Husqvarna LC 141iV User manual

LC 141iV, LC 141i, LC 141C
EN Operator's manual 9-27
BG Ръководство за експлоатация 28-49
CS Návod k použití 50-68
DA Brugsanvisning 69-87
DE Bedienungsanweisung 88-109
EL Οδηγίες χρήσης 110-132
ES Manual de usuario 133-153
ET Kasutusjuhend 154-172
FI Käyttöohje 173-191
FR Manuel d'utilisation 192-213
HR Priručnik za korištenje 214-232
HU Használati utasítás 233-253
IT Manuale dell'operatore 254-274
JA 取扱説明書 275-293
LT Operatoriaus vadovas 294-313
LV Lietošanas pamācība 314-333
NL Gebruiksaanwijzing 334-354
NO Bruksanvisning 355-373
PL Instrukcja obsługi 374-394
PT Manual do utilizador 395-415
RO Instrucţiuni de utilizare 416-435
RU Руководство по эксплуатации 436-459
SK Návod na obsluhu 460-479
SL Navodila za uporabo 480-498
SR Priručnik za rukovaoca 499-518
SV Bruksanvisning 519-537
TR Kullanım kılavuzu 538-556
UK Посібник користувача 557-579
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Husqvarna LC 141iV o
cerca il tuo prodotto tra le migliori offerte di Macchine Giardinaggio

4
3
67
8
9
1311 12
10
2
5
1
18
17
16
14
15
15
20
23
22
21
19
24
25
26
1
3
4
6
13
11
7
2
5
12
10
8
9
1
7
2

3 4 5 6 7 8
9 10 11 12 13 14
15 16 17 18 19 20
21 22 23 24
25
26 27

28 29
30 31
32 33
34 35

36 37
38 39
BA
40 41
42
3
4
56
78
9
43

44 45
46
A
B
47
48 49
50 51
A
B

52
A
B
53
54 55
56 57
58 59

60 61
62 63
64 65
66

Contents
Introduction..................................................................... 9
Safety............................................................................11
Assembly...................................................................... 18
Operation...................................................................... 18
Maintenance................................................................. 21
Troubleshooting............................................................ 22
Transportation, storage and disposal........................... 23
Technical data.............................................................. 24
EC Declaration of Conformity....................................... 27
Introduction
Product description
The product is a pedestrian-controlled rotary lawn
mower. The grass is collected in a grass catcher.
Remove the grass catcher to get rear discharge of the
grass. Attach a mulch kit (accessory) to cut the grass
into fertilizer.
Intended use
Use the product to cut grass in private gardens. Do not
use the product for other tasks.
Product overview LC 141iV/LC 141i
(Fig. 1)
1. Motor brake handle
2. Start inhibitor
3. Drive bail (LC 141iV)
4. Handle / handlebar
5. Control panel
6. ON/OFF button
7. SavE button
8. Battery indicator button
9. Battery charge indicator
10. Warning indicator (ERROR LED)
11. Decrease speed button (LC 141iV)
12. Speed level indicator (LC 141iV)
13. Increase speed button (LC 141iV)
14. Rear cover
15. Symbols
16. Battery lid
17. Safety key
18. Cutting cover
19. Cutting height lever
20. Rating plate
21. Grass catcher
22. Mulch plug for LC 141iV (Accessory)
23. Mulch plug for LC 141i (Accessory)
24. Battery charger (Accessory)
25. Battery (Accessory)
26. Operator's manual
Product overview LC 141C
(Fig. 2)
1. Motor brake handle
2. Start inhibitor
3. Power cord socket
4. Power cord holder
5. Handle / handlebar
6. Rear cover
7. Symbols
8. Cutting cover
9. Rating plate
10. Cutting height lever
11. Mulch plug (Accessory)
12. Grass catcher
13. Operator's manual
Symbols on the product
(Fig. 3) Injury or death can occur
to the operator or
bystanders if the product
is not used carefully and
correctly.
(Fig. 4) Read the operator's
manual and make sure
that you understand the
919 - 003 - 23.10.2019 9

instructions before you
use this product.
(Fig. 5) Keep persons and
animals at a safe distance
from the work area.
(Fig. 6) Look out for thrown
objects and ricochets.
(Fig. 7) Warning: Keep hands and
feet away from the
rotating blade.
(Fig. 8) Warning: Keep hands and
feet away from rotating
parts.
(Fig. 9) Remove the safety key
before you do
maintenance on the
product. (model
LC 141iV/LC 141i)
(Fig. 10) Disconnect the product
from electrical outlet
before you do
maintenance on the
product. (model LC 141C)
(Fig. 11) IPX1 - The product has
protection against
dripping water (model
LC 141iV/LC 141i)
(Fig. 12) IPX4 - The product has
protection against
splashing water (model
LC 141C)
(Fig. 13) Do not let rain fall on the
product (model LC 141iV/
LC 141i)
(Fig. 14) Warning: Do not operate
the product across the
power cord as this can
result in electrical shock
or damage to the product.
(model LC 141C)
(Fig. 15) This product is in
accordance with
applicable EC directives.
(Fig. 16) Noise emission to the
environment according to
the European
Community’s Directive.
The product’s emission is
specified in the Technical
data chapter and on the
label.
(Fig. 17) Direct current. 36V
(Fig. 18) Double insulation.
(Fig. 66)Recycle this product at a
recycling location for elec-
trical and electronic
equipment. (Applies to
Europe only)
(Fig. 25) Start procedure for model
LC 141iV/LC 141i: push
ON/OFF button, loosen
start inhibitor, push motor
brake handle down.
(Fig. 19) Start procedure for model
LC 141C: loosen start
inhibitor, push motor
brake handle down.
10 919 - 003 - 23.10.2019
