NOTE: THESE INSTRUCTIONS MUST NOT CONTRAVENE YOUR LOCAL ELECTRICAL AUTHORITY REGULATIONS, WITH WHICH
ALL INSTRUCTIONS HERE IN MUST COMPLY.
PLEASE KEEP INSTRUCTIONS FOR FUTURE REFERENCE.
CATENARY MOUNT HIGH POWER INSTALLATION INSTRUCTIONS
DO NOT connect in close proximity to inductive loads, eg. air conditioning systems, water
connected to the circuit.
DO NOT carry out a Megger or insulation test on a circuit with a RETROTM luminaires connected to it.
DO NOT mount on a horizontal surface where water may collect or pool.
DO NOT connect to any Electronic Home System without checking with the manufacturer that it is suitable to
control the HUNZA™ luminaire.
V2 06/23
Diagram A
M12 Grub Screw
Cable Tie
Cable
Catenary Wire or
Steel Rod
Apply Loctite to this
Luminaire
• Attach the luminaire to the wire or steel rod as shown in diagram A.
• IMPORTANT apply Loctite to the thread where shown to ensure that the nut will remain secure.
• Tighten the nut down on to the wire or rod as shown in diagram A.
• Secure the cable to the wire or rod as shown with cable ties.
Disclaimer: These installation instructions do not cover theengineering required for the stainless wire or
rod catenary sytem required to suspend the xture.
Please get advice from your local structural engineer with regards to appropriate stainless wire/rod and
xing specications.
INSTALLATION
Warning: Do not disconnect the LED luminaire from secondary side of the driver connected to the mains. Switch o
MAINS FIRST. Allow the LED to discharge, then disconnect luminaire from the output side of the driver.
Do not water blast/jet wash this xture under any circumstance.
