Husqvarna R 53SV L Setup guide

448193 12.02.11 BY
ILLUSTRATED PARTS LIST
MODEL NUMBER R 53SV L
PRODUCT NUMBER 961 41 02-26
MFG. ID. NUMBER 96141022603

2
HUSQVARNA ROTARY LAWN MOWER - MODEL NO. R 53SV L (96141022603) PRODUCT NO. 961 41 02-26
7
96
98
31
99
99
12
3
4
5
6
6
8
9
10 11
12
13
13
14
15
16
17
18
19
20
21
21
25
25
25
26
27
28
30
32
33
34
36
36
37
38
39
40
44
45
46
47
48
49
50
57
58
59
60
61
62
63
64
65
66
26
27
28
30
31
32
33
34
39
65 66
67
68
13 37
38
13

3
HUSQVARNA ROTARY LAWN MOWER - MODEL NO. R 53SV L (96141022603) PRODUCT NO. 961 41 02-26
KEY PART
NO. NO. DESCRIPTION
1 532 42 05-77 Upper Handle (Includes Foam Grip)
2 532 43 97-19 Lower Handle
3 532 42 68-12 Control Bar
4 532 41 53-50 Engine Zone Control Cable
5 532 18 23-98 Knob, Handle, Star
6 532 43 06-79 Handle Knob Assembly, Quick-Release
7 532 05 17-93 Hairpin Cotter
8 532 06 64-26 Wire Tie
9 532 40 69-85 Rear Door Assembly
10 532 12 84-15 Pop Rivet
11 532 41 05-40 Support Bracket, LH
12 532 41 05-42 Support Bracket, RH
13 817 06 04-10 Screw 1/4-20 x 5/8
14 532 43 45-50 Handle Bracket Assembly, LH
15 532 43 45-49 Handle Bracket Assembly, RH
16 532 40 54-17 Spring, Rear Door, LH
17 532 40 54-18 Spring, Rear Door, RH
18 532 13 20-04 Locknut, Hex 1/4-20
19 532 19 47-88 Rope Guide
20 532 43 61-19 Foot Guard, C.E.
21 817 49 04-16 Screw, Self-Tapping, Hex Head 1/4-20 x 1/2
24 - - - Engine, Briggs & Stratton, Model Number 12S902-
0110-H1 (order parts from engine manufacturer)
25 532 15 04-06 Hex Head Thread Rolling Screw 3/8-16 x 1-1/8
26 532 40 91-49 Hex Flange Nut
27 532 41 08-15 Wheel & Tire Assembly, Rear, 12"
28 532 40 16-38 Shoulder Bolt 5/16-18 x .33
30 532 41 31-41 Axle Arm Assembly, Rear
31 532 70 10-37 Selector Knob
32 532 40 98-89 Selector Spring
33 873 80 05-00 Nut, Hex 5/16-18
34 532 40 16-30 Washer, Curved, Cylindrical
KEY PART
NO. NO. DESCRIPTION
36 532 18 41-93 Bolt
37 874 78 05-12 Thread Cutting Screw w/Sems 5/16-18 x 3/4
38 532 40 16-29 Spacer
39 532 15 53-77 Nut, Hex, Flanged 5/16-18
40 532 43 50-59 Belt Keeper
44 532 40 80-16 Lawn Mower Housing
(Includes Key Numbers 10, 11, 12 and 45)
45 532 18 21-66 Danger Decal
46 532 43 22-79 Blade Adapter / Pulley
47 532 19 93-77 Blade 21"
48 532 85 10-74 Hardened Washer
49 532 85 02-63 Helical Washer 3/8-24 x 1-3/8 Grade 8
50 532 85 10-84 Hex Head Machine Screw 3/8-24 x 1-3/8 Grade 8
57 532 43 00-34 Upstop Bracket
58 532 17 88-48 Screw, Hex Washer Head #10-16 x 5/8
59 532 18 55-82 Discharge Deflector
60 532 17 57-35 Hinge Bracket Assembly
61 532 19 30-00 Spring, Hinge
62 532 17 56-50 Rod, Hinge
63 873 80 04-00 Locknut, Hex 1/4-20
64 532 18 55-76 Mulcher Door
65 532 19 74-80 O-Ring
66 532 08 83-48 Washer, Flat
67 532 19 92-55 Stud
68 532 75 11-53 Nut, Hex 1/4-20
96 532 19 79-91 Clip, Cable
98 872 25 05-05 Bolt, Carriage 5/16-18 x 5/8
99 532 19 19-38 Knob, Handle
- - 532 18 21-91 Decal, Warning (not shown)
- - 532 43 19-50 Operator’s Manual, European
- - 532 43 19-53 Operator’s Manual, Scandinavian
- - 532 43 19-51 Operator’s Manual, East Bloc
- - 532 43 19-52 Operator’s Manual, Baltic
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm. IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your lawn mower and void your warranty.

4
HUSQVARNA ROTARY LAWN MOWER - MODEL NO. R 53SV L (96141022603) PRODUCT NO. 961 41 02-26
54
1
57
829
28
18
18
32
35
16
13
14
15
15
11
26
33
38
38
36
41
25
40
12
16 13
14
12
6
7
11
33
17
17

5
HUSQVARNA ROTARY LAWN MOWER - MODEL NO. R 53SV L (96141022603) PRODUCT NO. 961 41 02-26
KEY PART
NO. NO. DESCRIPTION
1 532 42 56-61 Drive Control Assembly
(Includes Cable)
6 532 18 16-98 Screw
7 532 40 07-23 Mounting Bracket, Drive Control
8 532 40 62-59 Cable, Drive Control
11 532 41 10-81 Wheel & Tire Assembly
12 812 00 00-58 E-Ring
13 532 40 38-49 Pinion
14 532 18 94-03 Dust Cover
15 532 40 48-45 Pawl, Drive
16 532 06 77-25 Washer 1/2 x 1-1/2 x .134
17 532 42 18-36 Bearing Assembly,
Wheel Adjuster
18 532 70 10-37 Selector Knob
25 532 43 17-11 Belt Keeper
KEY PART
NO. NO. DESCRIPTION
26 532 16 34-09 Screw, Hi-Lo Thread #12 x 5/8
28 532 43 26-64 Drive Cover Assembly (Includes
Mounting Screw and Pushnut)
29 532 44 32-62 V-Belt
32 532 19 40-18 Pulley, Drive
33 532 40 91-48 Locknut, Hex
35 532 43 84-85 Kit, Wheel Adjuster, LH
(Includes Knob and Bearing)
36 532 40 48-33 Gearcase Assembly, Complete
38 873 80 04-00 Locknut 1/4-20
40 532 40 65-58 Spring
41 532 43 84-86 Kit, Wheel Adjuster, RH
(Includes Knob and Bearing)
54 532 40 19-03 Grassbag Assembly
57 532 41 19-50 Frame, Grassbag
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm. IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your lawn mower and void your warranty.
