HUM ARM-1L User manual

ARM-1L / ARM-1S Active Ribbon Microphones
OWNER'S MANUAL
v1.0 – 01/2020
The information in this document has been carefully verified and is assumed
to be correct. However HUM Audio Devices reserves the right to modify the product
described in this manual at any time without prior notice.
This document is the property of HUM Audio Devices and may not be copied or
reproduced in any manner, in part or full without the authorisation of HUM Audio
Devices.
ontents
Foreword Introduction .................................................... 2
Operation Safety ............................................................. 3
Service and Repairs .......................................................... 3
Replacement Parts …......................................................... 4
Cleaning …..................................................................... 4
Using ARM-1L and ARM-1S microphones …................................ 5
Hand Lever Operation …..................................................... 6
Specifications …............................................................... 7
Warranty …..................................................................... 8
Limitations of Liability ….................................................... 9
Contact …...................................................................... 9
-1-

Dear ustomer,
Thank you for the confidence you have shown towards HUM Audio Devices
by purchasing the ARM-1L / ARM-1S Active Ribbon Microphone. You have choosed a
high end tool which will help you to get excellent recordings. ARM-1 is a result of
meticulous development, careful audiophile quality component selection, and
extensive studio testing during real sessions to get THAT sound. Becaue we are also
sound engineers with 20 years of practice in recordings, we did our best to provide
ARM-1 mics with sound that make them very practical, creative and extraordinary
tool.
We believe you will have much fun using ARM-1 mics and love them as we do.
We wish you every success with your new ARM-1 mono Active Ribbon
Microphone!
Your HUM Audio Devices – Team
Krzysztof Tonn Krzysztof Rudnicki
Follow us on Youtube, Facebook and our site:
www.hum-audio.com
HUM Audio Devices ARM-1 was designed, developed and precisely handcrafted in
Poland.
Introduction
ARM-1L and ARM-1S are active mono ribbon microphones, that inherit build
and sound quality from our flagship stereo RS-2 Ribbon Recording System. Custom
tailored 1.8 micron aluminium foil ribbon motors are paired together with
audiophile quality handcrafted audio circuit and high precision CNC-machined
mechanics.
There are two mechanically similar models with distinct sound that will let
you choose appropriate mic for your application: ARM-1L (with blue suspension
orings) has the same 2 inch ribbon motor like our flagship RS-2 microphone and
little more „character” in sound, while ARM-1S (with white suspension orings) is
equiped with 1 inch ribbon motor and has more clean and neutral sound.
You will find that both ARM-1 models excel on many sound sources, covering
wide range of studio recording applications, including string section recordings,
piano, guitars, woodwinds, ambience, drum overheads and vocals. They will give
you precious classic, huge, larger than life sound with a lot of details typically
-2-

found in good condenser mics, but at the same time you have that classic lovely
ribbon sound flavour, so much beloved by musicians and sound engineers. Tracks
recorded with ARM-1 mics also blend very well with other elements in the mix.
That's a distinctive feature of all best mics on the market.
Operation Safety
Do not use this devices anywhere near water (for example in a bath room, a
damp cellar, near swimming pools, or similar environments). Otherwise your are
dealing with risk of mic damage. ARM-1 should also not be installed near equipment
which produce strong magnetic fields or extreme heat.
Be careful to not insert any object into any of the mic chassis openings. You can
otherwise taking the risk of ribbon motor damage. Never allow any fluids to be
spilled or sprayed on the ARM-1 body. Such actions can lead to ribbon damage or
short circuit in mic's signal patch!
Ribbon mics are very sensitive to air flow blowing
directly onto motors foil. In case you plan to
record sound sources that can emit blasts of air,
like vocal, woodwind, kick drum or guitar combo –
place ARM-1's mic head off axis of air flow source
and consider using a pop filter, otherwise you can
damage the motor !
Service and Repairs
Turn off the Phantom power on your preamp, unplug the ARM-1 mic from
preamp and contact your local dealer when you think repairs are needed – or when
moisture or foreign objects may accidentally have reached inside ARM-1 mic
housing, or in cases when the mic may have fallen and shows any sign of having
been damaged. This also applies to any situation in which the unit have not been
subjected to any of these unusual circumstances but still is not functioning
normally or its performance is substantially altered. All repairs are done at HUM
audio Devices factory or in some cases at authorized dealer's site.
-3-

Do not open any of ARM-1 mics yourself -
– there are no user serviceable parts inside !
Replacement parts
Be sure that any authorized service technician uses original replacement parts
or those with identical specifications as the originals. Incorrectly substituted parts
can lead to fire, electrical shock or other dangers, including further equipment
damage. HUM Audio Devices can only guarantee quality of performance if correct
replacement parts are used.
Always be sure to ask a service technician to conduct a thorough safety check
and ensure that the state of the repaired device is in all respects up to factory
standards.
leaning
Do not use any solvents or liquids, as these can damage the chassis, rubbers or
inscriptions. Use a clean, dry cloth. Great for cleaning ARM-1's anodised mic body
is dry microfibre cloth. Disconnect the device from Phantom power source before
cleaning.
Declaration of E onformity
The construction of these units is in compliance with the standards and
regulations of the European Community.
-4-

Using ARM-1L and ARM-1S microphones
To use ARM-1 mics connect them to mic preamplifier with +48V Phantom
power. Because both mics are built to have top-notch sound, we strongly
recommend using them with as good preamps as possible, that will extract and
preserve all subtle details from recorded sound.
Especially we recommend our RP-2 Remote Controlled Discrete Class A Mic
Preamp, to create perfect and very versatile set. That will give you strong benefits,
because ribbon mics are very sensitive to preamp quality and also to quality and
length of audio cables. Putting RP-2 Preamp Box near your ARM-1 microphone will
give you an advantage of short signal path. Also RP-2's high-end circuits are
precisely tailored to give you the best sound you wish to have from ribbon mic.
ARM-1 mics will not operate without Phantom power switched on!
XLR wiring scheme:
FEMALE MALE NOTES
1. View from front
(mates to other connector)
2. Pins 1 and 2 are reversed when looking
at the other end (with solder points)
- 5 -

On bottom of ARM-1 microphone you will find switch that will let you
choose High Pass Filter between 50 Hz and 100 Hz. This is gentle 6db/oct slope
passive filter that sounds musical and will lower excessive subsonics from mic if
necessary.
Hand Lever operation
ARM-1 microphone swivel has a special rotatable hand lever with built-in
spring mechanism. Together with locking clutch action it provides fast and
convenient change of microphone angle position.
Thanks to the spring mechanism you can tighten or loose the lever fully even
when only small rotation angle is possible. To make full use of this feature - just
pull the lever towards the grey arrow , rotate to a new required starting position
(black arrow) and release. Then you can continue to tighten or loose the lever.
-6-

Specifications
Ribbon motors: Custom built, equipped with 1,8 micron aluminium foil,
shielded with copper
ARM-1L: Two inch long (as used in our flagship RS-2 mic)
ARM-1S: One inch long
Low ut Filter: Switchable, passive Low Cut Filter with two useful
frequencies: 50 Hz and 100 Hz (6dB/Oct slope)
Anti-vibration system: Dual (external shock mount and internal vibration
isolators)
onnectors: Gold plated, male Neutrik XLR (mic body)
Supply: +48V Phantom Power (+/-5V)
Sensitivity: ARM-1L: -38 dB (1V/Pa)
ARM-1S: -39 dB (1V/Pa)
Output Impedance: 22 Ohm (electronic)
Recommended
Preamp Impedance: 150 Ohm or greater
Max SPL: ARM-1L: 137 dB
ARM-1S: 138 dB
Frequency Response: ARM-1L: 30Hz – 14KHz (+/-3dB)
ARM-1S: 40Hz – 14KHz (+/-3dB)
Weight: ARM-1 mic: 1,1 kg (incl. Suspension)
ARM-1 set in Flight Case: 2,6 kg
Dimensions: Mic Body Length: 286,5 mm
Diameter: 60 mm
Spider external diameter: 126 mm
Flight Case Length: 320 mm
Width: 230 mm
Height: 155 mm
-7-

Warranty
1) We provide full two (2) year Warranty for all HUM Audio Devices products
against defects in material and workmanship. This Warranty relates to
each original Customer of HUM Audio Devices product and is not
transferable to other persons.
2) The period of this Warranty commences at the official receipt date of
product purchase from authorized HUM Audio Devices Distributor or Dealer
in given country, or directly from HUM Audio Devices for other countries.
Within a period of Warranty, HUM Audio Devices will remove defects in
materials and manufacturing faults adversely affecting warranted product
performance, by repairing or replacing parts or replacing the product as
we deem appropriate, free of charge.
3) This Warranty does not apply to any defect, failure, or damage due to any
cause other than defects in materials or workmanship of the product.
4) HUM Audio Devices will not be responsible for damage to, or failure of, or
need for repair or correction of any product, which occurs as a result of
user abuse or misuse, including but not limited to the operation with
wrong power supply or excessive voltage, or other wrong application or
storage including unreasonable exposure to heat, cold, wind, water, or
other elements, negligence or accident, and to material fatigue or
degradation through very intensive normal usage.
5) Serial number removing or altering, actual or attempted correction,
repair, service, modification or alteration of any HUM Audio Devices
product by persons not authorized to do it automatically expires this
Warranty.
6) Customer must contact his local HUM Audio Devices Distributor or Dealer,
or in countries without Distribution – directly with HUM Audio Devices, to
receive Product Return Authorization Number that will be used to track
and identify the returned product.
7) After receiving Product Return Authorization Number please deliver the
complete product in the original packing or in such packing that is
adequate to prevent damage to the product during the normal course of
transport to your local HUM Audio Devices Dealer, or in case of direct
purchase – to HUM Audio Devices. Transportation and insurance is the
Customer’s responsibility and is not covered by this Warranty.
8) In the interests of product development, the specifications, construction
and appearance of all above products are subject to change without prior
notice and without obligation to install these improvements in any product
previously manufactured.
-8-

9) All remedies and the measure of damages are limited to the above
services. It is possible that economic loss or injury to person or property
may result from the failure of the product; however, even if HUM Audio
Devices has been advised of this possibility, this limited warranty does not
cover any such consequential or incidental damages. Some states or
countries do not allow the limitations or exclusion of incidental or
consequential damages, so the above limitation may not apply to you.
Limitations of Liability
In no event will HUM Audio Devices be liable for any damages, including loss
of data, lost profits, cost of cover or other special, incidental, consequential or
indirect damages arising from the use of the unit, however caused and on any
theory of liability. This limitation will apply even if HUM Audio Devices or an
authorised dealer has been advised of the possibility of such damage.
ontact
HUM Audio Devices
ul. Gen. Tadeusza Rozwadowskiego 4
94-408 Lodz
Poland
Phone: [phone]
[phone]
email: [email protected]
Please follow us on our site, Youtube, Facebook, Twitter and Instagram
and look for further High End products from us:
website: www.hum-audio.com
Facebook: www.facebook.com/HumAudioDevices/
Twitter: www.twitter.com/HumAudioDevices
Instagram: www.instagram.com/hum_audio_devices
-9-
