Husqvarna Rider 16C AWD Instruction manual

Workshop manual
Rider 16C AWD
Rider 18 AWD
Rider 15T/s AWD English

English-
2
Safety Instructions .................................................4
General Instructions .................................................... 4
Special Instructions ..................................................... 4
Risk of sparking ........................................................... 5
Special Tools ..........................................................7
Laser tachometer ........................................................ 9
Safety .......................................................................... 9
Measure speed ........................................................... 9
Read the last, highest and lowest values ....................9
Replace the batteries .................................................. 9
Maintenance ................................................................ 9
Specifications .......................................................10
Delivery and Dealer Service ................................15
Delivery Service ........................................................ 15
After the first 8 hours .................................................15
25-Hour Service ........................................................ 15
50-Hour Service ........................................................ 15
100/200-Hour Service ............................................... 15
300-Hour Service ...................................................... 16
At Least Once Each Season .....................................16
Service Schedule ..................................................... 17
Delivery Procedures .................................................. 20
Battery ....................................................................... 22
Steering Wheel .......................................................... 23
Towing eye and counterweight ................................. 23
Checking the Engine Oil Level ..................................23
Check the oil level in the hydraulic tank .................... 24
Wheels ...................................................................... 24
Skid guard ................................................................. 24
Checking and Adjusting the Cutting Unit ................... 25
Test Running ............................................................. 25
Starting the engine ....................................................25
Engine Speed Regulator ...........................................26
Final inspection ......................................................... 26
Administration ........................................................... 26
Design and Function ............................................28
General ..................................................................... 28
Serial Number ........................................................... 29
Engine ....................................................................... 30
Steering ..................................................................... 31
Driving ....................................................................... 32
Cutting unit ................................................................ 34
Repair instructions ..............................................36
Removing the Briggs & Stratton engine ....................36
Removing the Kawasaki engine ................................43
Fitting the Kawasaki engine ......................................46
Checking the engine’s oil level, Briggs & Stratton ..... 49
Changing the engine oil, Briggs & Stratton ...............50
Checking the engine’s oil level, Kawasaki ................ 51
Fuel tank ................................................................... 52
Changing the engine oil Kawasaki ............................53
Checking and Adjusting the Steering Cables ............54
Replacing the Steering Cables .................................. 55
Removing/Fitting the Cable Pulley ............................ 56
Adjusting the parking brake, Rider AWD-machines .. 57
Adjusting of the Hydrostatic Transmission Cable ...... 58
Checking and adjusting the throttle cable, Kawasaki 58
Adjusting the throttle cable, Briggs & Stratton ...........59
Checking and adjusting the choke cable, Kawasaki ..60
Replacing the Articulated Steering Bearings .............60
Removing the Pendulum Shaft ..................................63
Replacing Bushings ...................................................64
Fitting the Pendulum Shaft .........................................65
Drive axles .................................................................65
Front axle ...................................................................65
Rear axle ....................................................................69
Replacing the Hydrostatic Transmission Shaft Seals 74
Replacing the Hydrostatic Transmission Cable .........77
Fitting the Hydrostatic Transmission Cable ...............79
Bleeding the drive system ..........................................82
Adjustment of the transmission’s neutral position ......84
Transmission Maintenance ........................................85
Adjusting the lever housing ........................................87
Replacing the hydraulic pump’s drive belt .................88
Replacing the Centre Belt ..........................................90
Replacing the front belt ..............................................91
Equipment Frame ......................................................93
Fitting the cutting unit (CombiClip 103, CombiClip 110)
94
Removing the cutting unit
(CombiClip 103, CombiClip 112) ...............................97
Removing the cutting unit (CombiClip 94) ........ 98
The cutting unit’s service position ........................... 100
Placing in the Service Position
(CombiClip 103, CombiClip 112) ............................ 100
Restoring from service position ............................... 102
Placing in the service position
CombiClip 94 .......................................................... 103
Restoring from service position ............................... 106
Adjusting the Unit’s Parallelism and Cutting Height 107
Parallelism .............................................................. 107
Cutting height .......................................................... 107
Checking and Adjusting the Ground Pressure ........ 108
Belt Replacement:
the CombiClip 94 .................................................... 108
Removing Blades with Bearings ............................. 110
Sharpening and Balancing Blades .......................... 114
Removing the BioClip plug (Combi) ........................ 115
Electrical system ............................................... 117
Wiring diagram Rider 16 AWD, Rider 15T AWD and
Rider 18 AWD ......................................................... 117
Ignition and Starter Lock ......................................... 119
Main fuses ............................................................... 119
Safety System ......................................................... 120
Hydraulic System .............................................. 122
Hydraulic Hygiene ................................................... 122
Hydraulic Oils .......................................................... 122
Fixing Oil Leaks ...................................................... 122
Keep the hydraulic oil clean .................................... 123
Working Methods .................................................... 123
Hydraulic system AWD ........................................... 124
Hose bundle ............................................................ 125
Workshop Manual for the
Rider 16 AWD, Rider 18 AWD and
Rider 15T AWD, Rider 15Ts AWD

English-
3

English-
4
SAFETY INSTRUCTIONS
Safety Instructions
General Instructions
This workshop manual is written for personnel with
general knowledge about the repair and service of
riders.
The workshop where the rider is to be repaired
must be equipped with safety equipment in
accordance with local bylaws.
No one may repair the rider unless they have read
and understood the content of this workshop
manual.
The machine is tested and approved only with the
equipment originally provided or recommended by
the manufacturer.
This workshop manual contains the following
boxes in relevant places.
Special Instructions
The fuel used in the rider has the following
hazardous properties:
• The fluid and its vapour are poisonous.
• Can cause eye and skin irritation.
• Can cause breathing problems.
• Is highly inflammable.
When using compressed air, do not direct the jet
towards the body. Air can penetrate into the blood
circulation system, which entails mortal danger.
Use eye protection when working with tensioned
springs.
Wear protective earplugs or earmuffs when test
running.
After test running, do not touch the muffler until it
has cooled. Risk of burns.This is especially true if
the rider is equipped with a catalytic converter.The
coatings on and in the catalytic converter element
are hazardous to ingest. Use protective gloves
when working with the converter/muffler.
The blades are sharp and can cause cuts and
gashes.Use protective gloves when handling the
blades.
Use eye protection when working with the cutting
unit.The belt tensioning spring can break, fly off,
and could cause personal injury.
Use eye protection when working with the battery
with the plugs removed. Be especially careful
when handling battery acid.Acid on the skin can
cause serious corrosive injuries.In the event of
spillage on the skin wash immediately with water.
Acid in the eyes can cause blindness;contact a
doctor immediately.
Be careful when servicing the battery. Explosive
gases form in the battery. Never perform
maintenance on the battery while smoking or in
the vicinity of open flames or sparks.This can
cause the battery to explode and cause serious
injuries.
WARNING!
The warning box warns of the risk
of personal injury if the
instructions are not followed.
IMPORTANT INFORMATION
This box warns of material damage if the
instructions are not followed.
!
IMPORTANT INFORMATION
Waste oil and old filters shall be handled
as hazardous waste.

English-
5
SAFETY INSTRUCTIONS
Risk of sparking
Sparking can occur when working with the
battery and the thick cables in the starter
motor circuit.
This can cause the battery to explode, fire or
eye injuries.
Sparking in the circuit can not occur once the
battery’s power connection cable (usually the
black negative cable) has been disconnected.
Avoid sparking and its consequences by:
• Wearing protective glasses.
• Make sure that the fuel cap is fitted and
that no flammable liquids are stored in an
open container.
• Do not work on the starter motor circuit in
the vicinity of spilt fuel.
• Disconnect the battery’s power connec-
tion cable (usually the black negative
cable) first and connect it last.
• Exercise care with tools so that short
circuiting does not occur.
• Do not short circuit across the starter
relay’s connections to run the starter
motor.
8009-728
Risk of sparking

English-
6
SAFETY INSTRUCTIONS

English-
7
SPECIAL TOOLS
SpecialTools
The following special tools are used when working on the rider.
Special tools for the engine and transmission are specified in resp.Workshop Manuals.
506 66 48-01 Engine belt pulley remover.
506 56 76-01 Allen key, 5/16" for loosening the engine belt pulley’s Allen screw (Kawasaki).
506 79 06-01 Allen key, 3/8", for loosening the engine belt pulley allen screw (Briggs & Stratton).
506 89 92-01 Counter to aid removing the engine belt pulley.
506 89 93-01 Tool for the centre spring.
535 41 32-01 Punch kit for pendulum shaft bushings.
502 28 80-01 Speed gauge.
6021-034
506 66 48-01 506 56 76-01
506 79 06-01 506 89 92-01 506 89 93-01 535 41 32-01
502 28 80

English-
8
SPECIAL TOOLS
The figures show how the special tools are used.
506 66 48-01
506 89 93-01
535 41 32-01
506 56 76-01
506 79 06-01
8009-518
8009-517 8009-515
6021-035

English-
9
SPECIAL TOOLS
Laser tachometer
Safety
• Laser product class 1.
• Exercise care when the laser beam is on.
• Do not look straight at the beam.Do not
aim the beam towards anyone else’s
eyes, either people or animals.
• Do not aim the laser beam towards pol-
ished surfaces where the beam can be
reflected into someone’s eyes.
• Do not aim the laser beam towards explosive gases.
• Remember when measuring.
• The reflective surface must be smaller than the non-reflective surface.
• If the object to be measured is polished, cover the measurement surface with black tape or paint with
black paint prior to attaching the reflective tape.
• Clean the surface before attaching the tape.
• When measuring at low speed, more accurate measurement values can be obtained if you attach several pieces
of tape equally distributed around the measurement object. Now divide the read measurement value with the
number of pieces of tape to get the correct speed.
Measure speed
1. Move the switch to the RPM position to measure the speed, orTOT to measure the number of revolutions.
2. Attach a small piece of reflective tape (approximately 1 x 1 cm) on the rotating object to be measured.
3. Press and hold down the measurement button on the side of the instrument. Aim the measurement laser beam at
the object and the reflective tape.The display will come on after 1–2 seconds.
4. Hold the measurement button down during the entire measurement.The instrument switches off when the
measurement button is released.
Read the last, highest and lowest values
The instrument automatically saves the last, highest and lowest measurement values during a measurement (i.e. as
long as the measurement button is held down). Press and hold down the memory button (MEM) to read the saved
values.Values are shown on the display after 1–2 seconds.
Measuredvalue Indicated by
Press once Last “LA”
Press twice Highest “UP”
Press three times Lowest “DN”
Replace the batteries
When the symbol for a weak battery is shown on the display, the batteries will soon be spent.
1. Open the battery cover by loosening the crosshead screw that holds the cover in position.
2. Remove the old batteries and insert new ones.Use four, 1.5 volt batteries of the type R6 (AA).
3. Make sure the batteries are turned the right way, otherwise damage can be caused to the instrument.
4. Close the battery cover and secure with the screw.
Maintenance
Clean the tachometer using a soft, damp cloth. Never use any form of solvent to clean it.Never dip it into water or
another fluid.
Do not subject the tachometer to direct sunlight, high temperatures, extreme dust or mechanical impact.
Remove the batteries if the instrument is not to be used for a long period of time.
The tachometer may only be opened by accredited technicians.
RPM
TOT
MEM
DIGITAL TACHOMETER
8009-853

English -
10
SPECIFICATIONS
Specifications
Rider 16 AWD Rider 18 AWD
Dimensions and weight
Length, base machine - 2020 mm / 6.61 ft
Length with cutting deck, see note 1 2230 mm / 7.32 ft 2240 / 2260 / 2280 mm / 7.35 / 7.41
/ 7.48 ft
Width, base machine 890 mm / 2.92 ft 890 mm / 2.92 ft
Width with cutting deck, see note 1 1000 mm / 3.28 ft 1000 / 1080 / 1180 - 3,28 / 3,54 / 3,8
Height 1070 mm / 3.51 ft 1150 mm / 3.66 ft
Operating weight, base machine - 249 kg / 549lb
Operating weight with unit 252 kg / 595 lb 293 / 298 / 301kg - 646 / 657 / 664 lb
Wheelbase 887 mm / 2.91 ft 887 mm / 2.91 ft
Max. permitted slope 10° 10°
Wheels
Tyre dimensions 16*6,5*8 16*6,5*8
Air pressure, front and rear 60 kPa / 0.6 bar / 9 PSI 60 kPa / 0.6 bar / 9 PSI
Engine
Manufacturer Briggs & Stratton Briggs & Stratton
Model 31A6 31G7
Power 9.8 kW 9,7 kW
Displacement 502 cm
3
/ 30,7 cu.in 502 cm
3
/ 30,7 cu.in
Fuel at least 85 octane unleaded at least 87 octane unleaded
Tank volume 10 litres / 2,6 US Gal 10 litres / 2,6 US Gal
Oil SAE 5W/30, 10W/30, SAE 5W/30, 10W/30,
Oil volume
API SF-SJ
1.4 litres / 1.5 US qt
API SF-SJ
1.9 litres / 2.0 US qt
Oil volume incl.filter 1.7 litres / 1.8 US qt 2.0 litres / 2.1 US qt
Starting Electric start Electric start
Speed max 2900 + 100 rpm 2900 + 100 rpm
Speed idling 1500 rpm 1500 rpm
Drive axles
Manufacturer and type Front K574 KTM10L K574 KTM10L
Manufacturer and type Rear K574 KTM10L K574 KTM10L
Oil SAE 10W/40 SAE 10W/40,
Oil volume, total including hydraulic
system 5 litres / 5.2 US qt 5 litres / 5.2 US qt

English-
11
SPECIFICATIONS
Note 1. If the machine can be equipped with different cutting decks, the values are stated in order starting
from the cutting deck with the smallest cutting width.
Electrical System
Type 12 V, negative grounded 12 V, negative grounded
Battery 12 V, 24 Ah 12 V, 24 Ah
Main fuse Flat pin, 15 A Flat pin, 15 A
Spark plug Champion RC12YC EMS Platinum
Electrode gap 0.75 mm / 0.030" 1 mm / 0.040"
TighteningTorques
Drive disc steering 5–10 Nm / 3.5–7 lb-ft 5–10 Nm / 3.5–7 lb-ft
Line pulley steering cable 20–30 Nm / 14–21 lb-ft 20–30 Nm / 14–21 lb-ft
Belt pulley 45–50 Nm / 25–28 lb-ft 45–50 Nm / 25–28 lb-ft
Blades M10 bolt 45–50 Nm / 32–36 lb-ft 45–50 Nm / 32–36 lb-ft
Blades M12 bolt 45–50 Nm / 53–56 lb-ft 45–50 Nm / 53–56 lb-ft
Blade bearings 20–25 Nm / 14–18 lb-ft 20–25 Nm / 14–18 lb-ft
Belt tensioning wheel 15–25 Nm / 10–18 lb-ft 15–25 Nm / 10–18 lb-ft
Fitting screws, engine 20–25 Nm / 14–18 lb-ft 20–25 Nm / 14–18 lb-ft
Fitting screws, gearbox 20–25 Nm / 14–18 lb-ft 20–25 Nm / 14–18 lb-ft
Engine belt pulley 70–80 Nm / 50–56 lb-ft 70–80 Nm / 50–56 lb-ft
Rider 16 AWD Rider 18 AWD

English -
12
SPECIFICATIONS
Rider 15T AWD Rider 15Ts AWD
Dimensions and weight
Length, base machine 2020 mm / 6.61 ft 2020 mm / 6.61 ft
Length with cutting deck,
see note 1 2240 / 2260 / 2280 mm / 7.35 / 7.41 / 7.48 ft 2240 / 2260 / 2280 mm / 7.35 / 7.41 / 7.48 ft
Width, base machine 890 mm / 2.92 ft 890 mm / 2.92 ft
Width with cutting deck, see
note 1 1000 / 1080 / 1180 - 3,28 / 3,54 / 3,87 1000 / 1080 / 1180 - 3,28 / 3,54 / 3,87
Height 1150 mm / 3.66 ft 1150 mm / 3.66 ft
Operating weight, base
machine 250 kg / 551 lb 249 kg / 549 lb
Operating weight with unit 294-299-302 kg / 648–659-666 lb 307-312-315 kg / 677–688-694 lb
Wheelbase 887 mm / 2.91 ft 887 mm / 2.91 ft
Max. permitted slope 10° 10°
Wheels
Tyre dimensions 16*6,5*8 16*6,5*8
Air pressure, front and rear 60 kPa / 0.6 bar / 9 PSI 60 kPa / 0.6 bar / 9 PSI
Engine
Manufacturer Kawasaki Kawasaki
V-Twin V-Twin
Model FH430V FH430V
Power 8,3 kW 8,3 kW
Displacement cm
3
/ cu.in 431 / 26,3 431 / 26,3
Fuel at least 87 octane unleaded at least 87 octane unleaded
Tank volume 10 litres / 2,6 US Gal 10 litres / 2,6 US Gal
Oil SAE 10W/30, 10W/40, SAE 10W/30, 10W/40,
Oil volume, litres/US Gal 1,5 / 1,6 1,5 / 1,6
Oil volume incl.filter 1.7 litres / 1.8 US qt 1.7 litres / 1.8 US qt
Starting Electric start Electric start
Speed max 2900 + 75 rpm 2900 + 75 rpm
Speed idling 1500 rpm 1500 rpm
Drive axles
Manufacturer and type
Front K574 KTM10L K574 KTM10L
Manufacturer and type Rear K574 KTM10L K574 KTM10L
Oil SAE 10W/40, SAE 10W/40,
Oil volume, total including
hydraulic system 5 litres / 5.2 US qt 5 litres / 5.2 US qt

English-
13
SPECIFICATIONS
Note 1. If the machine can be equipped with different cutting decks, the values are stated in order starting
from the cutting deck with the smallest cutting width.
Electrical System
Type 12 V, negative grounded 12 V, negative grounded
Battery 12 V, 24 Ah 12 V, 24 Ah
Main fuse Flat pin, 15 A Flat pin, 15 A
Spark plug Champion RCJ8Y Champion RCJ8Y
Electrode gap 0.75 mm / 0.030" 0.75 mm / 0.030"
TighteningTorques
Drive disc steering 5–10 Nm / 3.5–7 lb-ft 5–10 Nm / 3.5–7 lb-ft
Line pulley steering cable 20–30 Nm / 14–21 lb-ft 20–30 Nm / 14–21 lb-ft
Belt pulley 45–50 Nm / 25–28 lb-ft 45–50 Nm / 25–28 lb-ft
Blades M10 bolt 45–50 Nm / 32–36 lb-ft 45–50 Nm / 32–36 lb-ft
Blades M12 bolt 45–50 Nm / 53–56 lb-ft 45–50 Nm / 53–56 lb-ft
Blade bearings 20–25 Nm / 14–18 lb-ft 20–25 Nm / 14–18 lb-ft
Belt tensioning wheel 15–25 Nm / 10–18 lb-ft 15–25 Nm / 10–18 lb-ft
Fitting screws, engine 20–25 Nm / 14–18 lb-ft 20–25 Nm / 14–18 lb-ft
Fitting screws, gearbox 20–25 Nm / 14–18 lb-ft 20–25 Nm / 14–18 lb-ft
Engine belt pulley 70–80 Nm / 50–56 lb-ft 70–80 Nm / 50–56 lb-ft
Rider 15T AWD Rider 15Ts AWD

English -
14
SPECIFICATIONS
Cutting unit
Check List
Parallelism, cutting unit with cutting height in position 1: ± 2 mm / ± 0.079"
Checking the cutting height in position 1: 25± 2 mm / 0,98 ± 0.079"
Distance between support plate and drive belt: 3–6 mm / 1/8"–1/4"
Distance between the belt adjuster lever and the belt guide, disengaged unit: 17 ± 5 mm / 7/16" ± 3/16"
Play
Brake cable: 1 mm / 0.040"
Cable, hydrostatic pedals: 0 mm
CombiClip 94 CombiClip 103
Cutting width 940 mm / 37" 1030 mm / 40.5"
Cutting heights 45–95 mm / 1.75–3.75" 45–95 mm / 1.75–3.75"
Blade length 360 mm / 14" 410 mm / 16"
Guaranteed noise level 100 dB(A) 100 dB(A)
Width 1080 mm / 3.54 ft 1115 mm / 3.66 ft
Weight 46 kg / 102 lb 48 kg / 106 lb
CombiClip 112
Cutting width 1120 mm / 44"
Cutting heights 40–100 mm / 1.57–3.93"
Blade length 420 mm / 16.5"
Guaranteed noise level 100 dB(A)
Width 1230 mm / 4.04 ft
Weight 50 kg / 110 lb

English-
15
DELIVERY AND DEALER SERVICE
Delivery and Dealer Service
Delivery Service
1. Charge the battery for 4 hours at
max. 3 amp.
2. Fit steering wheel, seat and any optional
equipment.
3. Check and adjust tyre pressure
(60 Kpa, 0.6 bar, 9 PSI).
4. Adjust cutting unit:
Adjust lift springs (effective weight of
cutting unit should be
12-15kg / 26.5-33 lb).
Adjust cutting unit so that rear edge is
about 2-4 mm / 1/8” higher than front edge.
Adjust the cutting unit’s cutting height
setting so that the connection rod is tensed
at the lowest cutting height.
5. Check that the right amount of oil is in the
engine.
6. Check that there is oil in the transmission’s
oil tank.
7. Connect battery.
8. Fill with fuel and start engine.
9. Check that machine does not move in
neutral.
10. Check:
Forward drive.
Reverse drive.
Operation of blades.
Seat safety switch.
Lif lever safety switch.
The safety switch for the hydrostat pedals.
11. Check the engine speed See theTechnical
data section.
12. Tell customer about:
Needs and benefits of following the service
schedule.
Servicing and the influence of this journal
on the second-hand value of the machine.
Range of applications for BioClip.
Complete proof of sale etc.
Pre-delivery service carried out. No
outstanding problems. Certified:
________________________________________
Date, mileage, stamp, signature
After the first 8 hours
1. Change engine oil.
2. Change the oil in the gearbox.
25-Hour Service
1. Clean the air filter’s pre-cleaner .(Shorter
intervals for dusty operating conditions.)
2. Clean the engine’s cooling air intake and the
transmission’s air intake.
3. Check the mounting bolts on the muffler.
4. Clean the fuel pump’s air filter (for dusty
operating conditions).
50-Hour Service
1. Perform the 25-hour service.
2. Clean the air cleaner’s filter cartridge (paper
filter). (Shorter intervals for dusty operating
conditions.)
3. Check/adjust the cutting height.
4. Check/adjust the parking brake.
5. Inspect the flame proofing/spark arrestor
(extra equipment).
6. Change the engine oil
7. Check the synchronisation between the front
and rear wheels.
8.
Check the V-belts
100/200-Hour Service
1. Perform the 25-hour service.
2. Perform the 50-hour service.
3. Change engine oil.
4. Check whether the engine oil filter needs
changing (every 200 hours). Not Briggs &
Stratton
5. Clean/replace the spark plugs.
6. Change the inline fuel filter.
7. Clean the cooling fins on the engine and the
transmission.
8. Check whether the transmission oil or filter
needs changing (every 200 hours).
9. Replace the air filter’s paper cartridge
(Kawasaki every 200 hours).
10. Check nuts and screws for tightness.
11. Check the fuel hose. Replace if necessary .

English-
16
DELIVERY AND DEALER SERVICE
300-Hour Service
1. Inspect the machine.Come to agreement with
the customer as to what additional work is to
be carried out.
2. Perform the 25-hour service.
3. Perform the 50-hour service.
4. Perform the 100-hour service.
5. Clean the combustion chamber and grind the
valve seats.
6. Check the play in the engine valves.
7. Replace the air filter’s pre-cleaner (foamed
plastic).
At Least Once Each Season
1. Clean the engine’s cooling air intake (25 hours).
2. Replace the air cleaner’s pre-filter (foamed
plastic) (300 hours).
3. Replace the air filter’s paper cartridge
(200 hours).
4. Change the engine oil (100 hours, Briggs &
Stratton 50 hours).
5. Replace the engine oil filter (200 hours). Not
Briggs & Stratton!
6. Adjust the cutting height (50 hours).
7. Adjust the parking brake (50 hours).
8. Inspect the flame proofing/spark arrestor,
extra equipment (50 hours).
9. Clean/replace the spark plugs (100 hours).
10. Change the inline fuel filter (100 hours).
11. Clean the cooling fins (100 hours).
12. Check the play in the engine valves
(300 hours).
13. Change the oil and the oil filter in the
transmission (200 hours).
14. Perform the 300-hour service at an authorised
service representative.
15. Check the fuel hose. Replace if necessary

English-
17
DELIVERY AND DEALER SERVICE
Service Schedule
The following is a list of maintenance procedures
that must be performed on the rider.Most of the
points that are not described in this workshop
manual are found in the operator’s manual.
●
= Described in this workshop manual.
❍
= Not described in this workshop manual or the
operator’s manual.
▼
= Described in the operator’s manual.
Maintenance Page Daily
mainte-
nance
before
Daily
mainte-
nance
after
Weekly
3)
mainte-
nance
Atleast
once a
year
Maintenance interval in
hours
25 50 100 300
Check for fuel and oil leaks –
❍
Check the parking brake 55
●
Checking the Engine Oil Level 23
●
Check the fuel pump’s air filter. –
▼
Check the safety switch, seat 119
●
Check the safety switch, lifting
lever 119
●
Check the safety switch, pedal
system 119
●
Check/clean the engine’s
cooling air intake –
▼
Check the cutting unit: 105
●
• Attaching the blades 108
●
• Condition of the blades
(sharpness, shape, etc.) 112
●
Check the steering cables (any
play, etc.) 52
●
Check fastenings (screws,
nuts, etc.) –
❍
Start the engine and blades,
listen for unusual sounds –
❍
Clean under the cutting unit –
▼
Clean the transmission’s cooling
air intake –
▼
Check the battery’s acid level 22 ●
Check the oil level in the
hydraulic tank 24 ●
Check the condition ofV-belts,
belt pulleys, etc. –❍
Check for damage – ❍
Check the tyre pressures
(60 kPa / 9 PSI) 24 ●
Clean thoroughly around the
engine. –❍
Clean thoroughly around the
transmissions. –❍

English-18
DELIVERY AND DEALER SERVICE
Clean around all belts, belt
pulleys, etc. –▼
Lubricate the belt adjuster
(nipple) –▼
Lubricate all cables – ▼
Lubricate joints in the cutting unit – ▼
Clean inside the frame tunnel – ❍
Lubricate the pedal mechanism
in the frame tunnel –▼
Lubricate the gear controller – ▼
Lubricate the parking brake
cable –▼
Lubricate the throttle. – ▼
Lubricate the choke control. – ▼
Lubricate the guide chain in the
frame tunnel –▼
Check the steering cables in the
frame tunnel 52 ●
Clean the engine’s cooling air
intake. –▼▼
Clean the air filter’s pre-cleaner
(foamed plastic). –▼▼
Change the engine oil1).
Kawasaki. 51 ●●
Change the engine oil1). Briggs
& Stratton. 48 ●●
Clean the air cleaner’s filter
cartridge 2) (paper filter). –▼▼
Check/adjust the cutting height. 106 ●●
Check/adjust the parking brake. 55 ●●
Inspect the flame proofing/spark
arrestor (extra equipment). –❍❍
Replace the engine oil filter
(every 200 hours). –▼▼
Clean/replace the spark plugs. – ▼▼
Change the inline fuel filter. – ▼▼
Clean the cooling fins. – ❍❍
Check the synchronisation
between the front and rear
wheels
70 ●●
Maintenance Page Daily
mainte-
nance
before
Daily
mainte-
nance
after
Weekly 3)
mainte-
nance
Atleast
once a
year
Maintenance interval in
hours
25 50 100 300

English-19
DELIVERY AND DEALER SERVICE
1) First change after 8 hours. When driving with a heavy load or at high ambient temperatures, replace every 50 hours,
Briggs & Stratton every 25 hours 2) In dusty conditions cleaning and replacement should be performed more frequently.
3) With daily use, the rider should be lubricated twice weekly. 4) Performed by an authorised service workshop. 5) First
change after 8 hours.
●= Described in this workshop manual.
❍= Not described in this workshop manual or the operator’s manual.
▼= Described in the operator’s manual.
Check the play in the engine
valves4).-❍❍
Check the fuel hose. Replace if
necessary ❍
Check whether the oil needs to be
changed in the transmission 4, 5)
(every 200 hours).
83 ●●
Change the filter in the
transmission4) (every 200 hours). 84 ●●
Replace the air filter’s pre-
cleaner (foamed plastic)2).-▼▼
Replace the air filter (paper
filter) 2) (every 200 hours). -▼▼
Perform the 300-hour service 4).16 ●●
Maintenance Page Daily
mainte-
nance
before
Daily
mainte-
nance
after
Weekly 3)
mainte-
nance
Atleast
once a
year
Maintenance interval in
hours
25 50 100 300
WARNING!
No service operations may be performed on the engine or cutting unit unless:
•The engine is stopped.
•The parking brake is on.
•The ignition key has been removed.
•The cutting unit is disengaged.
•The ignition cables have been removed from the spark plugs.
!

English-20
DELIVERY AND DEALER SERVICE
Delivery Procedures
To our dealers
A well performed pre delivery service is the first
step towards an active after-sales market.
An active after-sales market benefits everyone:
• The customer will be satisfied with their
machine.They know where to turn in order to
get help if problems arise.
• You gain a regular customer, who
recommends you and your company to other
prospective customers.
• In this way, together we build our brand, and
assume joint responsibility for our products
and our customers.
Be thorough with the paper work.
Fill in the guarantee and delivery documents etc.
and ensure that the customer gets the right
operator’s manual for their machine.
Organise a customer register so that in the future,
you can see which machine the customer owns, as
well as the appropriate serial numbers.The
register is of benefit when you order spare parts
and during future marketing activities.
In conjunction with the delivery, you shall also give
the customer the information required to handle
and maintain their machine in a safe manner.
Remember in particular to inform the customer
about:
• Safety regulations.
• Manoeuvre controls.
• Checking oil levels.Topping up oil and the
type of oil required.
• First oil change after the running in period.
• The need and benefit of following the service
schedule and leaving the machine for regular
service.
• Which fuel is to be used.
• Mowing tips to attain good results.Application
areas for mulching.
• The accessories available for the customer’s
type of machine.
• Guarantee rules.
• Your company and whom the customer should
approach if problems arise.
