Operator Manual / Manual del operador
Zero Turn Mower / Z 248F
967045401-00
Please read the operator manual carefully and make sure
you understand the instructions before using the machine.
Gasoline containing up to 10% ethanol (E10) is acceptable for use
in this machine.The use of gasoline with more than
10% ethanol (E10) will void the product warranty.
Lea el manual de instrucciones detenidamente y asegúrese
de comprender las instrucciones antes de utilizar la máquina.
La gasolina que contiene hasta 10 % de etanol (E10) se puede
usar en esta máquina. El uso de gasolina que tenga más
de 10 % de etanol (E10) anulará la garantía del producto.
En / SP

©2015 All rights reserved.
Orangeburg, SC Printed in U.S.A.
When this product is worn out and no longer
used, return it to the reseller or other party for
recycling.
To implement improvements, specications
and designs can be altered without prior
notication.
Note that no legal demands can be placed
based on the information contained in these
instructions.
Use only original parts for repairs. The use of
other parts voids the warranty.
Do not modify or install non-standard
equipment to the unit without consent from the
manufacturer. Modications to the unit may
cause unsafe operations or damage the unit.
WARNING! Failure to follow cautious
operating practices can result in dangerous
injury to the operator or other persons. The
owner must understand these instructions,
and must let only approved persons who
understand these instructions to operate the
mower.
Each person operating the mower must be of
sound mind and body and must not be under
the inuence of mind altering substances.
WARNING! Engine exhaust, some of its
constituents, and certain vehicle components
contain or emit chemicals known to the State of
California to cause cancer and birth defects or
other reproductive harm.
WARNING! Battery posts, terminals
and related accessories contain lead and lead
compounds, chemicals known to the State of
California to cause cancer and birth defects
or other reproductive harm. Clean your hands
after handling.
CONFORMITY CERTIFICATES
USA requirements
Labels are placed on the engine and/or in the engine compartment stating that the machine
will fulll the requirements. This is also applicable to special requirements for any of the states,
(California emission rules etc.). Do not remove these labels. Certicates can also be supplied
with the machine at delivery or written in the Engine manual. Take care of them as they are
valuable documents.
WARNING! Engine exhaust and certain
vehicle components contain or emit chemicals
considered to cause cancer, birth defects,
or other reproductive system damage. The
engine exhaust contains carbon monoxide,
which is an odorless, colorless, poisonous gas.
Do not use the machine in enclosed spaces.

CONTENTS
INTRODUCTION .......................................................4
Driving and Transport on Public Roads ............... 4
Towing.................................................................. 4
Operating .............................................................4
SYMBOLS AND DECALS..........................................6
SAFETY .....................................................................7
Protecting Children .............................................. 7
Personal Safety Equipment .................................8
Slope Operation...................................................8
Safe Handling of Gasoline ................................... 9
Transport............................................................10
Towing................................................................ 11
Spark Arrestor.................................................... 11
CONTROLS .............................................................12
Steering Control Levers ..................................... 13
Park Brake .........................................................13
Ignition Switch....................................................13
Throttle Control ..................................................14
Choke control.....................................................14
Service Meter.....................................................14
Blade Switch ......................................................14
Fuse ...................................................................15
Seat Adjustment Lever.......................................15
Fuel Shut Off Valve ............................................15
Cutting Height Lever .......................................... 15
Bypass Linkages................................................15
Fuel Tank............................................................16
Tracking .............................................................16
OPERATION ............................................................17
Training ..............................................................17
Operating on Hills ..............................................19
Moving Machine By Hand.................................. 20
MAINTENANCE.......................................................21
Battery................................................................ 23
Safety System....................................................24
Park Brake .........................................................24
Tire Pressures....................................................24
Caster Wheels ................................................... 25
Anti-scalp Rollers ...............................................25
V-belts................................................................25
Adjusting the Mower Deck ................................. 26
Cutting Blades.................................................... 27
Cleaning.............................................................27
LUBRICATION .........................................................28
Transmission......................................................28
Wheel and Deck Zerks....................................... 28
TROUBLESHOOTING.............................................29
STORAGE................................................................30
SCHEMATIC ............................................................31
TECHNICAL DATA...................................................32
SERVICE JOURNAL................................................34
INTRODUCCIÓN .....................................................39
Conducción y transporte en vías públicas ......... 39
Remolque........................................................... 39
Funcionamiento .................................................39
SÍMBOLOS Y RÓTULOS.........................................41
SEGURIDAD............................................................ 42
Seguridad infantil ...............................................42
Equipo de seguridad personal ........................... 43
Funcionamiento en pendientes..........................43
Manipulación segura de la gasolina................... 44
Transporte..........................................................46
Remolque........................................................... 46
Parachispas .......................................................46
CONTROLES........................................................... 47
Palancas de control de la dirección ................... 48
Freno de estacionamiento .................................48
Interruptor de encendido....................................49
Interruptor de cuchilla ........................................49
Medidor de servicio............................................49
Control del acelerador........................................ 49
Estrangulador..................................................... 49
Fusible ...............................................................50
Palanca de ajuste del asiento............................50
Válvula de corte de combustible........................ 50
Palanca de altura de corte.................................50
Varillajes de derivación ......................................50
Depósito de combustible.................................... 51
Desplazamiento .................................................51
OPERACIÓN ...........................................................52
Capacitación ......................................................52
Trabajo en pendientes ....................................... 55
Mover la máquina manualmente........................ 56
MANTENIMIENTO...................................................57
Batería ...............................................................59
Sistema de seguridad ........................................ 60
Freno de estacionamiento .................................60
Presión de los neumáticos.................................61
Ruedecillas ........................................................61
Ruedas de apoyo...............................................61
Correas en V......................................................62
Ajuste del equipo de corte ................................. 62
Discos de corte .................................................. 63
Limpieza............................................................. 64
LUBRICACIÓN ........................................................65
Transmisión........................................................ 65
Engrasadores de rueda y equipo.......................65
SOLUCIÓN DE PROBLEMAS.................................66
ALMACENAMIENTO ...............................................67
ESQUEMA ...............................................................68
DATOS TÉCNICOS .................................................69
REGISTRO DE SERVICIO...................................... 71

4
INTRODUCTION
Congratulations
Thank you for purchasing a Husqvarna ride-
on mower. This machine is built for superior
efciency to rapidly mow primarily large areas.
A control panel easily accessible to the operator
and a hydrostatic transmission regulated by
steering controls both contribute to the machine’s
performance.
This manual is a valuable document. Read the
contents carefully before using or servicing the
machine. The following of instructions (use,
service, maintenance) by all who operate this
machine is important for the safety of the operator
and others. It can also considerably increase the
life span of the machine and increase its resale
value.
If you sell your machine, be sure to give the
operator manual to the new owner.
The nal chapter of this operator manual provides
a Service Journal. Make sure that service and
repair work are documented. A correctly kept
service journal reduces service costs for the
maintenance and affects the machine’s resale
value. Please contact your dealer for more
information. Take the operator manual along
when the machine is taken to your dealer for
service.
General
In this operator manual, left and right, backward
and forward are used in relation to the machine’s
usual driving direction.
Continuous dedication to improve our products
require that specications and design are subject
to change without notice.
Driving and Transport on Public
Roads
Check applicable road trafc regulations before
transporting on public roads. If the machine is
transported, you must always use approved
fastening equipment and make sure that the
machine is correctly attached. DO NOT operate
this machine on public roadways.
Towing
If machine is equipped with a tow hitch, use much
more caution when towing. Do not let children or
others in or on the towed equipment. Make wide
turns to avoid jack-kning. Travel slowly and leave
more distance to stop.
Do not tow on sloped ground. The weight of the
towed equipment may cause loss of traction and
loss of control.
Follow the manufacturer's recommendation for
weight limits for towed equipment. Do not tow
near ditches, canals, and other hazards.
Operating
This machine is constructed only for mowing
grass on lawns and even ground without
obstacles such as stones, tree stumps, etc. The
machine can also be used for other tasks when
equipped with special accessories provided by
the manufacturer. Operating instructions for the
accessories are provided with delivery. All other
types of uses are incorrect. The manufacturer’s
directions concerning operation, maintenance,
and repairs must be carefully followed.
Lawn mowers and all power equipment, can
be potentially dangerous if used improperly.
Safety requires good judgment, careful use in
accordance with these instructions and common
sense.
The machine must only be operated, maintained,
and repaired by persons familiar with the
machine’s special characteristics and who are
also knowledgeable about the safety instructions.
Use only approved repair parts to maintain this
machine.
Accident prevention regulations, other general
safety regulations, occupational safety rules, and
trafc regulations must be followed without fail.
Unauthorized modications to the design of the
machine may absolve the manufacturer from
liability for resulting personal injury or property
damage.

5
INTRODUCTION
Good Service
Husqvarna's products are sold throughout the
world and only in specialized retail stores with
complete service. This ensures that you as a
customer receive only the best support and
service. Before the product is delivered, the
machine has, for example, been inspected and
adjusted by your retailer. See the certicate in the
Service Journal in this operator manual.
When you need spare parts or support in service
questions, warranty issues, etc., please consult
the following professional:
Manufacturing Number
The machine’s manufacturing number can be
found on the printed plate afxed to the engine
compartment.
Stated on the plate, from the top are:
• The machine’s type designation (I.D.).
• The manufacturer’s type number (Model).
• The machine’s serial number (Serial no.)
Please have the type designation and serial
number available when ordering spare parts.
This manual belongs to the machine with the
manufacturing number:
Engine Transmission
The engine’s manufacturing number is stamped
on one of the valve covers.
The plate states:
• The engine’s model.
• The engine’s type.
• Code
Please have these available when ordering spare
parts.
The wheel motors and hydrostatic pumps have a
bar code decal afxed at the rear.

6
SYMBOLS AND DECALS
R N
These symbols are found on the machine and in
the operator manual.
Study them carefully so that you know what they
mean.
IMPORTANT INFORMATION Xxxx xxxxxx
xxxxx xxxx xxxxxxxxx xxxxxx xxxxxxxxx.
WARNING! Xxxx xxxxxx xxxxx xxxx
xxxxxxxxx xxxxxx xxxxxxxxx.
Used in this publication to tell the reader of a
risk of personal injury or death, particularly if the
reader neglects to follow the instructions in the
manual.
Reverse Neutral Fast Slow Choke Fuel Park Brake
Danger Cut Height
Low
Cut Height
High
Use protective
glasses
Use protective
gloves
Wear hearing
protection
Do not
stand here
Read Operator
Manual
Shut off engine,
remove key before
maintenance
or repair
Keep a safe
distance from
the machine
Use on slopes no
greater than 10° No passengers
Full body
exposure to
thrown objects
Severing of ngers
and toes
Do not open or
remove safety
shields with engine
running
Careful backing up,
watch for
other persons
Careful going
forward, watch for
other persons
Warning!
Battery acid is
corrosive, explosive
and ammable
Warning!
Do not touch parts
Warning!
Keep away from the
discharge deck
Warning!
Do not use without
deector
or grass catcher
Used in this publication to tell the reader of a
risk of material damage, particularly if the reader
neglects to follow the instructions in the manual.
Used also when there is a possibility for misuse or
misassembly.

7
SAFETY
WARNING! THIS CUTTING MACHINE
IS CAPABLE OF AMPUTATING HANDS
AND FEET AND THROWING OBJECTS.
FAILURE TO OBEY THE FOLLOWING
SAFETY INSTRUCTIONS COULD RESULT IN
DANGEROUS INJURY OR DEATH.
General Operation
• Read, understand,
and follow all
instructions on the
machine and in
the manual before
starting.
• It is recommended
that someone be
aware that you are mowing and can provide
help in case of injury or accident.
• Anyone who operates, maintains, and/or
services this machine must rst read and
understand this Operator Manual. Local laws
may regulate the age of the user. The owner
is responsible for training the users of this
equipment.
• The owner and operator of this equipment
can prevent accidents and is responsible for
accidents or injuries occurring to themselves,
other people and/or property.
• Do not put hands or feet near rotating parts or
under the machine. Keep clear of the discharge
opening at all times.
• Only let responsible adults, who are familiar
with the instructions, to operate the machine.
• Clear the area of objects such as rocks, toys,
wire, etc., which
could be picked up
and thrown by the
blades.
• Be sure the area is
clear of bystanders
before operating.
Stop machine if
anyone enters the area.
• Do not mow in reverse unless fully necessary.
Always look down and behind before and while
backing.
• Do not direct discharged material toward
anyone. Avoid discharging material against a
wall or obstruction. Material may ricochet back
toward the operator. Stop the blades when
crossing gravel surfaces.
• Do not operate machine without the full grass
catcher, discharge guard, or other safety
devices in place and working.
• Slow down before turning.
WARNING! CHILDREN CAN BE
SERIOUSLY INJURED OR KILLED BY THIS
EQUIPMENT. Carefully read and follow all the
safety instruction that follow.
IMPORTANT INFORMATION The American
Academy of Pediatrics recommends that
children be a minimum of 16 years of age
beforeoperating a riding lawn mower.
Protecting Children
Tragic accidents can occur if the operator is
not alert to the presence of children. Children
are frequently attracted to the machine and the
mowing activity. Do not assume that children will
stay where you last saw them.
• Keep children out
of the mowing area
and in the watchful
care of a responsible
adult other than the
operator.
• Be alert and turn
machine off if a child
enters the area.
• Before and while backing, look behind and
down for small children.
• Do not carry children, even with the blades
shut off. They may fall off and be seriously
injured or interfere with safe machine operation.
Children who have
been given rides
in the past may
suddenly come into
the mowing area for
another ride and be
run over or backed
over by the machine.
Safety Instructions
These instructions are for your safety. Read them
carefully.
• Do not let children to operate the machine.
• Use extreme care when going near blind
corners, shrubs, trees, or other objects that may
block your view of a child.

8
SAFETY
• Always turn off blades, move the steering
control lever out to the park brake position, stop
engine and remove keys before dismounting.
• Do not carry passengers. The machine is only
intended for use by one person.
• Disengage blades when not mowing. Shut
off engine and wait for all parts to come to a
complete stop before cleaning the machine,
removing the grass catcher or unclogging the
discharge guard.
• Operate the machine only in daylight or good
articial light.
• Do not operate the machine while under the
inuence of alcohol or drugs.
• Watch for trafc when operating near or
crossing roadways.
• Use extra care when loading or unloading the
machine into a trailer or truck.
• Always wear eye protection when operating
machine.
WARNING! When using the machine,
approved personal protective equipment must
be used. Personal protective equipment cannot
eliminate the risk of injury but it will reduce the
degree of injury if an accident does happen.
Ask your retailer for help in choosing the right
equipment.
• Wear proper Personal Protective Equipment
(PPE) while operating this machine, including
(at a minimum) sturdy footwear, eye protection,
and hearing protection. Do not mow in shorts
and/or footwear with open toes.
• Data indicates that operators age 60 years and
above are involved in a large percentage of
riding mower-related injuries. These operators
must evaluate if they can safely operate the
riding mower sufciently to protect themselves
and others from serious injury.
• Follow the manufacturer’s recommendation for
wheel weights or counterweights.
• Keep machine free of grass, leaves or other
debris buildup which can touch hot exhaust or
engine parts and burn. Do not let the mower
deck plow leaves or other debris that can cause
a buildup to occur. Clean oil or fuel spillage
before operating or storing the machine.
• Let machine cool before storage.
Personal Safety Equipment
• Make sure that rst
aid equipment is
close at hand when
using the machine.
• Do not use the
machine when
barefoot.
• Always wear
protective shoes or boots, preferably with steel
toe caps.
• Always wear approved protective glasses or a
full visor when assembling or driving.
• Always wear gloves when handling the blades.
• Do not wear loose clothing that can get caught
in moving parts.
• Use ear protectors to avoid damage to hearing.
Slope Operation
Slopes are a major factor related to loss of control
and tip-over accidents, which can result in severe
injury or death. Operation on slopes requires
much more caution. If you cannot back up the
slope or if you feel uneasy on it, do not mow it.
• Mow up and down slopes (10 degrees
maximum), not across.
• Watch for holes, ruts,
bumps, rocks, or
other hidden objects.
Uneven terrain
could overturn the
machine. Tall grass
can hide obstacles.
• Choose a low
ground speed so that you will not have to stop
while on the slope.
• Do not mow on wet grass. Tires may lose
traction.
• Avoid starting, stopping, or turning on a slope. If
the tires lose traction, disengage the blades and
proceed slowly straight down the slope.
• Keep movement on the slopes slow and
gradual. Do not
make sudden
changes in speed
or direction, which
could cause
machine to roll over.
• Use extra care while
operating machine
with grass catchers or other attachments; the
stability of the machine can be effected.
• Do not use on steep slopes.
• Do not try to stabilize the machine by putting a
foot on the ground.

9
SAFETY
• Do not mow near drop-offs, ditches, or
embankments. The machine could suddenly
roll over if a wheel is over the edge or the edge
caves in.
WARNING! The engine and the exhaust
system become very hot during operation.
There is a risk for burns if touched. Let engine
and exhaust system to cool before refueling.
WARNING! The engine must not
be started when the driver’s oor plate or
protective plates for the mower deck’s drive
belt is removed.
WARNING! Do not drive up or down hills
with slopes greater than 10 degrees. Do not
drive across slopes.
CAUTION! Use protective glasses
for maintenance work.
Safe Handling of Gasoline
To avoid personal injury or property damage, use
much more care in handling gasoline. Gasoline is
very ammable and the vapors are explosive.
• Extinguish all cigarettes, cigars, pipes, and
other sources of ignition.
• Use only approved gasoline containers.
• Do not remove gas cap or add fuel with
the engine running. Let engine cool before
refueling.
• Do not fuel the machine indoors.
• Do not keep the machine or fuel container
where there is an open ame, spark or pilot light
such as on a water heater or other appliance.
• Before you begin refueling, minimize the risk
of static electricity
by touching a metal
surface.
• Do not ll containers
inside a vehicle or
on a truck or trailer
bed with plastic
liner. Always place
containers on the ground away from the vehicle
when lling.
• Do not overll fuel tank. Replace gas cap and
tighten securely.
• Remove gas-powered equipment from the truck
or trailer and refuel it on the ground. If this is not
possible, refuel such equipment with a portable
container, rather than from a gasoline dispenser
nozzle.
• Keep the nozzle in contact with the rim of the
fuel tank or container opening at all times until
fueling is complete. Do not use a nozzle lock-
open device.
• If fuel is spilled on clothing, change clothing
immediately.
• Do not start the engine near spilled fuel.
• Do not use gasoline as a cleaning agent.
• If leaks arise in fuel system, the engine must
not be started until problem has been resolved.
• Check the fuel level before each use and leave
space for the fuel to expand, as the heat from
the engine and the sun may otherwise cause
the fuel to expand and overow.
General Maintenance
• Do not use the
machine indoors or
in spaces lacking
proper ventilation.
The exhaust
fumes contain
carbon monoxide,
an odorless and
poisonous lethal
gas.
• Make sure that the equipment is in good
condition and that all nuts and bolts, especially
those fastening the blade attachments, are
properly tightened and torqued.
• Maintain or replace safety and instruction labels
as necessary.
• Do not interfere with the intended function of a
safety device or reduce the protection provided
by a safety device. Check their proper operation
regularly. NEVER operate a machine with a
safety device that does not function properly.
• Check grass catcher components and the
discharge guard frequently and replace with
manufacturer’s recommended parts when
necessary.
• Do not change the settings of governors and
avoid running the engine with overly high
engine speeds. If you run the engine too fast,
machine components could be damaged.
• To reduce the risk of re, keep machine free of
grass, leaves or other debris buildup. Clean oil
or fuel spills and remove fuel-soaked debris. Let
machine cool before storing.

10
SAFETY
• Stop to inspect the equipment if you run over or
into anything. If necessary, make repairs before
starting.
• Do not make adjustments or repairs with the
engine running.
• The blades are sharp and can cause cuts and
gashes. Wrap blades or use protective gloves
when handling them.
• Check the park brake’s functionality regularly.
Adjust and service as necessary.
• Do not work with the starter circuit if there is
spilled fuel.
• Make sure that the fuel ller cap is mounted
tightly and no ammable substances are kept in
an open vessel.
• Sparking can occur when working with the
battery and the heavy cables of the starter
circuit. This can cause battery explosion, re
or eye injury. Sparking will not occur after the
grounding cable (normally negative, black) is
removed from the battery.
• Disconnect the grounding cable from the battery
rst and reconnect it last.
• Do not make a bridge short circuit across the
starter relay to run the starter.
• Be very careful when handling battery acid.
Acid on skin can cause serious corrosive burns.
If you spill battery acid on your skin, rinse
immediately with
water.
• Acid in the eyes can
cause blindness,
contact a doctor
immediately.
• Be careful when
servicing the battery.
Explosive gases
form in the battery. Do not perform maintenance
on the battery when smoking or near open
ames or sparks. The battery can explode and
cause serious injury or damage.
• The machine is tested and approved only
with the equipment originally provided or
recommended by the manufacturer. Only use
approved repair parts for the machine.
• The mulch blades must only be used in familiar
areas when higher quality mowing is desired.
• Regularly clean deck and underside of
deck, avoid spraying engine and electrical
components with water.
Transport
• The machine is
heavy and can
cause serious
crushing injuries.
Be extra cautious
when it is loaded on
or unloaded from a
vehicle or trailer.
• Use full width ramps for loading machine into a
trailer or truck.
• Use an approved trailer to transport the
machine. Operate the park brake by securing
the steering controls in the outboard position
with elastic or ratcheting straps. Turn off the
fuel supply. Fasten the machine down with
approved devices such as bands, chains or
straps.
• Both front and rear tie down straps must be
used and directed down and out from the
machine.
IMPORTANT INFORMATION The park brake
is not sufcient to lock the machine in position
during transport. Make sure that the machine
is correctly fastened to the transport vehicle.
Always reverse the machine onto the transport
vehicle to avoid tipping it over.
WARNING! Use much more caution
when loading the machine into a truck or
trailer using ramps. There is the possibility of
dangerous injury or death if the machine falls
off the ramps.
• Do not operate this machine on public
roadways.
• Check and abide by local trafc regulations
before transporting the machine on roads.
• Do not tow this machine, it may cause damage
to the drive system.
• Do not tow trailers, etc. with this mower. They
may jackknife or overturn, causing damage to
the mower and possible serious injury to the
operator.
• Load the unit onto truck or trailer by driving up
ramps of suitable strength using a slow speed.
Do not lift! The machine is not intended to be
lifted by hand.
• When loading or unloading this machine, do
not use more than the maximum recommended
operation angle of 10 degrees.

11
SAFETY
Towing
If machine is equipped with a tow hitch, use much
more caution when towing. Do not let children or
others in or on towed equipment.
Make wide turns to avoid jack-kning. Travel
slowly and leave more distance to stop. Do not
tow on sloped ground. The weight of the towed
equipment may cause loss of traction and loss of
control.
Follow the manufacturer’s recommendation for
weight limits for towed equipment. Do not tow
near ditches, canals, and other hazards.
Spark Arrestor
This mower is equipped with an internal
combustion engine and must not be used on
or near unimproved forested, bush covered
or grassy lands unless the engine’s system is
equipped with a spark arrestor meeting applicable
local or state laws.
Federal laws apply on federal lands.
If a spark arrestor is used, it must be maintained
in effective working order by the operator.
A spark arrestor for the mufer is available
through your authorized Husqvarna dealer.

12
CONTROLS
1. Steering / park brake controls
2. Tracking bolt, left
3. Deck lift
4. Fuses
5. Bypass Linkages
6. Fuel shut off valve
7. Fuel tank
8. Choke control
9. Throttle control
10. Service meter
11. Ignition switch
12. Blade switch
This operator manual describes the Husqvarna
Zero Turn Rider. The rider is tted with a four-
stroke overhead valve engine.
Transmission from the engine is made via
belt-driven hydraulic pumps. Using the left and
right steering controls, the ow is regulated and
thereby the direction and speed.
1
2
10
11
12
3
4
6
7
8
9
5

13
CONTROLS
Forward
Neutral
Reverse
Park
Brake
Steering Control Levers
The machine’s speed and direction are
continuously variable using the two steering
controls. The steering controls can be moved
forward or backward about a neutral position.
There is a neutral position, which is locked if the
steering controls are moved out.
When both controls are in the neutral position (N),
the machine stands still.
By equally moving both controls forward or
backward, the machine moves in a straight line
forward or backward.
For example, to turn right while moving forward,
move the right control towards the neutral
position. The rotation of the right wheel is reduced
and the machine turns to the right.
Zero turn can be achieved by moving one control
backward (behind the neutral position) and
carefully moving the other steering control forward
from its neutral position. The rotation direction
when zero turning is determined by which
steering control is moved backward behind the
neutral position. If the left steering control is pulled
backward, the machine turns to the left. Use more
care when using this maneuver.
If the steering controls are in uneven positions
when standing still or do not t in the slots for
moving the controls out, they can be adjusted.
WARNING! The machine can turn very
rapidly if one steering control is moved much
further forward than the other.
Park Brake
IMPORTANT INFORMATION Failure to bring
the steering / park brake controls inward at the
same time will cause the unit's safety system to
shut the unit down.
The park brake is integrated with the steering
control levers. Move both levers out from the
neutral position to engage the park brake.
To release the park brake, pull both steering
control levers inwards to the neutral position at
the same time. Do not try to operate the unit
without both levers being inwards out of the
engaged position or machine components could
be damaged.
Ignition Switch
The ignition switch is placed on the control panel
and is used to start and stop the engine.

14
CONTROLS
Blade Switch
To engage the mower deck, pull the knob out;
mower blades are disengaged when the knob is
pressed down.
Service Meter
The service meter displays the total operating
time with the blade activated.
At 50 hour intervals of operation, an oil can
icon shows and stays on for two hours before
an automatic reset occurs. To manually reset
the meter, turn the key off and on ve times at
one second intervals. To service the engine and
mower, see the Service Journal of this manual.
Throttle Control
The throttle control regulates the engine speed
and thereby the rate of rotation of the blades,
assuming the blade switch is pulled out.
To increase or decrease the engine speed, the
control is moved forward or back respectively.
Avoid idling the engine for long periods, as there
is a risk of fouling the spark plugs. USE FULL
THROTTLE WHEN MOWING, for best mower
performance and battery charging.
Choke control
The choke control is used for cold starts to
provide the engine with a richer fuel mixture.
For cold starts the control should be pulled up.

15
CONTROLS
The 20 amp primary fuse is located on the left
hand side of the machine. It is accessed by tilting
the seat forward. The fuse is a at pin type used
in automobiles.
Fuse
Seat Adjustment Lever
The seat can be adjusted lengthways. When
making adjustments, the lever below the right side
of the seat is pulled up, after which the seat can
be moved backward or forward.
Fuel Shut Off Valve
The fuel shut off valve is located at the right rear
of the seat. The valve is off when the handle tab is
turned perpendicular to the fuel line.
Cutting Height Lever
IMPORTANT INFORMATION To obtain an
even cutting height, it is important that the air
pressure in all tires is 15 psi / 103 kPa / 1 bar.
IMPORTANT INFORMATION Always raise the
deck to the highest position for transport.
To set the deck cutting height, pull the cutting
height lever inwards and move it to the desired
height notch.
Bypass Linkages
WARNING! Bypass linkages are
located close to the mufer. To prevent burns,
the engine should be shut off and allowed
to cool before the bypass linkage levers are
handled.
Transaxle bypass linkages must be engaged
when pushing or pulling the mower. The release
levers are located on each side of the rear of the
unit below the rear engine guard. See Moving
Machine By Hand in the Operation section.

16
CONTROLS
Fuel Tank
WARNING! Fill to bottom of ller neck.
Do not overll. Clean off spilled oil or fuel. Do
not keep, spill or use gasoline near an open
ame.
Read the safety instructions before refueling. The
capacity for each tank is 5-1/2 gallons.
Regularly check the gas cap gasket for damage
and keep the cap correctly tightened.
The engine will operate on a minimum of
87-octane unleaded gasoline (no oil mix).
Environmentally adapted alkylate gasoline can
be used. See Technical Data concerning ethanol
fuel. Methanol fuel is not allowed. Do not use E85
alcohol based fuel. Damage to the engine and
components may occur.
When operating in temperatures below 32° F, use
fresh, clean winter grade gasoline to help insure
good cold weather starting.
WARNING! The engine and the exhaust
system, become very hot during operation.
There is a risk for burns if touched. Let engine
and exhaust system to cool before refueling.
IMPORTANT INFORMATION Experience
indicates that alcohol blended fuels (called
gasohol, ethanol or methanol) can attract
moisture which leads to separation and
formation of acids during storage. Acidic gas
can damage the fuel system of an engine while
in storage. To avoid engine problems, the fuel
system should be emptied before storage of
30 days or longer. Drain the gas tank, start the
engine and let it operate until the fuel lines and
carburetor are empty. Use fresh fuel the next
season. See Storage for additional information.
Do not use engine or carburetor cleaners in the
fuel tank or permanent damage may occur.
Tracking
If the mower is not tracking straight, check the
air pressure in both rear tires. Recommended air
pressure for the rear tires is 15 psi (1 bar).
1. Tracking adjustments are made using the
tracking bolts. The tracking bolts limit the
motion control levers when in the full-forward
position.
2. For preliminary tracking adjustment, move
unit to an open, unobstructed area such as an
empty parking lot or open eld.
3. Using a 1/2" wrench, back the tracking bolts
out until ush with nut.
4. Test operate unit by driving it at full throttle
and the full forward position on both motion
control levers. Gradually turn in the tracking
bolt on the right hand side until the unit
noticeably starts drifting right.
5. Drive forward at full throttle with both motion
control levers in the full forward position.
Gradually turn in the left tracking bolt until unit
tracks straight.

17
OPERATION
Read the Safety section and following pages, if
you are unfamiliar with the machine.
Training
Due to unique steering capabilities, zero turn
mowers are far more maneuverable than typical
riding mowers.
Review this section fully prior to trying to move the
mower under its own power. When rst operating
the mower or until becoming comfortable with
controls, use a reduced throttle speed and
reduced ground speed. DO NOT move control
levers to the furthest forward or reverse positions
during initial operation.
First time users must become familiar with the
mower’s movement on a hard surface, such as
concrete or blacktop PRIOR to trying to operate
on turf. Until the operator becomes comfortable
with the mower controls and zero turning
capability, overly aggressive maneuvers may
damage turf.
Steering
To move forward and backward
The direction and speed of the mower’s
movements are effected by the movement of the
control lever(s) on each side of mower. The left
control lever controls the left wheel. The right
control lever controls the right wheel.
First time users must push the mower (see
Moving Machine By Hand in the Operation
section) to an open, at area without other
persons, vehicles or obstacles nearby. To move
the unit under its own power, the operator must
sit in the seat and start the engine (see Before
Starting in the Operation section). Adjust the
engine speed to idle, disengage the park brake
but do not engage the blades at this time. Pull
control levers inward. As long as the control levers
have not been moved forward or backwards, the
mower will not move.
Slowly move both control levers forward slightly.
This will let the mower start moving forward in a
straight line. Pull the control levers back to the
neutral position and stop the mower from moving.
Pull back slightly on control levers, allowing the
mower to move backwards. Push the control
levers forward to the neutral position to stop the
mower from moving.
To turn to the right
While moving in a forward direction, pull the right
lever back towards the neutral position while
maintaining the position of the left lever, this will
slow the rotation of the right wheel and cause the
machine to turn in that direction.
To turn to the left
While moving in a forward direction pull the left
lever back towards the neutral position while
maintaining the position of the right lever, this will
slow the rotation of the left wheel and cause the
machine to turn in that direction.
To zero turn
While moving in a forward direction, rst pull both
control levers back until the mower stops or slows
dramatically.
Then by alternating one lever slightly to the
forward position and the other in the reverse
position, complete the turn.
Before Starting
1. Read the sections on Safety and Controls
before starting the machine.
2. Do the daily maintenance before starting (see
Maintenance Schedule in the Maintenance
section).
3. Check that there is sufcient fuel in the fuel
tank.
4. Adjust the seat to the desired position.
5. Set pin at desired cutting height. (Height
selection pin is removed by rotating 180O.)
Make sure that the pin is inserted fully through
the both sides of the height panels.
WARNING! The engine exhaust contains
carbon monoxide, which is a odorless,
colorless, poisonous gas. Do not use the
machine in enclosed spaces.
Starting the Engine
1. Sit on the seat.
2. Raise the mower deck to the highest position.

18
OPERATION
3. Disengage the mower blades by pressing the
blade switch downwards.
4. Move the steering / park brake controls rmly
out to the locked position.
5. Move the throttle lever to the middle throttle
position. If the engine is cold, the choke
control should be pulled up.
6. Push in and turn the ignition key to the start
position. Push the choke control in gradually
when the engine has started.
IMPORTANT INFORMATION Do not
operate the starter for more than ve seconds
each time. If the engine does not start, wait
approximately ten seconds before retrying.
3. Move throttle control to full throttle (rabbit
symbol).
4. Engage the mower deck by pulling the blade
switch up.
5. Pull control levers inward and slowly move
both control levers slightly forward to move
forward in a straight line.
WARNING! Make sure that no one is
near mower when engaging blade switch and
that the work area is free from objects that
could be thrown by the rotating blades.
Stopping the Engine
1. Move the throttle to the minimum position
(tortoise symbol).
2. Move the steering controls at the same time
out to the park brake position.
3. Disengage the mower deck by pressing the
blade switch down.
4. Raise the mower deck to the highest position.
If the engine has been worked hard, let it idle
at least 60 seconds to attain a usual operating
temperature before stopping. To prevent
fouling the spark plugs, avoid idling the engine
for longer periods.
5. Turn the ignition key to the stop position.
Remove key. Always remove key when
leaving the mower to prevent unauthorized
use.
IMPORTANT INFORMATION When stopping
and leaving the machine, both steering / park
brake controls must be moved out to the locked
position at the same time.
tries to leave the seat with the engine running,
without rst setting the park brake, the engine
will shut off.
2. Lower the mower deck to the desired cutting
height.
7. When the engine starts, immediately release
the ignition key back to the run position.
8. Set the engine speed with the throttle. Let
the engine to operate at a moderate speed,
approximately mid throttle, for a short time
before use.
9. USE FULL THROTTLE WHEN MOWING.
Running
1. Release the park brake by pulling the steering
/ park brake controls inwards to the neutral
position at the same time.
NOTE: The mower is equipped with an
operator presence system. If the operator

19
OPERATION
IMPORTANT INFORMATION Leaving the
ignition switch in a position than OFF will cause
the battery to be discharged.
WARNING! Do not drive the rider on
terrain that slopes more than 10 degrees.
Mow slopes up and down, never side to side.
Avoid sudden directional changes. Do not drive
across slopes.
Operating on Hills
Read the Safety Instructions Driving on Slopes
in the Safety section.
• Use the slowest speed possible before starting
up or down hills.
• Avoid stopping or changing speed on hills.
• If stopping is fully necessary, pull steering / park
brake controls into the neutral position and push
outward to engage the park brake.
• Pull the steering / park brake controls back to
the center of the mower and push forward to
regain forward movement.
• Make all turns slowly.
Mowing Tips
• Observe and ag rocks and other xed objects
to avoid collisions.
• Begin with a high cutting height and reduce it
until the desired mowing result is attained. The
average lawn must be cut to 2-1/2" during the
cool season and over 3" during the hot months.
For healthier and better looking lawns, mow
often after moderate growth.
• For best cutting performance, grass over 6" in
height must be mowed twice. Make the rst cut
relatively high; the second to the desired height.
• The mowing result will be best with a high
engine speed (the blades rotate rapidly) and
low speed (the rider moves slowly). If the grass
is not too long and dense, the driving speed can
be increased without negatively affecting the
mowing result.
• The nest lawns are obtained by mowing
often. The lawn becomes more even and the
grass clippings more equally distributed over
the mown area. The total time taken is not
increased as a higher operating speed can be
used without poor mowing results.
• When mowing large areas, start by turning to
the right so that clippings will discharge away
from shrubs, fences, driveways, etc. After one
or two rounds, mow in the opposite direction
making left hand turns until nished.
• Avoid mowing wet lawns. The mowing result
is poorer because the wheels sink into the soft
lawn, clumps build, and grass clippings fasten
under the cowling.
• Hose the mower deck underside with water
after each use. When cleaning, the mower deck
shall be raised into the transport position. Make
sure the mower is cooled and the engine is off.
• Use compressed air to clean top surface of
the deck. Avoid ooding water on top surface,
engine and electrical components.
• When the mulching kit is used, it is important
that the mowing interval is frequent.
Moving Machine By Hand
When pushing or pulling the mower, engage the
EZT bypass linkages. The EZT bypass linkages
are located on the rear of the frame, below the
rear engine guard.
1. Raise the deck into the highest cutting
position.
2. Move the steering / park brake controls
inwards to the neutral position.
3. Pull the EZT bypass linkages up and out of
the keyhole slots. Release the levers with the
head outside the frame and held in the bypass
position.
4. To reengage the EZT’s to drive, reverse the
above procedure.
Load the machine into truck or trailer by driving
slowly up the ramps. DO NOT LIFT! The machine
is not intended to be lifted by hand.

20
OPERATION
WARNING! Bypass linkages are located
close to the mufer. To prevent burns, the
engine should be shut off and allowed to cool
before the bypass linkage levers are handled.
WARNING! Make no adjustments without:
• the engine stopped,
• the ignition key removed,
• the park brake activated
WARNING! Use more caution when
loading the machine into a truck or trailer using
ramps. There is the possibility of dangerous
injury or death if the machine falls off the
ramps.
IMPORTANT INFORMATION To manually
push the mower, engage the hydro bypass
levers on both sides, pull both steering / park
brake controls inwards and push machine.
