hpmont HC10 Series User manual

V1.2 2021.12
HC10 Series Analog Module
User Manual

Size and Gross Weight ............................................... 1
Structure Description.................................................. 2
L0303A Terminal Description ...................................... 4
L0402A Terminal Description ...................................... 5
L0800A Terminal Description ...................................... 6
Product Specifications ................................................ 7
General Specifications...................................................... 7
Analog Input Specifications (L0303A/L0800A)..................8
Analog Input Specifications (L0402A)............................... 9
Analog Output Specifications (L0303A) .......................... 10
Analog Output Specifications (L0402A) .......................... 11
Instructions ............................................................. 12
Instruction Description (FROM, TO, RD3A) .................. 14
Module Data Address Description (L0303A/L0800A) ...... 16
Module Data Address Description (L0402A).................... 17

Warning
• Be sure to check the terminal label carefully
when wiring.
• Avoid installation in places exposed to direct
sunlight, moisture, or water.
• Avoid installation in locations with
flammable and explosive gases and liquids.
• Avoid installation in areas with oily dust,
fibers and metal particles.
• Use rails or M3 screws for installation.

HC10 Series Analog Module User Manual V1.2 1
Size and Gross Weight
54
74.5
35.5
46
85
93
84
74.5
35.5
76
85
93
1
GW: 0.25kg
2
GW: 0.3kg
Unit: mm

HC10 Series Analog Module User Manual V1.2 2
Structure Description
1/3 Input and output terminal
2Extension cable
4Expansion port
5Power/run/fault indicator
LED
1
6Mounting fixing hole (M3)
7DIN guideway groove
(35mm)
8DIN rail fixing buckle
3
4
1
25
6
7
8

HC10 Series Analog Module User Manual V1.2 3
2
3
1
2
6
4
5
7
8
Structure Description (Continued)

HC10 Series Analog Module User Manual V1.2 4
L0303A Terminal Description
VI2 VI3 GND
AI1 AI2 AI3 GND
AO3 GNDAO1 AO2
VI1
VO3 GNDVO1 VO2
Model
HC10-L0303A
Analog Input
Voltage VI1 ~ VI3 (GND)
Current AI1 ~ AI3 (GND)
Analog Output
Voltage VO1 ~ VO3 (GND)
Current AO1 ~ AO3 (GND)
Size and Structure
Size and structure Figure 1

HC10 Series Analog Module User Manual V1.2 5
L0402A Terminal Description
VI1 VI2 VI3
VI- AI1 AI2 AI3
VO1 VO2VI- VI4
VI-
AO1 AO2AI4 VO-
Model
HC10-L0402A
Analog Input
Voltage VI1 ~ VI4 (VI-)
Current AI1 ~ AI4 (VI-)
Analog Output
Voltage VO1, VO2 (VO-)
Current AO1, AO2 (VO-)
Size and Structure
Size and structure Figure 1

HC10 Series Analog Module User Manual V1.2 6
L0800A Terminal Description
.
VI1 VI2 VI3
. . .
VI4
AI1 GND AI2 GND GND GNDAI3 AI4
VI8 VI6
. .
VI7VI5 ..
AI5 GND GNDAI6 GNDAI7 GNDAI8
Model
HC10-L0800A
Analog Input
Voltage VI1 ~ VI8 (GND)
Current AI1 ~ AI8 (GND)
Size and Structure
Size and structure Figure 2

HC10 Series Analog Module User Manual V1.2 7
Product Specifications
General Specifications
Environmental
Temperature
Run: -10 ~ +55℃
Storage: -40 ~ +70℃
Relative Humidity 5 ~ 95%, no condensation
Altitude Run: <2000m
Storage: 0 ~ 3000m (not less than 70kPa)
Pollution Level Pollution level 2

HC10 Series Analog Module User Manual V1.2 8
Connection Barrier terminal block
(end point distance: 7.62mm)
Form Voltage or current optional
Negative Common GND
Range Voltage: 0 ~ 10V Current: 0 ~ 20mA
Resistance Voltage: 31kΩCurrent: 500Ω
Resolution Voltage: 0.3125mV
(10V / 32000)
Current: 0.625uA
(20mA / 32000)
Digital Input 0 ~ 32000
Comprehensive
Accuracy
±1% full range
Analog Input Specifications (L0303A/L0800A)

HC10 Series Analog Module User Manual V1.2 9
Analog Input Specifications (L0402A)
Connection Barrier terminal block
(end point distance: 7.62mm)
Form Voltage or current optional
Negative Common VI-
Range
Voltage:
0 ~ 5V, 0 ~ 10V
-5 ~ +5V, -10 ~ +10V
Current:
0 ~ 20mA, 4 ~ 20mA
-20 ~ +20mA
Resistance Voltage: 1kΩCurrent: 250Ω
Resolution Voltage (V):
Full range / 32000
Current (mA):
Full range / 32000
Digital Input -16000 ~ +16000, 0 ~ 32000
Comprehensive
Accuracy
±0.1% full range

HC10 Series Analog Module User Manual V1.2 10
Connection Barrier terminal block
(end point distance: 7.62mm)
Form Voltage or current optional
Negative Common GND
Range Voltage: 0 ~ 10V Current: 0 ~ 20mA
Resistance Voltage: 2kΩ~ 1MΩCurrent: 0 ~ 500Ω
Resolution Voltage: 0.3125mV
(10V / 32000)
Current: 0.625uA
(20mA / 32000)
Digital Output 0 ~ 32000
Comprehensive
Accuracy
±1% full range
Analog Output Specifications (L0303A)

HC10 Series Analog Module User Manual V1.2 11
Connection Barrier terminal block
(end point distance: 7.62mm)
Form Voltage or current optional
Negative Common VO-
Range
Voltage:
0 ~ 5V, 0 ~ 10V
-5 ~ +5V, -10 ~ +10V
Current:
0 ~ 20mA, 4 ~ 20mA
Resistance Voltage: 2kΩ~ 1MΩCurrent: <550Ω
Resolution Voltage (V):
Full range / 32000
Current (mA):
Full range / 32000
Digital Output -16000 ~ +16000, 0 ~ 32000
Comprehensive
Accuracy
±0.1% full range
Analog Output Specifications (L0402A)

HC10 Series Analog Module User Manual V1.2 12
Instructions
1. Wiring the analog module and confirm that it is correct.
Voltage type Current type
• Please isolate it from other power cables.
• If the analog input or output is disturbed by noise, it can be connected
with 0.1 ~ 0.47uF/25V capacitor or a ferrite magnetic ring.
L0303A
L0800A
VI1
GND
VO1
GND
+
-
VI1
VI-
AO1
VO-
+
-
VO1
VO-
+
-
L0402A
VI1
GND
AI1
AO1
GND
+
-
AI1
VI-
Current type
Current type
Current type
Voltage type
Voltage type
Voltage type

HC10 Series Analog Module User Manual V1.2 13
2. After connecting all expansion modules with expansion module
cables, the main module is powered up.
• Connect up to 8.
• According to the distance from the main module from near to far,
the expansion modules are numbered 0, 1, 2, 3, 4, 5, 6, 7.
3. Write user instructions to achieve read and write functions.
• See page 14 for instruction description.
• See page 16 for the description of the module data address.
• The configuration wizard function of HCStduio (programming
software) can be used to configure the initial parameters of the
module.
Instructions (Continued)

HC10 Series Analog Module User Manual V1.2 14
Instruction Description (FROM, TO, RD3A)
Read Input Data
FROM S1 S2 S3 S4
S1: Module number.
S2: Module data read starting address.
S3: Read the data storage register.
• When reading multiple data, the read data is stored sequentially
from this address.
S4: Read data length.
Write Output Data
TO S1 S2 S3 S4
S1: Module number.
S2: Module data write start address.
S3: Write the data register.
• When writing multiple data, write data sequentially from this
address.
S4: Write data length.

HC10 Series Analog Module User Manual V1.2 15
Read Analog Input Value
RD3A S1 S2 S3
S1: Module number.
S2: Analog input channel number.
• 0: AI1, VI1；
• 1: AI2, VI2；
• And so on.
S3: Store the analog input channel data set by S2.
Note: The read value is the analog input value that refreshes the cache
periodically. It is recommended to use this instruction to read the analog
input.
Instruction Description (FROM, TO, RD3A) (Continued)

HC10 Series Analog Module User Manual V1.2 16
Module Data Address Description (L0303A/L0800A)
HC10-L0303A
Module Data Address Data Content Read/Write
0 Module type (0x20) Read only
1 Software version (V100) Read only
2 ~ 4 Reserved /
5 ~ 71) AI1 ~ AI3, VI1 ~ VI3 Read only
8 ~ 101) AO1 ~ AO3, VO1 ~ VO3 Read and write
112) Current and voltage selection Read and write
1): 0.0 ~ 10.0V or 0.0 ~ 20.0mA, corresponding 0 ~ 32000.
2): 0 is voltage type (default), 1 is current type.
Set the channel in binary, starting from Bit0.
• Bit0 corresponds to AI1/VI1/AO1/VO1；
• Bit1 corresponds to AI2/VI2/AO2/VO2；
• And so on.
HC10-L0800A
Module Data Address Data Content Read/Write
0 Module type (0x21) Read only
1 Software version (V100) Read only
2 ~ 4 Reserved /
5 ~ 121) AI1 ~ AI8, VI1 ~ VI8 Read only
132) Current and voltage selection Read and write

HC10 Series Analog Module User Manual V1.2 17
Module Data Address Description (L0402A)
HC10-L0402A
Module Data Address Data Content Read/Write
0 Module type (0x22) Read only
1 Software version (V500) Read only
2 ~ 4 Reserved /
5 ~ 8 AI1 ~ AI4, VI1 ~ VI4 Read only
13, 14 AO1, AO2, VO1, VO2 Read and write
21, 22 Input filter coecient Read and write
25 Input range selection Read and write
27 Output range selection Read and write
29 Channel enable Read and write
