HP ProLiant SL250s User manual

The HP ProLiant SL250s Gen8 Server series with HP ProActive Insight architecture delivers even greater levels of configurability for high
performance and scale-out deployments, to help lower total cost of ownership.
Up to four HP ProLiant SL250s Gen8 nodes, in a 4U modular form factor, fit into the HP s6500 scalable system. In addition, each node
can support up to three GPUs or four additional 2.5-inch hard drives.
The SL250s Gen8 Server series includes the exclusive HP SmartMemory and delivers a 25% increase in memory bandwidth to improve
performance for certain applications.
Delivering on the promise of server lifecycle automation, the SL250s Gen8 features the exclusive HP Active Health System that provides
continuous, proactive, monitoring for over 1600 system parameters with zero impact to application performance.
NOTE: The 2U Open View image below shows two SL250s side by side to denote the left and right trays. Each unit is a 2U, half-width
form factor.
2U Open View: 2U Front View:
1. Rear dual GPU placement. This location is also for the optional
SFF 2.5" hard drive kit to enable four (4) SFF HDD's in place of
the GPUs.
1. PCIe Expansion slot
2. Single GPU riser mounts and underneath is Support for two
Intel® Xeon® E5-2600 sequence processors and 16 memory
slots. This location is also for the optional SFF 2.5" hard drive
kit to enable four (4) SFF HDD's in place of the GPUs
2. Four Hot-Plug Drive Slots
3. FlexibleLOM networking option slot 3. Dedicated iLO4 Management Port
4. (1) 1GbE Ports
5. (1) 1GbE Ports
6. Power Button
7. Health LED
8. UID LED
9. Serial Port
10. SUV (Serial/USB/Video)
What's New
Updating supported options
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Overview
DA - 14232 North America — Version 29 — December 16, 2013 Page 1

NOTE: For the Standard Features shipped in the Factory Integrated Models, please see the "Configuration Information - Factory
Integrated Models" section.
Processor
One of the following
depending on Model
E5-2600 v2 series Processors
Entry Processors
NOTE: All support up to 1333MHz DDR3 memory speeds.
Intel® Xeon® E5-2609 v2 (2.5GHz/4-core/10MB/6.4GT-s QPI/80W)
Base Processors
NOTE: All support up to1600MHz DDR3 memory speeds.
Intel® Xeon® E5-2630 v2 (2.6GHz/6-core/15MB/7.2GT-s QPI/80W, DDR3-1600, HT, Turbo2- 3/3/3/3/4/5)
Intel® Xeon® E5-2650L v2 (1.7GHz/10-core/25MB/8.0GT-s QPI/70W, DDR3-1600, HT, Turbo2-
2/2/2/2/2/2/2/2/3/4)
Performance Processors
NOTE: For 130W CPU support and configuration, please contact your HP account team.
NOTE: For 115W CPU support, customers must use the HP 1500W Common Slot Platinum Plus Hot Plug
Power Supply Kit (684532-B21).
NOTE: All support up to 1866MHz DDR3 memory speeds.
Intel® Xeon® E5-2695 v2 (2.4GHz/12-core/30MB/8.0GT-s QPI/115W, DDR3-1866, HT, Turbo2-
4/4/4/4/4/4/4/4/5/6/7/8)
Intel® Xeon® E5-2680 v2 (2.8GHz/10-core/25MB/8.0GT-s QPI/115W, DDR3-1866, HT, Turbo2-
3/3/3/3/3/4/5/6/7/8)
Intel® Xeon® E5-2670 v2 (2.5GHz/10-core/25MB/8.0GT-s QPI/115W, DDR3-1866, HT, Turbo2-
4/4/4/4/4/4/5/6/7/8)
Intel® Xeon® E5-2660 v2 (2.2GHz/10-core/25MB/8.0GT-s QPI/95W, DDR3-1866, HT, Turbo2-
4/4/4/4/4/4/5/6/7/8)
Intel® Xeon® E5-2650 v2 (2.6GHz/8-core/20MB/8.0GT-s QPI/95W, DDR3-1866, HT, Turbo2-
4/4/4/4/5/6/7/8)
E5-2600 series Processors
Entry Processors
NOTE: All support up to 1066MHz memory speeds.
Intel® Xeon® E5-2609 (2.4GHz/4-core/10MB/6.4GT-s QPI/80W)
Intel® Xeon® E5-2603 (1.8GHz/4-core/10MB/6.4GT-s QPI/80W)
Base Processors
NOTE: All support up to1333MHz DDR3 memory speeds.
Intel® Xeon® E5-2640 (2.5GHz/6-core/15MB/7.2GT-s QPI/95W, DDR3-1333, HT, Turbo2- 3/3/4/4/5/5)
Intel® Xeon® E5-2630 (2.3GHz/6-core/15MB/7.2GT-s QPI/95W, DDR3-1333, HT, Turbo2- 3/3/4/4/5/5)
Intel® Xeon® E5-2620 (2.0GHz/6-core/15MB/7.2GT-s QPI/95W, DDR3-1333, HT, Turbo2- 3/3/4/4/5/5)
Intel® Xeon® E5-2630L (2.0GHz/6-core/15MB/8.0GT-s QPI/60W, DDR3-1333, HT, Turbo2- 3/3/4/4/5/5)
Performance Processors
NOTE: For 130W CPU support and configuration, please contact your HP account team.
NOTE: For 115W CPU support, customers must use the HP 1500W Common Slot Platinum Plus Hot Plug
Power Supply Kit (684532-B21).
NOTE: All support up to 1600MHz DDR3 memory speeds.
Intel® Xeon® E5-2670 (2.6GHz/8-core/20MB/8.0GT-s QPI/115W, DDR3-1600, HT, Turbo2-
4/4/5/5/6/6/7/7)
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Standard Features
DA - 14232 North America — Version 29 — December 16, 2013 Page 2

Intel® Xeon® E5-2665 (2.4GHz/8-core/20MB/8.0GT-s QPI/115W, DDR3-1600, HT, Turbo2-
4/4/5/5/6/6/7/7)
Intel® Xeon® E5-2660 (2.2GHz/8-core/20MB/8.0GT-s QPI/95W, DDR3-1600, HT, Turbo2- 5/5/6/6/7/7/8/8)
Intel® Xeon® E5-2650 (2.0GHz/8-core/20MB/8.0GT-s QPI/95W, DDR3-1600, HT, Turbo2- 4/4/5/5/5/7/8/8)
Intel® Xeon® E5-2650L (1.8GHz/8-core/20MB/8.0GT-s QPI/70W, DDR3-1600, HT, Turbo2-
2/2/3/3/4/4/5/5)
Intel® Xeon® E5-2637 (3.0GHz/2-core/5MB/8.0GT-s QPI/80W, DDR3-1600, HT, Turbo2- 5/5)
NOTE: HT indicates that the processor model supports Intel® Hyper-Threading Technology.
NOTE: Turbo indicates the maximum potential frequency increment when using Intel® Turbo Boost
Technology, with 8, 7, 6, 5, 4, 3, 2 or 1 core(s) active.
NOTE: DDR3 speed is the maximum memory speed of the processor. Actual memory speed may depend on
the quantity and type of DIMMs installed.
NOTE: Up to 2 processors supported. Mixing different processor models is not supported.
NOTE: For the Intel® C600 Chipset E5-2600 Series, the letter preceding the model number indicates the
Product Line (E3, E5, E7); 2600x, 2 = number of CPUs in a Node, 6 is socket/segment designation, 00 =
Processor SKU, and x = L for low power SKUs.
Cache Memory
One of the following
depending on Model
30MB (1x30MB) Level 3
NOTE: For Twelve-core processors.
25MB (1x25MB) Level 3
NOTE: For Ten-core processors.
20MB (1x20MB) Level 3
NOTE: For Eight-core processors.
15MB (1x15MB) Level 3
NOTE: For Six-core processors.
10MB (1x10MB) Level 3
NOTE: For Quad-core processors.
5MB (1x5MB) Level 3
NOTE: For Dual-core processors.
Chipset Intel® C600 Series Chipset
Intel® E5-2600 Processor Family
Intel® E5-2600 Processor Family
Intel® E5-2600v2 Processor Family
NOTE: For more information regarding Intel® chipsets, please see the following URL:
http://www.intel.com/products/server/chipsets/ .
Upgradeability Upgradeable to two processors
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Standard Features
DA - 14232 North America — Version 29 — December 16, 2013 Page 3

On System Management
Processor
HP iLO (Firmware: HP iLO 4)
NOTE: For more information, visit: http://www.hp.com/go/ilo .
Memory Protection Advanced ECC (multi-bit error protection)
Memory Type HP SmartMemory
DDR3 Registered (RDIMM), Unbuffered (UDIMM)
DIMM Slots Available 16 total DIMM Slots available
Maximum (RDIMM) (per
server tray)
256GB (16 x 16GB) Memory DIMMs
Maximum (UDIMM) (per
server tray)
128GB (16 x 8GB)
NOTE: HP memory from previous generation servers are not qualified or warranted with this HP ProLiant
Server. HP SmartMemory is required to realize the memory performance improvements and enhanced
functionality listed in this document for Gen8. For additional information, please see the HP SmartMemory
QuickSpecs at: http://h18000.www1.hp.com/products/quickspecs/14225_na/14225_na.html
NOTE: RDIMM and UDIMMs are all distinct memory technologies and cannot be mixed within a server. The
majority of ProLiant Gen8 servers support RDIMM, UDIMM.
NOTE: HP certified SmartMemory must be used to guarantee full 1600MHz speeds.
NOTE: Depending on the memory configuration and processor model, the memory speed may run at
1800MHz, 1600MHz, 1333MHz, or 1066MHz. Please see the Online Memory Configuration Tool at:
www.hp.com/go/ddr3memory-configurator .
NOTE: Kits described as LP include Low Power DIMMs. For more information on ProLiant Energy Efficient
Features, see: www.hp.com/go/proliant-energy-efficient .
Network Controller HP Ethernet 1Gb 2-port 361i
Expansion Slots Expansion Slots
#
Technology Bus Width * Connector
Width
Form Factor Notes
Low Profile PCIe 3.0 x8 x8 Half-length,
half-height
Front Panel
Access
FlexibleLOM PCIe 3.0 x16 x16 FlexibleLOM Front Panel
Access
GPU1
rear bottom
PCIe 3.0 x16 x16 Full-length, full
height
GPU only
GPU2
rear top
PCIe 3.0 x16 x16 Full-length, full
height
GPU only
GPU3
front top
PCIe 3.0 x16 x16 Full-length, full
height
GPU only
*Indicates the number of physical electrical lanes running to the connector
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Standard Features
DA - 14232 North America — Version 29 — December 16, 2013 Page 4

HP Server ROM HP ROM (Read Only Memory) is now digitally signed using HP's Corporate Signing Service. This signature is
verified before the flash process starts, reducing accidental programming and preventing malicious efforts
to corrupt system ROM.
HP ROM provides for essential initialization and validation of hardware components before control is
passed to the customer-installed operating system. The ROM also provides the capability of booting from
various fixed media (HDD, CD-ROM) and removable media (USB), to continue operation to the operating
system.
HP ROM performs very early configuration of the video controller, to allow monitoring of initialization
progress via an attached monitor. If configuration or hardware errors are discovered during this early
phase of hardware initialization, suitable messages are now displayed on the connected monitor.
Additionally, these configuration or hardware errors are logged to the Integrated Management Log (IML) to
assist in diagnosis.
HP's ProLiant ROM is used to configure the following:
Processor and chipset status registers
System memory, memory map, and memory initialization
System hardware configuration (Integrated PCI devices and optional PCIe cards).
Customer-specific BIOS configuration (using the HP ROM-Based Setup Utility (RBSU).
NOTE: For further information, please refer to HP's RBSU (ROM based setup utility) user guide:
www.hp.com/support/rbsu .
Storage Controller HP H220i Host Bus Adapter (B320i Dynamic Smart Array with FW update)
Internal Storage Devices Diskette Drives Via USB through the SUV port, external support only
Optical Drives Via USB through the SUV port, external support only
Hard Drives None ship standard
Maximum Internal
Storage
2U Half Width tray
Hot Plug SAS SFF 4.8TB 4 x 1.2TB
Hot Plug SATA SFF 4.0TB 4 x 1TB
Hot Plug SAS SSD SFF 3.2TB 4 x 800GB
Hot Plug SATA SSD SFF 3.2TB 4 x 800GB
Quick Release SAS SFF 4.8TB 4 x 1.2TB
Quick Release SATA SFF 4.0TB 4 x 1TB
Quick Release SSD SAS SFF 1.6TB 4 x 400GB
NOTE: The Non-Hot Plug Quick Release drives can only be used when implementing the internal SFF kit
and not implementing the GPUs
NOTE: The SL250 SFF Internal Enablement Kit (PN: 679991-B21) allows for up to four SFF HDD to be
implemented in place of the three GPUs.
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Standard Features
DA - 14232 North America — Version 29 — December 16, 2013 Page 5

Interfaces Network RJ-45 Two 1GbE NIC ports
FlexibleLOM ProLiant Gen8 servers offer a new networking technology - Flexible Network
Technology. The SL250 Gen8 server offers the customer the choice of
1Gigabit, 10Gigabit or InfiniBand FlexibleLOM solutions depending on
workload. For further details on the choices, see FlexibleLOM in the
Networking Section of this document.
KVM Serial USB Video Port (SUV)
Micro SD 1 (internal)
USB Ports 1 (internal)
HP iLO Remote
Management Network Port
1 Gb Dedicated
Health LED 1 front
Power 1 front
UID 1 front
Industry Standard
Compliance
ACPI 2.0b Compliant
PCIe 3.0 Compliant
WOL Support
Microsoft® Logo certifications
PXE Support
USB 1.1 and 2.0 Compliant
SMBIOS 2.6.1
Server Power Cords One 6' Highline (IEC-IEC) power cord ships standard
NOTE: HP ProLiant SL servers are primarily connected to PDU's in data center racks so they ship standard
with only a PDU power cord (416151-B21). If a user wishes to power a ProLiant SL server using a 110V
receptacle (NEMA-15), the NEMA power cord must be ordered separately.
NOTE: If customers require a local power cord, they can check the power cord matrix for the appropriate
cord. Please see the following power cord matrix: http://www.hp.com/go/powercordmatrix .
Power Specifications To review typical system power ratings use the HP Power Advisor which is available via the online tool
located at URL: www.hp.com/go/proliant-energy-efficient or www.hp.com/go/hppoweradvisor .
NOTE: Power Specification and Technical Content for supported power supplies can be found at:
http://h18000.www1.hp.com/products/quickspecs/14209_na/14209_na.html
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Standard Features
DA - 14232 North America — Version 29 — December 16, 2013 Page 6

Common Slot Power
Supplies
NOTE: Mixing of power supplies in the same server is not supported. All power supplies inside a server
must be exactly the same model. Mixing Gold, Platinum, and Platinum Plus certified power supplies is not
supported.
HP's Common Slot (CS) power supplies allow for commonality of power supplies across a wide range of
ProLiant and Integrity servers, as well as HP Storage solutions, and are designed to provide the highest
power supply efficiency without degrading system performance. HP CS power supplies are tested by the
Electric Power Research Institute (EPRI) and certified through the ECOS 80 Plus power supply program. HP
CS power supply options provide efficiency ratings of up to 94% (80 Plus Platinum) and are available in
three power output options - 750W, 1200Wand 1500W - allowing the customer to "right-size" a power
supply for their specific server configuration. All HP Common Slot power sources are UL, CE Mark
Compliant, hot-plug and support redundant configurations.
NOTE: Mixing of power supplies in the same server is not supported. All power supplies must be of the
same output and efficiency rating. If non-matched power supplies are inserted you will get errors and
operation will fail.
It is highly recommended that you use the HP Power Advisor in defining the "Right-Size" power supply for
your needs. HP Power Advisor can be accessed at: www.hp.com/go/hppoweradvisor .
NOTE: The 80 PLUS program is a unique forum that unites electric utilities, the computer industry, and
consumers in an effort to bring energy efficient technology solutions to the marketplace. 80 Plus
independently tests power supply efficiency and publicly posts the results on 80Plus.org.
Redundant Power: Optional (1+ 1 or n+n redundant) power supplies can be purchased through power
supply option kits (see Power Supplies for part numbers).
NOTE: Power Specification and Technical Content for supported power supplies can be found at:
http://h18000.www1.hp.com/products/quickspecs/14209_na/14209_na.html
System Fans HP s6500 Redundant Fan Kit
NOTE: This kit includes only 1 fan
NOTE: This selection must be ordered in quantities of 8 (PN 617856-B21)
HP s6500 Non-Redundant Fan Kit
NOTE: This kit includes only 1 fan
NOTE: This selection must be ordered in quantities of 8 (PN 617858-B21)
NOTE: all 8 fan bays must be populated with either redundant or non-redundant fans
NOTE: mixing and matching of fans is not allowed
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Standard Features
DA - 14232 North America — Version 29 — December 16, 2013 Page 7

Operating Systems and
Virtualization Software
Support for ProLiant
Servers
Microsoft Windows Server
Canonical Ubuntu
Red Hat Enterprise Linux (RHEL)
SUSE Linux Enterprise Server (SLES)
VMware
NOTE: For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization
Software and latest listing of software drivers available for your server including how to purchase from
HP, please visit our OS Support Site at: http://www.hp.com/go/ossupport and our driver download page:
http://www.hp.com/support/SL250sGen8
Graphics Integrated Matrox G200 video standard
1280 x 1024 (32 bpp)
1920 x 1200 (16 bpp)
HP iLO 4 On System Management Memory
16 MB Flash
256 MB DDR 3 with ECC (112 MB after ECC and video)
Form Factor Fully configured SL250 is 2U, half-width
Fully configured SL6500 chassis is 4U, full-width
On System Management HP iLO Management
Engine
HP iLO Management Engine is a comprehensive set of embedded management
features supporting the complete lifecycle of the server, from initial
deployment, through ongoing management, to service alerting and remote
support. HP iLO Management Engine comes standard on all HP ProLiant Gen8
servers. The HP iLO Management Engine portfolio includes:
HP iLO: The HP iLO (Integrated Lights-Out) management processor is
the core foundation for the HP iLO Management Engine
HP Agentless Management: Provides built in server health monitoring
and alerting capability without OS agents, that starts working the
moment a power cord and an Ethernet cable are connected.
HP Active Health System: Always on, continuous monitoring for
increased stability and shorter downtimes; 100% configuration history;
Health and service alerts and easy export and upload to Service and
Support.
HP Intelligent Provisioning: Lets customers provision and configure a
single server without any separate media. No more SmartStart CDs or
Smart Update Firmware DVD are needed.
To start Intelligent Provisioning:
Press the F10 key during the ProLiant Gen8 server boot
process (also known as power on self test or POST).
Please go to the Intelligent Provisioning website at
www.hp.com/go/intelligentprovisioning for additional
information and to view usage videos.
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Standard Features
DA - 14232 North America — Version 29 — December 16, 2013 Page 8

Use the Service Pack for ProLiant (SPP) at
www.hp.com/go/spp to get firmware and software
updates.
HP iLO Mobile App: Enables the ability to access, deploy, and manage
your server anytime from anywhere from select smartphones and
mobile devices. For additional information please visit:
www.hp.com/go/ilo/mobileapp
NOTE: For more information, visit: http://www.hp.com/go/ilo or HP iLO
Management Engine technologies whitepaper
HP Insight management HP Service Pack for
ProLiant (SPP)
HP Service Pack for ProLiant (SPP) and HP Smart Update Manager (HP SUM)
provide a comprehensive approach to firmware and system software
maintenance. Together they provide better operating stability and ensure
maximum uptime. The SPP will be updated at a predictable cadence, typically
coinciding with new HP server hardware launches. By enabling firmware to be
updated online and integrating firmware and system software updates in one
operation, HP SUM and the SPP offer faster updates of individual servers and
dramatically faster updates of entire BladeSystem enclosures. Further
improving system uptime and stability is the fact that HP provides 12 months
of support for each Service Pack for ProLiant release.
The user experience around HP SUM and the SPP has been improved in several
ways, starting with the web download. A single web page provides access to a
single download containing both the latest version of HP SUM and the latest
SPP. Optional smaller subsets with only specific types of servers or specific
operating systems are offered to save on download time. The HP SUM
application provides a straightforward, intuitive user interface that guides the
user through the steps of discovery, analyses and update, providing
comprehensive information on available updates, criticality and
interdependencies. This information is also available in reports. By providing
the option of multiple local or shared repositories which can be easily updated
from hp.com, HP SUM provides the tools to optimize stability and consistency
throughout the company. While HP SUM and the SPP recommend the
combinations of firmware and system software that HP has found to be the
best practice, the application gives customers the flexibility to set their own
specific baseline.
The Service Pack for ProLiant has been rigorously tested with specific
attention for interaction between firmware, drivers and agents both within the
server as well as in interaction with the BladeSystem enclosure components
(Onboard Administrator and Virtual Connect). This testing ensures the highest
quality as well as providing the input for HP SUM to deploy updates taking into
account all interdepencies, when determining the correct updates and order of
update deployment.
NOTE: The Service Pack for ProLiant (which includes HP SUM) can be
downloaded from www.hp.com/go/spp/download . More information can be
found: http://www.hp.com/go/SmartUpdate , www.hp.com/go/spp and
http://www.hp.com/go/hpsum
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Standard Features
DA - 14232 North America — Version 29 — December 16, 2013 Page 9

Security Power-on password
Keyboard password
QuickLock, Network Server Mode
Serial interface control
Administrator's password
iLO 4 (Integrated Lights-Out 4) has 12 customizable user accounts and SSL encryption
iLO 4 can be disabled via a Global Setting
iLO Advanced supports directory services integration
Warranty This product is covered by a global limited warranty and supported by HP Services and a worldwide
network of HP Authorized Channel Partners. Hardware diagnostic support and repair is available for one
year from date of purchase. Support for software and initial setup is available for 90 days from date of
purchase. Enhancements to warranty services are available through HP Care Pack services or customized
service agreements. Hard drives have either a one year or three year warranty.
NOTE: Server Warranty includes 1 year Parts, 1 year Labor, 1-year on-site support with next business day
response. Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts.
These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel
and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR
parts are also designed for easy replacement but may involve added complexity. Customers may choose
to have HP replace Optional CSR parts at no charge. Additional information regarding worldwide limited
warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html .
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Standard Features
DA - 14232 North America — Version 29 — December 16, 2013 Page 10

HP Insight management HP Insight Control HP Insight Control, a product option, delivers essential infrastructure
management that can help save time and money by making it easy to deploy,
migrate, monitor, remote control, and optimize your IT infrastructure through
a single, simple management console. For more information, see
http://www.hp.com/go/insightcontrol .
HP Insight Control includes one year of 24 x 7 HP Software Technical Support
and Update Service ensuring rapid access to HP support staff and proactive
delivery of software updates. For more information about this service, see:
http://www.hp.com/services/insight .
HP Matrix Operating
Environment
The HP Matrix Operating Environment (Matrix OE) for ProLiant and Integrity
servers is an integrated command center that helps you instantly adjust to
dynamic business demands. This advanced infrastructure management
software lets you reduce the cost of common data center tasks by up to 40
percent while keeping pace with your changing business.
The HP Matrix OE includes the automated provisioning, optimization, and
recovery management capabilities for HP CloudSystem Matrix, the ideal
platform for private cloud and Infrastructure as a Service (IaaS).
NOTE: For more information, visit: http://www.hp.com/go/matrixoe
HP iLO Advanced HP Integrated Lights-Out Advanced License a product option, providing smart
remote server management without compromise. iLO Advanced unlocks the
full set of remote administration functionality for all HP ProLiant servers by
activating the full Virtual Keyboard Video and Mouse remote console, multi-
user collaboration, console record and replay, GUI-based and scripted virtual
media and virtual folders, and enhanced security and power management
functionality. For more information, see: http://www.hp.com/go/iloadvance
HP iLO Scale-Out HP iLO Scale Out offers, Remote Serial Console (text-based video re-direction
via SSH), email-based alerting, remote system log, serial record/playback and
power management capabilities. These features can significantly assist
customers purchasing "SL" series to manage their servers. It is ideal for the
web hosting/cloud service providers, High Performance Computing and Scale-
Out businesses.
If customers require more advanced features such as graphical remote
console, multi-user collaboration, and video record/playback they can
purchase HP iLO Advanced.
HP Matrix Operating
Environment
The HP Matrix Operating Environment (Matrix OE) for ProLiant and Integrity
servers is an integrated command center that helps you instantly adjust to
dynamic business demands. This advanced infrastructure management
software lets you reduce the cost of common data center tasks by up to 40
percent while keeping pace with your changing business.
The HP Matrix OE includes the automated provisioning, optimization, and
recovery management capabilities for HP CloudSystem Matrix, the ideal
platform for private cloud and Infrastructure as a Service (IaaS).
NOTE: For more information, visit: http://www.hp.com/go/matrixoe
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Optional Features
DA - 14232 North America — Version 29 — December 16, 2013 Page 11

High Performance
Clusters
HP Cluster Platforms HP Cluster Platforms are specifically engineered, factory-integrated large-
scale ProLiant clusters optimized for High Performance Computing, with a
choice of servers, networks and software. Operating system options include
specially priced offerings for Red Hat Enterprise Linux and SUSE Linux
Enterprise Server, as well as Microsoft Windows HPC Server. A Cluster
Platform Configurator simplifies ordering. http://www.hp.com/go/clusters
HP HPC Interconnects High Performance Computing (HPC) interconnect technologies are available
for this server as part of the HP Cluster Platform portfolio. These high-speed
InfiniBand and Gigabit interconnects are fully supported by HP when
integrated within an HP cluster. Flexible, validated solutions can be defined
with the help of configuration tools.
http://www.hp.com/techservers/clusters/ucp/index.html
HP Insight Cluster
Management Utility
HP Insight Cluster Management Utility (CMU) is an HP-licensed and HP-
supported suite of tools that are used for lifecycle management of hyperscale
clusters of Linux ProLiant systems. CMU includes software for the centralized
provisioning, management and monitoring of nodes. CMU makes the
administration of clusters user friendly, efficient, and effective.
http://www.hp.com/go/cmu
Storage Software Whether you need to solve a specific data protection, archiving, or storage command and control
challenge, or deliver on strategic consolidation, compliance, or continuity initiatives, look no further than
HP storage software. Our storage software helps you reduce costs, simplify storage infrastructure,
protect vital assets and respond faster to business opportunities.
Storage software that gets the job done:
Data Protection and Recovery Software
Whether you're a large enterprise or a smaller business, HP data protection and recovery software
will cost-effectively protect you against disaster and ensure business continuity.
Data Archive and Migration Software
HP's storage software enables you to comply with data retention and retrieval requirements,
improve application performance, and reduce costs by efficiently migrating infrequently accessed
or less valuable data to lower cost storage.
Storage Resource Management Software (SRM)
HP's storage resource management software reduces operational costs and provides the command
and control foundation you need to efficiently manage and visualize your physical and virtual
environments.
Data Replication Software
HP offers array-based and host-based replication software for use in disaster recovery, testing,
application development and reporting.
Storage Device Management Software
Maximize your investment in HP storage and networking with software that enables hardware-
specific configuration, performance tuning and connectivity management.
HP StoreVirtual VSA
With HP StoreVirtual VSA you can use the power of virtualization to turn a set of heterogeneous and
disconnected physical disk drives in your servers and storage devices into a single pool of logical
storage capacity.
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Optional Features
DA - 14232 North America — Version 29 — December 16, 2013 Page 12

NOTE: For more information available Storage Software including QuickSpecs, please see:
www.hp.com/go/storage/software .
HP Insight Online HP Insight Online is a new addition to the HP Support Center for one stop, secure access to product and HP
support information personalized to your IT environment. Insight Online can automatically display devices
remotely monitored by HP Insight Remote Support. With Insight Online's easy navigation you can
efficiently track your IT support contracts and device status from anywhere and at anytime.
www.hp.com/go/insightonline
Factory Express Portfolio
for Servers and Storage
HP Factory Express offers configuration, customization, integration and deployment services for HP
servers and storage products. Customers can choose how their factory solutions are built, tested,
integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex
configuration and design services as well as individual factory services, such as image loading, asset
tagging, and custom packaging. HP products supported through Factory Express include a wide array of
servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000
servers as well as the MSAxxxx, VA7xxx, EVA, XP, rackable tape libraries and configurable network
switches.
For more information on Factory Express services for your specific server model please contact your sales
representative or go to: http://www.hp.com/go/factory-express .
HP Simple Configurator SCE is a guided self service tool to help sales and non technical people provide customers with initial
configurations in 3 to 5 minutes. You may then send the configuration on for configuration help, or use in
your existing ordering processes. If you require "custom" rack configuration or configuration for products
not available in SCE, please contact HP's Customer Business Center or an Authorized Partner for
assistance. http://www.hp.com/products/configurator
GPU Computing Modules Each SL250s tray will accommodate up to three GPUs, with options including HP NVIDIA Tesla M2075,
M2070Q, M2090, K2, K10, K20, K20x computational accelerator modules and Intel® Xeon Phi™ 5110p and
Intel® Xeon Phi™ 7120p Coprocessors. The NVIDIA M2070Q module enables computational acceleration as
well as high-end QUADRO® graphics. The other modules are primarily for computational acceleration.
NOTE: Each SL250s tray will accommodate up to three GPUs. For 3 GPU's, at least three (3) HP 1500W
Common Slot Platinum Plus Hot Plug Power Supply Kits (684532-B21) must be used. For 1-2 GPUs, either
three of the 1500W or four of the HP 1200W Common Slot Platinum Plus Hot Plug Power Supply Kit
(578322-B21) must be used.
NOTE: When implementing three M2090's in the SL250s, one must run at the default power cap of 225W. If
implementing two or one, one can run at the higher power cap of 250W.
NOTE: One must configure a minimum of 4GB of memory per CPU when GPU's are installed.
NOTE: Mixing of GPGPU's or coprocessors within the same server is not allowed.
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Optional Features
DA - 14232 North America — Version 29 — December 16, 2013 Page 13

Service and Support HP Technology Services for Industry Standard Servers and BladeSystem
Capitalizing on HP ProLiant server and HP BladeSystem capabilities requires a service partner who
understands your increasingly complex business technology environment. That's why it makes sense to
team up with the people who know HP infrastructure hardware and software best - the experienced
professionals at HP Services.
What HP ProLiant and BladeSystem Services can do for you
HP ProLiant and BladeSystem Services can help you design, deploy, test, integrate, support, and manage
IT and infrastructure solutions. This way, HP proposes services solutions that include more than just uplift
of base warranty. Foundation Care services deliver scalable support-packages for HP industry-standard
servers and software. You can choose the type and level of service that is most suitable for their business
needs. New to this portfolio is HP Collaborative Support. If you are running business critical environments,
HP offers Proactive Care or Critical Advantage. These services help deliver high levels of application
availability through proactive service management and advanced technical response
You can get the support you need by choosing from one of a number of service packaged solutions we
have designed to address wider set of customer support needs.
HP Technology Services meets business challenges with services offered in three support
recommendations - Optimized Care, Standard Care, and Basic Care - available for each product group.
Such support solutions enable customers to optimize technology operations, minimize risk and drive
better business outcomes with easy-to-buy, easy-to-use scalable support recommendations for servers,
storage, networking and software.
All three service recommendations include support services from the broader portfolio of Foundation Care
and Proactive Care services.
Optimized Care Optimized Care: Supports maintaining servers at optimum performance availability
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf
HP Installation and Startup for Insight Control Software / HP SIM
Provides for the deployment and basic configuration of HP Insight Control or HP SIM (Systems Insight
Manager) on HP ProLiant ML and DL series servers or HP BladeSystem servers
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA0-9972ENW.pdf
3-Year HP 24x7 4 hour Response, Proactive Care or Critical Advantage
Helps optimize your systems and delivers high levels of application availability through proactive service
management and advanced technical response. A skilled Technical Manager will own your query or issue
end to end until resolved, delivering a single point of contact for you
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-2140ENW.pdf
Additional Services: Data Center Transformation Services
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Service and Support
DA - 14232 North America — Version 29 — December 16, 2013 Page 14

Standard Care Standard Care: Service recommendation that maintains high level of server availability
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf
HP Installation and Startup for Insight Control Software / HP SIM
Provides for the deployment and basic configuration of HP Insight Control or HP SIM (Systems Insight
Manager) on HP ProLiant ML and DL series servers or HP BladeSystem servers
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA0-9972ENW.pdf
3-Year HP 24x7 4 hour Response, Collaborative Support
Offers customers a single point of contact for server problem diagnosis, hardware problem resolution, and
basic software problem diagnosis, fault isolation, and resolution if available to HP. If the problem is with
HP HW, the representative will arrive on site any time and day of the year to begin hardware maintenance
service within 4 hours of the service request being logged. In case, the issue is with HP or supported third-
party software product and cannot be resolved by applying known fixes, HP will contact the third-party
vendor and create a problem incident on your behalf.
Additional Services: Software OS (Microsoft, Linux (SUSE/Red Hat) & VMware) Installation & Start Up and
Software Support; Microsoft or Linux or VMware education courses; +60 Proactive Select Credits
Basic Care Basic Care: delivers minimum recommended support service level
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN.pdf
3-Year HP 24x7 4 hour Response, Hardware Support Onsite Service
Provides for the deployment and basic configuration of HP Insight Control on HP ProLiant ML and DL series
servers or HP BladeSystem servers
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA0-9972ENW.pdf
Additional Services: Software OS (Microsoft, Linux (SUSE/Red Hat) & VMware) Installation & Start Up and
Software Support; +30 Proactive Select Credits, Factory Express.
Insight Remote Support Provides 24 X 7 remote monitoring, proactive notifications, and problem resolution. Learn more
http://www.hp.com/go/insightremotesupport
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Service and Support
DA - 14232 North America — Version 29 — December 16, 2013 Page 15

HP Support Center Personalized online support portal with access to information, tools and experts to support HP business
products. Submit support cases online, chat with HP experts, access support resources or collaborate with
peers. Learn more http://www.hp.com/go/hpsc
HP's Support Center Mobile App * allows you to resolve issues yourself or quickly connect to an agent for
live support. Now, you can get access to personalized IT support anywhere, anytime.
HP Insight Remote Support and HP Support Center are available at no additional cost with a HP warranty,
HP Care Pack or HP contractual support agreement.
*HP' Support Center Mobile App is subject to local availability
Warranty / Service
Coverage
For ProLiant servers and storage systems, the services cover HP-branded hardware options qualified for
the server, purchased at the same time or afterward, internal to the enclosure, as well as external
monitors up to 22" and tower UPS products; these items will be covered at the same service level and for
the same coverage period as the server unless the maximum supported lifetime and/or the maximum
usage limitation has been exceeded. Coverage of the UPS battery is not included; standard warranty terms
and conditions apply.
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives
replaced by HP due to malfunction. It does not apply to any exchange of Disk or SSD/Flash Drives that
have not failed. SSD/Flash Drives that are specified by HP as consumable parts and/or that have exceeded
maximum supported lifetime and/or the maximum usage limit as set forth in the manufacturer's operating
manual or the technical data sheet are not eligible for the defective media retention service feature option.
For more information To learn more on HP ProLiant servers and HP BladeSystem servers, please contact your HP sales
representative or HP Authorized Channel Partner. Or visit: http://www.hp.com/services/proliant
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Service and Support
DA - 14232 North America — Version 29 — December 16, 2013 Page 16

NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are
ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on
configurable product offerings and requirements.
NOTE: Configure-to-order (CTO) servers must start with a CTO Chassis.
NOTE: FIO indicates that this option is only available as a factory installable option.
NOTE: If you already have an s6500 chassis skip to Step 1A.
NOTE: s6500 Chassis cannot have a mix of SL270s and SL250s and/or SL230s due to different Carbondale (CD) FW versions. You will be
unable to order such a configuration. SL250s and SL230s can be intermixed in an s6500 chassis because they possess the same
Carbondale (CD) FW versions, but one that differs from SL270s. This rule does not apply to any combination of servers with Ivy Bridge
processors, the Carbondale version in those processors is the same.
Step 1: Base Configuration (choose one from each list unless otherwise noted)
HP Chassis HP ProLiant s6500 without Fans 4U Configure-to-order Chassis
NOTE: You must choose Power Supplies and fans as the chassis does not include them.
NOTE: If you already have an s6500 chassis you can buy server trays below.
614167-B21
Step 1A: Select Nodes
NOTE: Mixing and matching of half width trays is supported in the s6500 chassis.
NOTE: If you do not fill up chassis with servers, the HP node blank Kit (688928-B21 for left and 688930-B21 for right) needs to be
ordered for each half width 1U space unpopulated.
HP Server Nodes HP ProLiant SL250s Gen8 2U PCIe Gen3 Left Tray Configure-to-order Svr 698723-B21
HP ProLiant SL250s Gen8 2U PCIe Gen3 Right Tray Configure-to-order Svr 698724-B21
Step 2: Choose Required Node Options (only one of the following from each list unless
otherwise noted)
HP Processors NOTE: If 2 processors are desired, select one xxxxx-L21 and one xxxxxx-B21
Entry Processors - E5-2600 v2 series Processors
NOTE: All support up to 1333MHz memory speeds.
HP SL2x0s Gen8 Intel® Xeon® E5-2609v2 (2.5GHz/4-core/10MB/80W) FIO Processor Kit 725942-L21
Base Processors - E5-2600 v2 series Processors
NOTE: All support up to1600MHz DDR3 memory speeds.
HP SL2x0s Gen8 Intel® Xeon® E5-2630v2 (2.6GHz/6-core/15MB/80W) FIO Processor Kit 725941-L21
HP SL2x0s Gen8 Intel® Xeon® E5-2650Lv2 (1.7GHz/10-core/25MB/70W) FIO Processor
Kit
725943-L21
Performance Processors - E5-2600 v2 series Processors
NOTE: For 130W CPU support and configuration, please contact your HP account team.
NOTE: For 115W CPU support, customers must use the HP 1500W Common Slot
Platinum Plus Hot Plug Power Supply Kit (684532-B21).
NOTE: All support up to 1866MHz DDR3 memory speeds
HP SL2x0s Gen8 Intel® Xeon® E5-2695v2 (2.4GHz/12-core/30MB/115W) FIO Processor
Kit
725944-L21
HP SL2x0s Gen8 Intel® Xeon® E5-2680v2 (2.8GHz/10-core/25MB/115W) FIO Processor
Kit
725937-L21
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Configuration Information - Factory Integrated Models
DA - 14232 North America — Version 29 — December 16, 2013 Page 17

HP SL2x0s Gen8 Intel® Xeon® E5-2670v2 (2.5GHz/10-core/25MB/115W) FIO Processor
Kit
725938-L21
HP SL2x0s Gen8 Intel® Xeon® E5-2660v2 (2.2GHz/10-core/25MB/95W) FIO Processor
Kit
725939-L21
HP SL2x0s Gen8 Intel® Xeon® E5-2650v2 (2.6GHz/8-core/20MB/95W) FIO Processor Kit 725940-L21
Entry Processors - E5-2600 series Processors
NOTE: All support up to 1066MHz memory speeds.
HP SL250s Gen8 Intel® Xeon® E5-2609 (2.4GHz/4-core/10MB/80W) FIO Processor Kit 662326-L21
HP SL250s Gen8 Intel® Xeon® E5-2603 (1.8GHz/4-core/10MB/80W) FIO Processor Kit 662327-L21
Base Processors - E5-2600 series Processors
NOTE: All support up to1333MHz DDR3 memory speeds.
HP SL250s Gen8 Intel® Xeon® E5-2640 (2.5GHz/6-core/15MB/95W) FIO Processor Kit 662323-L21
HP SL250s Gen8 Intel® Xeon® E5-2630 (2.3GHz/6-core/15MB/95W) FIO Processor Kit 662324-L21
HP SL250s Gen8 Intel® Xeon® E5-2620 (2.GHz/6-core/15MB/95W) FIO Processor Kit 662325-L21
HP SL250s Gen8 Intel® Xeon® E5-2630L (2.0GHz/6-core/15MB/60W) FIO Processor Kit 662332-L21
Performance Processors
NOTE: For 130W CPU support and configuration, please contact your HP account team.
NOTE: For 115W CPU support, customers must use the HP 1500W Common Slot
Platinum Plus Hot Plug Power Supply Kit (684532-B21).
HP SL250s Gen8 Intel® Xeon® E5-2670 (2.6GHz/8-core/20MB/115W) FIO Processor Kit 662319-L21
HP SL250s Gen8 Intel® Xeon® E5-2665 (2.4GHz/8-core/20MB/115W) FIO Processor Kit 662320-L21
HP SL250s Gen8 Intel® Xeon® E5-2660 (2.2GHz/8-core/20MB/95W) FIO Processor Kit 662321-L21
HP SL250s Gen8 Intel® Xeon® E5-2650 (2.0GHz/8-core/20MB/95W) FIO Processor Kit 662322-L21
HP SL250s Gen8 Intel® Xeon® E5-2650L (1.8GHz/8-core/20MB/70W) FIO Processor Kit 662331-L21
HP SL250s Gen8 Intel® Xeon® E5-2637 (3.0GHz/2-core/5MB/80W) FIO Processor Kit 662330-L21
HP Memory NOTE: HP memory from previous generation servers are not qualified or warranted with
this HP ProLiant Server. HP SmartMemory is required to realize the memory
performance improvements and enhanced functionality listed in this document for
Gen8. For additional information, please see the HP SmartMemory QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/14225_na/14225_na.html
NOTE: LRDIMM, RDIMM, and UDIMMs are all distinct memory technologies and cannot
be mixed within a server. The majority of ProLiant Gen8 servers support LRDIMM,
RDIMM and UDIMMs.
Registered DIMMs (RDIMMs)
NOTE: The following memory is supported by the E5-2600 v2 series Processors.
HP 4GB (1x4GB) Single Rank x4 PC3L-12800R (DDR3-1600) Registered CAS-11 Low
Voltage Memory Kit
713981-B21
HP 4GB (1x4GB) Single Rank x4 PC3-14900R (DDR3-1866) Registered CAS-13 Memory
Kit
708637-B21
HP 8GB (1x8GB) Dual Rank x4 PC3L-12800R (DDR3-1600) Registered CAS-11 Low
Voltage Memory Kit
713983-B21
HP 8GB (1x8GB) Single Rank x4 PC3L-12800R (DDR3-1600) Registered CAS-11 Low
Voltage Memory Kit
731765-B21
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Configuration Information - Factory Integrated Models
DA - 14232 North America — Version 29 — December 16, 2013 Page 18

HP 8GB (1x8GB) Dual Rank x4 PC3-14900R (DDR3-1866) Registered CAS-13 Memory Kit 708639-B21
HP 8GB (1x8GB) Single Rank x4 PC3-14900R (DDR3-1866) Registered CAS-13 Memory
Kit
731761-B21
HP 16GB (1x16GB) Dual Rank x4 PC3L-12800R (DDR3-1600) Registered CAS-11 Low
Voltage Memory Kit
713985-B21
HP 16GB (1x16GB) Dual Rank x4 PC3-14900R (DDR3-1866) Registered CAS-13 Memory
Kit
708641-B21
Registered DIMMs (RDIMMs)
NOTE: The following memory is supported by the E5-2600 series Processors.
HP 4GB (1x4GB) Single Rank x4 PC3L-10600R (DDR3-1333) Registered CAS-9 Low
Voltage Memory Kit
647893-B21
HP 4GB (1x4GB) Single Rank x4 PC3-12800R (DDR3-1600) Registered CAS-11 Memory
Kit
647895-B21
HP 8GB (1x8GB) Dual Rank x4 PC3L-10600R (DDR3-1333) Registered CAS-9 Low
Voltage Memory Kit
647897-B21
HP 8GB (1x8GB) Single Rank x4 PC3-12800R (DDR3-1600) Registered CAS-11 Memory
Kit
647899-B21
HP 8GB (1x8GB) Dual Rank x4 PC3-12800R (DDR3-1600) Registered CAS-11 Memory Kit 690802-B21
HP 16GB (1x16GB) Dual Rank x4 PC3L-10600R (DDR3-1333) Registered CAS-9 Low
Voltage Memory Kit
647901-B21
HP 16GB (1x16GB) Dual Rank x4 PC3-12800R (DDR3-1600) Registered CAS-11 Memory
Kit
672631-B21
Unbuffered with ECC DIMMs (UDIMMs)
NOTE: The following memory is supported by the E5-2600 v2 series Processors.
HP 2GB (1x2GB) Single Rank x8 PC3L-12800E (DDR3-1600) Unbuffered CAS-11 Low
Voltage Memory Kit
713975-B21
HP 2GB (1x2GB) Single Rank x8 PC3-14900E (DDR3-1866) Unbuffered CAS-13 Memory
Kit
708631-B21
HP 4GB (1x4GB) Dual Rank x8 PC3L-12800E (DDR3-1600) Unbuffered CAS-11 Low
Voltage Memory Kit
713977-B21
HP 4GB (1x4GB) Dual Rank x8 PC3-14900E (DDR3-1866) Unbuffered CAS-13 Memory
Kit
708633-B21
HP 8GB (1x8GB) Dual Rank x8 PC3L-12800E (DDR3-1600) Unbuffered CAS-11 Low
Voltage Memory Kit
713979-B21
HP 8GB (1x8GB) Dual Rank x8 PC3-14900E (DDR3-1866) Unbuffered CAS-13 Memory
Kit
708635-B21
Unbuffered with ECC DIMMs (UDIMMs)
NOTE: The following memory is supported by the E5-2600 series Processors.
HP 2GB (1x2GB) Single Rank x8 PC3-12800E (DDR3-1600) Unbuffered CAS-11 Memory
Kit
669320-B21
HP 2GB (1x2GB) Single Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low
Voltage Memory Kit
647905-B21
HP 4GB (1x4GB) Dual Rank x8 PC3-12800E (DDR3-1600) Unbuffered CAS-11 Memory
Kit
669322-B21
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Configuration Information - Factory Integrated Models
DA - 14232 North America — Version 29 — December 16, 2013 Page 19

HP 4GB (1x4GB) Dual Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low
Voltage Memory Kit
647907-B21
HP 8GB (1x8GB) Dual Rank x8 PC3-12800E (DDR3-1600) Unbuffered CAS-11 Memory
Kit
669324-B21
HP 8GB (1x8GB) Dual Rank x8 PC3L-10600E (DDR3-1333) Unbuffered CAS-9 Low
Voltage Memory Kit
647909-B21
Load Reduced DIMMs (LRDIMMs)
NOTE: The following memory is supported by the E5-2600 v2 series Processors.
HP 32GB (1x32GB) Quad Rank x4 PC3-14900L (DDR3-1866) Load Reduced CAS-13
Memory Kit
708643-B21
NOTE: All DDR3 memory option kits consist of one DIMM per kit. For detailed memory
configuration rules and guidelines, please use the Online DDR3 Memory Configuration
Tool: www.hp.com/go/ddr3memory-configurator .
NOTE: Kits described as LP include Low Power DIMMs. For more information on ProLiant
Energy Efficient Features, see: www.hp.com/go/proliant-energy-efficient
NOTE: PC3L is a low voltage memory
Step 3: Choose Additional Factory Integratable Options
HP Networking Gigabit Ethernet Adapters
HP Ethernet 1Gb 4-port 366FLR FIO Adapter 684217-B21
FlexibleLOM Adapters
HP FlexFabric 10Gb 2-port 526FLR-SFP+ FIO Adapter 684219-B21
HP Ethernet 10Gb 2-port 560FLR-SFP+ FIO Adapter 684218-B21
HP Ethernet 10Gb 2-port 561FLR-T FIO Adapter 700700-B21
HP FlexFabric 10Gb 2-port 534FLR-SFP+ FIO Adapter 700752-B21
HP FlexFabric 10Gb 2-port 533FLR-T FIO Adapter 700760-B21
NOTE: Please see the QuickSpecs for Technical Specifications and additional
information: www.hp.com/go/ProLiantNICs
HP Insight Software HP Insight Control including 1yr 24x7 Support ProLiant ML/DL/BL-bundle Single Server
FIO License
C6N36A
Step 4: Choose Additional Options for Factory Integration
NOTE: For additional options, please refer to the "Core Options" and "Additional Options" section below.
QuickSpecs
HP ProLiant SL250s Generation 8 (Gen8)
Configuration Information - Factory Integrated Models
DA - 14232 North America — Version 29 — December 16, 2013 Page 20
