Hunter 20171 User manual

Hunter Fan Company
41681-01 • 02/20/04
Step 1 Choose the Fan Site
Proper ceiling fan location and attachment to the building structure are
essential for safety, reliable operation, maximum e ciency, and energy
savings.
Choose a fan site where:
• No object can come in contact with the rotating fan blades during normal
operation.
•  e fan blades are at least 7 feet above the  oor and the ceiling is at least 8
feet high.
•  e fan blades have no obstructions to air  ow, such as walls or posts,
within 30 inches of the fan blade tips.
•  e fan is directly below a joist or support brace that will hold the outlet
box and the full weight of the fan.
Tools and Supplies You May Need
Checklist for Existing Fan Site
If you want to use an existing fan site, complete the following
checklist to determine if the site is acceptable and safe for your
new Hunter fan. If you cannot check o every item, prepare a new
fan site as described on this page.
Fan Support System
o Fan attaches directly to building structure.
o Fan support system will hold full weight of the fan and light
kit.
Ceiling Hole
o  e outlet box clearance hole is directly below the joist or
support brace.
Outlet Box
o  e outlet box is an UL-approved octagonal 4” x 1-1/2” outlet
box (or as speci ed by the support brace manufacturer).
o  e outlet box is secured to the joist or support brace by
wood screws and washers through the inner holes of outlet
box.
o  e outer holes of the outlet box are aligned with joist or
support brace.
o  e bottom of the outlet box is recessed a minimum of 1/16”
into ceiling.
Wiring
o  e electrical cable is secured to outlet box by an approved
connector.
o Six inches of lead wires extend from outlet box.
If your existing fan site is suitable, go to your fan manual and begin
with 2 • Installing the Ceiling Plate.
Step 2 Cut the Ceiling Hole
2-1. Locate the site for the ceiling hole directly below the joist or support
brace that will hold the outlet box and fan.
2-2. Cut a 4” diameter hole through the drywall or plaster of the ceiling. You
will use the hole to install the support brace and outlet box.
Step 3 Install a Support Brace, If Necessary
Determine if there is a ceiling joist directly above the ceiling hole. If the joist
is there, determine if it is positioned to allow you to recess the outlet box a
minimum of 1/16” into the ceiling. If NOT, install a support brace as follows:
3-1. Attach a 2” x 4” support brace between two joists. Position it to allow
you to recess the bottom of the outlet box a minimum of 1/16” into the
ceiling.
3-2. Check the support brace to ensure it will support the full weight of the
fan and light kit.
Step 4 Install the Outlet Box
4-1. Obtain a UL-approved octagonal 4” x 1-1/2” outlet box, plus two #8 x
1-1/2” wood screws and washers, available from any hardware store or
electrical supply house.
4-2. Orient the outlet box so that both the inner and outer holes in the box
align with the joist or support brace.
4-3. Drill pilot holes no larger than the minor diameter of the wood screws
(5/64”) through the inner holes of the outlet box.
4-4. Attach the outlet box directly to the support brace or joist with two #8 x
1-1/2” wood screws and washers.  e bottom of the outlet box must be
recessed a minimum of 1/16” into the ceiling.
Step 5 Prepare the Wiring
5-1. Make sure the circuit breakers to the fan supply line leads and associated
wall switch location are turned o . If you cannot lock the circuit
breakers in the o position, securely fasten a prominent warning device,
such as a tag, to the service panel.
5-2.  read the fan supply line through the outlet box so that the fan supply
line extends at least 6” beyond the box.
5-3. Attach the fan supply line to the outlet box with an approved connector,
available at any hardware store or electrical supply house.
5-4. Make certain the wiring meets all national and local standards and ANSI/
NFPA 70.
You have now successfully prepared your ceiling fan site. For instructions to
install your ceiling fan, go to your fan manual and continue with 2 • Installing
the Ceiling Plate.
CAUTION: All wiring must be in
accordance with national and local electrical
codes and ANSI/NFPA 70. If you are unfamiliar
with wiring, use a quali ed electrician.
Fan Support
System
Outlet BoxFan Support
System
Wiring
Suitable Existing Fan Site
• Drill
• Keyhole saw
• 2’ x 4’ support brace
• UL-approved octagonal
4” x 1-1/2” outlet box
• Two #8 x 1-1/2” wood screws
and washers
• Approved connector for
electrical wire
Preparing the Fan Site
8’ Minimum
Ceiling Height
7’ Minimum
to Floor
30” From
Wall or
Nearest
Obstruction
Step 5
Step 4
Steps 2 – 3
