HQ IR-EGGS2 User manual

REMOTE CONTROL
EXTENDER
For use in: Italy, U. K., Holland, Sweden
Made in China
Germany, France, Spain,
0336
OWNERS MANUAL

Transmitter Side
Accessory
Transmitter and
Receiver Front
Receiver Side
DC 12 V
AC 220V or 240V
Adaptor x2
Infrared
Extender X 1
Remote Control
Indicators &
IR Transmitter/Receiver
LOCATION OF CONTROLS
Infrared Remote
Control Antenna
DC Power
IR Probe
DC Power

IMPORTANT SAFETY PRECAUTIONS
This equipment has been tested and found to comply with CE
regulation. These regulations are designed to provide reasonable
protection against harmful inter-ference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with this manual,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular situation. If this equipment does cause harmful interferen
ce to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna
Increase the distance between the interfered equipment and the
receiver
Connect the interfered equipment into an outlet on a circuit
which is different from that the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
To prevent fire or shock hazard, do not submerge or expose this
products to water
To avoid electric shock, do not open this units. The IR-EGGS2
contains no user serviceable parts. Doing so will void the
warranty
Use only the power supply provided with the
Do not overload wall outlets or extension cords.
If you are experiencing difficulty with this products, do not
attempt to service it yourself. Please call your vendor for
assistance.
IR-EGGS2
CAUTION:

The Remote operation of electronics products that utilize IR
(Infrared) remote control technology such as:
Product Description
Applications
The IR-EGGS2 Wireless Infrared Remote Control Extender enables
you to extend the range of your present Infrared Remote Control so
that you can operate VCRs, stereos, Cable Converter, Satellite
receivers, etc. Virtually any where within your home.
Unlike ordinary remote controls which are only effective in close
range." line of sight" use, The IR-EGGS2 use the radio frequency
which can operate through walls, doors, around corners, etc.
Satellite Receivers
Television
VCR's (Video Cassette Recorders)
CDs (Compact Disc)
DVD's (Digital Video Disc)
LDP's (Laser Disc Players)
Cable Converter Boxes
Audio / Hi-Fi Stereo Systems
Wireless Video Sender Systems
Any (IR) Remote Controlled Devices
"Operation is subject to the following two conditions: (1) this device may
not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device."

APPLICATION DIAGRAM
IR Remote
Control
IR-EGGS2
Transmitter
IR-EGGS2
Receiver
Probe
Stereo
Wire to Extension Speaker
IR-EGGS2
Transmitter
2nd TV
2. DSS / Satellite Receiver with
remote control:
1. Stereo system with remote control:
IR Signal
RF Signal
IR-EGGS2
Receiver
IR Remote
Control
Wall
Wall
DSS or Satellite
Receiver

Power
Adaptor
Picture 1
Picture 3
Make sure the IR probe is sticked toward
IR sensor receiving Window with proper position
o
(about within 1M and working angles 15 )
Antenna
o
15
o
15
Side View
Receiver
o
15
o
15
Picture 2
Picture 4
Not less than 0.4M and
no more than 7M
7 M
6.6M
0.4
(Using IR )
Working Angle not more
than o
15
Installation & Operation Guide
Working with extender probe
Working without
extender probe Working without extender probe
Keep
Vertical
DVD
Working Angle not more than o
15

Picture 7
o
15
Distance Not less than 0.3M and no more than 6M
o
15
6 M
5.7M
0.3 M
Antenna
Remote Control
o
15
o
15
Transmitter
Power
Adaptor
Antenna
Picture 5
Picture 6
Working Angle
not more than o 15
o
Working Angle not more than 15
Keep
Vertical

Care and Maintenance
Keep the IR-EGGS2 Remote Extender dry. If it gets wet,
wipe it dry immediately.
Use and store the IR-EGGS2 only in normal temperature
environments. Extreme temperature can shorten the life of
electronic devices
Handle the IR-EGGS2 gently and carefully. Dropping it can
damage the circuit board and can cause it to work improperly.
Keep the IR-EGGS2 away from dust and dirt, which can
cause premature wear of parts.
Wipe the IR-EGGS2 with a damp cloth occasionally to keep
it looking new. Do not use harsh chemicals, cleaning solvents,
or strong detergents.
Specifications
Operating Voltage ............................................230 or 240VAC, 60Hz/
DC 12V, 150mA
Power Consumption (pair).................................................4 Watts Max
Transmission Frequency......................................433.9MHz 250KHz
Power Gain................................................................................10dBM
Effective operating range.....................................................about 35M
(clear line of sight)
Infrared Receiver Section: Tuning Frequency...........................38 KHz
Infrared Emitter Section: Carrier Frequency(R/C).....................38 KHz
