HP ProLiant DL385 Generation 7 (G7) User instructions

As the leading 2P 2U AMD rack server, the HP ProLiant DL385 G7 is designed with virtualization in mind, yet flexible and expandable to
support any business need in many environments from corporate datacenters to sophisticated SMBs.
Front View: Rear View:
1. Redundant Power Supplies 1. PCI slot 5
2. Two HP NC382i Dual Port Multifunction NICs 2. PCI slot 6
3. SD Card Reader 3. PCI slot 4
4. PCI Riser Slots 4. PCI slot 2
5. Quick Removal Access Panel 5. PCI slot 3
6. AMD Opteron Processors (up to 2) 6. PCI slot 1
7. Hot Plug Redundant Fans 7. Power Supply 2
8. Hard Drive Bays 8. Power Supply 1
9. Slimline Optical bay 9. USB Connectors (2)
10. UID LED Button 10. Video Connector
11. Health LED 11. NIC 1 Connector
12. Power On/Standby Button and System Power LED 12. NIC 2 Connector
13. USB Connectors (2) 13. Mouse Connector
14. Video Connector 14. Keyboard Connector
15. System Insight Display 15. Serial Connector
16. Twenty-four sockets for DDR3 Memory 16. iLO3 connector
17. NIC 3 Connector
18. NIC 4 Connector
What's New
Support for 4TB LFF 3G SATA 7.2k Midline hard drive and the 1.2TB SFF 6G SAS 10K Enterprise hard drive
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Overview
DA - 13594 North America — Version 48 — March 25, 2013 Page 1

NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory
Integrated Models" section.
Processor
One of the following
depending on Model
Sixteen-Core Processors
AMD Opteron™ 6282SE (2.60GHz/16-core/16MB/140W TDP) Processor
AMD Opteron™ 6276 (2.30GHz/16-core/16MB/115W TDP) Processor
AMD Opteron™ 6274 (2.20GHz/16-core/16MB/115W TDP) Processor
AMD Opteron™ 6272 (2.10GHz/16-core/16MB/115W TDP) Processor
AMD Opteron™ 6262HE (1.60GHz/16-core/16MB/85W TDP) Processor
Twelve-Core Processors
AMD Opteron™ 6238 (2.60GHz/12-core/16MB/115W TDP) Processor
AMD Opteron™ 6234 (2.40GHz/12-core/16MB/115W TDP) Processor
AMD Opteron™ 6180SE (2.50GHz/12-core/12MB/140W TDP) Processor
AMD Opteron™ 6176SE (2.30GHz/12-core/12MB/140W TDP) Processor
AMD Opteron™ 6176 (2.30GHz/12-core/12MB/115W TDP) Processor
AMD Opteron™ 6174 (2.20GHz/12-core/12MB/115W TDP) Processor
AMD Opteron™ 6172 (2.10GHz/12-core/12MB/115W TDP) Processor
AMD Opteron™ 6166HE (1.80GHz/12-core/12MB/85W TDP) Processor
Eight-Core Processors
AMD Opteron™ 6220 (3.0GHz/8-core/16MB/115W TDP) Processor
AMD Opteron™ 6212 (2.60GHz/8-core/16MB/115W TDP) Processor
AMD Opteron™ 6140 (2.60GHz/8-core/12MB/115W TDP) Processor
AMD Opteron™ 6136 (2.40GHz/8-core/12MB/115W TDP) Processor
AMD Opteron™ 6134 (2.30GHz/8-core/12MB/115W TDP) Processor
AMD Opteron™ 6128 (2.0GHz/8-core/12MB/115W TDP) Processor
AMD Opteron™ 6132HE (2.20GHz/8-core/12MB/85W TDP) Processor
AMD Opteron™ 6128HE (2.0GHz/8-core/12MB/85W TDP) Processor
Quad-Core Processors
AMD Opteron™ 6204 (3.30GHz/4-core/16MB/115W TDP) Processor
NOTE: Up to 2 processors supported. High Performance Model configurations include two processors,
16GB system memory, 1G storage controller memory, FBWC, DVDRW, ICE license, Redundant 750W Power
Supplies, and 6 hot plug redundant fans.
Cache Memory
One of the following
depending on Model
16MB (1 x 16MB) Level 3 cache memory
NOTE: Supported on 6200 series processors.
12MB (1 x 12MB) Level 3 cache memory
NOTE: Supported on 6100 series processors.
Chipset AMD SR5690 Northbridge and SP5100 Southbridge
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Standard Features
DA - 13594 North America — Version 48 — March 25, 2013 Page 2

Upgradeability Upgradeable to two processors
Memory Protection Advanced ECC
Online Spare
Memory Type DDR3 Registered (RDIMM) and Unbuffered (UDIMM)
Maximum (RDIMM) 512GB
Maximum (UDIMM) 64GB
NOTE: If only one processor is installed, only half the DIMM slots are available
NOTE: Depending on the memory configuration and processor model, the memory speed may run at
1600Mhz, 1333MHz, 1066MHz, or 800MHz. Please see the Online Memory Configuration Tool at:
www.hp.com/go/ddr3memory-configurator .
Network Controller Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports total)
NOTE: 1GB of memory is sufficient to support up to eight Total Ports. 2GB of memory is required if nine or
more Total Ports have been selected.
Expansion Slots
NOTE: Up to 6 PCI slots (PCIe slots are Gen 2). Standard riser with PCIe (1) x8 FL/FH, (2) x4 HL/FH. Optional second risers with PCIe (1)
x8, (2) x4; or a PCIe/PCI-X mixed riser with (2) PCI-X, (1) x8; or a x16 225w PCIe riser with (1) x16; or a (2) x8 Dual Port 10GbE riser.
Primary Riser
(Standard)
Expansion
Slots #
Technology Bus
Width
Connector
Width
Bus Number Form Factor Notes
1 PCI-e 2.0 x8 x16 6 Full
Length/Full
Height
2 PCIe 2.0 x4 x8 12 Half length,
full height
3 PCIe 2.0 x4 x8 15 Half length,
full height
NOTE: Bus number - Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the
actual bus assignment number
NOTE: Bus width - Indicates the number of physical electrical lanes running to the connector
NOTE: Only single wide cards are supported
PCIe Riser
(Optional Secondary)
Expansion
Slots #
Technology Bus
Width
Connector
Width
Bus Number Form Factor Notes
4 PCIe 2.0 x8 x16 18 Full
Length/Full
Height
5 PCIe 2.0 x4 x8 24 Low Profile
6 PCIe 2.0 x4 x8 27 Low Profile
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Standard Features
DA - 13594 North America — Version 48 — March 25, 2013 Page 3

NOTE: Bus number - Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the
actual bus assignment number
NOTE: Bus width - Indicates the number of physical electrical lanes running to the connector
NOTE: Only single wide cards are supported
PCIe/PCI-X Riser (Optional
Primary)
Expansion
Slots #
Technology Bus
Width
Connector
Width
Bus Number Form Factor Notes
1 PCI-X 64-bit N/A 7 Full length,
Full height
2 PCI-X 64-bit N/A 7 Half Length,
Full Height
3 PCIe 2.0 x8 x8 11 Half Length,
Full Height
NOTE: Bus number - Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the
actual bus assignment number
NOTE: Bus width - Indicates the number of physical electrical lanes running to the connector
NOTE: Only single wide cards are supported
NOTE: PCI-X support is limited to PCI-X cards only
PCIe/PCI-X
(Optional Secondary)
Expansion
Slots #
Technology Bus
Width
Connector
Width
Bus Number Form Factor Notes
4 PCI-X 64-bit N/A 19 Full
Length/Full
Height
5 PCI-X 64-bit N/A 19 Low Profile
6 PCIe 2.0 x8 x8 23 Low Profile
NOTE: Bus number - Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the
actual bus assignment number
NOTE: Bus width - Indicates the number of physical electrical lanes running to the connector
NOTE: Only single wide cards are supported
NOTE: PCI-X support is limited to PCI-X cards only
x16 PCIe Riser
(Optional Primary)
Expansion
Slots #
Technology Bus
Width
Connector
Width
Bus Number Form Factor Notes
1 PCIe 2.0 x16 x16 6 Full
Length/Full
Height
Supports up
to 150W
NOTE: Bus number - Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the
actual bus assignment number
NOTE: Bus width - Indicates the number of physical electrical lanes running to the connector
NOTE: Only single wide cards are supported
x16 PCIe Riser
(Optional Secondary)
Expansion
Slots #
Technology Bus
Width
Connector
Width
Bus Number Form Factor Notes
1 PCIe 2.0 x16 x16 18 Full
Length/Full
Height
Supports up
to 150W
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Standard Features
DA - 13594 North America — Version 48 — March 25, 2013 Page 4

NOTE: Bus number - Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the
actual bus assignment number
NOTE: Bus width - Indicates the number of physical electrical lanes running to the connector
NOTE: Only single wide cards are supported
(2) x8 PCI-E Riser
(Optional Primary)
Expansion
Slots #
Technology Bus
Width
Connector
Width
Bus Number Form Factor Notes
1 PCIe 2.0 x8 x16 6 Full
Length/Full
Height
2 PCIe Gen2 x8 x16 9 Half length,
full height
NOTE: Bus number - Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the
actual bus assignment number
NOTE: Bus width - Indicates the number of physical electrical lanes running to the connector
NOTE: Only single wide cards are supported
NOTE: The shared network port is only supported in the secondary riser connector
(2) x8 PCI-E Riser
(Optional Secondary)
Expansion
Slots #
Technology Bus
Width
Connector
Width
Bus Number Form Factor Notes
4 PCIe 2.0 x8 x16 18 Full
Length/Full
Height
5 PCIe 2.0 x8 x16 21 Low Profile
NOTE: Bus number - Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the
actual bus assignment number
NOTE: Bus width - Indicates the number of physical electrical lanes running to the connector
NOTE: Only single wide cards are supported
NOTE: The shared network port is only supported in the secondary riser connector
Storage Controller
One of the following
depending on Model
Entry Models: HP Smart Array P410i/Zero Memory Controller
Base Models: HP Smart Array P410i/256 MB Controller
HP Smart Array P410i/512MB FBWC Controller
High Performance Models: HP Smart Array P410i/1G FBWC Controller
Available upgrades: 1G FBWC, 512MB FBWC, 256MB, 512MB with BBWC, Battery kit upgrade (for the
256MB cache), and Smart Array Advanced Pack (SAAP)
NOTE: RAID 6 and 60 requires purchase of HP Smart Array Advanced Pack (516471-B21).
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Standard Features
DA - 13594 North America — Version 48 — March 25, 2013 Page 5

Internal Storage Devices Diskette Drive None
Optical Drive
One of the following
depending on Model
None Standard
HP Slim SATA DVD RW Optical Drive (standard on Performance Models)
NOTE: The Optical Drive option is not available when you upgrade with the
additional 8 SFF drive cage, or in the LFF Models.
Hard Drives None Standard
Hard Drive Bays Standard (8) small form factor (SFF) hot-plug drive bays to support Serial-
attached SCSI (SAS) and Serial ATA (SATA) drives
Optional second drive cage for additional (8) SFF drive bays (total 16)
Optional cage for (6) Large Form Factor SAS/SATA hard drive bays
Maximum Internal
Storage
Hot Plug SFF SAS 19.2TB 16 x 1.2TB (with optional SFF drive cage)
Hot Plug LFF SAS 24TB 6 x 4TB (with optional LFF drive cage)
Hot Plug SFF SAS SSD 12.8TB 16 x 800GB (with optional SFF drive cage)
Hot Plug LFF SATA SSD 2.4TB 6 x 400GB (with optional LFF drive cage)
Hot Plug SFF SATA SSD 6.4TB 16 x 400GB (with optional SFF drive cage)
Interfaces Serial 1
Video 2 (1 front, 1 back)
Network RJ-45 (Ethernet) 4
iLO3 remote management
port
1
Keyboard 1
Pointing Device (Mouse) 1
Graphics 1
USB 2.0 Ports 6 (2 front, 2 back, 2 inside - one for internal tape)
Industry Standard
Compliance
ACPI 2.0 Compliant
PCIe 2.0 Compliant
PCI 2.2 Compliant
WOL Support
Microsoft® Logo certifications
USB 2.0 Support
Server Power Cords NOTE: If customers require a power cord, they can check the power cord matrix for the appropriate sku.
Please see the following power cord matrix for details: http://www.hp.com/go/powercordmatrix
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Standard Features
DA - 13594 North America — Version 48 — March 25, 2013 Page 6

Common Slot ProLiant HP has a new design for ProLiant power. The new Common Slot Power Supply bay. This design provides
the customer with commonality in power supplies across multiple platforms to save on the cost of spares
and allows HP to offer multiple power solutions to fit the customers' needs. Many HP ProLiant Servers
come with Common Slot, High Efficiency power supplies that allow you to right-size power supplies for
your server configuration. Common Slot (CS) designates commonality of the power supply across multiple
ProLiant servers. HP's new Common Slot power supplies are designed for highest efficiency to provide
power efficiency without degrading performance of the ProLiant. Power Supplies will have efficiency
ratings up to 94%. There are three power wattage options to choose from - 460W, 750W, and 1200W -
depending on the configuration of your server. To make sure you select the correct power supply to meet
your configuration, we suggest that you use the HP Power Advisor ( www.hp.com/go/hppoweradvisor ) to
decide the "Right-Size" for your configuration. All HP Common Slot power sources are UL, CE Mark
Compliant, Hot Plug and Redundant.
It is highly recommended that you use the HP Power Calculator in defining the "Right-Size" power supply
for your needs.
HP's ProLiant Common Slot Power supplies (460W & 750W) meet multiple Energy Efficiency Initiatives
including Climate Savers Computing Initiative GOLD, ECOS Consulting 80PLUS GOLD, and plans on offering
models that meet the Energy Star for Server requirements when they are published.
HP's ProLiant Common Slot Power supplies (1200W, 750W & 460W) meet multiple Energy Efficiency
Initiatives including Climate Savers Computing Initiative Platinum and ECOS Consulting 80PLUS Platinum
Power Supply requirements.
Redundant Power: Optional (1+ 1 or n+n redundant) power supplies can be purchased through power
supply option kits (see Redundant Options for part numbers).
NOTE: Pre-Configured Performance models include two power supplies; Pre-Configured Base and Entry
models include one power supply. On Factory Integrated models, power supply must be selected from
available options.
System Fans Hot plug fans ship standard, N+1 fully redundant
(3+1) for 1 processor, (5+1) for 2 processors
NOTE: Processor option kits include 2 additional fans when upgrading to 2 processors.
Required Cabling For required cabling information, refer to the HP Web site at: www.hp.com/servers/dl385-g7
Operating Systems and
Virtualization Software
Support for ProLiant
Servers
Microsoft Windows Server
Red Hat Enterprise Linux (RHEL)
SUSE Linux Enterprise Server (SLES)
Oracle Solaris
VMware
Citrix XenServer
NOTE: For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization
Software and latest listing of software drivers available for your server, please visit our Support Matrix at:
http://www.hp.com/go/ossupport
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Standard Features
DA - 13594 North America — Version 48 — March 25, 2013 Page 7

Graphics Integrated ATI ES1000, 64MB video standard
16 bit color: maximum resolution of 1600 x 1200
32 bit color: maximum resolution of 1280 x 1024
NOTE: Maximum resolution available via iLO3 remote console is 1280 x 1024 (for 32 bit color) and 1600 x
1200 (DVR max resolution).
Form Factor Rack (2U), (3.5-inch)
HP Insight management HP Service Pack for
ProLiant
HP Service Pack for ProLiant (SPP) and HP Smart Update Manager (HP SUM)
version 5 provide a new, comprehensive approach to firmware and system
software maintenance. Together they provide better operating stability and
ensure maximum uptime. The SPP will be updated at a predictable cadence,
typically coinciding with new HP server hardware launches. By enabling
firmware to be updated online and integrating firmware and system software
updates in one operation HP SUM and the SPP offer faster updates of
individual servers and dramatically faster updates of entire BladeSystem
enclosures. Further improving system uptime and stability is the fact that HP
provides 12 months of support on each Service Pack for ProLiant.
The user experience around HP SUM and the SPP has been improved in several
ways, starting with the web download. A single web page provides access to a
single download containing both the latest version of HP SUM version 5 and
the latest SPP. Optional smaller subsets with only specific types of servers or
specific operating systems are offered to save on download time. The HP SUM
application has been re-written to provide a more straightforward, intuitive
user interface that guides the user through the steps of discovery, analyses
and update, providing comprehensive information on available updates,
criticality and interdependencies. This information is also available in reports.
By providing the option of multiple local or shared repositories which can be
easily updated from hp.com, HP SUM provides the tools to optimize stability
and consistency throughout the company. While HP SUM and the SPP will
recommend the combinations of firmware and system software that HP has
found to be the best practice, the application gives customers the flexibility to
set their own specific baseline.
The Service Pack for ProLiant has been rigorously tested with specific
attention for interaction between firmware, drivers and agents both within the
server as well as in interaction with the BladeSystem enclosure components
(Onboard Administrator and Virtual Connect). This testing ensures the highest
quality as well as providing the input for HP SUM to deploy updates taking into
account all interdepencies, when determining the correct updates and order of
update deployment.
The Service Pack for ProLiant (which includes HP SUM 5) can be downloaded
from: www.hp.com/go/spp/download . More information can be found:
http://www.hp.com/go/spp and http://www.hp.com/go/hpsum
HP Insight Foundation Insight Foundation is being baselined at version v8.70 which means the
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Standard Features
DA - 13594 North America — Version 48 — March 25, 2013 Page 8

following:
Its Media Kit (contains 2 SmartStart CDs, the Firmware DVD, and the
Management DVD) will continue to ship with all supported ProLiant G7
or earlier BTO servers until the last supported server is no longer
shipping.
The Media Kit will not be updated past version 8.70.
ProLiant G7 or earlier CTO servers are able to order the Media Kit with
the understanding that the media is not updated. Please check specific
server QuickSpecs for availability of CTO Kit.
PSP and Firmware DVD downloads will be updated through 2Q 2012 at
the HP Insight Foundation Suite for ProLiant downloads tab:
http://www.hp.com/go/foundation
Customers are urged to use the replacement product, HP Service Pack for
ProLiant, instead of Insight Foundation Suite which is found at these location:
www.hp.com/go/spp
www.hp.com/go/spp/download
HP Integrated Lights-Out
(iLO) for ProLiant
HP Integrated Lights-Out (iLO) simplifies server setup, health monitoring,
power and thermal control, and lights-out remote administration of ProLiant
ML, DL, and BL servers. HP iLO functions without additional software and can
be accessed from any location via a web browser. HP iLO works hand-in-hand
with HP Systems Insight Manager, Insight Control, and Insight Dynamics for
ProLiant, helping customers unleash the value of the ProLiant platform and
deliver the highest possible quality of IT service. For more information, visit:
www.hp.com/go/iLO
Intelligent Manageability HP Systems Insight Manager software
SmartStart
Management Agent
Redundant ROM
Remote Flash ROM
ROM-Based Setup Utility (RBSU)
Integrated Management Log
Automatic Server Recovery (ASR)
Dynamic Sector Repairing (with Smart Array controller)
Drive Parameter Tracking (with Smart Array controller)
Pre-Failure Warranty (covers processors, SAS hard drives and memory)
Security Power-on password
Keyboard password
QuickLock, Network Server Mode
Serial interface control
Administrator's password
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Standard Features
DA - 13594 North America — Version 48 — March 25, 2013 Page 9

Warranty This product is covered by a global limited warranty and supported by HP Services and a worldwide
network of HP Authorized Channel Partners resellers. Hardware diagnostic support and repair is available
for three years from date of purchase. Support for software and initial setup is available for 90 days from
date of purchase. Enhancements to warranty services are available through HP Care Pack services or
customized service agreements. Hard drives have either a one year or three year warranty; refer to the
specific hard drive QuickSpecs for details.
NOTE: Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day
response. Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts.
These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel
and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR
parts are also designed for easy replacement but may involve added complexity. Customers may choose
to have HP replace Optional CSR parts at no charge. Additional information regarding worldwide limited
warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Standard Features
DA - 13594 North America — Version 48 — March 25, 2013 Page 10

HP Insight management HP Insight Control HP Insight Control, a product option, delivers essential infrastructure
management that can help save time and money by making it easy to deploy,
migrate, monitor, remote control, and optimize your IT infrastructure through
a single, simple management console. For more information, see
http://www.hp.com/go/insightcontrol .
HP Insight Control includes one year of 24 x 7 HP Software Technical Support
and Update Service ensuring rapid access to HP support staff and proactive
delivery of software updates. For more information about this service, see:
http://www.hp.com/services/insight.
HP iLO Advanced HP Integrated Lights-Out Advanced License a product option, providing smart
remote server management without compromise. iLO Advanced unlocks the
full set of remote administration functionality for all HP ProLiant servers by
activating the full Virtual Keyboard Video and Mouse remote console, multi-
user collaboration, console record and replay, GUI-based and scripted virtual
media and virtual folders, and enhanced security and power management
functionality. For more information, see, http://www.hp.com/go/iloadvance
HP Insight Dynamics for
ProLiant
HP Insight Dynamics for ProLiant, a product option, is advanced infrastructure
management software that enables IT staff to instantly adjust their
environments to meet dynamic business demands by provisioning, optimizing
and protecting complex infrastructure in minutes. It's a powerful toolkit,
integrated-by-design, that accelerates complex technology projects and
simplifies daily operations, transforming data center economics. With Insight
Dynamics IT professionals can plan capacity and power continuously, balance
workloads across physical and virtual resources, and ensure cost-effective
high availability. It also enables IT organizations to provision infrastructure
consistently and automatically from pools of shared resources using a self-
service portal. Resources provisioned can range from a single virtual machine
to complex multi-tier environments and their associated physical and virtual
resource requirements. In addition to the previous functional benefits, it also
provides a cost-effective disaster recovery for physical and virtual
environments that works with HP Continuous Access software for both the
Enterprise Virtual Array and the XP storage array allowing application
environments to be reactivated in minutes with the touch of a button to a
remote location.
NOTE: For more information, visit:
http://www.hp.com/go/insightdynamics
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Optional Features
DA - 13594 North America — Version 48 — March 25, 2013 Page 11

High Performance
Clusters
HP Cluster Platforms HP Cluster Platforms are specifically engineered, factory-integrated large-
scale ProLiant clusters optimized for High Performance Computing, with a
choice of servers, networks and software. Operating system options include
specially priced offerings for Red Hat Enterprise Linux and SUSE Linux
Enterprise Server, as well as Microsoft Windows HPC Server. A Cluster
Platform Configurator simplifies ordering. http://www.hp.com/go/clusters .
HP HPC Interconnects High Performance Computing (HPC) interconnect technologies are available
for this server as part of the HP Cluster Platform portfolio. These high-speed
InfiniBand and Gigabit interconnects are fully supported by HP when
integrated within an HP cluster. Flexible, validated solutions can be defined
with the help of configuration tools.
http://www.hp.com/techservers/clusters/ucp/index.html
HP Cluster Management
Utility
HP Cluster Management Utility (CMU) is an HP-licensed and HP-supported
suite of tools that are used to manage large-scale Linux ProLiant systems.
CMU includes software for the centralized provisioning, management and
monitoring of nodes. CMU makes the administration of clusters user friendly,
efficient, and effective. http://www.hp.com/go/cmu
HP HPC Linux Value Pack HP HPC Linux Value Pack (Value Pack) is an HP-licensed and HP-supported
specially priced software bundle for the development and deployment of
applications on HPC Cluster Platforms. Value Pack includes the Platform HPC
Enterprise Edition suite of tools including the LSF workload scheduler, the HP-
MPI parallelization library. Also included are the HP Unified Parallel C compiler
and the HP Shmem library, as well as the execution environments for the
libraries and compiler. HP HPC Linux Value Pack
HP Insight Online HP Insight Online is a new capability available through the HP Support Center portal for one stop, secure
access to product and HP support information specific to your IT environment. Insight Online can
automatically display devices remotely monitored by HP Insight Remote Support. With Insight Online's
easy navigation you can efficiently track your IT support contracts and device status from anywhere and at
anytime. www.hp.com/go/insightonline
HP Proactive Insight
experience
Prevent problems with innovative, automated monitoring tools and proactive services. The HP Proactive
Insight experience consist of using Insight Online, Insight Remote Support, and Proactive Care Support
Service as one integrated solution. The Proactive Insight experience provides you with expert advice and
personalized, cloud-based automated IT support, helping to prevent unplanned down time and solve
problems quickly. For more information, visit: www.hp.com/go/proactiveinsightexperience
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Optional Features
DA - 13594 North America — Version 48 — March 25, 2013 Page 12

Factory Express Portfolio
for Servers and Storage
HP Factory Express offers configuration, customization, integration and deployment services for HP
servers and storage products. Customers can choose how their factory solutions are built, tested,
integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex
configuration and design services as well as individual factory services, such as image loading, asset
tagging, and custom packaging. HP products supported through Factory Express include a wide array of
servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000
servers as well as the MSAxxxx, VA7xxx, EVA, XP, rackable tape libraries and configurable network
switches.
For more information on Factory Express services for your specific server model please contact your sales
representative or go to: http://www.hp.com/go/factory-express .
HP Simple Configurator SCE is a guided self service tool to help sales and non technical people provide customers with initial
configurations in 3 to 5 minutes. You may then send the configuration on for configuration help, or use in
your existing ordering processes. If you require "custom" rack configuration or configuration for products
not available in SCE, please contact HP's Customer Business Center or an Authorized Partner for
assistance. http://www.hp.com/products/configurator
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Optional Features
DA - 13594 North America — Version 48 — March 25, 2013 Page 13

Service and Support HP Technology Services for Industry Standard Servers and BladeSystem
Capitalizing on HP ProLiant server and HP BladeSystem capabilities requires a service partner who
understands your increasingly complex business technology environment. That's why it makes sense to
team up with the people who know HP infrastructure hardware and software best - the experienced
professionals at HP Services.
What HP ProLiant and BladeSystem Services can do for you
HP ProLiant and BladeSystem Services can help you design, deploy, test, integrate, support, and manage
IT and infrastructure solutions. This way, HP proposes services solutions that include more than just uplift
of base warranty. You can get the support you need by choosing from one of a number of service
packaged solutions we have designed to address wider set of customer support needs:.
HP Technology Services meets business challenges with services offered in three packages - Optimized
Care Package, Standard Care Package, and Basic Care Package - available for each product group. Such
packaged solutions enable customers to optimize technology operations, minimize risk and drive better
business outcomes with easy-to-buy, easy-to-use scalable support packages for servers, storage,
networking and software.
Optimized Care Optimized Care Package: Supports maintaining servers at optimum performance availability
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN
HP Installation and Startup for Insight Control Software
Provides for the deployment and basic configuration of HP Insight Control on HP ProLiant ML and DL series
servers or HP BladeSystem servers http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA0-9972ENW.pdf
3-Year HP Critical Advantage
Provides end-to-end infrastructure support solution for business critical applications running on
virtualized/x86 infrastructures, enabling the customers to cost effectively build, operate, and
continuously improve their IT environment
http://h20195.www2.hp.com/V2/GetDocument.aspx?docname=4AA3-1772ENW
Additional Services : Microsoft or Linux or VMware education courses + Facility & technology
environmental assessment services + Energy Efficiency Design, Factory Express
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Service and Support
DA - 13594 North America — Version 48 — March 25, 2013 Page 14

Standard Care Standard Care Package: Package that maintains high level of server availability
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN
HP Installation and Startup for Insight Control Software
Provides for the deployment and basic configuration of HP Insight Control on HP ProLiant ML and DL series
servers or HP BladeSystem servers http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA0-9972ENW.pdf
3-Year HP 6 hour Hardware Support Onsite Call-to-Repair Service
Provides an IT manager with a team of support specialists who will quickly begin troubleshooting the
system to help return the hardware to operating condition within 6 hours of the initial service request to
the HP Global Solution Center
http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-6547EN.pdf
3-Year , HP 24x7 Software Support for Insight Control
Provides for the deployment and basic configuration of HP Insight Control on HP ProLiant ML and DL series
servers or HP BladeSystem servers
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-6645EEE.pdf
Additional Services : Software OS (Microsoft, Linux (SUSE/Red Hat) & VMware Installation & Start Up, and
Software Support; Install and Startup Services for Insight Control; Microsoft or Linux or VMware education
courses; +30 Proactive Select Credits, Factory Express
Basic Care Basic Care Package: delivers minimum recommended support service level
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN
3-Year HP 24x7 4 hour Response, Hardware Support Onsite Service
Provides for the deployment and basic configuration of HP Insight Control on HP ProLiant ML and DL series
servers or HP BladeSystem servers
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA0-9972ENW.pdf
Additional Services: Software OS (Microsoft, Linux (SUSE/Red Hat) & VMware Installation & Start Up and
Software Support); +10 Proactive Select Credits, Factory Express
Insight Remote Support The packages include HP Insight Remote Support that uses proven technology to deliver secure, reliable
24x7 remote monitoring, diagnoses, and problem resolution. It is available at no additional cost to all
warranty, HP Care Pack Service, and service agreement customers.
For more information To learn more on HP ProLiant servers and HP BladeSystem servers, please contact your HP sales
representative or HP Authorized Channel Partner. Or visit: http://www.hp.com/services/proliant
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Service and Support
DA - 13594 North America — Version 48 — March 25, 2013 Page 15

NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory
Integrated Models" section.
NOTE: Pre-configured models ship with the configurations below. Options can be selected from the Core or Additional options section
of this QuickSpecs.
NOTE: HP does not allow factory integration of options into pre-configured models. Any additional options purchased will be shipped
separately.
NOTE: If you desire a custom configuration please see "Configuration Information - Factory Integrated Models" section of this
QuickSpecs.
NOTE: DL385 G7 chassis has 24 DIMM slots available.
Performance Models
HP ProLiant DL385 G7
6282SE 64GB-R Hot Plug
SATA SFF 750W PS Server
654841-001
Processor (s) (2) AMD Opteron™ 6282SE (2.6GHz/16-core/16MB/140W) Processors
Cache Memory 16MB L3 cache
Memory 64GB (8 x 8GB) PC3-10600R (DDR3-1333) Registered DIMMs
Network Controller Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports
total)
Storage Controller HP Smart Array P410i/1GB FBWC Controller
Hard Drive None ship standard
Internal Storage Standard: 8 SFF SAS/SATA HDD Bays
Optical Drive Slim SATA DVD-RW Optical Drive
Power Supply (2) HP 750W Common Slot Platinum Hot Plug Power Supplies
Fans 6 Hot Plug Fully Redundant Fans
Insight Control HP Insight Control No Media single server license, including 1 year of 24x7
Technical Support and Updates
Form Factor Rack (2U), (3.5-inch)
Warranty Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support
with next business day response.
HP ProLiant DL385 G7
6174 2P 16GB-R
P410i/1GB FBWC 8 SFF
750W RPS Perf IC Sever
573087-001
Processor (s) (2) AMD Opteron™ 6174 (2.2GHz/12-core/12MB/80W) Processors
Cache Memory 12MB L3 cache
Memory 16GB (8 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs
Network Controller Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports
total)
Storage Controller HP Smart Array P410i/1GB FBWC Controller
Hard Drive None ship standard
Internal Storage Standard: 8 SFF SAS/SATA HDD Bays
Optical Drive Slim SATA DVD-RW Optical Drive
Power Supply (2) HP 750W Common Slot Gold Hot Plug Power Supplies
Fans 6 Hot Plug Fully Redundant Fans
Insight Control HP Insight Control, No Media, single server license, including 1 year of 24x7
Technical Support and Updates
Form Factor Rack (2U), (3.5-inch)
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Pre-configured Models
DA - 13594 North America — Version 48 — March 25, 2013 Page 16

Warranty Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support
with next business day response.
HP ProLiant DL385 G7
6180SE 2P 16GB-R
P410i/1GB FBWC SFF
750W RPS IC Server
636071-001
Processor (s) (2) AMD Opteron™ 6180SE (2.5GHz/12-core/12MB/105W) Processors
Cache Memory 12MB L3 cache
Memory 16GB (8 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs
Network Controller Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports
total)
Storage Controller HP Smart Array P410i/1GB FBWC Controller
Hard Drive None ship standard
Internal Storage Standard: 8 SFF SAS/SATA HDD Bays
Optical Drive Slim SATA DVD-RW Optical Drive
Power Supply (2) HP 750W Common Slot Gold Hot Plug Power Supplies
Fans 6 Hot Plug Fully Redundant Fans
Insight Control HP Insight Control No Media single server license, including 1 year of 24x7
Technical Support and Updates
Form Factor Rack (2U), (3.5-inch)
Warranty Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support
with next business day response.
Base Models
HP ProLiant DL385 G7
6274 32GB-R Hot Plug SFF
460W PS Server
654853-001
Processor (s) (2) AMD Opteron™ 6274 (2.2GHz/16-core/16MB/115W) Processor
Cache Memory 16MB L3 cache
Memory 32GB (4 x 8GB) PC3-10600R (DDR3-1333) Registered DIMMs
Network Controller Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports
total)
Storage Controller HP Smart Array P410i/512MB FBWC Controller
Hard Drive None ship standard
Internal Storage Standard: 8 SFF SAS/SATA HDD Bays
Optical Drive Not included on Base model
Power Supply (1) 460W Common Slot Platinum Hot Plug Power Supply
Fans 6 hot plug redundant fans
Form Factor Rack (2U), (3.5-inch)
Warranty Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support
with next business day response.
HP ProLiant DL385 G7
6238 16GB-R Hot Plug SFF
460W PS Server
654856-001
Processor (s) (2) AMD Opteron™ 6238 (2.6GHz/12-core/16MB/115W) Processor
Cache Memory 16MB L3 cache
Memory 16GB (4 x 4GB) PC3-10600R (DDR3-1333) Registered DIMMs
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Pre-configured Models
DA - 13594 North America — Version 48 — March 25, 2013 Page 17

654856-001
Network Controller Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports
total)
Storage Controller HP Smart Array P410i/512MB FBWC Controller
Hard Drive None ship standard
Internal Storage Standard: 8 SFF SAS/SATA HDD Bays
Optical Drive Not included on Base model
Power Supply (1) 460W Common Slot Platinum Hot Plug Power Supply
Fans 6 hot plug redundant fans
Form Factor Rack (2U), (3.5-inch)
Warranty Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support
with next business day response.
HP ProLiant DL385 G7
6172 1P 8GB-R P410i/256
8 SFF 460W PS Base
Server
573088-001
Processor (s) (1) AMD Opteron™ 6172 (2.1GHz/12-core/12MB/80W) Processor
Cache Memory 12MB L3 cache
Memory 8GB (4 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs
Network Controller Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports
total)
Storage Controller HP Smart Array P410i/256MB Controller
Hard Drive None ship standard
Internal Storage Standard: 8 SFF SAS/SATA HDD Bays
Optical Drive Not included on Base Model
Power Supply (1) 460W Common Slot Gold Hot Plug Power Supply
Fans 4 hot plug redundant fans
Form Factor Rack (2U), (3.5-inch)
Warranty Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support
with next business day response.
HP ProLiant DL385 G7
6176 1P 8GB-R P410i/256
SFF 460W PS Server
636075-001
Processor (s) (1) AMD Opteron™ 6176 (2.3GHz/12-core/12MB/80W) Processor
Cache Memory 12MB L3 cache
Memory 8GB (4 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs
Network Controller Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports
total)
Storage Controller HP Smart Array P410i/256MB Controller
Hard Drive None ship standard
Internal Storage Standard: 8 SFF SAS/SATA HDD Bays
Optical Drive Not included on Base model
Power Supply (1) 460W Common Slot Gold Hot Plug Power Supply
Fans 4 hot plug redundant fans
Form Factor Rack (2U), (3.5-inch)
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Pre-configured Models
DA - 13594 North America — Version 48 — March 25, 2013 Page 18

Warranty Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support
with next business day response.
HP ProLiant DL385 G7
6136 1P 8GB-R P410i/256
Hot Plug 1 SFF 460W PS
Base Server
585335-001
Processor (s) (1) AMD Opteron™ 6136 (2.4GHz/8-core/12MB/80W) Processor
Cache Memory 12MB L3 cache
Memory 8GB (4 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs
Network Controller Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports
total)
Storage Controller HP Smart Array P410i/256MB Controller
Hard Drive None ship standard
Internal Storage Standard: 8 SFF SAS/SATA HDD Bays
Optical Drive Not included on Base model
Power Supply (1) 460W Common Slot Gold Hot Plug Power Supply
Fans 4 hot plug redundant fans
Form Factor Rack (2U), (3.5-inch)
Warranty Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support
with next business day response.
Entry Models
HP ProLiant DL385 G7
6128 1P 4GB-R P410i/ZM 8
SFF 460W PS Entry Server
573089-001
Processor (s) (1) AMD Opteron™ 6128 (2.0GHz/8-core/12MB/80W) Processor
Cache Memory 12MB L3 cache
Memory 4GB (2 x 2GB) PC3-10600R (DDR3-1333) Registered DIMMs
Network Controller Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports
total)
Storage Controller HP Smart Array P410i/Zero Memory Controller
Hard Drive None ship standard
Internal Storage Standard: 8 SFF SAS/SATA HDD Bays
Optical Drive Not included on Entry model
Power Supply (1) 460W Common Slot Gold Hot Plug Power Supply
Fans 4 hot plug redundant fans
Form Factor Rack (2U), (3.5-inch)
Warranty Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support
with next business day response.
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Pre-configured Models
DA - 13594 North America — Version 48 — March 25, 2013 Page 19

High Efficiency Models
HP ProLiant DL385 G7
6128HE 1P 4GB-U
P410i/ZM 8 SFF 460W PS
Efficiency Server
573090-001
Processor (s) (1) AMD Opteron™ 6128HE (2.0GHz/8-core/12MB/65W) Processor
Cache Memory 12MB L3 cache
Memory 4GB (2 x 2GB) PC3-10600 (DDR3-1333) Unbuffered DIMMs
Network Controller Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports
total)
Storage Controller HP Smart Array P410i/Zero Memory Controller
Hard Drive None ship standard
Internal Storage Standard: 8 SFF SAS/SATA HDD Bays
Optical Drive Not Included on HE model
Power Supply (1) 460W Common Slot Platinum Hot Plug Power Supply
Fans 4 hot plug redundant fans
Form Factor Rack (2U), (3.5-inch)
Warranty Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support
with next business day response.
HP ProLiant DL385 G7
6132HE 4GB-U P410i/ZM 8
SFF 460W 94 EFF PS
Server
636076-001
Processor (s) (1) AMD Opteron™ 6132HE (2.2GHz/8-core/12MB/65W) Processor
Cache Memory 12MB L3 cache
Memory 4GB (2 x 2GB) PC3-10600 (DDR3-1333) Unbuffered DIMMs
Network Controller Two HP NC382i Dual Port Multifunction Gigabit Server Adapters (four ports
total)
Storage Controller HP Smart Array P410i/Zero Memory Controller
Hard Drive None ship standard
Internal Storage Standard: 8 SFF SAS/SATA HDD Bays
Optical Drive Not Included on HE model
Power Supply (1) 460W Common Slot Platinum Hot Plug Power Supply
Fans 4 hot plug redundant fans
Form Factor Rack (2U), (3.5-inch)
Warranty Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support
with next business day response.
QuickSpecs
HP ProLiant DL385 Generation 7 (G7)
Pre-configured Models
DA - 13594 North America — Version 48 — March 25, 2013 Page 20
