Huawei MateBook E User manual

User Guide
E

Contents
About this guide
Getting to know your computer
Charging your computer
Using the power adapter 4
Safety information 4
Battery status information 4
Powering your computer on and off
About Windows 10
Using the Start menu 7
Action center 7
Connecting to Wi-Fi 8
Enabling Tablet Mode 9
HUAWEI MateBook Manager
Managing drivers 10
Backing up and restoring data 10
Instant Online * 11
Huawei Share * 11
Eye protection mode
Restoring your computer to the factory settings *
HUAWEI Folio Keyboard
Attaching the HUAWEI Folio Keyboard 15
Function keys 15
Touchpad 16
Configuring the touchpad 18
HUAWEI MatePen
Getting to know your HUAWEI MatePen 19
Charging your HUAWEI MatePen 19
Replacing the MatePen tip 19
Pairing the HUAWEI MatePen with your computer 20
Buttons 20
HUAWEI MateDock2
Getting to know your HUAWEI MateDock2 22
Connecting to a TV, monitor, or projector 23
Connecting a USB mouse, printer, or other peripheral device 24
i

Appendix
Safety information 25
Personal Information and Data Security 32
Legal Notice 33
Contents
ii

About this guide
This guide was written for computers that run Windows 10. It explains how to use basic features
on your computer. For more information about Windows 10 features, visit http://
www.microsoft.com or click > on your computer's desktop.
Optional accessories and software mentioned in this guide may not be provided with or installed
on your computer. The system environment described in this guide may differ from your actual
system environment, and the interface on your computer may differ from the screenshots in this
guide. Functions marked with asterisk (*) may not by supported in certain regions.
Symbols and definitions
Note Highlights important information and tips to help you perform the steps
described in this guide.
Important Indicates potential problems, such as device damage or data loss, that
may arise if proper care or attention is not given.
Warning Warns of potential hazards that could cause serious injury.
1

Getting to know your computer


 

  







1 Headset jack and
microphone port
Used to connect to the headset and microphone
2 Speakers The speakers play sound when a headset is not connected.
3 Power button lWhen your computer is powered on:
–Hold down the power button until the power-off screen is
displayed, and then swipe down to turn off your computer.
–Press the power button to enter sleep mode, and then
press again to exit sleep mode.
lHold down the power button to turn on your computer.
4 Microphone Use the microphone to make video or voice calls, or record
sound.
5 Ambient light
sensor (hidden)
Detects the ambient light level and automatically adjusts the
screen brightness.
Do not cover the ambient light sensor. When purchasing
a screen protector, choose a screen protector with a
purpose-built hole for the ambient light sensor.
6 Camera Front camera for taking photos or making video calls.
7 Camera indicator Indicates the camera status. The indicator stays constant
when the camera is on.
8 Volume up button Increases the volume.
2

9 Fingerprint sensor After adding a fingerprint, you can use the fingerprint sensor to
unlock the screen.
When you power on your computer for the first time,
follow the onscreen instructions in the setup wizard to
add a fingerprint. You can also add a fingerprint by
touching > on the desktop and going to the
account login settings.
10 Volume down
button
Decreases the volume.
11 Charging indicator Indicates the charging status.
lRed: Low battery
lOrange: Medium battery
lGreen: At least 90% remaining
12 USB Type-C port lConnect the power adapter to charge your computer.
lConnect a MateDock2, mobile phone, or USB flash drive to
transfer files.
13 Magnetic pin ports Secures the computer to the Folio Keyboard.
Make sure the keyboard is aligned properly with your
computer to prevent the ports from being damaged.
14 Folio Keyboard
socket
Connects the Folio Keyboard.
Getting to know your computer
3

Charging your computer
Using the power adapter
Your computer features a built-in rechargeable battery. When you connect the power adapter
and USB Type-C cable provided to a power supply, the charging indicator will turn on to indicate
that the battery is charging. The battery charges faster when your computer is powered off or in
sleep mode.
Safety information
Always use the power adapter and USB Type-C cable that came with your computer for
charging.
Third-party accessories may present a potential safety hazard and impair performance.
Charge your computer at room temperature in a well-ventilated area.
lExposing your computer to high ambient temperatures during charging may damage the
internal components.
lCharging duration may vary depending on the ambient temperature and the battery
usage.
lYour computer may become warm after prolonged use or charging. If it becomes hot to
the touch, disable non-essential features and disconnect the charger.
Battery status information
The battery status is indicated by the battery icon in the status bar.
lWhen your computer is charging, the icon will indicate that a charger is connected.
lTo view the remaining battery percentage and battery life, move the cursor over the icon.
4

All batteries have a limited lifespan. If you notice a significant deterioration in battery life,
contact your nearest Huawei service center for a replacement. Do not attempt to replace the
battery yourself.
Charging your computer
5

Powering your computer on and off
When using your computer for the first time, connect the power adapter and USB Type-C cable
to charge the battery.
Press the power button to power on your computer or wake the screen.
When your computer is switched on:
lClick > to power off, restart, or enter sleep mode.
lTo power off your computer, hold down the power button until the power-off screen is
displayed, and then swipe down.
To force your computer to power off, hold down the power button for 10 seconds. All
unsaved data will be lost.
6

About Windows 10
Using the Start menu
Use the Start menu to access apps, settings, and files on your computer.
Click in the lower-left corner of the screen to open the Start menu.
lSelect to change, lock, or log out of the current user account.
lSelect to access the system settings.
lSelect to shut down or restart your computer, or enable Sleep mode.
lApp list: Swipe up or down on the screen to scroll through the app list.
lPinned tiles: Pin your favorite apps or websites to the Start menu and organize them into
groups.
Action center
Action center displays system updates and other system notifications. It also provides quick
access to enable or disable specific functions and configure the functions.
Click in the lower-right corner of the screen, or swipe left from the right side of the screen to
launch the action center. You can:
lQuickly access the settings, VPN, and projector screens.
lQuickly access frequently-used settings, such as the power saving mode, airplane mode, and
screen brightness.
7

Connecting to Wi-Fi
1Click in the lower-right corner of the screen to open the Wi-Fi settings screen.
2Switch on the Wi-Fi. Your MateBook will automatically search for available Wi-Fi networks.
3Select the network that you want to connect to and follow the on-screen instructions to
proceed. Some Wi-Fi networks require a security key or password to connect. You can find
this in your router settings, or obtain it from your Internet Service Provider (ISP) or network
administrator.
About Windows 10
8

Enabling Tablet Mode
Tablet mode provides a convenient interface that lets your computer function like a tablet when
no mouse or keyboard is connected.
1Click in the lower-right corner of the screen, or swipe left from the right side of the screen
to launch the action center.
2Enable Tablet Mode in the action center.
About Windows 10
9

HUAWEI MateBook Manager
Managing drivers
MateBook Manager automatically detects system drivers and reminds you to update them for an
improved user experience.
Click > Driver Management:
On the ToUpdate tab, click Update or Update all to update a single driver, or all drivers.
Open the Installed tab to view all drivers installed on your computer.
Backing up and restoring data
If the operating system on your computer is faulty, you can restore it to a previous working state
from an earlier backup.
MateBook Manager can only back up system files to the local disk or to the network disks.
Backups to an external USB disk drive are not supported.
Backing up or restoring system files can take a long time. Do not switch off or restart your
computer during this time.
Ensure that your computer is plugged in to the charger while backing up or restoring
system files.
Click > Backup and Restore:
10

lOn the Backup tab, click Start Backup and select a backup destination.
lOn the Restore tab, click Start Restore and follow the onscreen instructions to select the
system backup that you want to restore.
Instant Online *
Connect your computer to your phone's mobile hotspot and use mobile data to access the
Internet anywhere. You can also set a data usage limit to avoid incurring charges.
lThis feature is only supported on Huawei phones running EMUI 5.1 or later.
lYour mobile phone carrier may charge you for using mobile data. To avoid incurring
excessive data charges, purchase a data plan. For more information about mobile data
charges, contact your carrier.
1Open MateBook Manager and click . Log in to your computer and phone using the same
Huawei ID. Enable Bluetooth and mobile data on your phone, and then enable Bluetooth on
your computer. Your computer will automatically display nearby phones that are logged in to
the same Huawei ID.
2On your computer, tap twice on your phone to connect to it. Once connected, your computer
can use your phone's mobile data to access the Internet.
lUse Consumed to monitor how much data you have used.
lUse the dropdown menu under Limited flow to configure a limit for mobile data usage.
When this limit is reached, your computer will stop using mobile data and display a
notification.
lClick CANCEL TO CONNECT to disconnect your computer from the mobile hotspot.
Functions marked with asterisk (*) may not by supported in certain regions.
Huawei Share *
Use Huawei Share to quickly transfer files between two Huawei devices. Huawei Share uses
Bluetooth to detect nearby Huawei devices and Wi-Fi to transfer files.
MateBook Manager
11

Before using Huawei Share, check that this feature is supported on your Huawei device.
Enabling Huawei Share
1On Huawei phones, drag down from the status bar to open the notification panel. Click
and follow the onscreen instructions to enable Huawei Share.
2In MateBook Manager, click and select Allow the people nearby to find me. This
allows your phone to discover your computer and connect to it automatically.
lWhen you enable Huawei Share, Wi-Fi or Bluetooth will be enabled automatically.
lAfter you disable Wi-Fi or Bluetooth, Huawei Share will be unavailable.
Using Huawei Share to transfer files
1Right-click on the file you want to send and click Share by Huawei Share. Select the profile
picture of the receiving device from the popup dialog box. Alternatively, drag the file onto the
profile picture of the receiving device in MateBook Manager.
2A popup dialog will appear on the receiving device. Follow the onscreen instructions to
accept the file transfer request.
To cancel the file transfer, touch the profile picture of the receiving device.
If you want to receive the files shared by other devices with your computer, click ACCEPT in the
popup dialog to accept the file transfer request. To view or change the storage path for received
files, click > Huawei Share.
Functions marked with asterisk (*) may not by supported in certain regions.
MateBook Manager
12

Eye protection mode
When reading text on your computer, enable eye protection mode to reduce blue light output and
prevent eye strain and fatigue.
Right click on a blank part of the desktop to open the display management screen, and enable
eye protection mode.
Eye protection mode reduces the amount of blue light emitted from the screen, which may
give the screen a slightly yellow hue.
13

Restoring your computer to the factory
settings *
You can use the system recovery screen to quickly restore your computer to the factory settings.
Before restoring the factory settings, back up all files on the Drive C and connect your
computer to the charger.
1Hold down the F10 button when powering on your computer to access the factory settings
screen.
2Follow the onscreen instructions to restore your computer to the factory settings.
Functions marked with asterisk (*) may not by supported in certain regions.
14

HUAWEI Folio Keyboard
Attaching the HUAWEI Folio Keyboard
Place the Folio Keyboard on a level surface and align the magnetic pins with the holes on the
bottom of the computer (see the following figures).
Do not attempt to bend the flap inwards, as this may damage the hinge.
Function keys
Use the hot keys to perform specific tasks.
You can use F1 and F2 as function keys in two ways:
lHold down the Fn key until the Fn key indicator turns on, and then press the corresponding
key. Press the Fn key again to disable the function keys.
lTo use the function keys without pressing the Fn key, open MateBook Manager and configure
the following settings:
–Click > System Configuration to switch function key mode and hotkey mode. You can
then use the function keys without pressing the Fn key.
Decrease the screen brightness.
Increase the screen brightness.
Enable or disable the keyboard backlight, and adjust the backlight
brightness.
Mute or unmute
Decrease the volume.
15

Increase the volume.
Enable or disable the microphone.
Enable or disable screen projection.
Enable or disable Wi-Fi.
Open MateBook Manager.
The keyboard layout may vary depending on your country or region.
To use the Home, Page up, Page down, and End functions, hold down the Fn key and press
the corresponding arrow key .
Combination Function
Fn key + Left arrow Home
Fn key + Up arrow Page up
Fn key + Down arrow Page down
Fn key + Right arrow End
Touchpad
The touchpad functions like a computer mouse.
The touchpad supports the following gestures:
Touch with one finger: Left mouse click.
HUAWEI Folio Keyboard
16

Touch twice with one finger: Double mouse click.
Swipe with one finger: Move the cursor across the screen.
Left button: Left mouse click.
Right button: Right mouse click.
Touch with two fingers: Right mouse click.
Swipe up or down with two fingers: Scroll up or down.
Spread or pinch two fingers: Zoom in or out.
HUAWEI Folio Keyboard
17
