HuneTec M-900R User manual
1/7
HuneTec Confidential Proprietary
COPYRIGHT , 2006 HuneTec CO., Ltd.
All Rights Reserved
M-900R
User’s Guide
January, 2006
HuneTec Co.,Ltd
2/7
HuneTec Confidential Proprietary
COPYRIGHT , 2006 HuneTec CO., Ltd.
All Rights Reserved
General Information
Introduction
# ReFLEX 2.7.2 Two-way Telemetry Device
# Small Size
# Serial interface for smart GPS antenna.
# 8 GPIO for telemetry
# System code format: ReFLEXTM 2.7.2, 1600, 3200, 6400 bps
RF Specification
# Tx Frequency Range: 896 MHz ~902MHz
# Rx Frequency Range: 929 MHz ~932MHz, 935 MHz ~942MHz
# Channel Spacing: 12.5 KHz/10KHz
# Frequency Deviation: 800Hz and 2400Hz
# Signaling Modulation: 4 level FSK
Physical Specification
# Operating temperature range: -30°C ~ +60°C (22F~140F)
# Dimensions
Size: 86×62×23mm
Weight: 300g
3/7
HuneTec Confidential Proprietary
COPYRIGHT , 2006 HuneTec CO., Ltd.
All Rights Reserved
# Power Consumption
Rx Consummation: 15mA
Tx Consummation: 250mA
Idle Current: 2mA
# Display
- LED (Red,Green)
# Accessories for Serial Port Interface
I/O Cable
Data Cable
Smart GPS antenna
The serial port interface provides a connection to the programming fixture and external GPS device.
Manufacturers
Hunetec Co.,LTD
7th fl. Chosun-Nae-Hwa Bldg.,4-1 Soonae-dong, Bundang-ku,
Sungnam-si, Kyungki-do, Korea 463-020
Telephone : +82-31-712-6868
Facsimile : +82-31-712-6889
4/7
HuneTec Confidential Proprietary
COPYRIGHT , 2006 HuneTec CO., Ltd.
All Rights Reserved
Specifications
1. Receiver
Item Specification
Frequency 929~932MHz, 935~942MHz
Channel Spacing 12.5KHz / 10KHz
Bit Rate 1600~6400bps
Signaling Modulation 2 or 4 Level FSK
Frequency Deviation 800Hz and 2400Hz
Receiver Sensitivity 20uV/M with 80 char(TBD)
Frequency Accuracy 1ppm
Adjacent Channel Rejection
> 50dB from Sensitivity to -80dBm
> 40dB at -70dB Signal Level
> 30dB at -60dB Signal Level
Co-Channel Rejection
< 15dB at -105dBm
< 10dB at -102dBm
< 6dB at -95dBm
Spurious Response Rejection > 55dB at -105dBm
Image Rejection > 55dB at -105dBm
Inter-Modulation Distortion Rejection
> 50dB from Sensitivity to -80dBm
> 40dB at -70dB Signal Level
> 30dB at -60dB Signal Level
Simulcast Delay Spread Tolerance
> 1/4 symbol width at -105dBm and 15dB C/I
> 1/4 Symbol width at -102dBm and 10dB C/I
> 1/4 Symbol width at -55dBm and 6dB C/I
2. Transmitter
5/7
HuneTec Confidential Proprietary
COPYRIGHT , 2006 HuneTec CO., Ltd.
All Rights Reserved
Item Specification
Frequency Range 896~902MHz
Channel Spacing 12.5KHz/10KHz
Bit Rate 800~9600bps
Signaling Modulation 4Level FSK
Frequency Deviation 800Hz and 2400Hz
Frequency Accuracy -2.5ppm < X < 2.5ppm
Frequency Stability -1.0ppm < X < 1.0ppm
Output Power 0.75W into Antenna
ERP 0.2W minimum over 8 positions
Spurious Emission In-Band/Out-Band < -50dB
Occupied Bandwidth 8.5KHz
6/7
HuneTec Confidential Proprietary
COPYRIGHT , 2006 HuneTec CO., Ltd.
All Rights Reserved
Installation
Please follow the next steps.
1. Put the device at any place you want.
2. Put the GPS antenna at any place to be able to see the Sky.
3. Connect GPS cable to device CON2
4. Connect power cable to device CON1
5. Reset the device by contact switch at the right side of the device.
6. After reset, confirm the red ‘ReFLEX’ LED blink.
Registration
It is different from each service provider. So, please see the service manual or contact the service provider.
7/7
HuneTec Confidential Proprietary
COPYRIGHT , 2006 HuneTec CO., Ltd.
All Rights Reserved
FCC Warning Statement
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO
THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
“CAUTION: Exposure to Radio Frequency Radiation.
The antenna used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in
conjunction with any other antenna or transmitter.
