• The AMBER LED flashes on and off steadily once per second if an error prevents the 802.11a radio
from operating normally.
Radio Port 210 LED Indicators
The Radio Port 210 has two LEDs indicators displaying connection status, error conditions, and networking
activity for its 802.11 b/g radio. Operation is as follows:
Startup Radio:
•Operation of the indicators is identical to the Radio Port 230 during Startup.
Normal Operation:
•During Normal Operation, the GREEN LED will flash to indicate connection and traffic on the 802.11b/
g radio, similar to the Radio Port 230. The AMBER LED will remain off.
Radio Error Mode:
•The GREEN LED flashes on and off steadily once per second if an error prevents the 802.11b/g radio
from operating normally.
Installation Instructions.
The ProCurve Radio Port 230 and 210 can be mounted either on a wall or on a suspended ceiling T-bar. The Radio Port
are not designed for mounting on a desk. The diagrams on the next page note the key installation features.
To prepare for installation, perform the following steps:

6
1. Match the model number on the purchase order with the model numbers in the packing list and on the case
of the device shipped.
2. Verify that the contents of the box include the intended ProCurve Radio Port 230 or 210 and mounting
hardware:
3. Review site survey and network analysis reports to determine the location and mounting position for the
ProCurve Radio Port 230 and 210.
4. Connect a CAT-5 cable to a compatible 802.3af power source and run the cable to the installation site. Ensure
that there is sufficient slack on the cable to perform the installation steps.
Wall Mount
Radio Port Item Notes
230 J9006A 802.11a & 802.11b/g integrated antenna configuration.
210 J9004A 802.11b/g integrated antenna configuration.
Wall Mount Slot
T-Bar Suspension Clips
See Detail Below
T-Bar Retaining Clip
Safety Wire Tie Point
RJ-45 Port
Lock Port

7
Wall mounting consists of hanging the ProCurve Radio Port 230 or 210 along its width or length using the pair of wide-
shoulder screws provided and mounting slots on the underside of the Radio Port. The ProCurve Radio Port 230 or 210
can be mounted onto any wood, plaster, or cement wall surface using the provided wall anchors when necessary. The
illustration shows a horizontal mount.
Wall Mount Hardware
• Two wide-shoulder Phillips pan head self-tapping screws.
• Two wall anchors.
• Safety wire (recommended) and security cable (optional)
In the event that the original mounting screws are lost, the following screws can be used instead: ANSI Standard)
#6-18 X 0.875in. Type A or AB Self-Tapping Screw, or (ANSI Standard Metric) M3.5 X 0.6 X 20mm Type D Self-
Tapping Screw.
Wall Mount Procedure
1. Lightly mark a vertical line on the wall at the location where the midline of the Radio Port is to be located.
2. Using the alignment arrows on one edge of the Radio Port case as guides, move the edge of the Radio Port to the
midline from step 1. and mark the two points on the midline for the location of the mounting screws. (See diagrams
below)
3. At each of the two points, drill a hole in the wall, insert an anchor (if required), screw the wall mounting screw
into the anchor and stop when there is 2 mm remaining between the screw head and the wall
Note: When pre-drilling holes, the recommended hole size is 3mm (0.125 or 1/8 in.) if the screws are going directly
into the wall and 6mm (0.25 or 1/4 in.) if the provided wall anchors are being used.
4. If required, loop a safety wire, between 1.0 mm (.04in.) and 1.6 mm (.0625in.) in diameter, through the safety wire
tie point and secure the loop. Attach the opposite end of the safety wire to a secure point on the wall.
5. If required, install and attach a security cable to the Radio Port's lock port. The lock port, compatible with laptop-
style security cables, is on the side of the case. Attach the opposite end of the security cable to a secure, stationary
point.
6. Plug the Ethernet cable to the Radio Port's RJ-45 port and connect the opposite end of the cable to a switch with
an 802.3af compatible power source. The Ethernet cable can be tucked inside the cable recess on the underside
of the Radio Port case for a completely clean installation. See diagram below.
7. Place the middle of each of the case's mounting slots over the mounting screw heads.
8. Slide the case down along the mounting surface to hang the mounting slots on the mounting screws.
9. Verify the Radio Port has power by observing that the LED indicators are lit or flashing.

8
See Detail Below
U
se
th
ese a
li
gnmen
t
arrows
t
o mar
k
th
e wa
ll
i
n prepara
ti
on
f
or
i
ns
t
a
lli
ng moun
ti
ng screws

9
RJ45 Wiring Options
The Radio Port case is designed to accommodate multiple options for routing the RJ-45 cable.
Cable exits vertically
Cable exits horizontally
RJ-45 cable
connection
RJ-45 cable tucked into cable recess and routed through wall or tile

10
Suspended Ceiling Tile T-Bar Mount
Mounting the Radio Port 230 or 210 to a suspended ceiling T-Bar grid consists of attaching the Radio Port to the
underside of a T-Bar in a suspended ceiling grid, and twisting the Radio Port to lock the case onto the T-Bar.
Ceiling Mount Hardware
• Safety wire (recommended) and security cable (optional)
Ceiling Mount Procedure
1. Lift the ceiling tiles around the T-Bar where the Radio Port is to be installed.
2. If required, loop a safety wire, between 1.01mm (.04in.) and 1.58mm (.0625in.) in diameter, around the safety
wire tie point and secure the loop. Attach the opposite end of the safety wire to a secure point on the ceiling
or T-bar grid.
3. If required, install and attach a security cable to the Radio Port's lock port. The lock port, compatible with
laptop-style security cables, is on the side of the Radio Port case. Secure the opposite end of the security
cable to a secure, stationary point on the ceiling.
4. Plug the Ethernet cable into the Radio Port's RJ-45 jack and connect the opposite end of the cable to a switch
with an 802.3af-compatible power source. Thread the Ethernet cable through the suspended ceiling T-Bar grid
on the side of the T-Bar where the top of the Radio Port will be located after installation.
5. Position the Radio Port so the back of the Radio Port faces the bottom of the T-Bar. The Radio Port's RJ-45 jack
should be positioned on the same side of the T-Bar as the Ethernet cable descending from above the ceiling.
Position the Radio Port case so that the T-Bar fits into the channel formed into the underside of the Radio Port
case (see diagram).
6. To install the Radio Port on the T-Bar, slide the Radio Port so that the T-Bar Suspension Clip on the opposite
side of the Radio Port case from the RJ-45 connector slips over the T-Bar. Then rotate the Radio Port slightly
(approximately 15 degrees), to lock the remaining T-Bar Suspension Clip into place on the T-Bar. (see diagram).
The T-Bar Retaining Clip will click into place as the Suspension Clips fasten onto the T-Bar.
7. Verify the Radio Port has power by observing the LED indicators
8. Tuck the Ethernet cable into the cable recess on the underside of the Radio Port so that the cable lies next to
the T-Bar. Replace the ceiling tiles around the T-Bar to complete the installation.
T-Bar Suspension Clip (Lock first)
T-Bar Retaining Clip
T-Bar Suspension Clip (Lock second)

11
To Remove the Radio Port from the T-Bar
1. Lift the ceiling tiles away from the T-Bar to which the Radio Port is attached.
2. Using your finger, depress the T-Bar Retaining Clip that locks the Radio Port to the T-Bar
3. Rotate the Radio Port counter clock-wise to release the T-Bar from the Radio Port’s T-Bar Suspension Clips.
Troubleshooting Radio Port Installation
This section describes how to troubleshoot the installation of your ProCurve Radio Port primarily from a hardware
perspective. You can perform more in-depth troubleshooting of your wireless LAN system from the console or web
UI on your wireless services-enabled ProCurve switch. For more information on software configuration or trouble-
shooting, see the "ProCurve Wireless EDGE Services xl Module Getting Started Guide" for details.
Basic troubleshooting relies on the LED indicators to diagnose the condition of the Radio Port. The table below shows
LED patterns on the Radio Port that indicate problem conditions.
Startup Error Checklist
Startup errors occur when the Radio Port is unable to communicate with a compatible wireless services-enable switch,
or when the Radio Port successfully communicates to a compatible switch but the switch is not able to adopt and
manage the Radio Port. The following steps can be used to determine the different circumstances that may be
preventing the Radio Port from being adopted by the switch and operating normally.
1. The network connection between the Radio Port and the wireless services-enabled switch has been disrupted.
Verify that network connectivity between the Ethernet cable and the wireless services-enabled switch by
connecting another device, such as a laptop, to the Ethernet cable and confirming network connectivity to the
switch. Verify that the Ethernet port to which the Radio Port is connected has not been disabled, and if 802.1x
port security is turned on, that the 802.1x Port security is compatible with the Radio Port's 802.1x settings.The
network between the Radio Port and the wireless services-enabled switch has a Layer 3 compatibility issue
(e.g. the two devices are on different subnets.
LED Error Indicators
GREEN LED AMBER LED Diagnostic Tips
Off steadily while Ethernet cable is
linked to a PoE source. Remains off
even when Radio Port is disconnected
from Ethernet cable and reconnected.
Off steadily while Ethernet cable is
linked to a PoE source. Remains off
even when Radio Port is disconnected
from Ethernet cable and reconnected.
Radio Port is not receiving PoE power. Verify that the Ethernet
cable is connected directly to an IEEE 802.3af-compatible PoE
source, and that all cable connections are tight and secure.
Verify that the PoE source device is powered on, and that the
PoE function has been administratively enabled on the source
port connected to the Radio Port. Verify that the network cable
is functioning properly, or try a different cable. Try plugging
the Radio Port into another PoE power source, or connect
another PoE device to the port to confirm if the PoE source is
functioning appropriately.
Both GREEN and AMBER LED Indicators light steadily for several seconds,
followed by the AMBER LED flashing steadily on and off three times a second for
several seconds, then this cycle repeats itself continuously.
The Radio Port is encountering a Startup Error, and is unable to
successfully communicate with or be adopted by a compatible
wireless services-enabled switch. See the Startup Error
checklist below for further diagnostic tips.
Flashes on and off steadily once per
second * The Radio Port has encountered an error that prevents the 802.11b/g radio from operating normally.
* Flashes on and off steadily once per
second
(Radio Port 230 only) The Radio Port has encountered an error
that prevents the 802.11a radio from operating normally.
*This LED Indicator is not important for this diagnosis

12
2. The network between the Radio Port and the wireless services-enabled switch has a Layer 2 compatibility issue
(e.g. the two devices are on different VLANs.)
3. The wireless services-enabled switch may not be configured properly. In the case of the ProCurve Switch 5300xl,
verify that the Wireless EDGE Services xl Module is properly installed, configured, and operational. In particular,
verify that the wireless services' country-code setting has been properly configured, as this setting must be
configured to enable the wireless service to function. Refer to the "ProCurve Wireless EDGE Services xl Module
Getting Started Guide" for details.
4. The wireless services-enabled switch may not be functioning normally. Refer to the "ProCurve Wireless EDGE
Services xl Module Getting Started Guide" for details on verifying operation.
5. The wireless service may have adopted Radio Ports up to it's Authorization Level and may not be authorized to
adopt additional Radio Ports. Review the number of Radio Ports the wireless services-enabled switch has
currently adopted and compare this number to the number of Radio Ports authorized based on the licenses
installed.
CAUTION All HP ProCurve devices are designed to be compliant with the rules and regulations in locations they are sold and
will be labeled as required. Any changes or modifications to HP ProCurve Equipment, not expressly approved by HP,
could void the user’s authority to operate this device.
This device is to be used only with HP ProCurve Switch 5300xl with a ProCurve Wireless EDGE Services xl Module,
or other compatible wireless services-enabled switch. Information on configuration this device to operate in a
compliant manner can be found in the ProCurve 5300 xl Module Installation Guide.
HP Customer Service
If you are still having trouble with your Radio Port or ProCurve wireless services-enabled switch, Hewlett-Packard
offers support 24 hours a day, seven days a week through the use of a number of automated electronic services. See
the Customer Support/Warranty booklet that came with your Radio Port for information on how to use these services
to get technical support. The HP ProCurve web site, www.procurve.com also provides up-to-date support information
under product support. In addition, your HP-authorized network reseller can provide you with assistance, both with
services that they offer and with services offered by HP.
Before Calling Support.
To make the support process most efficient, before calling your networking dealer or HP Support, you first should
retrieve the following information
Information Item Information Location
• product identification • the front of the module,J9004A or J9006A
• product identification for the wireless ser-
vices-enabled switch to which the Radio
Port is intended to connect, and any mod-
ules installed in that switch, if any
• the front of the switch

13
See your Warranty Booklet for the appropriate phone number in your area.
Service Information: For the latest version of this Guide, go to: http://www.procurve.com
Safety and Regulatory Statements
Safety Information
Grounding
• If your LAN covers an area served by more than one power distribution system, be sure their safety
grounds are securely interconnected.
• LAN cables may occasionally be subject to hazardous transient voltages (such as lightning or disturbances
in the electrical utilities power grid). Handle exposed metal components of the network with caution.
Servicing
There are no user-serviceable parts inside this product. Any servicing, adjustment, maintenance or repair must be
performed only by service trained personnel.
This product does not have a power switch; it is powered on when the LAN cable is plugged in.
• details about the Radio Port's status and the
status of the wireless services-enabled
switch including the software (OS) version
of the switch and any installed modules, a
copy of the wireless services configuration,
• a copy of the switch Event Log,
• a copy of the switch status
• counters information
• Switch console (Wireless Services Configura-
tion Level): show command
• switch event Log
• Syslog server entry file, if configured
• copy of your network topology map, includ-
ing network addresses assigned to the rel-
evant devices
• your network records
Information Item Information Location
Documentation reference symbol. If the product is marked with this symbol, refer to the product
documentation to get more information about the product.
WARNING A WARNING in the manual denotes a hazard that can cause injury or death.
CAUTION A CAUTION in the manual denotes a hazard that can damage the equipment or create a non-compli-
ant condition.
Do not proceed beyond a WARNING or CAUTION notice until you have understood the hazardous
conditions and have taken appropriate steps.

14
Regulatory Model Identification Number
For regulatory identification purposes, this product has been assigned a Regulatory Model Number (RMN). The
RMN for your product is RSVLC-0502. The RMN should not be confused with the marketing name (ProCurve Radio
Port 210, ProCurve Radio Port 230) or the Product Number (J9004A, J9006A).
Regulatory Statements
Notice for U.S.A.
Manufacturer's FCC Declaration of Conformity Statement
Product No: J9004A, J9006A
FCC ID No: B94RSVLC-0502, B94RSVLC-0505
Regulatory Model No: RSVLC-0502
Manufacturer:: Hewlett-Packard Company
3000 Hanover Street
Palo Alto, CA 94394-1185 USA
Phone: [phone]
For questions regarding this declaration, contact the Product Regulations Manager at the above address or phone
number.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this
device may not cause harmful interference, and 2) this device must accept any interference received, including inter-
ference that may cause undesired operation.
This device has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful interference to radio com-
munications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/television technician for help.
The FCC requires the user to be notified that any changes or modifications made to the device that are not expressly
approved by the Hewlett-Packard Company may void the user’s authority to operate the equipment.
Tested to Comply
with FCC Standards

zOperations in the band 5.15-5.25GHz are restricted to indoor usage only.
zFCC RF exposure compliance for specific co-located transmitter conditions
(radio port 230) was evaluated for mobile operating configurations, other
co-located configurations or operations in conjunction with any other
antenna or transmitter are not authorized and require separate FCC
approval.

16
5 GHz Operation:
• "This device requires the user to properly enter the current country of operation during the initial setup
of the Radio Port. Once the country of operation has been entered, the Radio Port will automatically limit
the available channels, ensuring compliant operation in the selected country. Incorrectly entering the
country of operation may result in illegal operation and may cause harmful interference to other systems.
The user is obligated to ensure the device is operating according to the channel limitations, indoor/
outdoor restrictions and license requirements for each European Community country as described in this
document. Information on configuring this device can be found in the ProCurve 5300xl Module Installation
Guide.
• "This device employs a radar detection feature required for European Community and EFTA country
operation in the 5GHz band. This feature is automatically enabled when the country of operation is
correctly configured for any European Community or EFTA country. The presence of nearby radar operation
may result in temporary interruption of operation of this device. The radar detection feature will
automatically restart operation on a channel free of radar.
• "This device is restricted to indoor use when operated in EU and EFTA countries using the 5.15-5.35GHz
band (Channels 36, 40, 44, 48, 52, 56, 60 and 64). See the table below for the allowed 5GHz channels
in each band.
Operation Using 5 GHz Channels in the European Community
The user must ensure operation of this device is in conformance with European National spectrum usage laws as
shown below and elsewhere in this document.
Frequency Band
(MHz) Allowed Channels Usage Maximum EIRP (mW) Maximum EIRP (dBm)
5150-5250 36,40,44,48 Indoor Use only 200 23
5250-5350 52,56,60,64 Indoor Use only 200 23
5470-5725 100, 104, 108, 112, 116, 120, 124, 128, 132,
136, 140 Indoor or outdoor use 1000 30

17
Notice for Canada
This device complies with the limits for a Class B digital device and conforms to Industry
Canada standard ICES-003. Products that contain a radio transmitter comply with Industry
Canada standard RSS210 and are labeled with an IC approval number.
Cet appareil numérique de la classe B est conforme à la norme ICES-003 de Industry Canada.
La radio sans fil de ce dispsitif est conforme à la certification RSS 210 de Industry Canada et
est étiquetée avec un numéro d'approbation IC.
This device complies with the Class B limits of Industry Canada. Operation is subject to the
followingtwoconditions:1)thisdevice may notcause harmful interference,and2) this device
must accept interference received, including interference that may cause undesired
operation.

18
EU Declaration of Conformity
DECLARATION OF CONFORMITY
according to ISO/IEC Guide 22 and EN 45014
Manufacturer's Name: Hewlett-Packard Company
Manufacturer's Address: 8000 Foothills Blvd.
Roseville, CA 95747-5502
U.S.A.
declares, that the product
Product Name: HP Procurve Radio Port 210, 230
Product Number(s): J9004A, J9006A
Regulatory Model: RSVLC-0502
conforms to the following Product Specifications:
Safety: EN 60950-1:2001 / IEC 60950-1:2001
Health: EU 1999/519/EC
EMC: EN 55022:1998 +A1+A2 / CISPR 22:1997 +A1+A2 Class B1
EN 301 489-1 V1.4.1 (2002-08)
EN 301 489-17 V1.2.1 (2002-08)
EN 60601-1-2:2001 / IEC 60601-1-2:2001
Radio: EN 300 328 V1.4.1 (2003-04)
EN 301 893 V1.2.3 (2003-08)
Supplementary Information:
The product herewith complies with the requirements of the Low Voltage Directive
73/23/EEC, the EMC Directive 89/336/EEC and the R&TTE Directive 1999/5/EC and
carries the CE marking accordingly.
1) The Product was tested in a typical configuration with a laptop computer.
Roseville, December 20 2005
European Contact: Your local Hewlett-Packard Sales and Service Office or Hewlett-Packard GmbH, Department
HQ-TRE, Herrenberger Straße 140, D-71034 Böblingen (FAX: + 49-7031-14-3143)

19
Notice For Japan
Notice For Taiwan:
DGT LPD (Low Power devices) Statement

20
Recycle Statements
Waste Electrical and Electronic Equipment (WEEE) Statements
1
Recycle Statements
Waste Electrical and Electronic
Equipment (WEEE) Statements
Disposal of Waste Equipment by Users in Private Household in the European Union
This symbol on the product or on its packaging indicates that this product must not be disposed of with
your other household waste. Instead, it is your responsibility to dispose of your waste equipment by
handing it over to a designated collection point for the recycling of waste electrical and electronic
equipment. The separate collection and recycling of your waste equipment at the time of disposal will
help to conserve natural resources and ensure that it is recycled in a manner that protects human health
and the environment. For more information about where you can drop off your waste equipment for
recycling, please contact your local city office, your household waste disposal service or the shop where
you purchased the product.
Bortskaffelse af affald fra husstande i den Europæiske Union
Hvis produktet eller dets emballage er forsynet med dette symbol, angiver det, at produktet ikke må
bortskaffes med andet almindeligt husholdningsaffald. I stedet er det dit ansvar at bortskaffe kasseret
udstyr ved at aflevere det på den kommunale genbrugsstation, der forestår genvinding af kasseret
elektrisk og elektronisk udstyr. Den centrale modtagelse og genvinding af kasseret udstyr i forbindelse
med bortskaffelsen bidrager til bevarelse af naturlige ressourcer og sikrer, at udstyret genvindes på en
måde, der beskytter både mennesker og miljø. Yderligere oplysninger om, hvor du kan aflevere kasseret
udstyr til genvinding, kan du få hos kommunen, den lokale genbrugsstation eller i den butik, hvor du købte
produktet.
Likvidace zařízení soukromými domácími uživateli v Evropské unii
Tento symbol na produktu nebo balení označuje výrobek, který nesmí být vyhozen spolu s ostatním
domácím odpadem. Povinností uživatele je předat takto označený odpad na předem určené sběrné
místo pro recyklaci elektrických a elektronických zařízení. Okamžité třídění a recyklace odpadu
pomůže uchovat přírodní prostředí a zajistí takový způsob recyklace, který ochrání zdraví a životní
prostředí člověka. Další informace o možnostech odevzdání odpadu k recyklaci získáte na
příslušném obecním nebo městském úřadě, od firmy zabývající se sběrem a svozem odpadu nebo v
obchodě, kde jste produkt zakoupili.
