HRW HPD0440BNMR User manual

HRW Limited 504-505, 5/F, Wai Wah Commercial Centre Ph [phone]
6 Wilmer Street, Sai Ying Pun Fax [phone]
Hong Kong www.hrw.hk
HPD0440BNMR Controller, Logger, Gateway
BACnet MS/TP with Modbus RTU integration
FW4.01
The HPD0440BNMR may be used as a BACnet networked HVAC device or standalone; as an HMI for
control and display of multiple controllers on a local network, as a controller with high flexibility for user
configuration to suit a wide variety of control applications or as a network manager including multi-zone
annual time scheduling.
Two key features of this device:
32 register Modbus RTU 485 gateway port to allow Modbus device data to be gathered for
display, used in control applications and/or for network integration in to the wider BACnet
system
Eight channel data logger for local retrieval of user selected operating parameter history.
Logger channels may be individually started/stopped by local or network events (clock
schedule, function block output state, remote network object state via NIO)
The display is programmable to indicate user specific text and dynamic data points. Data points may be
adjusted directly at the LCD (parameters such as set-points, fan-speeds and manual overrides). The
text and dynamic values for each of the 32 user lines may be set as small font size or large font size.
The user push-buttons, indication LED’s and an audible sounder may be independently programmed to
suit the user application. Physical I/O points may be used in the system independently or, subject to the
version, by the internal control loops and logic blocks.
Predefined logic function blocks enable easy configuration of a variety of functions including Economy
Changeover (temperature or enthalpy), VAV Volume, Hours Run monitoring, Lead/Lag changeover and
instantaneous Power calculation (kW, BTU).
The time clock features a 365 day clock/calendar with four channel time-switch, 20 holidays (one-off or
annually recurring) and summer/winter time.
Typical Applications
Temperature, humidity, pressure, IAQ, universal
On/off, 3-point modulating, PWM (Pulse Width Modulation), step control, DX
Equipment and space monitoring (chillers, AHU’s, controlled environments)
Local User Interface, network interface, networked or standalone controller
Modbus RTU master / gateway for BACnet
Time-clock & calendar / time-switch, networked or standalone

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 2 of 43
Feature Summary
4 Digital Outputs (DO) with power up presetting
1 NTC 10k temperature sensor internal (UI1)
1 Universal input (UI) fixed NTC 10k or DI n/o or n/c (UI2)
2 Universal Inputs (UI - user configurable analogue [AI, active or passive] or binary [DI, n/o or
n/c])
8 Virtual Digital Inputs (VDI)
8 Virtual UI’s (VUI)
8 Digital Logic blocks (DL)
8 Analogue/Application Logic blocks (AL)
8 PI Control Loop blocks (CL)
48 Network Interface Objects (NIO) for BACnet peer-to-peer connectivity
32 register Modbus RTU integration port (RS485)
8 channel data logger, programmable sampling frequency
32 user programmable LCD lines (text and dynamic point per line)
UI’s user scalable and units user settable (C, F, rH, %, Pa, kPa, PPM, etc.)
Connected sensors may be calibrated and filtered by way of the UI configuration
DO change-of-state delay timer (short cycle timer)
365 day time clock & calendar 
20 holidays, recurring or one-off event 
Summertime/Wintertime

4 Channel time switch 
4 Push buttons, programmable to suit application (DI1, DI2, DI3, DI4)
4 Navigation buttons, up/down/right/left (DI5, DI6, DI7, DI8)
4 LED’s, indication programmable to suit application (Blue / DO7, DO8. Orange / AO1. Red /
AO2)
Audible alarm programmable to suit application (AO3)
LCD Backlight, 60 sec after any button press
BACnet communication speeds from 2400 baud up to 76800 baud
BACnet System-wide unique device addressing
BACnet application services; Single-Read, Multiple-Read, Single-Write, Who Is, I Am, Who
Has, I Have
Automatic communication resumption after a power loss
PC configurable with HyperTerminal
PC configuration manually or with FUNCPROG configuration tool for downloadable program file
creation

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 3 of 43
OPERATION OVERVIEW ....................................................................................................................................5
BACNET OBJECT INSTANCES ..........................................................................................................................6
BACNET PRIORITY ARRAY...............................................................................................................................6
USER INTERFACE.................................................................................................................................................7
INTERFACE OPERATION..........................................................................................................................................8
LARGE FONT DISPLAY ...........................................................................................................................................9
CLOCK &TIME-SWITCH SETTING...........................................................................................................................9
FUNCTION BLOCK OBJECTS & SUB-PARAMETERS................................................................................11
HMI /CONTROLLER /TIME CLOCK......................................................................................................................11
MODBUS RTU GATEWAY ....................................................................................................................................13
DATA LOGGER .....................................................................................................................................................14
TERMINAL MODE ..............................................................................................................................................15
HYPERTERMINAL SETTINGS.................................................................................................................................15
Additional Settings..........................................................................................................................................16
Connecting at 76800 Baud Rate .....................................................................................................................16
Saving HyperTerminal Settings ......................................................................................................................16
BREAK IN TO TERMINAL MODE............................................................................................................................16
ADMINISTRATION COMMANDS.............................................................................................................................17
BACnet & General..........................................................................................................................................17
Modbus Section...............................................................................................................................................18
Logger Section................................................................................................................................................18
DISPLAY NAVIGATION .........................................................................................................................................19
SUMMARY SCREEN &LCD SETTING ...................................................................................................................19
MANUAL OVERRIDE /RELEASE............................................................................................................................20
OPERATIONAL DISPLAYS & INSTRUCTION ..............................................................................................21
USER SUMMARY SCREEN .....................................................................................................................................21
DOWNLOAD TEXT FILE ........................................................................................................................................22
‘MAIN’PHYSICAL I/O DISPLAY ...........................................................................................................................23
POINT LIST ...........................................................................................................................................................23
CONTROL LOOP (CL) ...........................................................................................................................................24
DIGITAL LOGIC (DL) &ANALOGUE LOGIC (AL) .................................................................................................25
NETWORK INTERFACE OBJECTS (NIO).................................................................................................................26
MODBUS SECTION................................................................................................................................................27
Point Setting ...................................................................................................................................................27
Diagnostics .....................................................................................................................................................30
Find Function .................................................................................................................................................31
LOGGER SECTION.................................................................................................................................................32
Overview.........................................................................................................................................................32
Data Upload File Creation.............................................................................................................................33
Upload Single Channel...................................................................................................................................33
Upload Multiple Channels..............................................................................................................................34
Excel Data Import ..........................................................................................................................................34
RESET TO FACTORY DEFAULT .....................................................................................................................36
UNIVERSAL INPUTS...........................................................................................................................................37
LINEARISATION TABLE...................................................................................................................................37
FACTORY DEFAULT SENSOR TYPES .....................................................................................................................37
ACTIVE SENSOR SCALINGS ..................................................................................................................................38
PASSIVE SENSOR DEFINITION...............................................................................................................................39
RESET TO FACTORY DEFAULT..............................................................................................................................39

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 4 of 43
INSTALLATION & COMMISSIONING ...........................................................................................................40
CONNECTIONS ....................................................................................................................................................41
DIMENSIONS ........................................................................................................................................................41
TECHNICAL DATA .............................................................................................................................................42
ORDERING INFORMATION .............................................................................................................................43
ACCESSORIES .......................................................................................................................................................43
OTHER HP_BN SERIES DEVICES..........................................................................................................................43

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 5 of 43
Operation Overview
All physical inputs, outputs and internal logic & control function blocks, and critical control loop
parameters are numerically represented as an ‘Object’. The object is a function block’s output value.
Depending on the purpose of a function block the object may have a range of sub-parameters available
for defining the block’s function and the operational features & limitations of the function. In the case of
control loops the active set point, the proportional band and the integral time sub-parameters are also
represented as objects for network access and remote tuning of a control loop if required.
In this document the term ‘Objects’ will mainly be used in the context of BACnet networks but will
otherwise be referred to as a ‘point’ or ‘points’ when discussing specific control applications.
The process of setting up function blocks and connecting function blocks to form an application uses
simple text lines therefore it is not necessary to learn a complex programming language. The settings
may be manually typed in to the device or, using the FUNCPROG 110601 programming tool which
provides a visual representation of each block, an application text file may be created, saved and
downloaded to the device as a complete group of settings.
The ability to make single setting changes directly at the device makes for easy debugging and
commissioning.
The function blocks comprise:
Physical I/O for connection of input switches, sensors and output control devices
Virtual inputs for taking over external commands and values from other network devices or for
manual settings and overrides
Logic blocks for event based reactions and influences
PI Control Loop blocks for set point based control reactions
In all cases points may be manually overridden for testing & commissioning purposes or for service
override. In respect of BACnet priority arrays manual overrides are Priority 9 (factory default = Null /
internal program control = 16).
Connection to the device for programming and service is via a terminal program such as HyperTerminal
(recommended). While on-line to the device it is possible to view point statuses and where applicable,
any dependent or influencing point’s connections. Statuses are updated live to the terminal screen
every 10 seconds or manually refreshed any time by pressing the enter key.
In additional to the predefined point displays a user-defined display is available for a customised point
summary related to an application. The user display may contain up to 32 lines of user text with or
without dynamic points included.
The user has the freedom to specify own display text in up to 32 lines with or without dynamic object
displays. Text lines may be programmed to be invisible until a specific object (or group of objects) met a
predefined criteria at which time the text will ‘pop-up’ at the top of the display. When the predefined
criteria is no longer true then the text will no longer be displayed. This feature is designed for use as
alarm indication and can be used together with the programmable LED’s and audible beeper to raise
attention to an alarm situation.

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 6 of 43
BACnet Object Instances
Up to 110 function blocks exist in the device depending on the version. Because many objects may be
Binary or Analogue, and may be seen as an Input, an Output or a Value, the final total of discoverable
and device relevant object instances may be up to 124.
A physical universal input (UI) may be an AI (Analogue Input) or AV (Analogue Value) but
when used as a digital input then it’s object instance would be a BV (Binary Value)
A Virtual Universal Input (VUI) is seen as an AV (Analogue Value)
A physical digital output is a BO (Binary Output) by default but if programmed for PWM control,
which has a control value of 0…100%, then it is seen as an AV (Analogue Value)
Using UI3 as an example:
Description: Physical universal input
Object #: 19
Object Instance when binary DI: BV19
Object Instance when analogue sensor: AI19 or AV19
Using AL1 as an example:
Description: Analogue Logic block
Object #: 53
Object Instance when Digital function: BV53
Object Instance when Analogue function: AV53
The common reference in all cases is the object # therefore during device Object Discovery over the
network the option of Input, Output or Value is decided based on the programmed application use of the
object in question.
BACnet Priority Array
The BACnet protocol utilises a Priority Array for each object to enable various network devices to take
control of a device’s object based on the level of need. Priority 16 is the least significant level and may
be considered normal ‘Auto’ operating level. Priority 1 is the highest control level, generally used for
emergency control under fire condition or similar events.
In respect of this device:
The objects are null priority by default
Commands from the internal control program of the device are at priority level 16
Manual commands via terminal mode operate at priority level 9
Release of a manual results in an object reverting to next lowest and still valid priority level
Commands from the network to DO, AO, VUI and VDI objects are remembered after a power
reset if priority 1…8
Commands from the network to Proportion Band & Integral Time points of Control Loops are
written to those objects if other than null priority

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 7 of 43
User Interface
The illustration below shows a factory default HPD0460BNCT (full controller & time-clock functionality)
Using HyperTerminal the display may be customised either by manual configuration or download of an
application text-file.
Up to 32 display lines
Small or large font
Up to 21 text characters per line (small font)
Each display line may include a dynamic point
The dynamic point’s unit tag may be customised
The time switch display above indicates ‘1 34’ which tells us that switch channels 1, 3 & 4 are ON
1 – Button 1 / LED 1
2 – Button 2 / LED 2 All LED’s invisible
unless active
3 – Button 3 / LED 3
4 – Button 4 / LED 4
5 – LCD scroll UP / adjust value UP
6 – LCD scroll DOWN / adjust value DOWN
(hold continuous to access clock setting)
7 – LCD select value for adjustment / Write value
8 – LCD release manualled value to AUTO
9 – LCD user display
10 – Calendar/Clock/Time Switch channels status

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 8 of 43
Interface Operation
After download of an application text-file
the HPD0440 screen may appear as in
the following example:
Press the down navigation button (D) to
scroll down to see up to 32 lines of user
display:
D
Press the up or down button to scroll through display lines. A press of the right button (R) makes cursor aligned point
available for adjustment (A) via the up and down buttons (U/D). To save the change press and hold the right button (R)
until a beep is heard. To exit adjustment mode without saving the change press the left button (L).
Exiting a set point adjustment without saving the change will result in the start up default being retained after a power
reset. If an output is being manualled via the LCD and the change is to be a start-up default then after making the
adjustment press and hold the right button until the a beep is heard. To release a M(Manualled) point back to auto
align the cursor with the point and press the left button.
Right side cursor
indicates point
now Adjustable
using the up/down
buttons
D
U
LR
R
› › ‹
A

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 9 of 43
Large Font Display
Any of the 32 display lines may be programmed for large font. Below are two example display
possibilities using both standard and large fonts
Clock & Time-switch Setting
In versions with 365 day time-clock & four-channel time-switch.
Each time switch channel has two On times and two Off times available per day
Twenty holidays, either recurring annually or one-off events, may be programmed
Each time switch channel may be applied to any days of the week combination, and/or
exception day 8 which is active on holidays
Wintertime/Summertime shift may be set to occur automatically
European or North American date format may be set
› ‹

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 10 of 43
A long press of the left button (L) after making all settings will exit back to the normal display. Saving of
the new clock settings will be confirmed by a beep being heard.
Notes:
Hours may be set in the range 0…23
Minutes may be set in the range 0…59
Holiday date setting with year =0 will occur every year
Holiday date setting with year >0 will occur once only, in the set year
To enter the clock setting mode press and
hold the down button (D) until the display
shown below is visible (15sec). Scroll so that
the line cursor is aligned with the desired
setting line then press the right button (R) to
select the value for adjustment
Press the up or down buttons (U/D) to adjust
the setting. Press the left button (L) to save the
exit adjustment of the current clock parameter.
Cursor indicates point now
Adjustable using the up/down
buttons
U
D
L
R
D
› › ‹
A

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 11 of 43
Function Block Objects & Sub-Parameters
HMI / Controller / Time Clock
The following is an overview of the function block features and options. For in-depth description of
function choices and their use please also download or request the separate FUNCPROG Application
Tool document.
Function Block Object Para # Description Selection Options
Digital Input 1…4 1…4
x00=
x01=
x02=
Buttons 1…4, input type
Output OR
Output AND
7 - Digital, 14 - n/c, 15 - Toggle on/off
Object #
Object #
Digital Input 5…8 5…8 x00=7 Navigation buttons Fixed, dedicated to Up, Down, Right, Left
respectively
Digital Output 1…4 9…12
(x)x00=
(x)x01=
(x)x02=
(x)x03=
(x)x04=
(x)x05=
(x)x06=
(x)x07=
(x)x08=
(x)x09=
OR1
OR2
AND
PWM cycle time (sec)
ON
OFF
Minimum ON time (sec)
Minimum OFF time (sec)
Maximum Run time (sec)
Remember last state at power return
Object #
Object #
Object #
0…255
% of control loop demand
% of control loop demand
0…255
0…255
0…1000
0 - Disable, 1 Enable
LED 1 & 2
(Digital Output 7…8,
blue)
15…16
(x)x00=
(x)x01=
(x)x02=
(x)x03=
(x)x04=
(x)x05=
(x)x06=
(x)x07=
(x)x08=
(x)x09=
OR1
OR2
AND
PWM cycle time (sec)
ON
OFF
Minimum ON time (sec)
Minimum OFF time (sec)
Maximum Run time (sec)
Remember last state at power return
Object #
Object #
Object #
0…255
% of control loop demand
% of control loop demand
0…255
0…255
0…1000
0 - Disable, 1 Enable
Universal Input 1 17 1700=5 Fixed NTC 10k internal 5 - 10k NTC (-10…90°C) [Ctx]
Universal Input 2 18 1800= Sensor type
5 - 10k NTC (-10…90°C) [Ctx]
7 - DI [D]
14 – DI n/c [DNC]
15 - Toggle on/off [D T]
Universal Input 3…4 19…20 xx00= Sensor type
0 - 100k NTC (-10…90°C) [Ctc]
2 - 0-10Vdc (0…100%) [%V1]
3 - 4…20mA (0…100%) [%mA]
5 - 10k NTC (-10…90°C) [Ctx]
7 - DI [D]
8 - % (0-100%) [%]
9 - Seconds [Sec]
14 - Digital normally-closed [DNC]
15 - Toggle on/off [D T]
xx01=
Input calibration - Offsets the
measured value up to 10% of the
sensor range
Any value within 10% of the sensor range
xx02=
Filter incoming sensor measurement
when the connected sensor is
unstable
0 - Minimum (factory default)
1…9 - User setting where 9 represents
the maximum filtering sample time
For unstable sensors then a setting of 1
or 2 will typically be enough filtering to
result in a stable measurement
Common settings of UI 1…4
xx03=
xx04=
Output OR*
Output AND*
Object #
Object #
* Digital 1 = 1000 (100%) when applied to these analogue logic functions. Analogue values will act as a
Output Minimum when applied to an Output OR and Output Maximum when applied to an Output AND.

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 12 of 43
Function Block Object Para # Description Selection Options
LED 3 & 4 
(Analogue Output
1/orange…2/red)
25…26
xx00=
xx01=
xx02=
xx03=
xx04=
OR1
OR2
AND
100%
0%
Object #
Object #
Object #
% of control loop demand
% of control loop demand
Audible alarm beeper 
(Analogue Output 3) 27
xx00=
xx01=
xx02=
xx03=
xx04=
OR1
OR2
AND
100%
0%
Object #
Object #
Object #
% of control loop demand
% of control loop demand
Virtual Digital Input 1…8 29…36 x01=
x02=
Output OR
Output AND
Object #
Object #
Digital Logic 1…8 37…44
xx00=
xx01=
xx02=
xx03=
xx04=
xx05=
xx06=
xx07=
xx08=
Function
Input1
Input2
Input3
Input4
Delay On
Delay Off
Output OR*
Output AND*
OR, NOR, AND, NAND, XOR, NXOR,
Lead/Lag
Object #
Object #
Object #
Object #
0…65,535 sec
0…65,535 sec
Object #
Object #
Virtual Univ. Input 1…8 45…52
xx00=
xx01=
xx02=
Set sensor type
Output OR*
Output AND*
Same as UI selection Type 0… 9, 10 -
Hours Run
Object #
Object #
Analogue Logic 1…8 53…60
xx00=
xx01=
xx02=
xx03=
xx04=
xx05=
xx06=
xx07=
xx08=
xx09=
xx10=
xx11=
xx12=
Function
Set output-relevant sensor type
Input1
Input2
Input3
Input4
Offset
Value In 1
Value Out 1
Value In 2
Value Out 2
Output OR *
Output AND *
Max, Min, Avg, Signal-Select, +, -, *, /, or
Eco-Changeover, Proportion, VAV
Volume, Up/Down counter, Power
Same as UI selection
Object #
Object #
Object #
Object #
Relative value
Shift input start value
Shifted output minimum value
Shift input stop value
Shifted output maximum value
Object #
Object #
61…68 Read
only Setpoint Absolute value
69…76
xx00=
xx01=
xx02=
xx03=
xx04=
xx05=
xx06=
xx07=
xx08=
xx09=
xx10=
Start/Stop (Dig/Analogue)
Input (Analogue)
Occupied Setpoint
Unoccupied Setpoint
Protection Setpoint
SetPoint Deadband
Setpoint Max.
Setpoint Min.
Output action
Output OR *
Output AND *
Object #
Object #
Absolute value
Absolute value
Absolute value
Relative value
Absolute value
Absolute value
0 – Direct, 1 – Reverse, 2 – Direct 50,
3 – Reverse 50
Object #
Object #
77…84 xx= Proportional Band Absolute value based on related sensor
range
Control Loops 1…8
85…92 xx= Integral time 0…1000 Seconds
Clock Channels 1…4 101…104 xxx00=
xxx01=
Output OR
Output AND
Object #
Object #
* Digital 1 = 1000 (100%) when applied to these analogue logic functions. Analogue values will act as a
Output Minimum when applied to an Output OR and Output Maximum when applied to an Output AND.

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 13 of 43
Function Block Object Para # Description Selection Options
Network Interface
Objects (NIO) 105…112
xxx00=
xxx01=
xxx02=
xxx03=
xxx04=
xxx05=
xxx06=
xxx07=
Target node number
Object Instance type
Target Object Instance within target
node
Sensor type
Read/Write
Read-Value Scaling
Output OR *
Output AND *
Device # in the same network
0 - Disabled
1 - DI
2 - DV
3 - DO
4 - AI
5 - AV
6 - AO
1…65,535
Same as UI selection
0 = Read status of target Instance of
target node
1…112 = Write local Instance status to
target Instance of target node
0 – Normal (apply Sensor Type units
only), 1 - Raw (apply Sensor Type units,
intercept & scaling)
Object #
Object #
* Digital 1 = 1000 (100%) when applied to these analogue logic functions. Analogue values will act as a
Output Minimum when applied to an Output OR and Output Maximum when applied to an Output AND.
LED 3 & 4 and the audible beeper have a fixed 5sec PWM cycle time with 1sec resolution. Therefore
if digital 1 or 100% is applied then the LED/beeper will be on continuously. If 60% applied then the
LED/beeper will be on for 3sec, off 2sec, on 3sec, and so on. The minimum applied value for an output
reaction is 20% (1sec on, 4sec off). In HPD0460BN these outputs may be driven by peer-to-peer
controllers on the network or via the internal NIO’s reading in object values from other controllers on the
network. HPD0460BNC, T or CT can control objects 25…27 directly using their own internal function
blocks.
Modbus RTU Gateway
Function Block Object Para # Description Selection Options
xxx=
Modbus register definition
string;
Device address, register
table #, register row #,
data scaling #, Function
type
Example: 153=1,4,2,0,3
1 is the device address
4 is the data table # (register # / 256)
2 is the data row # (register # - (256*4) -1)
0 is the scaling selection (default 0 = *1)
3 is the data Function type (3 = Holding
Register, Integer)
MRSCxxx=
Apply individual data
scaling after initial
definition string is entered
0=1
1=0.1
2=0.01
3=0.001
4=0.0001
5=0.00001
6=0.000001
7=10
8=100
9=1000
10=10000
11=100000
12=1000000
13=1
14=0.00390625 (1/256)
15=65536
Modbus Register
1…32 153…184
xxx=0…5
Sensor type (Apply units
and local scaling if
required)
Sensor Type as defined in the linearization table.
Units tags and any data manipulation associated
with linearization table rows 12…14 are applied
Modbus Error Count 185 185= Current Modbus network
comms error count/reset Read error count / Write 0 to reset

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 14 of 43
Data Logger
Function Block Object Para # Description Selection Options
xxx00=1…185 The local point value to be
logged Object #
xxx01=1…60 The sample period in
minutes 1, 5, 10, 15, 30, 60
LOG1…8 186…193
xxx02=1…185 The point that will start/stop
the logging Object #

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 15 of 43
Terminal Mode
The HPECOM serial data cable is used for terminal mode between the device and a PC running a
terminal program. HyperTerminal is recommended. A USB port <> Serial comm port (DB9) converter
may be required if the PC being used does not include a Com 1 serial port.
HyperTerminal Settings
For successful communication between HyperTerminal and the device, initial Properties setup of
HyperTerminal should be as per the screen prints below.
‘Connect to’ Comm Configuration: ‘Settings’ General:
‘Settings’ ASCII Setup:
9600

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 16 of 43
Additional Settings
Some PC platforms may need keyboard response adjustment for initial Terminal Mode success. These
settings may be done via the PC Control Panel >> Keyboard Settings:
Fastest Repeat rate
Shortest Delay time
Fastest Cursor Blink rate
Connecting at 76800 Baud Rate
Because HyperTerminal does not support 76800 baud then after setting to 76800 the device baud rate
will remain at 9600 baud for HyperTerminal communication and switch to 76800 after Writing the new
baud rate and eXiting terminal mode.
To allow later terminal communication a device set with 76800 baud will operate at 9600 baud for the
first 5 seconds after a power-up. If no attempt to connect the terminal at 9600 baud is made within 5
seconds of a power-up then the device will automatically switch to 76800 for normal network operation.
Saving HyperTerminal Settings
For ease of connection it is recommended to save the HyperTerminal setup for each baud rate you may
wish to use with an easily recognised configuration name. For example:
HPECOM 24 (2400)
HPECOM 48 (4800)
HPECOM 96 (9600)
HPECOM 19.2 (19200)
HPECOM 38.4 (38400)
HPECOM 57.6 (57600)
Break in to Terminal Mode
When HyperTerminal is running and the HPECOM cable is connected to the device the initial terminal
screen will be receiving an ASCII character dump which is the BACnet transmission from the device.
The ASCII dump will appear differently with different device address setting and if HyperTerminal baud
rate is different to the baud rate set in the device. Below is an illustration of how the ASCII dump will
look for a device at default settings; address 98 and 9600 baud.
To break in to terminal mode set Caps Lock on and hold the ‘T’ character key continuously
(TTTTTTT…). After five (5) T’s have been sent to the device it will switch to terminal mode. At this point
the BACnet activity on the network will be halted and the device will display the default user screen.

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 17 of 43
Administration Commands
BACnet & General
Function Enter Result Options / Comments
Start
communicati
on
TTTTT(TTT…) Display of configuration
and I/O status
With the Caps Lock on, hold the T key down
until the screen updates with HPE data. It is
not necessary to press the enter key to start
communication.
Download
textfile DE Make ready for file path Menu: Transfer > Send textfile > file
Reset to
Factory
Default
FD=1 Reset to ex-factory settings FD will be displayed in the top line of the I/O
summary screen after reset
Set node
address
(MAC)
98=1…255 Network node number is
assigned
Example: 98=25
1…127 the device will be a ‘token passing
master’
128… 255 the device will become a network
slave after power reset
Set system
Device
Instance
DI=0…4194303 Unique Device Instance is
assigned
Example: DI=401025 (building 4, network 1,
node 25)
Set baud rate 99=… Network comms speed is
set
2400, 4800, 9600, 19200, 38400, 57600,
76800 Example: 99=9600
After changing comm. speed it will be
necessary to reconnect with HyperTerminal
at the new comm. speed to save (write) the
change!
Set
Maximum
Master
address
MM=1…127
Highest Master device
address on the network is
registered
Next address searching limited to MM
address
Set Sys.
Vendor ID
(SysVid)
SV=0…255 System vendor specific
features may be available
SV=0 applies generic BACnet operation. If
an entered ID is not implemented then the
generic operation will be applied
Zero the
Reset
counters
95=0, 96=0, 97=0 Each Reset counter is
zeroed
Factory diagnostics
Resets = <95> <96> <97>
Rx timeout, Tx timeout, Hardware reset
Write values
as default W Changes written. Always do this after making changes that you wish to be permanent
Exit
communicati
on
X
Communication with
HyperTerminal no longer
active
Auto X after 240sec without key entry. After
eXit unplug the HPECOM cable to allow
network communication to take place

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 18 of 43
Modbus Section
Function Enter Result Options / Comments
Set Modbus
RTU subnet
baud rate
MRB=… Subnet comms speed is
set
2400, 4800, 9600, 19200 Example:
MRB=9600
Set Modbus
RTU subnet
comms
configuration
MRB=… Subnet comms data
configuration is set
7N1, 7N2, 8N1,
7O1, 7O2, 8O1, 8O2
7E1, 7E2, 8E1, 8E2
8N2Example: MRB=8E1
Enable
Modbus
RTU subnet
communicati
on
MRE
Toggles
Enabled/Disabled of
Modbus RTU Subnet
communication
Default Disabled to allow easy
configuration when no Modbus devices
are connected. Always ‘Enable’ when
Modbus devices are connected and points
are configured!
Diagnostic
display MRD Point by point response codes are displayed
For data stream analysis between the HPE
and the Modbus RTU devices. Also
displays scaled data results within the
point listings
Find
Modbus
point detail
MRF
Point data structure is
revealed from a specified
starting point
Starting point is the register number and
type as set at point 153
View Page MRP=1…2
Enter MRP=2 to display
the second page of
configured points if used
To return to top of list enter MRP=1
IEEE
Reverse IR=1
For IEEE Floating Point
registers, Reverse High
Word/Low Word order
When activated IRev=1 will be
displayed at the bottom of the MR
screen. When disabled (IR=0) no
status is displayed
Write values
as default W Changes written. Always do this after making changes that you wish to be permanent
Exit
communicati
on
X
Communication with
HyperTerminal no longer
active
Auto X after 240sec without key entry. After
eXit unplug the HPECOM cable to allow
network communication to take place
Logger Section
Function Enter Result Options / Comments
Upload LOG
Channel LOG1…8
Upload individual trend
data for logger channel
1…8
Example: LOG3
Upload
Multiple
LOG
channels
LOG1+…7+
Upload trend data for
multiple logger channels
having identical sample
period and identical start
point
Example: LOG3+ will upload channel 3 +
any subsequent channels having the same
sample period and start point as channel 3

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 19 of 43
Display Navigation
Function Enter Result Options / Comments
A1…8 Display Analogue Logic block A1, A2, … A8
C1…8 Display Control Loop block C1, C2, … C8
D1…8 Display Digital Logic block D1, D2, … D8
L Display Linearisation table D1, D2, … D8
LOG Display LOG settings D1, D2, … D8
M Display I/O summary screen M
MR Display Modbus RTU summary
screen MR
MRS Display Modbus RTU register Scaling
table MRS
N Display Network Interface Object
(NIO) bindings N
P Display Point status list
Enter P or P1 to display the first 21 Objects. Enter
Pxx (where ‘xx’ is a point #) to display any other
point and the following 20 points
S Return to User Summary display S
SS Screen Static Disable 10 sec live update
SL Screen Live Enable 10 sec live update
Display Control
Commands
SLLD Screen Line Logic Display Enable/Disable display of object numbers and
screen line numbers in the summary display
Summary Screen & LCD Setting
Function Line Method Result Options / Comments
SL1…32 SL(x)x=abc… Assign Screen Line text as information or in
relation to SP1…24
Alpha/numeric, 40
characters max.
SP1…32 SP(x)x=nnn Assign Screen Point dynamic point value Object #
SLL1…32 SLL(x)x=nnn
Assign Screen Line Logic point who’s value
>0 will cause the related screen line to appear
at the top of the display (alarm state for
instance)
Object #
Summary Display
Lines & dynamic point
setting
SLS1…32 SLS(x)x=1…3
Assign LCD font size & point number format
per line.
Type 0 & 1 are small font. Type 2 & 3 are large
font. 5 digit point format is standard.
8 digit point format would normally be for pulse
counts or other metering related values read in
via NIO
0 = 21 character/5 digit
1 = 16 character/8 digit
2 = 9 character/5 digit
3 = 4 character/8 digit

HRW HPD0440BNMR V401 Manual 111116.doc E. & O. E. / Subject to change without notice Page 20 of 43
Manual Override / Release
Values that have been manually set will be indicted in HyperTerminal by an Mtag next to the displayed
value. The BACnet priority level = 9
Manualled physical inputs (points 1…4 & 17…20) will revert to ‘Auto’ after being Released or after a
power reset. Physical outputs will retain the Manual setting after a power reset if the Manual state is
Written (W) before being released, thereby making the Manual state the power-up default state.
Function Enter Result Options / Comments
Manual a
Digital Object #=1, 0 Digital on or off
1=On
0=Off
Example: 37=1
Manual an
Analogue Object #=0…n0…100% block output
Block range 0….max
Example: 25=50 (AO1 50% output
/ 5Vdc output)
Release
Manual
overrides back
to ‘Auto’ *
R
R=1…193
Inputs will return to auto state/value.
Other points will remain at manualled
state/value until power reset or
commanded
Example 1: R
All overrides are cleared
Example 2: R=9
DO1 (point 9) only return to Auto
