Husqvarna 701 Enduro User manual

OWNER'S MANUAL 2021
701 Enduro
Art. no. 3402463en

DEAR HUSQVARNA MOTORCYCLES CUSTOMER
*3402463en*
3402463en
02/2021
DEAR HUSQVARNA MOT ORCYCLES CUSTOMER
Congratulations on your decision to purchase a Husqvarna motorcycle. You are now the owner of a state-of-
the-art sports vehicle which, with appropriate care, will bring you pleasure for a long time to come.
We wish you good and safe riding at all times!
Enter the serial numbers of your vehicle below.
Vehicle identification number ( p. 24) Dealer's stamp
Engine number ( p. 26)
Key number ( p. 26)
The Owner's Manual contained the latest information for this model series at the time of publication. However,
minor differences due to further developments in design cannot be ruled out completely.
All specifications contained herein are non-binding. Husqvarna Motorcycles GmbH specifically reserves the
right to modify or delete technical specifications, prices, colors, forms, materials, services, designs, equipment,
etc., without prior notice and without specifying reasons, to adapt these to local conditions, as well as to stop
production of a particular model without prior notice. Husqvarna Motorcycles accepts no liability for delivery
options, deviations from illustrations and descriptions, as well as misprints and other errors. The models por-
trayed partly contain special equipment that does not belong to the regular scope of supply.

DEAR HUSQVARNA MOTORCYCLES CUSTOMER
2
© 2021 Husqvarna Motorcycles GmbH, Mattighofen Austria
All rights reserved
Reproduction, even in part, as well as copying of all kinds, is permitted only with the express written permission
of the copyright owner.
ISO 9001(12 100 6061)
Husqvarna Motorcycles applies quality assurance processes that lead to the highest possible
product quality as defined in the ISO 9001 international quality management standard.
Issued by: TÜV-Management Service
Husqvarna Motorcycles GmbH
Stallhofnerstraße 3
5230 Mattighofen, Austria
This document is valid for the following models:
701 ENDURO EU (F2603U1)

TABLE OF CONTENTS
3
TABLE OF CONTENTS
1 MEANS OF REPRESENTATION........................ 9
1.1 Symbols used ....................................... 9
1.2 Formats used...................................... 10
2 SAFETY ADVICE ............................................. 11
2.1 Use definition –intended use ............. 11
2.2 Misuse................................................. 11
2.3 Safety advice ...................................... 11
2.4 Degrees of risk and symbols .............. 12
2.5 Tampering warning ............................. 13
2.6 Safe operation..................................... 14
2.7 Protective clothing.............................. 15
2.8 Work rules........................................... 15
2.9 Environment........................................ 16
2.10 Owner's Manual.................................. 16
3 IMPORTANT NOTES....................................... 18
3.1 Manufacturer warranty, implied
warranty .............................................. 18
3.2 Fuel, auxiliary substances................... 18
3.3 Spare parts, accessories .................... 18
3.4 Service ................................................ 19
3.5 Figures ................................................ 19
3.6 Customer service................................ 19
4 VIEW OF VEHICLE .......................................... 20
4.1 View of vehicle, front left (example) .... 20
4.2 View of vehicle, rear right
(example)............................................. 22
5 SERIAL NUMBERS.......................................... 24
5.1 Vehicle identification number.............. 24
5.2 Type label............................................ 25
5.3 Key number......................................... 26
5.4 Engine number.................................... 26
5.5 Fork part number ................................ 27
5.6 Shock absorber article number .......... 27
6 CONTROLS ..................................................... 28
6.1 Clutch lever......................................... 28
6.2 Hand brake lever................................. 28
6.3 Throttle grip......................................... 29
6.4 Horn button......................................... 29
6.5 Light switch......................................... 30
6.6 Turn signal switch............................... 30
6.7 Emergency OFF switch....................... 31
6.8 Start button......................................... 32
6.9 ABS button ......................................... 32
6.10 Combination switch ............................ 33

TABLE OF CONTENTS
4
6.11 Ignition and steering lock.................... 35
6.12 Overview of indicator lights ................ 36
6.13 Seat release ........................................ 38
6.14 Grab handles ...................................... 38
6.15 Passenger foot pegs........................... 39
6.16 Shift lever ............................................ 39
6.17 Foot brake lever.................................. 40
6.18 Side stand........................................... 41
6.19 Opening fuel tank filler cap................. 42
6.20 Closing the fuel tank filler cap............. 44
7 DASH............................................................... 45
7.1 Overview ............................................. 45
7.2 Activation and test.............................. 45
7.3 Setting the combination instrument.... 46
7.4 Setting kilometers or miles ................. 47
7.5 Setting the clock................................. 48
7.6 Setting the service interval.................. 49
7.7 Distance 1........................................... 50
7.8 Distance 2........................................... 51
7.9 Average speed 1................................. 52
7.10 Average speed 2................................. 52
7.11 Riding time 1....................................... 53
7.12 Riding time 2....................................... 54
7.13 Service hour counter........................... 54
7.14 Clock................................................... 55
7.15 Service interval display ....................... 55
7.16 Tachometer......................................... 56
7.17 odometer............................................. 57
7.18 Gear display........................................ 58
7.19 Service display.................................... 58
7.20 Distance fuel reserve .......................... 59
8 PREPARING FOR USE.................................... 60
8.1 Advice on preparing for first use......... 60
8.2 Running in the engine ......................... 62
8.3 Loading the vehicle............................. 63
9 RIDING INSTRUCTIONS ................................. 66
9.1 Checks and maintenance measures
when preparing for use....................... 66
9.2 Starting the vehicle ............................. 67
9.3 Starting off .......................................... 70
9.4 Shifting, riding..................................... 70
9.5 Easy Shift............................................ 76
9.6 Motorcycle traction control................. 77
9.7 Braking................................................ 78
9.8 Stopping, parking ............................... 80
9.9 Transport............................................. 82
9.10 Refueling............................................. 83

TABLE OF CONTENTS
5
10 SERVICE SCHEDULE...................................... 86
10.1 Additional information......................... 86
10.2 Required work..................................... 86
10.3 Recommended work........................... 89
11 TUNING THE CHASSIS................................... 90
11.1 Fork/shock absorber........................... 90
11.2 Adjusting the compression damping
of the fork............................................ 90
11.3 Adjusting the rebound damping of
the fork................................................ 92
11.4 Compression damping of the shock
absorber.............................................. 93
11.5 Adjusting the low-speed
compression damping of the shock
absorber.............................................. 94
11.6 Adjusting the high-speed
compression damping of the shock
absorber.............................................. 95
11.7 Adjusting the rebound damping of
the shock absorber............................. 97
11.8 Handlebar position.............................. 98
11.9 Adjusting the handlebar position .... 99
12 SERVICE WORK ON THE CHASSIS ............. 102
12.1 Raising the motorcycle with a lift
stand ................................................. 102
12.2 Removing the motorcycle from the
lift stand ............................................ 102
12.3 Raising the motorcycle with rear
lifting gear ......................................... 103
12.4 Removing the rear of the
motorcycle from the lifting gear........ 104
12.5 Cleaning the dust boots of the fork
legs ................................................... 105
12.6 Removing the fork protector............. 107
12.7 Installing the fork protector............... 107
12.8 Bleeding the fork legs....................... 108
12.9 Removing the seat............................ 109
12.10 Mounting the seat............................. 109
12.11 Removing the tool set....................... 110
12.12 Storing tool set.................................. 111
12.13 Take off the side cover ..................... 112
12.14 Mounting the side cover ................... 113
12.15 Removing front fender ...................... 113
12.16 Installing front fender ........................ 114
12.17 Removing the air filter ................... 115
12.18 Installing the air filter ..................... 116

TABLE OF CONTENTS
6
12.19 Checking the chain for dirt................ 117
12.20 Cleaning the chain ............................ 118
12.21 Checking the chain tension .............. 119
12.22 Adjusting the chain tension............... 121
12.23 Checking the chain, rear sprocket,
engine sprocket, and chain guide..... 123
12.24 Adjusting the chain guide ............. 128
12.25 Adjusting the basic position of the
clutch lever........................................ 129
12.26 Checking/correcting the fluid level
of the hydraulic clutch ...................... 130
12.27 Removing engine guard.................... 132
12.28 Installing the engine guard................ 133
13 BRAKE SYSTEM ........................................... 134
13.1 Anti-lock braking system (ABS) ........ 134
13.2 Adjusting the basic position of the
hand brake lever ............................... 137
13.3 Checking the brake discs ................. 138
13.4 Checking the front brake fluid
level................................................... 139
13.5 Adding front brake fluid ................ 140
13.6 Checking the front brake linings....... 143
13.7 Changing the brake linings of the
front brake ..................................... 144
13.8 Checking the free travel of foot
brake lever ........................................ 149
13.9 Adjusting the basic position of the
foot brake lever ............................. 150
13.10 Checking the rear brake fluid level ... 152
13.11 Adding rear brake fluid .................. 153
13.12 Checking the rear brake linings ........ 155
13.13 Changing the rear brake linings .... 156
14 WHEELS, TIRES............................................ 161
14.1 Removing the front wheel ............. 161
14.2 Installing the front wheel ............... 163
14.3 Removing the rear wheel .............. 165
14.4 Installing the rear wheel ................ 166
14.5 Checking the rear hub damping
rubber pieces ................................ 169
14.6 Checking the tire condition............... 172
14.7 Checking tire pressure...................... 174
14.8 Checking spoke tension ................... 176
14.9 Using tire repair spray....................... 178
15 ELECTRICAL SYSTEM.................................. 179
15.1 Removing the 12-V battery ........... 179
15.2 Installing the 12-V battery ............. 181
15.3 Charging the 12-V battery ............. 183

TABLE OF CONTENTS
7
15.4 Changing the main fuse.................... 185
15.5 Changing the ABS fuses................... 188
15.6 Changing the fuses of individual
electrical power consumers.............. 190
15.7 Removing the headlight mask with
the headlight ..................................... 193
15.8 Installing the headlight mask with
the headlight ..................................... 194
15.9 Changing the headlight bulb............. 195
15.10 Changing the position light lamp...... 197
15.11 Checking the headlight setting ......... 198
15.12 Adjusting the headlight range........... 199
15.13 ACC1 and ACC2............................... 200
15.14 Diagnostics connector...................... 200
16 COOLING SYSTEM....................................... 201
16.1 Cooling system ................................. 201
16.2 Checking the antifreeze and
coolant level...................................... 202
16.3 Checking the coolant level................ 204
16.4 Draining the coolant ...................... 206
16.5 Filling/bleeding the cooling
system ........................................... 208
16.6 Changing the coolant .................... 210
17 TUNING THE ENGINE................................... 214
17.1 Changing the riding mode ................ 214
17.2 Adjusting traction control.................. 215
17.3 Checking the basic position of the
shift lever........................................... 216
17.4 Adjusting the basic position of the
shift lever ....................................... 217
18 SERVICE WORK ON THE ENGINE ............... 218
18.1 Changing the fuel screen .............. 218
18.2 Checking the engine oil level ............ 220
18.3 Changing the engine oil and oil
filter, cleaning the oil screens ....... 221
18.4 Adding engine oil .............................. 229
19 CLEANING, CARE......................................... 232
19.1 Cleaning the motorcycle................... 232
19.2 Checks and maintenance steps for
winter operation................................ 235
20 STORAGE...................................................... 237
20.1 Storage ............................................. 237
20.2 Preparing for use after storage......... 239
21 TROUBLESHOOTING ................................... 240

TABLE OF CONTENTS
8
22 TECHNICAL DATA ........................................ 244
22.1 Engine ............................................... 244
22.2 Engine tightening torques................. 246
22.3 Capacities ......................................... 252
22.3.1 Engine oil...................................... 252
22.3.2 Coolant......................................... 252
22.3.3 Fuel............................................... 252
22.4 Chassis ............................................. 253
22.5 Electrical system............................... 254
22.6 Tires .................................................. 255
22.7 Fork................................................... 256
22.8 Shock absorber ................................ 257
22.9 Chassis tightening torques ............... 258
23 SUBSTANCES............................................... 266
24 AUXILIARY SUBSTANCES............................ 269
25 STANDARDS ................................................. 272
26 INDEX OF SPECIAL TERMS ......................... 273
27 LIST OF ABBREVIATIONS ............................ 274
28 LIST OF SYMBOLS ....................................... 275
28.1 Red symbols ..................................... 275
28.2 Yellow and orange symbols.............. 275
28.3 Green and blue symbols................... 276
INDEX .................................................................... 277

MEANS OF REPRESENTATION 1
9
1.1 Symbols used
The meaning of specific symbols is described below.
Indicates an expected reaction (e.g. of a work step or a function).
Indicates an unexpected reaction (e.g. of a work step or a function).
All work marked with this symbol requires specialist knowledge and technical understanding.
In the interests of your own safety, have these jobs performed by an authorized Husqvarna
Motorcycles workshop. There, your motorcycle will be optimally cared for by specially trained
experts using the specialist tools required.
Indicates a page reference (more information is provided on the specified page).
Indicates information with more details or tips.
Indicates the result of a testing step.

1 MEANS OF REPRESENTATION
10
Indicates a voltage measurement.
Indicates a current measurement.
Indicates the end of an activity, including potential rework.
1.2 Formats used
The typographical formats used in this document are explained below.
Proprietary name Indicates a proprietary name.
Name®Indicates a protected name.
Brand™ Indicates a brand available on the open market.
Underlined terms Refer to technical details of the vehicle or indicate technical terms, which
are explained in the glossary.

SAFETY ADVICE 2
11
2.1 Use definition –intended use
The vehicle is designed and constructed to withstand the usual demands of regular traffic and use on gentle
terrain (unpaved roads).
This vehicle is not suitable for use on race tracks.
Info
This vehicle is only authorized for operation on public roads in its homologated version.
When used in a dusty environment, it may be necessary to use air filter protection. Your authorized
Husqvarna Motorcycles dealer will be glad to advise you.
2.2 Misuse
The vehicle must only be used as intended.
Dangers can arise for people, property and the environment through use not as intended.
Any use of the vehicle beyond the intended and defined use constitutes misuse.
Misuse also includes the use of operating and auxiliary fluids which do not meet the required specification for
the respective use.
2.3 Safety advice
A number of safety instructions need to be followed to operate the product described safely. Therefore read
this instruction and all further instructions included carefully. The safety instructions are highlighted in the text
and are referred to at the relevant passages.

2 SAFETY ADVICE
12
Info
Various information and warning labels are attached in prominent locations on the product described.
Do not remove any information or warning labels. If they are missing, you or others may not recognize
dangers and may therefore be injured.
2.4 Degrees of risk and symbols
Danger
Identifies a danger that will immediately and invariably lead to fatal or serious permanent injury if the
appropriate measures are not taken.
Warning
Identifies a danger that is likely to lead to fatal or serious injury if the appropriate measures are not
taken.
Caution
Identifies a danger that may lead to minor injuries if the appropriate measures are not taken.
Note
Identifies a danger that will lead to considerable machine and material damage if the appropriate measures are
not taken.
Note
Indicates a danger that will lead to environmental damage if the appropriate measures are not taken.

SAFETY ADVICE 2
13
2.5 Tampering warning
Tampering with the noise control system is prohibited. Federal law prohibits the following acts or the causing
thereof:
1 The removal or rendering inoperative by any person other than for purposes of servicing, repair, or replace-
ment, of any device or element of design incorporated into any new vehicle for the purpose of noise control
prior to its sale or delivery to the ultimate purchaser or while it is in use, or
2 the use of the vehicle after such device or element of design has been removed or rendered inoperative by
any person.
Among those acts presumed to constitute tampering are the acts listed below:
1 Removal or puncturing of the main silencers, baffles, header pipes or any other components which conduct
exhaust gases.
2 Removal or puncturing of parts of the intake system.
3 Lack of proper maintenance.
4 Replacing moving parts of the vehicle, or parts of the exhaust system or intake system, with parts other
than those specified by the manufacturer.

2 SAFETY ADVICE
14
2.6 Safe operation
Danger
Danger of accidents A rider who is not fit to ride poses a danger to him or herself and others.
–Do not operate the vehicle if you are not fit to ride due to alcohol, drugs or medication.
–Do not operate the vehicle if you are physically or mentally impaired.
Danger
Danger of poisoning Exhaust gases are toxic and inhaling them may result in unconsciousness and
death.
–Always make sure there is sufficient ventilation when running the engine.
–Use effective exhaust extraction when starting or running the engine in an enclosed space.
Warning
Danger of burns Some vehicle components become very hot when the vehicle is operated.
–Do not touch any parts such as the exhaust system, radiator, engine, shock absorber, or brake sys-
tem before the vehicle parts have cooled down.
–Let the vehicle parts cool down before you perform any work on the vehicle.
Only operate the vehicle when it is in perfect technical condition, in accordance with its intended use, and in a
safe and environmentally compatible manner.
An appropriate driver's license is needed to ride the vehicle on public roads.
Have malfunctions that impair safety promptly eliminated by an authorized Husqvarna Motorcycles workshop.
Adhere to the information and warning labels on the vehicle.

SAFETY ADVICE 2
15
2.7 Protective clothing
Warning
Risk of injury Missing or poor protective clothing presents an increased safety risk.
–Wear appropriate protective clothing such as helmet, boots, gloves as well as trousers and a jacket
with protectors on all rides.
–Always wear protective clothing that is in good condition and meets the legal regulations.
In the interest of your own safety, Husqvarna Motorcycles recommends that you only operate the vehicle while
wearing protective clothing.
2.8 Work rules
Unless specified otherwise, the ignition must be turned off during all work (models with ignition lock, models
with remote key) or the engine must be at a standstill (models without ignition lock or remote key).
Special tools are necessary for certain tasks. The tools are not a component of the vehicle, but can be ordered
using the number in parentheses. Example: bearing puller (15112017000)
During assembly, use new parts to replace parts which cannot be reused (e.g. self-locking screws and nuts,
expansion screws, seals, sealing rings, O-rings, pins, and lock washers).
In the case of certain screws, a screw adhesive (e.g. Loctite®) is required. Observe the manufacturer's instruc-
tions.
If thread locker (e.g., Precote®) has already been applied to a new part, do not apply any additional thread
locker.
After disassembly, clean the parts that are to be reused and check them for damage and wear. Change dam-
aged or worn parts.
After completing a repair or service work, check the operating safety of the vehicle.

2 SAFETY ADVICE
16
2.9 Environment
If you use your motorcycle responsibly, you can ensure that problems and conflicts do not occur. To protect
the future of the motorcycle sport, make sure that you use your motorcycle legally, display environmental con-
sciousness, and respect the rights of others.
When disposing of used oil, other operating and auxiliary fluids, and used components, comply with the laws
and regulations of the respective country.
Because motorcycles are not subject to the EU regulations governing the disposal of used vehicles, there are
no legal regulations that pertain to the disposal of an end-of-life motorcycle. Your authorized Husqvarna Motor-
cycles dealer will be glad to advise you.
2.10 Owner's Manual
It is important that you read this Owner's Manual carefully and completely before making your first trip. The
Owner's Manual contains useful information and many tips on how to operate, handle, and service your motor-
cycle. This is the only way to find out how best to customize the vehicle for your own use and how you can
protect yourself from injury.
Info
Store the Owner's Manual on your terminal device, for example, so that you can read it whenever you
need to.
If you would like to know more about the vehicle or have questions on the material you read, please contact an
authorized Husqvarna Motorcycles dealer.
The Owner's Manual is an important component of the vehicle. If the vehicle is sold, the Owner's Manual must
be downloaded again by the new owner.
The Owner's Manual can be downloaded several times using the QR code or the link on the delivery certificate.

SAFETY ADVICE 2
17
The Owner's Manual is also available for download from your authorized Husqvarna Motorcycles dealer
and on the Husqvarna Motorcycles website. A printed copy can also be ordered from your authorized
Husqvarna Motorcycles dealer.
International Husqvarna Motorcycles website: www.husqvarna-motorcycles.com

3 IMPORTANT NOTES
18
3.1 Manufacturer warranty, implied warranty
The work prescribed in the service schedule must only be carried out in an authorized Husqvarna Motorcy-
cles workshop and confirmed in the Husqvarna Motorcycles Dealer.net, as otherwise all warranty claims will
be void. Damage or secondary damage caused by tampering with and/or conversions on the vehicle are not
covered by the manufacturer warranty.
3.2 Fuel, auxiliary substances
Note
Environmental hazard Improper handling of fuel is a danger to the environment.
–Do not allow fuel to enter the groundwater, the soil, or the sewage system.
Use fuels and auxiliary substances in accordance with the Owner's Manual and specification.
3.3 Spare parts, accessories
For your own safety, only use spare parts and accessory products that are approved and/or recommended by
Husqvarna Motorcycles and have them installed by an authorized Husqvarna Motorcycles workshop. Husq-
varna Motorcycles accepts no liability for other products and any resulting damage or loss.
Certain spare parts and accessory products are specified in parentheses in the descriptions. Your authorized
Husqvarna Motorcycles dealer will be glad to advise you.
The current Husqvarna Motorcycles technical accessories for your vehicle can be found on the
Husqvarna Motorcycles website.
International Husqvarna Motorcycles website: www.husqvarna-motorcycles.com
