Hudson RT2417S User manual

1


































DANGER
DO NOT use gas grill for indoor
cooking or heating. TOXIC fumes
can accumulate and cause
asphyxiation. DO NOT use in or on
boats or recreational vehicles.
WARNING
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property
damage.
Read the installation, operation
and maintenance instructions
thoroughly before installing or
servicing this equipment.
DANGER
Failure to follow these
instructions could result in fire
or explosion that could cause
property damage, personal injury
or death.
WARNING
FORYOURSAFETY
F
or
O
ut
d
oor
U
se
O
n
ly
(Outsideanyenclosure)
3-BURNER 304 STAINLESS STEEL GAS GRILL
ASSEMBLY AND CARE INSTRUCTIONS
ITM. / ART. 239418 (U.K)
ITM. / ART. 555820 (ICELAND)
MODEL NO. RT2417S
U.K PART NO. RT2417S-UK
ICELAND PART NO. RT2417S-IS
IMPORTANT:
RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
FORCUSTOMERSERVICE：
Please E-mail: [email protected].

2

GrillOperation 1-2-3
Before Grilling
Step 1 Keep your grill a safe distance away from your property.
Step 2 Always perform a Leak Test on all connections and hoses.
Step3 Keepchildren away from the grill.
DuringGrilling
(To avoid tripping safety valves, please follow these instructions carefully!)
Step 1 First open lid and turn gas tank on slowly.
Step 2 Turn only one knob on at a time when lighting up the grill.
Step 3 Use protective gloves when grill gets hot.
Step 4 Never leave a lit grill unattended.
After Grilling
Step 1 Always burn grill for 10-15 minutes to burn off food residues after use.
Step 2 Turn off the gas supply at the gas cylinder after use.
Step 3 Wait until the grill is completely cooled before closing lid.
Step 4 Clean up grease build-up to avoid grease fire and cover your grill to prevent rust.
* Please refer to the owner’s manual for details.















Alwaysreadandunderstandthe WARNINGS andINSTRUCTIONS that are contained in this manual before
attemptingtousethis gas barbecue grill to prevent possible bodily injury or property damage.
NOTE: This grill must be used with propane orbutane gas only (gas cylinder not included).
Installer: Leave this manual with the consumer. Consumer: Retain this manual for future reference.
WARNING
1. DO NOT use or store gasoline or
other
flammable liquids or vapors in
the vicinity of
thisappliance.
2. DO NOT store any other spare LP
orbutane cylinder in the vicinity of
this appliance.
DANGER
IF YOU SMELL GAS
1. TURN OFF gas.
2. Extinguishany open flame.
3. Open the lid.
4. If odor continues, keep away from
the appliance immediately. Call your
gas supplier or dial 911.


3

TableofContents
ForYourSafety........................................................3
SafeLocationsforUseofThisOutdoorGrill......................................5
PackageContents......................................................7
HardwareContents.....................................................8
AssemblyInstructions...................................................9
OperatingYourGrill...................................................17
Connecting & Disconnecting Gas Cylinder . . .................................18
CheckingforLeaks.......................................................19
LightingYourGrill ..........................................20
Excess flow safety valve reset procedure .....................................21
Care and Maintenance . . . . . . . . . . ................................22
Troubleshooting .........................................24
WarrantyProgram ..............................................25
Illustrated Parts List. . ............................................26

For YourSafety
Dear ValuedCustomer,
Congratulations on your new barbecuegrill purchase! You’ve made the right choice. In this manual, youwill find
assembly
instructions, suggestions for grilling and helpful hints, as well as guidelines for the safe operation, proper
care and use of your grill. Our expert staff strives to provide you with an easy-to-assembleproduct.Shouldyouhave
any questions or problems with thisproduct, please E-mail: [email protected].

4


WARNING
1. This grill is for outside use only. It should not be used in a building, garage or any other enclosed area.
2. Read the instructions before using the appliance.
3. The use of alcohol,prescription or non-prescription drugs may impair an individual’s ability to properly assemble
or safely operate this appliance.
4. Always open the grill lid carefully and slowly as heat and steam trapped within the grill could cause severe
burns.
5. Always place your grillon a hard andlevel surface far away from combustible materials and structures. An
asphalt or blacktop surface may not be acceptable for this purpose.
6. Do not leave a lit grill unattended.
7. WARNING: accessible parts maybe very hot, Keep young children and pets away.
8. This is not a tabletop grill.Do not place this grill on any type of tabletop surface.
9. Do not use the grill in high winds.
10. This grill must be used withsource of energy listed on CE label (gas cylinder not included).
11. Do not attempt to attach this grill to the self-contained propane or butane system of a camper, trailer, motor
home or house.
12. Do not use charcoal or lighter fluid.
Do not use gasoline, kerosene or alcohol for lighting.
13. This outdoor gas appliance is not intended to be installed in or on recreation vehicles and/or boats.
14. Do not attempt to move the grill while it is lit.
15. Do not use the grill unless it is COMPLETELY assembled and all parts are securely fastened and tightened.
16. Keep combustible items and surfaces at least 91.44 cm/ 36 in. away from the grill at all times. DO NOT use this
gas grill or any gas product under any overhead enclosure or near any unprotected combustible constructions.
17. Do not use in an explosive atmosphere. Keep grill area clear and free from combustible materials, gasoline
and other flammable vapors and liquids.
18. Do not attempt to use or assemble with missing or damaged parts. Contact customer service for replacement
part.
19. Do not move the appliance during use.
20. Do notmodify the appliance.
21. This appliance must be kept away from flammable materials during use.
22. Turn off the gas supply at the gas cylinder after use.

CAUTION - Prevention of Burns
1. To avoid burns, do not touch metal parts of the grill until they have completely cooled for at least 45 minutes or
unless you
are wearing protective gear such as pot holders, protective gloves or mittens.
2. Do not alter the grill in any manner.
3. Clean and inspect the hose before each use. If there isevidence of abrasion, wear, cuts or leaks, the hose must
be
replaced prior tooperation. The replacementhoseassemblyshould be in accordancewith the
manufacturer’s
specifications.
4. Move gas hoses as far away as possible from hot surfaces and dripping hot grease.
5. Never keep a filled gas container in a hot car or car trunk. Heat will cause the gas pressure to increase, which
could open
the relief valve andallow gas to escape.
6. Keep any electrical supply cord and the fuel supply hose away from any heated surfaces.
7. When the national conditions require it, theflexible tube should bechanged. Under the conditions of servicing,
ensure the flexible tubeshould be never subjected totwisting.








5

Safe Locations for Use of This Outdoor Grill
CAUTION
Never use this outdoor grill inside any building, garage, shed or breezeway, or inside any boat, trailer or
recreational vehicle to prevent a possible fire and to preventthe possibility of carbon monoxide poisoning or
asphyxiation.
WARNING
Do not use thisappliance underoverhead combustible surface or covered area (e.g., awnings, umbrellas,
porchesorgazeboes).
Always confirm that this grill is not positioned under the overhang of
a house, agarage or otherstructure beforelighting it. Anoverhang
will serve to deflect flare-upsand radiated heat intothe structure
itself, which could result in a fire.
Always confirm that this grill is positioned more than 91.44 cm/ 36 in.
away from any
building orcombustible materials or surface before
lighting it, and that no gasoline or other volatile substances are
stored in the vicinity of this grill. (See diagram to right).
The temperature of a grease fire or ofthe radiated heat might
otherwise be sufficient
to ignite nearby combustible orvolatile
substances. Always locate this grill where there willbe ample
combustion and ventilation air,but never position it inthe direct path
of astrongwind.
Never allow the grill tooperate while unattended to prevent
uncontrolled grease fires from erupting.
Never attempt to move this grill while it is in operation or while it is still hot to prevent possible personal injury.
Never store or use gasoline or other flammable or volatile substances in the vicinity of this grill or inthe vicinity
of any other heat-generating appliance because of the dangerof starting a fire.

DANGER – Gas Safety
● Liquefied gas is flammable and hazardous if handled improperly. Become aware of its characteristics
before using any propane or butane product. In the even of gas leak, turn off the gas supply.
● Propane and butaneCharacteristics: Flammable,explosive under pressure, heavier than air and settles in
poolsinlow areas.
● In its natural state, propane or butane has noodor. For your safety, an odorant has been added.
● Contact with propaneor butane could burn to the skin.
● This grill is shipped from the factory for propane or butane gas use only.
● Never use a propane or butane cylinder with a damaged body,valve, collar or footing.
● Dented or rusted gas cylinders may be hazardous and should be checked by your gas propane orbutane
supplier.
CAUTION
● It is essential to keep thegrill’s valve compartment, burners and circulating air passages clean.
● Inspect the grill before each use.
Step 1. Inspect all hoses and connections and make certain they are
secure.
Step 2. Check and clean the burner venture tubes for insects and
insect nests by removing the burner andinserting a bottle brush
cleaner into each tube to make sure the passageis clear.
*** A clogged tube can lead to a fire beneaththe grill. ***
Step 3. Ensure that thevalve nozzle is pointing straightandcompletely inserted into the venture tube.







91.44 cm/
36in/
36po 91.44 cm/
36in/
36po

6

GENERALINFORMATION

1. A propane or butanegas cylinder is required for operation.
2. This gas grill is NOT intended for commercial use.
3. Don’t obstruct theventilationopening of the cylinderenclosure.

GasCategory I3+(28-30/37) I3B/P(30)
Gas and SupplyPressure G30 Butane at 28~30 mbar
G31 Propane at 37 mbar
G30 Butane,G31 Propane or
their mixtures at 28~30 mbar
CountryCode
BE, CH, CY, CZ, ES, FR,
GB, GR, IE, IT, LT, PT, SI, SK
BE, CY, CZ, DK, EE, FI, FR, GB,
HU, IS, IT, LT, NL, NO, RO, SE,
SI, SK
Burner MainBurnerx 3
BurnerInjectorSize Main Burner: 0.91mm
TotalHeatInput 10.5kw（G30:764g/h；G31:750g/h）

7
PACKAGE CONTENTS


























ABD
F
JKLM
N
O
P
Q
R
S
T
I
G
C
H
E
H
E

8
PACKAGE CONTENTS

















HARDWARE CONTENTS








Part Description Quantity
A Burner Box 1
B Heat Tent 3
C Main Grid 2
D Warming Rack 1
E Right Side Shelf
Bracket 2
F Right Side Shelf 1
G Left Side Shelf 1
H Left Side Shelf
Bracket 2
I Igniter 1
J Left Panel 1
K Front Beam 1

Part Description Quantity
L Drip Tray Support 1
M Rear Panel 1
N Right Panel 1
O Drip Tray 1
P Bottom Panel 1
Q Locking Caster 2
R Caster 2
S Door 1
T Tank Stopper 1

AA BB
3/16-24 x 1/2in. Screw
Qty. 53 AA Battery Qty. 1

9
AssemblyInstructions

UNPACKING
After removing all parts and hardware pack from the top of the shipping box, and when the only part
showing is the grill head, use a box cutting knife to slice down the sides of the box. Be careful of
staples along shipping box edges.
Remove the steel and cardboard corner supports from the box and the styrofoam side pieces from the
grill head. Open grill lid and remove all packaged parts and packing material. Allow grill head to rest on
cardboard until placing grill head on cart in Step 9.
WARNING: Assemble the grill on a flat level surface. Compare the parts and hardware with the list and
diagrams. Do not attempt assembly if any part is missing or damaged.
EstimatedAssembly Time:30 minutes by 2 people.
1. Attach the locking casters (Q) and the casters (R) to
the bottom panel (P) using 12 screws (AA). When this
process is completed, turn the bottom panel over.
The two locking casters (Q) should be at the back of
the grill.
2. Align the holes in the rear panel (M) with the holes in
the bottom panel (P) and insert screws (AA) into the
aligned holes.
Note: Do not tighten the screws completely. Leave at least
one full turn on each. After all the screws have been installed,
go back and tighten them fully.
Hardware Used
3/16-24 x 1/2 in.
Screw X 12
AA
Hardware Used
3/16-24 x 1/2 in.
Screw X 3
AA
AA
Q
R
P
1
2
P
M
AA

10
3. Attach the left panel (J) and right panel (N) to the bottom
panel (P). For both the left and right panels, there are three
screws for the rear panel (L) and four for the bottom panel.
Insert the four bottom panel screws first.
4. Attach the tank stopper (T) to the left panel and the right
panel with 2 screws (AA) on each side as shown.
Hardware Used
3/16-24 x 1/2 in.
Screw X 14
AA
3 AA
M
J
N
P
Hardware Used
3/16-24 x 1/2 in.
Screw X 4
AA
4
T
AA

11
5. Attach the front beam (K) to the left panel and the right
panel with 2 screws (AA) on each side as shown.
6. Attach the drip tray support (L) to the front beam and rear
panel with 4 screws (AA) as shown.
7. Remove the cap and the nut from the igniter (I). Secure the
igniter to the left panel with the nut. Then, reassemble the
cap to the igniter.
Hardware Used
3/16-24 x 1/2 in.
Screw X 4
AA
Hardware Used
3/16-24 x 1/2 in.
Screw X 4
AA
AA
K
5
AA
L
6
I
7

12
8. For the door (S), insert bottom hinge pin into hole on
bottom panel. Push top hinge pin in the corner of the door
to insert into hole in top corner of the right panel. Then, put
the drip tray (O) onto the drip tray support.
9. Take the pressure regulator out from under the burner box
(A). Lift the burner box (A) onto the cabinet, making sure
that the gas pressure regulator is in the cabinet, then
position burner box on the cabinet by aligning the four tabs
on top of the cabinet with the holes in the burner box.
Fasten the burner box to the cabinet with 4 screws (AA).
Hardware Used
3/16-24 x 1/2 in.
Screw X 4
AA
S
O
8
9
AA
Gas pressure
regulator

13
10. Attach the left side shelf bracket (H) to the left of the burner
box (A) and the right side shelf bracket (E) to the right of the
burner box with 2 screws (AA) on each bracket.
Follow steps 11 - 13 for installing or removing the
side shelves (G and F).
11. To install the shelves:
Hold the shelf at its fold-down position (vertical). Align the
large holes on the shelf to the mounting screw on the side
shelf bracket. Move the side shelf from front to back,
making sure the screws fit inside the holes on the side
shelf, then slide into the slot.
Hardware Used
3/16-24 x 1/2 in.
Screw X 8
AA
10
H
H
E
E
G
F
Side shelf bracket Large hole
Screw
11
10a
H
10b
E

14
12. To fold up the shelves:
Make sure the screws are in the slot as shown, then
slowly rotate the side shelf up.
When folding up to level position, press down the hinge
area to lock the shelf. Adjust the side shelves to align it
with the control box.
13. To remove the shelves:
Lift up the shelf, position the shelf at its fold down
position (vertical).
Align the screws with the holes on the shelf, move the
shelf from back to front until the side shelf disconnect
from the screw on the bracket.
12
Large hole
12a
Large hole
Screw
13

15
14. Plug the main burner igniter wires into the sockets in the
igniter.
15. Place the heat tents (B), main grids(C) and warming
rack (D) into the burner box (A). Remove the battery
cap on the igniter (M) and insert a AA battery (BB) with
the positive end facing outward. Replace the cap.

Igniter wire
14
B
C
D
Insert AA battery
15
15a
B

16
16. Open the door of cart. Take the regulator head out of the cart through the hole of the right side panel of the
cart. Connect LP tank with the regulator, Please note that the LP tank must be placed outside of the cart.
It is forbidden to place the tank into the cart. (See connection instructions in Page 18-19)





17

Fully Assembled View



















OperatingYour Grill
CAUTION
Use only the regulator provided. If a replacement is necessary, call our customer service center. The use of
unauthorized parts can create an unsafe condition andenvironment.
Use only the pressure regulator and hose assembly supplied with the outdoorcooking gasappliance must be
used. The regulator
ofthe applianceshall comply with therelevant EN standard. Replacement pressure
regulators and hoseassembly must bethose specified by the outdoorcooking gas appliance manufacturer. Use
LP or butane cylinders equipped with a cylinder
connection device compatible with the connection for outdoor
cookingappliances.Thecylindermust include a collarto protect the cylindervalve. Do notdrop or handle the
cylinder roughly. If the appliance is not in use, disconnect the cylinder. Turn off the cylinder first if you need
changeit.
Storage of theappliance indoors is permissible ONLYif the cylinder is disconnected and removed from the
appliance.Store cylinderoutdoors and out ofthe reach ofchildren. Do not store the cylinder in a building,
garage or other enclosed areas. Never store your cylinder where temperatures can reach over 51.6℃/124.8°F.
Before connecting, make sure there is no debris caught in the head ofthe gas cylinder, regulator valve or in the
head of the burnerandburner ports. Connect regulator valve andhand tighten firmly. Disconnect the gas
cylinder fromthe regulator valve when the grill is not in use. DO NOT obstruct the flow of combustion air or
ventilation air to the grill. Arrange the propane or butanecylinder for vapor withdrawalandequippedwithalisted
overfill prevention device(OPD).
This Appliance must be kept awayfrom flammable materials during use. Do not contact with the surface when
thesupport temperatureexceeds 50K.



18


DANGER
A fire causing death or serious injury may occur if the following is not followed exactly:
Never store or use gasoline or other volatile substances in the vicinity of this grill.
Never store a spare propane or butane cylinder in the vicinity of this grill, or in the vicinity of another potential heat
source. Never fill the propane or butane cylinder beyond80% full.
This grill is designed to connect to a standard LP or butane cylinder only, please refer to the Step 16of assembly
instructions fortheinstallation.
It is recommended that the LP tank is not exceed 13kg.



WARNING
Don’t store spare gas cylinder in or near grill.
Useprotectivegloves when handlingparticularly hot components. Please do not manipulate the pre-
sealed parts to avoid leakage.
Connecting & Disconnecting the Gas Cylinder
LP (Propane) and Butane Gas Supply Connection &Disconnection (for UK)
1. Connecting on the gas cylinder. Make sure that: all taps of the
consuming appliance are closed. The connecting pipe to the
consuming appliance is correctly fitted. The regulator handle is in
the off position. With no flame on, remove the seal cap from the
automatic valve, place the appliance onto the valve and push
down firmly and vertically. You should hear a “click” sound which
means the regulator is securely latched.
2. Operation. Once the appliance is correctly mounted on the valve,
gas supply is possible by turning the regulator handle upwards. To
shut off the gas supply reverse above procedure. An arrow
engraved on the handle indicates the closing direction. Caution: if
you are unable to turn the regulator handle to the “on” position, this
means that your appliance is not correctly connected to the valve.
Do not force the handle to open, and restart the operations above.
3. Exchange of a cylinder. Make sure that: all taps on the gas
consuming appliance in the “ off ” position. The regulator handle is
in the “off” position. Then, dismount the appliance by pressing
horizontally on the button and pulling upwards at the same time.
4. Operation of excess flow check device. The regulator can be
fitted with a safety device designed to automatically limit the gas
escape in case of separation or rupture of the pipe that supplies
gas to the consuming appliance.
IMPORTANT: The regulator is never to be left on the cylinder
without its being connected to the consuming appliance, as the
tear-off proof safety is not designed to ensure the operation of the
cylinder valve.
LP (Propane) and Butane Gas Supply Connection &Disconnection (for Iceland)
1) Fitting and operating conditions
‐The A310/A300 is a household regulator designed to supply gas to gas consuming appliances at a
pressure and capacity as indicated on the identification label(1).
‐The A310/A300 can be fitted to any cylinder equipped with a cylinder valve with hand operated closure
ButtonHandle
OFF
ON



19

(9).The gas cylinder must always be used in the upright position.
‐Whenever used outdoors, the A310/A300 must be suitably protected against rain.
‐Never look for leaks using a flame, just use a soapy-water solution.
‐In case of any difficulties or problems. Shut off the gas supply and contact your dealer immediately.
‐Should a leak catch fire prematurely before you can close the cylinder valves (2), then use a wet cloth to
close the cylinder valve.
2) Assembly on the gas cylinder make sure that:
‐All taps on the consuming appliance are closed.
‐The connecting pipe to the gas appliance is correctly fitted.
In total absence of any flame, remove the plug or seal cap from the
cylinder valve. After checking the presence and the good state of the
gasket (8), tighten the union nut (9) by screwing up in the direction
indicated by the arrow (10).The union nut should be tightened
moderately. Nevertheless sufficiently to ensure a leak-tight joint
which must be checked by using a soapy-water solution. Hold the
regulator and turn the union nut, the regulator itself is never to be
rotated.
3) Plant Operation
Once the A310/A300 has been correctly mounted on cylinder valve.
The gas supply occurs by turning the valve hand wheel in the
direction shown by the arrow (11).To shut off the gas supply ,reverse
above procedure.
4) Replacing the gas cylinder
Make sure that:
‐All taps on the consuming appliance are in the closed position.
‐The cylinder valve is closed.
Then, dismount the A310/A300 by unscrewing the union nut (9).
DANGER
To prevent fire or explosion hazard when testing for a leak:
1. Always perform the “leak test“ as below before lighting the grill and each time the cylinder is connected for use.
2. Do not smoke or allow other sources of ignition in the area while conducting a leak test.
3. Conduct the leak test outdoors in a well-ventilatedarea.
4. Do not use matches, lighters or a flame to check for leaks.
5. Do not use grill until all leaks have been stopped. If you are unable to stop a leak, disconnect the propane or
butane supply, call forgas applianceservice or your local gassupplier.

Checking for Leaks

1. Make 2-3 oz. of leak solution by mixing one part liquid dishwashing
soap with three parts water.
2. Make sure control knobsare in the “OFF” position.
3. Spray some solution on the tank valveup to the regulator connection.
(See diagram toright.)
4. Inspect the solution at theconnectionsforbubbles.If no bubbles appear,
the connection is secure.
5. If bubbles appear, you have a leak. Go to step 6.
6. Disconnecttheregulator from the tank and reconnect. Make sure the
connectionistightandsecured.
7. Retestwith solution.
8. If you continue to see bubbles, replace thecylinder.

1
9
10
8
11
2

20

LightingYour Grill

DANGER
Failure to open lid while igniting the grill’s burners or not waiting five minutes to allow gas to clear if the grill
does not light, may result in an explosion, which could cause serious bodilyinjury or death.
WARNING
Never stand with your head directly over the grill when preparing to light the main burners, to prevent possible
bodily injury.
Igniter Lighting the Grill
WARNING:
Attempting to light the burner with the lid closed may cause an explosion. Make sure there are no
obstructions of airflow to the gas unit. Spiders and insects can nest and clog theburner/venture tube at the
orifice. A clogged burner tube can lead to a fire beneaththeappliance.
1. Read instructions before lighting your grill.
2. Open lid during lighting.
3. Open LP cylinder valve.
4. Push control knob in and turn the knob to the left to “HIGH” position. You will hear a clicking sound
from all burners. Keep pressing the knob until the burner is lit.
5. If ignition does not occur in 5 seconds, turn the burner control off, wait 5 minutes for gas to clear away,
and repeat the lighting procedure.
NOTE: If ignitor does not work, follow Match Lighting instructions.

Main Burner Match Lighting
Do not lean over grill while lighting.
1. Open lid during lighting.
2. Place match into match holder (hanging from side of cart).
Light match, place into the firebox.
3. Push in and turn right knob to HIGH position.
Be sure burner lights and stays lit..
4. Light other burners by pushing knob in and turning to HIGH position.


PRECAUTIONS:
1. Afterlighting,observethe burner flame. Make sure allburner ports are lit.
2. If the burner flame goes out during operation, immediately turn the gas “OFF”. Open lid to let the gas
clear for at least 5
minutes beforere-lighting.
3. Before cooking on the grill for the firsttime and operate the grill for approximately 15 minutes with the lid
closed and the gasturned on “HIGH”.This will “heat clean” the internal parts, dissipate odor from the
manufacturing process and paintedfinish.
4. Clean the grill after each use.DO NOT use abrasive or flammable cleaners. This may damage parts of
the grill andcause a fire.













