KitchenAid KSMMGA User manual

KSMMGA
W11204951A_ENv07.indd 1 3/2/18 4:45 PM

PARTS AND FEATURES
PARTS AND ACCESSORIES
Food pusher
Blade
Fine grinding
plate (3 mm)
Sausage
stuffer plate
Coarse
grinding plate
(8 mm)
CollarMedium
grinding plate
(4.5 mm)
Main housing
Grind screw
Removable tray
Cleaning brush
Small sausage stuffer
tube (9.5 mm)
Large sausage stuffer
tube (19 mm)
W11204951A_ENv07.indd 2 3/2/18 4:45 PM

ENGLISH
METAL FOOD GRINDER ATTACHMENT SAFETY | 3
METAL FOOD GRINDER ATTACHMENT SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed, including the following:
1. Read all instructions.
2. This appliance is not intended for use by persons (including children) with
reduced physical, sensory, or mental capabilities, or lack of experience or
knowledge, unless they are closely supervised and instructed concerning use
of the appliance by a person responsible for their safety. Close supervision is
necessary when any appliance is used by or near children. Children should be
supervised to ensure that they do not play with the appliance.
3. Turn the Stand Mixer OFF (and detach the Metal Food Grinder attachment from
the Stand Mixer) after each use of the attachment and before cleaning. Make
sure motor stops completely before disassembling.
4. Avoid contacting moving parts. Keep ngers out of discharge opening.
5. The use of attachments not recommended or sold by KitchenAid may cause
re, electric shock, or injury.
6. Never feed food by hand. Always use the food pusher.
7. Blades are sharp. Handle carefully.
W11204951A_ENv07.indd 3 3/2/18 4:45 PM

4| USING THE METAL FOOD GRINDER ATTACHMENT
METAL FOOD GRINDER ATTACHMENT SAFETY
USING THE METAL FOOD GRINDER ATTACHMENT
GUIDE TO GRINDING
8. Do not use ngers to scrape food away from discharge disc while appliance is
operating. Cut-type injury may result.
9. Also see the Important Safeguards section included in the Stand Mixer Use
and Care guide.
SAVE THESE INSTRUCTIONS
This product is designed for household use only.
NOTE: None of the parts and accessories of this KitchenAid®Metal Food Grinder attachment
(model KSMMGA) are compatible with the parts and accessories of the KitchenAid®Food
Grinder attachment (models FGA, SSA, FT, FVSP, FVSFGA, KSMFPPA, KSMGSSA) and vice
versa.
USE THESE PARTS WITH THESE
PARTS
SUGGESTED
USES SPEED
Fine grinding plate
(3 mm) Blade Cooked meats for spreads, hard
cheeses (e.g. Parmesan), bread
crumbs 4
Medium grinding plate
(4.5 mm) Blade Raw or cooked meats, meats for
sausages 4
Coarse grinding plate
(8 mm) Blade Raw meats for burgers and chili,
vegetables for salsas and sauces 4
Small sausage stuffer
tube (9.5 mm) Sausage stuffer plate Breakfast sausage, smaller sausages 4
Large sausage stuffer
tube (19 mm) Sausage stuffer plate Bratwurst, larger sausages 4
W11204951A_ENv07.indd 4 3/2/18 4:45 PM

ENGLISH
USING THE METAL FOOD GRINDER ATTACHMENT | 5
USING THE METAL FOOD GRINDER ATTACHMENT
ASSEMBLING THE METAL FOOD GRINDER ATTACHMENT
1
Insert the grind screw into the main housing. Then,
place the blade over the end of the grind screw.
The blade should t entirely inside the housing. If it
doesn’t, pull it off, turn it over, and place it again.
2 Place grinding plate over the blade, matching the
notch of the plate with the tab on the bottom of the
main housing.
3 Place the collar on the main housing, turning clockwise
by hand until secured but not tightened.
Wash all parts with warm, soapy water and dry thoroughly before use.
ATTACHING THE METAL FOOD GRINDER ATTACHMENT TO THE
STAND MIXER
1 Turn the Stand Mixer off and unplug.
2
For Stand Mixers with a hinged attachment hub
cover: Flip up to open.
For Stand Mixers with a removable attachment hub
cover: Turn the attachment knob counterclockwise to
remove attachment hub cover.
3
Insert the attachment shaft housing into the
attachment hub, making certain the power shaft ts
into the square hub socket. If necessary, rotate the
attachment back and forth. The pin on the attachment
housing will t into the notch of the hub rim when in
the proper position.
Tab
Notch
