HPC EI Series Installation instructions

VILLA, FORNO AND
Di NAPOLI SIGNITURE
SERIES
EISeries
On/Off Models
Installation&OperationInstructions
Hearth Products Controls
860-EION/OFF

2
This is a Safety Alert Symbol
Whenyouseethissymbolonthefirepitinsert,or inthismanual,
lookforone of thefollowingsignalwordpanelsalertingyouto
thepotentialforpersonalinjury,deathor majorpropertydamage.
WARNING: For Outdoor Use Only.
Installation and service must be performed by a qualified
installer, service agency, or the gas supplier.
WARNING
Do not store or use gasoline or other flammable vapors
and liquids in vicinity of this or any other appliance.
An LP-cylinder not connected for use shall not be stored
in the vicinity of this or any other appliance.
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
Shut off gas to the appliance.
Extinguish an open flame.
If odor continues, leave the area immediately.
After leaving the area, call your gas supplier or fire
department.
Failure to follow these instructions could result in fire or
explosion, which could cause property damage, personal
injury, or death.
DANGER
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide
which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed
space
such as a camper, tent, car or home.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.

3

4
Table of Contents
1 ImportantSafetyInformation .................................................................................................5
Technical Support..................................................................................................................5
Symbol Legend ..................................................................................................................... 6
Important Safety Information for Installers............................................................................ 7
Important Safety Information for End-Users......................................................................... 8
2 RemoteLPTankSystemEnclosureRequirements-IfApplicable ........................................ 9
3 Lighting the Oven ................................................................................................................. 13
4 First Firing ............................................................................................................................................ 15
5 Forno Series Installation ...................................................................................................... 16
6 Battery Requirements (Battery or DC Adaptor) ............................................................... 22
7 Villa Series Installation ..................................................................................................................... 23
8 Di Napoli Series Installation ............................................................................................................31
9 Troubleshooting ............................................................................................................................... 42
10 Combatable Accessories ……………………………………………………………………………… 43
11 Replacement Parts………………………………………………………………..………………………..43
12 Wiring Diagram…………………………………………………………………………………………….44
13 Warranty ............................................................................................................................................. 45

5
Important Safety Information
• HPC Fire Inspiredrecommendsthatourproductsareinstalled by
professionalslocallylicensedbytheauthorityhavingjurisdictioningas
piping. Allinstallationinstructionsmustbefollowedtoensureproper
performanceand safety.HPC Fire Inspiredassumesnoresponsibility
forproblems relatingtotheinstallation.
• Toqualifyforwarranty,allinstructionsmustbestrictlyfollowed.
Otherwise, warrantymaybevoid.Neveralterproductor
configurationinanyway.
• Annualservicingshould behandled byprofessionals certifiedinthe
US by the National FireplaceInstitute (NFI) as NFIGas Specialists
orinCanadabyWETT (Wood Energy Technical Training).
• Itistheinstaller’sresponsibilitytoensureasafeinstallationandto
educatethe end-userregardingthefeatures,safety
recommendationsandproperoperation of this product.
• Pleasereferencepage1forallwarnings.
Technical Support
ForinformationandsupportcontactyourHearthProductsControlsdealer.
INSTALLER:
Leavethismanualwith
the appliance.
ENDUSER:
Retainthismanualfor
future reference.

6
Important Safety Information
Symbol Legend
This is a Safety Alert Symbol
Whenyouseethis symbolonthe firepitinsert,orinthis
manual,lookforone ofthefollowingsignalwordpanels
alertingyoutothepotentialforpersonal injury,deathor major
propertydamage.
Necessary instructions

7
Important Safety Information
Please reference page 1 for all warnings.
Important Safety Information for Installers
Leave this manual with theend-user and instruct them to retain itfor
future reference.Instructionsandproductupdatesarealsoavailableat
www.hpcfire.com under the Support tab.
Installersmustcarefullyfollowtheinstructionsinthismanualtoprevent
personal injuryorpropertyloss.Theseinstructionscontaininformation
criticaltothesafe installationandoperationofthefirepit.
• Instructionsareupdatedasneeded. It istheresponsibilityofthe
installersto check for product updates and installation manual
updates atwww.hpcfire.com/ support.htmlpriortoinstallation.
• Itistheresponsibilityofthe installertofollow:
- TheNationalFuelGasCode,ANSIZ223.1/NFPA54orInternationalFuel
GasCode.
- Natural Gas and Propane Installation Code CSA B149.1 or CSA
B149.2.
- TheNationalElectricalCode,ANSI/NFPA70. In Canada, Canadian Electrical Code CSA22.1.
- Localcodes
• Controloptions:Useof wallswitch,optionalremotecontrol(#578-C),
automatic shut-offtimerorwholehousesystem.
Gas
• Onlyuse thegas/fuel typespecifiedforthis firepit,refer to the labelon
thefirepit controlbox.Neveruseanalternativefueltoincludebiofuel,
ethanol,lighterfluidor anyotherfuel.
• Gaspressureand type shouldbecheckedprior to useandinstallation.
- Natural Gas Fire Pit: Supply Pressure: Minimum: 6.0
inchesW.C.; Maximum:7.0inchesW.C.
- LPGas: SupplyPressure:Minimum:8.0
inchesW.C.; Maximum:11.0inchesW.C.
If pressure is low, this will reduce flame height
on HIGH setting, possibly resulting in little to
no flame variation.

8
Important Safety Information
The oven is not to be installed in or on a recreational vehicle and/or boat.
Consider when installing:
1. Always maintain a minimal clearance of 24 inches or 60 cm from all sides of oven to any
combustible construction.
2. Minimum clearance of most superior part of oven opening to any combustible material
immediately above the oven’s opening; including attached roof overhang/soffit
connected to a building is 36 inches. Do not obstruct the flow of combustion and
ventilation air.
3. Keep the ventilation opening(s) of the cylinder enclosure free and clear from debris.
WARNING
DO NOT lean on oven.
NEVER use lighter fluid in the oven.
Oven is hot when in use; to avoid burns, DO NOT touch hot oven parts or
surfaces. Keep children and pets away from hot oven.
NEVER leave the oven unattended while it is in use.
It is your responsibility to assemble and store, operate and care for your gas
oven properly.
Do not vent propane vapors from the cylinder before taking it to be refilled.
Do not use oven indoors or store any propane cylinder indoors, including in
the garage, breezeways, sheds or enclosed areas.
Under some circumstances, propane may lose the distinctive odor that was
added. Keep the service valve closed and plugged or capped (as recommended
by the manufacturer) when the cylinder is not connected to the appliance
including “empty” cylinders, Other strong odors may hide or mask the odor of
propane. Colds, allergies, sinus congestion and the use of tobacco, alcohol or
drugs may impair your ability to detect the odor of propane.
WARNING
DO NOT move oven while it is operating or hot.
Keep outdoor cooking gas appliance area clear and free of combustible
materials, gasoline or other flammable vapors or liquids.

9
RemoteLP TankSystem EnclosureRequirements-IfApplicable
Locate the hose out of pathways to avoid
accidental damage and prevent it from
becoming a trip hazard.
ForanenclosureusinganLPtanksystem,followthese
recommended specifications:
• Youmust follow localcodes.
• Onesideoftheenclosureshallbecompletelyopen;OR
• Foranenclosurehavingfour sides,
atop,and a bottom:
- Atleasttwoventilationopeningsshall
beprovided inthe side walls of the
enclosure, located within 5 inches
(127mm)ofthetopofthe enclosure,
equally sized, spaced at a minimum of
180degrees,and unobstructed.The
opening(s)shallhaveatotalfree area
of not less than 1 in2 lb (14.2 cm2kg) of
stored fuelcapacity.SeeFigure6.1.
- Ventilationopening(s)shallbeprovidedatthe
floor leveloftheenclosureandshallhavea
totalfreearea of not less than 1/2 in2 lb (7.1
cm2kg) of stored fuel capacity.Ifventilation
openingsatfloorlevelareina sidewall,there
shallbeat leasttwoopenings.The bottom of
the openings shall be 1 inch (25.4mm) or less
from thefloor leveland the upper edge no
more than5inches(127mm)abovethefloor
level.The openingsshallbeequallysized,
spacedataminimum of 180 degrees and
unobstructed. See Figure 6 1.
• Everyopeningshallhaveminimumdimensionsso
asto permit the entrance of an1/8 inch (3.2mm)
diameter rod.
Figure6.1 –Topandbottomsideventilation
openings forLPtankenclosure.

10
Remote LP Tank System Enclosure Requirements - If Applicable
• Ventilationopeningsinsidewallsshallnotcommunicatedirectly
withother enclosuresofthe appliance.SeeTables6.1 and6.2.
LP Tank Size
Top Opening
Bottom Opening
20LB(9.1KG)
20 in2 (130cm2)
10 in2 (65cm2)
30LB(13.6KG)
30in2 (195 cm2)
15in2 (100 cm2)
Table6.1–LPtankenclosureopeningspecificationsbytanksize.
LP TankEnclosure Specifications
2 Openings for each top and bottom - 180° apart
From LP tank base to bottom of opening - Max. 1" (25.4mm)
From floor to base of LP tank - Min. 2" (50.8mm)
Table6.2–LPtankenclosureopeningspecifications.
• Thecylindervalveshallbereadilyaccessibleforhandoperation.Adoor
onthe enclosuretogain access tothe cylinder valves is acceptable,
providedit is non- locking and can be opened without the use of tools.
Designs using a cover to gain accesstothecylinderand cylindervalve
shallbeprovidedwithhandlesorthe equivalent at aminimum of180
degreesapart tofacilitate lifting of thecover.
• TheenclosurefortheLP-gascylindershallisolatethecylinderfrom
theburner compartment to provide:
- Shielding from radiation;
- Aflamebarrier;and
- Protectionfromforeignmaterial.
• Thereshallbeaminimumclearance of 2inches(50.8mm) betweenthe
floorofthe non-disposableLP-gascylinderenclosureandtheground.
• Thedesignoftheenclosureshallbesuchthat:
- Anon-disposableLP-gascylindercanbeconnected,
disconnected,and the connectionsinspectedandtestedoutside
thecylinderenclosure;and
- Thoseconnections, whichcouldbedisturbedwheninstallingthe
cylinderinthe enclosure,canbeleak-testedinsidetheenclosure.

11
Remote LP Tank System Enclosure Requirements - If Applicable
Propane Cylinder: Safety Requirements
• Thisappliancehas been designed for use with a20-lb. or30-lb.
sizepropane cylinder (not supplied).
• Thepropanecylindershouldbechecked byyourpropane
supplierpriorto installation and use.
• Neveruseacylinderwithadamagedvalve.Aworncylindermaybe
hazardousand should be checked byyour propane supplier.
• Useonlya propanesupplycylinderconstructedand markedin
accordancewiththe specificationsforLPgascylindersbytheNational
StandardofCanada,CAN/CSA B339,Cylinders,SpheresandTubesfor
TransportationofDangerousGoods;and Commission,asapplicableor
theSpecificationsforLP-GasCylindersofbytheU.S. Department of
Transportation (DOT).
• DonotstoreaspareLP-gas cylinderunderor nearthisappliance.
• Neverfillthecylinderbeyond80percentfull.
• Onlyusethepressureregulatorandhoseassemblyprovidedwiththis
appliance orreplacementpressureregulatorsandhoseassembliesas
specifiedbythe manufacturer.Theregulatorsuppliesa pressureof11
inches water column tothe applianceandhasaQCC1typefitting.
Propane cylinder specifications
• Thepropanecylindermustbeprovidedwithacylinder
connectiondevice compatiblewiththeconnectionforoutdoor
appliances.
• Thepropanecylindermustbesupplied witha shut-offvalveterminatingin
apropane cylindervalvetypeQCC1andincludeacollartoprotectthe
cylindervalve.AQCC1 cylinderhasapositiveseatingconnection, which
willnotallowgastoflowuntila positivesealhasbeenachieved.Itisalso
equippedwithanexcessflowdevice.In order toattain full flow to the
appliance, the valve must be in the off position when thecylindervalveis
turnedon.
• Thepropanecylindermusthaveasafetyreliefdevicehavingdirect
communication with the vapor space of thecylinder.
• Thecylindersupplysystemmustbearrangedforvaporwithdrawal.
• Thecylindershallincorporatelistedoverfillprotectiondevice(OPD).

12
INSTALLATION
Wesuggestthat our products beinstalled by
professionalsthatarelocallylicensedbythe
authorityhavingjurisdictioningaspiping.
Remote LP Tank System Enclosure Requirements - If Applicable
SecuringtheLPtank:
1. Fasten the L-bracket to the bottom of the
propane tankusingthenutand bolt
(supplied).Ensurethenut istight and will
notloosen.
2. Selectthe locationfor thepropanetank
followingthe guidelinesabove,Figure6.2.
3. Screw the bracket to the mounting
surface. For concretesurface,usea
concreteanchor(not supplied).
Ensurethatscrewistight sothat the
cylindercannotmove.
Connecting the Cylinder:
1. Ensurethegas regulatorhas no
kinksandis smooth.
2. Removethecaporplugfromthecylinderfuel
valve.
3. Inserttheblack QCC1regulatornipple
ontothe QCC1fuelvalve andtighten
untilsnug.Donotuse tools.
4. Perform a leak teston alljoints priorto
usingthe gas appliance.Aleaktestmust
beperformedannually and each time a
cylinder is hooked up or if a part of the
gassystem isreplaced.
5. Followtheinstructionsfornaturalgas
hook-upif the appliance is tobe
connected directlytoa house propane
gassupplyline.
WARNING
Failure to follow location and mounting guidelines
for the LP tank could result in serious injury.
WARNING
• Locate the LP Tank and enclosure out of pathways
to avoid accidental damage and prevent them
from becoming a trip hazard.
• Locate the hose out of pathways to avoid
accidental damage and prevent it from becoming
a trip hazard.
WARNING
• Always ensure L-bracket is securely fastened to
prevent the LP tank from tipping.

13
Lighting the Oven
This oven is equipped with an electronic ignition system. This system can operate with 2 D batteries or it
can be used with a 3 volt DC adaptor. The batteries should last between 6months to 1 year depending
on use and where the oven is placed (extreme heat and cold temperatures will decrease the life of the
batteries). Please check battery frequently to make sure its appearance is normal. We recommend
battery replacement every 1 year from time of purchase. HPC Hybrid Oven also has an adaptor that can
be used to electronically ignite the pilot and operate the oven gas burner. This adaptor has to be plugged
in an 110v GFCI outlet.
The oven’s gas burner will not operate unless the safety pilot is on.
Please follow these steps to turn your burner on:
Make sure burner is clear of ashes or debris.
Make sure valve control valve is on off position.
Turn on valve on LP cylinder or natural gas shut off valve
Turn valve in the oven control panel to off position.
Turn electronic igniter switch to ON. It might take 30 to 60 seconds for gas to travel from tank to
pilot the first time you start your oven)
Once pilot is lit, turn the gas control knob from OFF position slowly to regulate burner flame.
Turn gas regulator knob to OFF and place small pieces of dried hardwood on burner. Regulate
gas flame so wood can ignite. Leave gas on.
Once wood has ignited and smaller pieces of coals have formed, with the back of brush push
wood to center of oven to heat the hearth. Then place more wood on top of coals.
Leave the gas line ON. It will do a couple of things
1. Keep the oven hot and the flame steady
2. Keep the smoke to a minimum
(If you have too much smoke because the fire is dying, wood is wet or not enough wood –try turning the
gas up a bit, it usually burns off the smoke.)
Your oven should be hot enough to bake a pizza in about 30 min. (obviously cooler temperatures
take a bit longer) the use of our insulating blanket should also help with heat retention.)
Different locations in the oven heat up differently –The hearth at its hottest temperature gets
around 800°. Inside the dome on top-over 1000°. The outside of dome on left side (where the
burner is lit) can reach about 400° The dome on the opposite side of the burner can reach about
300°.
Gas control knob. Turns flame up or down
Pilot has to be ignited for burner flame.
On/Off switch

14
Lighting the Oven
A good way to test the hearth to see if it is hot enough to bake a pizza –throw some flour on
hearth and it should burn within 1-2 seconds. If not, then with brush bring the wood back to center
of oven, add more wood and let it burn hotter. Then move it to the back of the oven.
Brush center of the hearth
Place pizza on hearth and turn pizza ¼ turn every 30 seconds or watch for golden brown on
cheese and dough.
Remove pizza and enjoy.
To Use a Grill
Follow same steps to start oven and hearth
Place disposable aluminum pan on hearth to catch grease.
Insert grill rack with a hot pad/mittens
Add grill rack to oven (It’s a good idea to spread some olive oil on the grill rack top before putting
it in the oven.)
Add food –Watch it sizzle
Remove. Enjoy.
If your food doesn’t need a grease pan, you can leave ambers on hearth and slide grill rack on
top of it.
You may grill, bake, or use a skillet on top of the rack. The possibilities are endless.
We suggest the use of an infrared thermometer if you want to do more detailed temperature
control like breads and chicken.
We suggest baking bread in the front of the oven where the temperature is around 300-400°.
We suggest smoking after cooking is complete. Close the door and let the fire die out. Adding
some of your favorite smoking wood chips to the “died-out fire” will create smoke in the oven and
it will remain circulating inside the oven. Smoking should be done at lower temperatures. Oven
door temperature gauge should be pretty accurate in displaying oven temperature.
Heat control can be achieved by decreasing the amount of wood, decreasing gas, closing the
door (Door works as a damper-less oxygen entering oven, less fire).
BAKE
You may also bake bread in the oven. Turn on gas and leave door half open. Regulate heat. Bake.
Whenever you are done using oven, make sure LP tank is off and let oven cool down.
Do not place outdoor cover on till oven has cooled down.
Careful! Door will be hot. Only touch the wooden handle.
CAUTION
Never place door without door vent whenever gas is turned on. It might cause an
explosion. If smoking, remove door vent turn gas completely “off” at gas control knob
and at the LP tank/shut off valve.

15
FirstFiring
HPC Hybrid Oven ovens are constructed for optimum performance. It is important to heat
the oven gradually if water has come in contact with the oven.
If water gets absorbed by oven, small cracks might appear if quick oven heating occurs.
About your refractory oven:
A refractory material is one that
retains its strength at
high temperatures. Your oven’s
refractory material can withstand
temperatures up to 2400 degrees.
Unlike other ovens in the industry
that are multi–pieced and joined
together with mortar, your oven is
shaped as one piece allowing it to be
moved maintaining its shape and
aesthetics of a century’s old oven.
This shape enables the best
functional heat distribution in the
oven. Its two inch wall thickness
reflects enough heat back to the
inside of the oven, and the
temperature on the outside of the
oven remains one third of the inside
temperature; optimizing heat
retention .
3 heat sources and
temperatures that exceed
1000°
Important information:
Once your oven is poured and
removed from its mold, it goes
through a drying process that allows
water to evaporate. Glass is
mortared using a proprietary
formula that will withstand the high
heat generated during normal
operation. In order to properly cure
the glass to the oven a heat up
schedule should be properly
performed. During your first oven
firing, small water molecules that
remained trapped in the refractory
during the drying process will come
out in a vapor form.
WOOD-OAK-ONLY!
Simple and very important for proper
operation.
-Use at least 1 year dried , debarked
1 1/2 to 3 inch diameter, 12 to 14
inch long OAK. You’ll have
consistency during operation, no
smoke, no popping ambers on to
your food, intense heat and a great
smell.
Your oven’s first firing:
First time firing-heat up with gas only.
1. Start with a 1/2 inch very low flame on
the gas burner for 2 hours.
2. Raise flame to 1 1/2 inch in size for 1
hour.
3. Increase flame to 2 1/2 for 1 hour
4. Stoke with kindling on the burner to
continue to raise oven’s temperature
for another 1 hour
5. Do not use door during first firing
6. Complete at least 5 hours for the first
firing
Important:
Follow oven curing instructions to maximize the
longevity
of your oven.
Do not
heat up the oven too quickly. It will
damage the tile.

16
FornoSeriesInstallation
Cart Hearth Oven
Preparation

17
FornoSeriesInstallation
HOW TO DISASSEMBLE AND REASSEMBLE YOUR OVEN
(this method should be used when moving oven to a location that it cannot be rolled to)
You must use HPC Hybrid Oven’s transporting kit
1. Remove gas line from under hearth
3.Unscrew 4 pins from top of
oven. Make sure those pins are
replaced when oven is
reassembled when oven
4.Place wood in front of
pilot(to protect it), lift oven
and place board under
oven. Lower oven to board
carefully, secure it with
bungee cords
2. Remove 3 screws
from under cart
Board placed in front of pilot

18
FornoSeriesInstallation
6. Place hearth to another
sturdy location
7. Place cart to desired location
5. Two people transfer oven to sturdy
location. Prior to re-assembly.
8. Place hearth on top of cart. Tighten 3 underneath
screws, then re-install gas regulator (make sure pipe
paste or tape for gas is applied on pipe threads.

19
FornoSeriesInstallation
12. Push control knob in pilot position and light up the pilot, wait 5
seconds turn knob to on and control heat intensity
13. Turn knob to off position. You’ve
completed the installation.
5.
9. Place oven on top of hearth.
Carefully Remove bungee cords.
10. Place oven in desired location, carefully lift
front of oven so rear is in contact with carbon
fiber gasket and remove board.
11. Place locking
pins on hearth.

20
FornoSeriesInstallation
Natural gas connection
The Forno Series can be purchased to be used with natural gas.
This connection has to be done by a licensed hearth installer.
It’s very important to have correct diameter gas lines for desired oven output.
A shut off valve should be placed between the house and the oven.
Connect an approved Natural Gas line to the right side of the oven, located on the underside of
the oven hearth plate.
Make sure all the connections are tight and comply with local codes. Turn gas shut off valve on
and check for leaks.
Follow how to start the oven instructions.
Natural Gas needs to
be connected here.
The installation of this appliance must conform with local codes or, in the absence of local codes , with either
the National Fuel code, ANSI Z223.1/NFPA54, National Gas propane Installation code, CSA B149.2.Installation
in Canada must be in accordance with the standard CAN/CGA-B149.2.(Installation code for gas burning
appliances and equipment) and local codes
Gas pressure is affected by gas line and length of gas line from house gas line. Please follow recommendations
on the chart:
Distance
Tubing size
4ft(stainless flex line) to oven connection from valve
½” diameter
Up to 25’
3/4’” diameter
26’ to 50’
1”diameter
51’to 100’
2/3 of run 1 ¼” 1/3 of run 3/4”
