The dependable HP NetServer LH 3 has the performance, availability, and
scalability features your growing business needs, all in one compact package,
all at departmental server prices:
•Up to 2 Intel®Pentium® II 450MHz, or Pentium III 500MHz, 550MHz or
600MHz processors with 100 MHz front-side bus. Tool-free upgrade to
four-way Intel PentiumII Xeonor Pentium III Xeon processing
•Capacity for up to 12 Ultra2 SCSI drives driven by an integrated dual-
channel HP NetRAID controller with I2O
•Up to 1GB memory capacity with registered ECC SDRAM and memory
scrubbing
•Hot-swap power supplies and fans
•Automatic hardware-level IRQ re-directs using HP’s Smart IRQ
technology to ease configuration and boost performance
•Supports industry-leading DAT or DLT technology. For reliable,
timesaving, automated network backup choose the HP SureStore
DAT24x6i autoloader
•Integrated HP Remote Assistant and optional HP TopTools Remote
Control card for easiest remote access, advanced security, and
diagnostics
•HP TopTools for Servers with Web interface for device management, HP
OpenView ManageX/SE for NOS and application management
Hewlett-Packard redefines the
standard for departmental servers
with the HP NetServer LH 3.
Incorporating the latest
performance, industry-leading
storage, and high-availability
technologies, this workhorse is
loaded with features you’d expect
only in high-end servers.

2
VSHFLILFDWLRQV
+
3
+3 1HW6HUYHU 1HW6HUYHU  D
DQG/+U
QG /+ U
)HDWXUHV
3HUIRUPDQFH
Processor Up to 2 Intel Pentium II 450MHz or Pentium III 500MHz, 550MHz or 600MHz with
100MHz bus
Cache 512KB ECC L2 cache per processor
ECC Memory •128MB high-performance 100MHz ECC SDRAM standard with memory scrubbing
•1GB maximum capacity
I/O Expansion Slots 8 total full-length 32-bit PCI (one occupied by preinstalled 10/100TX NIC,
1 shared with 2/3 length ISA)
Controllers •Integrated dual-channel HP NetRAID disk array controller with I2O
•Integrated dual Ultra2 SCSI controllers
•Additional Ultra2 to SE (single-ended) converter
Mass Storage System •4 front-accessible (half-height) shelves
−One 3.5-inch flexible disk drive
−One CD-ROM drive
−Two open common tray (non-hot-swap) shelves, suitable for drives or tape
backup (DLT, DDS, autoloader)
•12 front-accessible hot-swap shelves
−6 low-profile standard (also supports 4 half-height or mixed low-profile and half-
height)
−6 additional low-profile (or 4 half-height) with optional cage for full duplex
capability
Maximum Internal Storage 218.4GB maximum hot-swap (12 x 18.2GB half-height drives), plus two 9.1GB
common tray drives for maximum internal storage of 236.6GB
Video •Integrated; supports 1024x768, 256-color resolution at 60–75Hz
•1MB standard video memory, upgradeable to 2MB
•Super VGA drivers available with operating system
CD-ROM Drive 32x Max EIDE
Flexible Disk Drive 3.5” 1.44MB flexible disk drive
Built-in I/O Ports •Two SCSI knock-outs
•One 25-pin parallel port
•Two 9-pin serial/RS-232 ports
•Video port
•Mini-DIN keyboard and mouse ports
•Management port (9-pin)
Keyboard and Mouse Localized keyboard and two-button mouse1
1Not included with HP NetServer LH 3r

3
VSHFLILFDWLRQV
+
3
+3 1HW6HUYHU 1HW6HUYHU  D
DQG/+U
QG /+ U
)HDWXUHV
$YDLODELOLW\
High-Availability/Clustering Support For further information on cluster support go to:
http://www.hp.com/netserver/products/cluster
Self-Restart Capability Automatic Server Restart (ASR) that reboots the server in the event of a NOS hang
Self-Correcting Memory Manageable Error Checking and Correcting (ECC) system and cache memory with
memory scrubbing feature
Hot-Swap Disk Drives •Supports 4.2GB, 9.1GB, and 18.2GB 7,200rpm Ultra2 SCSI disk drives
•Supports 9.1GB and 18.2GB 10,000rpm Ultra2 SCSI disk drives
•Hot-swap and hot-spare support
Disk Array Controller •Integrated dual-channel HP NetRAID disk array controller with I2O technology
•16MB write-back cache
•Supports RAID 0, 1, 3, 5, 10, 30, 50
Advanced Cooling System •6 hot-swap fans standard
•2 additional hot-swap fans optional (for Totally Cool redundant system cooling)
•Active fan-speed control and failure sensing
•Superior air flow design for low internal temperature rise
IPMI (Intelligent Platform
Management Interface) •Open specification for system component monitoring
•Foundation for self-healing
Network Interface Preinstalled 10/100TX network interface card with support for optional network
interface card to support redundancy, load balancing, and Cisco®Fast EtherChannel®
Automatic Tape Backup Optional automated DAT backup with up to 24GB to back up daily. With six
cartridges there is a cartridge for every day, Monday to Friday; with a slot dedicated
to a cleaning cartridge, backup is reduced to a once-weekly task of changing the
magazine, so maintenance is easier.
0DQDJHDELOLW\

Installation and Configuration •HP NetServer Navigator with automated, menu-driven system setup
and configuration
•Guided network operating system installation
•Automatic installation of monitoring tools
Management Software •HP TopTools for Servers, a comprehensive server management solution with an
intuitive browser-based user interface; facilitates troubleshooting, administration,
and information collection
•Detailed inventory information provided through standard DMI 2.0 protocol
•Industry-leading HP OpenView ManageX/SE for NOS and application management
•Easy integration with other leading network and system management products
Remote Administration •Integrated HP Remote Assistant provides emergency remote access with a single
event log and expanded inventory data collection for faster troubleshooting
•Optional HP TopTools Remote Control card for remote LAN access, advanced
security, and online diagnostics
•File transfer capabilities for secure and easy remote updates
1See HP NetServer Management Web site at http://www.hp.com/go/netserver_mgmt

4
VSHFLILFDWLRQV
+
3
+3 1HW6HUYHU 1HW6HUYHU  D
DQG/+U
QG /+ U
)HDWXUHV
([SDQGDELOLW\
Design Features •Tool-free access and interchangeable side covers
•All major assemblies easy to remove for upgrades or repair
•Simple conversion from pedestal to rack configuration
•Physically compatible with standard 19-inch racks
)OH[LELOLW\
Supported Operating Systems •Microsoft®Windows NT®Server 3.51 and 4.0; Novell®NetWare®, IntranetWareTM,
and NetWare SFTTMIII; Red Hat Linux 6.0; SCO®OpenServerTM and UnixWare®;
IBM®OS/2®Warp Server; and Banyan®VINES®
6HFXULW\ DQG 6DIHW\
System Security •Startup password
•Network server mode
•Power reset switch cover and keyboard lock button
•Enable or disable serial port, flexible disk drives, and write operations to
flexible disk drives
•Chassis intrusion detection
•System lock and hot-swap hard disk drive lock
6HUYLFH DQG 6XSSRUW
Warranty 3-year, next-business day, onsite limited warranty from HP or authorized resellers
(standard business hours) worldwide
HP SupportPack Options •Free telephone support for basic setup, installation, and troubleshooting in
North America, Europe, and Asia Pacific during warranty
•Optional HP SupportPack for 4-hour response during standard business hours
•Optional HP SupportPack for 24 hours a day, 7 days a week
•Optional HP SupportPack for Comprehensive Technical Support
Reseller Support Services Comprehensive reseller support framework to ensure successful support of
HP NetServers, includes:
•Proactive Notification e-mail service1
•Service and support Web site1
•Server Management and Hardware Troubleshooting courses (STAR)1
•Troubleshooting Toolkit1
•24x7 telephone support for authorized resellers
•HP BusinessBuilders - blueprints for new business opportunities
1See http://www.hp.com/netserver/servsup for details

5
VSHFLILFDWLRQV
+
3
+3 1HW6HUYHU 1HW6HUYHU  D
DQG/+U
QG /+ U
)HDWXUHV
5HJXODWRU\ &RPSOLDQFH
Electromagnetic Emissions •USA: FCC Class B (Self Declaration)1
•EU Countries: EN 55022 Class B1
•Korea: M of C Class A
•Japan: VCCI Class B1
•Australia/New Zealand: CISPR 22 Class B1
•Taiwan: BCQI Class A
•IEC 1000-3-2: Harmonic Current
•IEC 1000-3-3: Voltage Fluctuation and Flicker
Electromagnetic Immunity Generic Immunity (EN50082-1, EU Countries), including
•ESD (IEC-801-2): 4KV Contact, 8KV Air
•Radiated Immunity (IEC-801-3): 3V/m, 80% AM Mod, 27MHz-1000MHz
•EFT (IEC-801-4): 1.0KV Power, 0.5KV I/O lines
Safety •EN 60950/IEC 950 Compliance (International)
•UL Listed (USA, File E139742)
•CUL Listed (Canada, File E139742)
•NOM Certified (Mexico)
•TÜV Certified (Germany)
•CE Marking (Europe)
•CSA Certified (Canada, File LR106647)
1Class A for Pentium III 500MHz, 550 MHz, and 600MHz processors.

6
VSHFLILFDWLRQV
+
3
+3 1HW6HUYHU 1HW6HUYHU  D
DQG/+U
QG /+ U
$FFHVVRULHV
3URGXFW $FFHVVRU\

3URGXFW 1R
Memory •64MB 100MHz ECC SDRAM DIMM
•128MB 100MHz ECC SDRAM DIMM
•256MB 100MHz ECC SDRAM DIMM
•1MB Video RAM
D6097A
D6098A
D6099A
D4219A
Processors •Pentium II 450MHz, 512KB cache
•Pentium III 500MHz, 512KB cache
•Pentium III 550MHz, 512KB cache
•Pentium III 600MHz, 512KB cache
D7032A
D7129A
D8583A
D9342A
Storage Devices •4.2GB, Ultra/Wide SCSI disk drive (7,200rpm–common tray)
•4.2GB, low-profile, hot-swap Ultra2 SCSI disk drive (7,200rpm)
•9.1GB, Ultra/Wide SCSI disk drive (7,200rpm–common tray)
•9.1GB, low-profile, hot-swap Ultra2 SCSI disk drive (7,200rpm)
•9.1GB, low-profile, hot-swap Ultra2 SCSI disk drive (10,000rpm)
•18.2GB, low-profile, hot-swap Ultra2 SCSI disk drive (7,200rpm)
•18.2GB, low-profile, hot-swap Ultra2 SCSI disk drive (10,000rpm)
•18.2GB, half-height, hot-swap Ultra2 SCSI disk drive (7,200rpm)
•18.2GB, half-height, hot-swap Ultra2 SCSI disk drive (10,000rpm)
D4910A
D6104A
D4911A
D6106A
D6107A
D7174A
D7175A
D6108A
D7031A
Internal Storage Expansion Second drive cage for up to 6 additional hot-swap drives2D6077A
Disk Controllers & SCSI Cables •Integrated dual-channel HP NetRAID with I2O technology
•HP NetRAID-1 Disk Array Controller (1 channel)
•HP NetRAID-1Si Disk Array Controller (1 channel)
•HP NetRAID-3Si I2O Disk Array Controller (3 channels)
•HP Ultra/Wide SCSI PCI Controller
•2.5m SCSI Cable to connect from HP NetRAID Family Controller
to External Storage3
•HP NetServer LH 3/LH 4 Internal SCSI Cable Kit4
included
D4992A
D2140A
D5955A
D5025A
D6020A
D4282B
External Storage Solutions •HP NetServer Storage System/6
•HP NetServer Rack Storage/12 (Ultra2 SCSI)
•HP NetServer Rack Storage/12 SCSI Card
D3604B
D5989B
D6025B
Backup Devices1•Internal HP SureStore DAT24i DDS-3 tape drive
•Internal HP SureStore DAT24x6i DDS-3 Autoloader
•Internal HP SureStore DLT 40i DLT 4000 tape drive
•External HP SureStore DAT24e DDS-3 tape drive
•External HP SureStore DAT24x6e DDS-3 Autoloader
•External HP SureStore DLT 40e DLT 4000 tape drive
TapeRack:
•HP SureStore TapeRack Enclosure
•HP SureStore DLT 24r DDS-3 tape drive
•HP SureStore DLT 40r DLT 4000 tape drive
C1555C
C5677A
C5647A
C1556C
C1559B
C5679A
C5695A
C5696A
C5697A
1Please see the
HP NetServers Configuration Guide
for important technical information when choosing your
accessories or go to http://www.hp.com/go/netserver. For HP SureStore backup see http://www.hp.com/storage.
2When used in RAID configuration, an additional SCSI HBA (D5025A) is required to support tape devices. This
upgrade includes cable to connect to internal SCSI controller.
32.5m SCSI Cable 68-pin male ultra-high-density offset connector to 68-pin male high-densityconnector.
4Use in HP NetServer LH 3/LH 4 when HP NetRAID Family Controller is used with internal storage.

7
VSHFLILFDWLRQV
+
3
+3 1HW6HUYHU 1HW6HUYHU  D
DQG/+U
QG /+ U
$FFHVVRULHV
3URGXFW $FFHVVRU\

3URGXFW 1R
Hot-Swap Redundant Fans and
Power Supplies •Secondary fan tray, second power supply cage with one power supply module
•Additional power supply module for total redundancy
D6093A
D6095A
Network Interface Cards •HP NetServer 10/100TX PCI LAN adapter
•HP DeskDirect 10/100VG PCI LAN adapter D5013A J2585B
Remote Management •Integrated HP Remote Assistant
•HP TopTools Remote Control Card including battery
•Optional AC adapter required for remote power on
Included
D6028A
D6138A
Uninterruptible Power Supply UPS devices are available from American Power Conversion (APC). For
additional information, contact your local APC reseller, or see APC’s web page
at http://www.apcc.com
Conversion Kit Pedestal-to-rack conversion kit D6094B
Upgrade Kits2LH 3 to LH 4 upgrade kit includes 2 Intel Pentium II Xeon or Pentium
III Xeon processors, system board, and 256MB 50ns EDO DIMM kit
(4 x 64MB)
•Intel Pentium II Xeon 450MHz processors with 1MB L2 cache
•Intel Pentium III Xeon 500MHz processors with 512K L2 cache
•Intel Pentium III Xeon 500MHz processors with 1MB L2 cache
•Intel Pentium III Xeon 550MHz processors with 512K L2 cache
•Intel Pentium III Xeon 550MHz processors with 1MB L2 cache
•Intel Pentium III Xeon 550MHz processors with 2MB L2 cache
D7015A
D7111A
D7112A
D9330A
D9331A
D9332A
Monitors •HP 15” Rackmount Flat Panel Monitor/Keyboard
•HP 50 15" Color Monitor
•HP M500 15" Color Monitor
•HP 70 17" Color Monitor
•HP M700 17" Color Monitor
J1470A
D2826A
D2832A
D2837A
D2838A
Disk Tray •3.5” hard disk drive mounting trays (3 pack, non-hot-swap)
•Tape/DAT/CD-ROM mounting trays (3 pack, no front panel)
•HP NetServer low-profile hot-swap disk tray
•HP NetServer half-height hot-swap disk tray
D2198B
D2199A
D6128A
D6127A
HP Racks For a complete list of racks and rack accessories, download the HP NetServer Rack
Assistant tool from http://www.hp.com/netserver/products/racks
Keyboard and Mouse •HP NetServer keyboard
•Mouse D4950B C3751B
+3 6XSSRUW3DFN 2IIHULQJ
Support can be delivered either by your local reseller or by the Hewlett-Packard Customer Support organization. For more
information, visit our Web site at http://www.hp.com/go/netserver.
+3 6XSSRUW3DFN 2UGHU 1R
3-year, onsite with 4-hour response (standard business hours) H5518A
3-year, onsite with 4-hour response (24 hours/day, 7 days/week) H5513A
Onsite installation and network configuration H5756A
Remote NOS, Applications, LAN, WAN, and Management Phone Support H1847AA
1 Please see the
HP NetServers Configuration Guide
for important technical information when choosing your
accessories or go to http://www.hp.com/go/netserver
2LH 3 to LH 4 upgrade kit requires secondary fan tray and second power supply cage with one power supply module,
Product No. D6093A

8
VSHFLILFDWLRQV
+
3
+3 1HW6HUYHU 1HW6HUYHU  D
DQG/+U
QG /+ U
Dual integrated
Ultra2 SCSI controllers
Integrated dual-channel HP NetRAID
controller with I O
1 PCI/ISA slot
Up to 12 hot-swap
Ultra2 SCSI drives
Upgradable
to hot-swap PCI
7 PCI slots
Up to eight
Totally Cool
hot-swap fans
2 open half-height
shelves, suitable for
DAT24x6i autoloader or DLT
HP Smart IRQ for
easy configuration
Uni or dual Pentium II
with 100MHz bus
Up to 1GB ECC SDRAM
with memory scrubbing
Tool-free upgrade
to 4-way processing
Integrated control
panel with display
Easy conversion from
pedestal to 8U rack
Integrated
HP Remote Assistant
Hot-swap power
modules
2
/
III

9
VSHFLILFDWLRQV
+
3
+3 1HW6HUYHU 1HW6HUYHU  D
DQG/+U
QG /+ U
6SHFLILFDWLRQV
Operating Temperature 41 to 95 degrees F (5 to 35 degrees C)
Operating Humidity 20% to 80% noncondensing
Acoustic Emissions Sound pressure (LpA): <55 dB(A), bystander position
Power Supply Auto-ranging 90 to 132 VAC, or 180 to 264 VAC at 47–63Hz
Power Availability 550W continuous
Power Consumption 809/786W maximum with 110/220V supply
System Dimensions Rack: 19"W x 14"H x 29.5"D (482.6mmW x 354.7mm H x 749.2cm D)
Pedestal: 13.8"W x 19.5"H x 28.5"D (350.5mm W x 494.8mm H x 724.2mm D)
System Weight 79–132lbs (36–60kg), depending on configuration
&KRRVH <RXU +3 1HW6HUYHU /+  RU /+ U
Product Number Processor Configuration All Models Include:
D7033A Pentium II/450 MHz Pedestal
D7034A Pentium II/450 MHz Rack1
D8503A Pentium III/500 MHz Pedestal
D8504A Pentium III/500 MHz Rack1
D8567A Pentium III/550 MHz Pedestal
D8568A Pentium III/550 MHz Rack1
D9343A Pentium III/600 MHz Pedestal
D9344A Pentium III/600 MHz Rack
128MB 100MHz ECC SDRAM with memory scrubbing,
integrated dual-channel HP NetRAID controller with I2O
driving dual PCI Ultra2 SCSI controllers, bundled 10/100TX
NIC, CD-ROM drives, flexible disk drive, hot-swap power
supplies and fans, integrated HP Remote Assistant, HP
TopTools for Servers, HP OpenView ManageX/SE
1 Keyboard and Mouse not included with Rack Configurations
IBM and OS/2 are registered trademarks of IBM Corporation. Intel and Pentium are U.S. registered trademarks of, and Xeon is a trademark of, Intel Corporation. Microsoft and Windows NT
are registered trademarks of Microsoft Corporation. Novell and NetWare are registered trademarks of, and IntranetWare is a trademark of, Novell, Inc. OpenView is a trademark of
Hewlett-Packard Company. SCO and UnixWare are registered trademarks of, and OpenServer is a trademark of, The Santa Cruz Operation. All other brand names are trademarks of their
respective owners.
Information in this document is subject to change without notice.
© Copyright Hewlett-Packard Company 1999. All Rights Reserved. Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the
copyright laws.
Printed in USA August 1999
HP Select Express Program:
HP NetServer LH 3 is also available
through HP Select Express Program. This
program offers custom integration of HP
hardware offered at HP’s lowest price. For
more information visit our Web site at:
http://www.hp.com/netserver/products/sep
