Hunter 28482 Manual

Hardware
(Drawn to Scale)
Fan Parts
(Not Drawn to Scale)
PARTS GUIDE
PARTS GUIDE
Hunter Fan Company • 2500 Frisco Avenue • Memphis, TN 38114 • www.hunterfan.com • 98000-01-818 08-21-2007 • ©2007
Using this Parts Guide, make sure all
parts are included in the box.
If parts are missing, DO NOT RETURN
THIS ITEM TO THE STORE, call 888-830-1326 for assistance.
THIS PARTS GUIDE IS FOR REFERENCE ONLY.
REFER TO THE INSTALLATION MANUAL FOR FULLASSEMBLY INSTRUCTIONS.
R
SINCE 1886
Parts List
Model # 28482
Asm. Dwg. # 97747-01
Finish Brushed Nickel
Item Name Qnty Part #
*Hanging System Kit 1 94949-09
Ceiling Plate
Canopy
Canopy Trim Ring
Setscrew
Canopy Screw
Wood Screw
Wood Screw
Flat Washer
Mounting Isolator
Hanger Ball / Downrod Assembly 1 85770-02
Switch/Housing Assembly 1 93598-05
Blade Iron Set 1 87914-05
Blade Set 1 76238-16
Screw, Blade Iron Armature 11 63755-05
Hardware Kit 1 97747-00-860
Blade Grommet
Blade Assembly Screw
Screw, Machine, 6-32
Wire Connector
Screw, Switch Housing Assembly
Balancing Kit 1 07570-01
Remote Control Receiver 1 85662-06
Remote Control Transmitter 1 85752-01
Remote Control Cradle 1 85775-01
Cap, Finial 1 75421-01
Finial 1 75422-01
Globe/Shade 1 97782-01
Globe/Shade 1 97749-01
Allen Wrench 1 64801-01
Hanger
Bracket
Assembly
Blade
Assembly
Switch
Housing
Assembly
Screw,
Machine, 6-32
Screw,
Switch Housing
Set Screw
Screw, Blade
Iron Armature
Canopy Screw
Flat Washer
Screw, Blade
Assembly
3” Wood Screw
Balancing
Kit
Wire Nut
1.5” Wood Screw
Mounting
Isolator
Blade Grommet
Allen
Wrench
x 2
x 4
x 2
x 3
x 1
x 11
x 16
x 3
x 3
x 1
x 4
x 4
x 16
x 1
