Husqvarna ST 324P Owner's manual

English
586 83 26-27 Rev. 1
Repair Parts Manual
ST 324P
Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine.
The use of any gasoline exceeding 10% ethanol (E10) will void the product warranty.
Please read the owner's manual carefully and make sure you
understand the instructions before using the machine.

2
HOW TO USE THIS MANUAL
This manual is designed to provide the customer with a means to identify the parts on his/her snow
thrower when ordering repair parts. The illustrations may or may not represent the actual assemblies;
therefore, it is not recommended to use this manual as a guide to assemble or disassemble the snow
thrower. Some hardware and parts are drawn larger in order to more readily identify them.
Each snow thrower has its own model number.
The model and serial numbers will be found on a decal attached to the rear of the snow thrower housing.
When ordering parts, always give the following information:
• Product - “SNOW THROWER”
• MODEL NUMBER - “ST 324P" (96193009101)”
• Part Number
• Part Description
TABLE OF CONTENTS
AUGER HOUSING / IMPELLER ASSEMBLY ..........................................................3-7
CONTROL PANEL / DISCHARGE CHUTE............................................................8-11
HANDLES .............................................................................................................12-14
DRIVE....................................................................................................................15-17
CHASSIS / ENGINE / PULLEYS ..........................................................................18-19
WHEELS .................................................................................................................... 20
BAG OF PARTS....................................................................................................21-22
DECALS................................................................................................................23-24
ENGINE BREAKDOWN........................................................................................26-27
WARRANTY..........................................................................................................28-31

3
REPAIR PARTS AUGER HOUSING / IMPELLER ASSEMBLY
SNOW THROWER - MODEL NO.
ST 324P
ST 324P (96193009101), PRODUCT NO. 961 93 00-91
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
05.09.015-B
1
2
3
4
5X
5X
1 581 97 67-02 AUGER HOUSING 24 LS
2 585 04 83-02 SHAVE PLATE 24 LS MS428
3 872 27 05-05 BOLT CARRIAGE 5/16-18 X .625
4 532 15 53-77 NUT 5/16-18 HEX TOP LOCK
05.09.018-D
2
1
3
4
56
3
4
5
6
1 581 97 01-03 AUGER RIBBON 24 RH LS
2 581 97 02-03 AUGER RIBBON 24 LH LS
3 580 85 55-01 SUPPORT AUGER BEARING
4 532 11 04-85 BEARING IDLER 6203
5 812 00 00-28 RING RETAINING #5100-52
6 585 51 78-01 SCREW 1/4-20 X .65 W/DOG
POINT

4
REPAIR PARTS AUGER HOUSING / IMPELLER ASSEMBLY
SNOW THROWER - MODEL NO.
ST 324P
ST 324P (96193009101), PRODUCT NO. 961 93 00-91
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
10
10
11
1
2
3
4
5
6
7
7
7
9
8
8
8
12
13
13
14 14
15
15
15
16
05.09.021-D

5
REPAIR PARTS AUGER HOUSING / IMPELLER ASSEMBLY
SNOW THROWER - MODEL NO.
ST 324P
ST 324P (96193009101), PRODUCT NO. 961 93 00-91
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
1 586 71 50-01 GEARBOX AUGER CAST IRON 5/8 THREAD
2 585 19 83-03 IMPELLER CAST IRON
3 586 71 54-01 PULLEY IMPELLER 7.9 SCREW ON
4 585 10 90-04 SUPPORT GEARBOX – GREY
5 585 05 69-01 CHUTE DISCHARGE BASE
6 532 18 40-95 BRACKET CORNER DISCHARGE BASE
7 585 51 18-01 BOLT SHEAR 1/4-20
8 873 80 04-00 NUT NYLOCK 1/4-20
9 872 11 05-10 BOLT CARRIAGE 5/16-18 X 1-1/4
10 585 69 13-01 NUT FLANGE NYLOCK 5/16-18 – BLK
11 532 75 11-53 NUT FLANGE TOP LOCK 5/16-18
12 585 83 20-01 BOLT CARRIAGE 5/16-18 X 5/8 – BLK
13 532 16 31-83 SCREW HEX HEAD 5/16-18 X 5/8
14 585 69 12-01 BOLT CARRIAGE WAFER HEAD 5/16-18 X 5/8 – BLK
15 532 42 79-42 NUT FLANGE NYLOCK 5/16-18
16 532 18 89-09 BEARING FLANGE

6
REPAIR PARTS AUGER HOUSING / IMPELLER ASSEMBLY
SNOW THROWER - MODEL NO.
ST 324P
ST 324P (96193009101), PRODUCT NO. 961 93 00-91
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
05.09.040-A
1
2
3
4
5
55
5
1 532 19 21-99 TOOL CLEANOUT
2 586 41 48-01 TRIM AUGER HOUSING
FRONT ASM
3 586 33 03-02 TRIM AUGER HOUSING
WING RH
4 586 33 04-02 TRIM AUGER HOUSING
WING LH
5 817 67 04-12 SCREW HEX WASHER
TRI-LOBE 1/4-20 X 3/4
05.12.003-A
1
2
3
1
3
1 532 40 78-34 SKID PLATE
2 585 69 17-01 BOLT CARRIAGE
5/16-18 X .750 – BLK
3 585 69 13-01 NUT FLANGE NYLOCK
5/16-18 – BLK

7
REPAIR PARTS AUGER HOUSING / IMPELLER ASSEMBLY
SNOW THROWER - MODEL NO.
ST 324P
ST 324P (96193009101), PRODUCT NO. 961 93 00-91
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
KEY PART
NO. NO. DESCRIPTION
05.13.001-A
1
1
2
2
2
2
3
3
3
3
5
5
55
4
4
4
4
1 532 18 47-47 DRIFT BAR CUTTER
2 532 17 92-46 WASHER FRICTION NYLON
3 872 27 05-06 CARRIAGE BOLT
5/16-18 X .75 GR5
4 810 04 05-00 LOCKWASHER 5/16 SPLIT
5 532 12 86-38 WING NUT 5/16-18 ZINC

8
REPAIR PARTS CONTROL PANEL / DISCHARGE CHUTE
SNOW THROWER - MODEL NO.
ST 324P
ST 324P (96193009101), PRODUCT NO. 961 93 00-91
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
KEY PART
NO. NO. DESCRIPTION
10
10
10
10
11
11
11
11
1
2
3
4
56
7
9
9
8
12
12
12
12
13
01.08.022-B
1 585 19 88-02 CONTROL PANEL
2 581 77 98-01 LH CONTROL LEVER
3 581 77 97-01 RH CONTROL LEVER
4 584 80 90-01 INTERLOCK CONTROL ROD
5 585 00 47-03 INTERLOCK BRACKET
6 874 78 04-10 1/4-20 X .625 HEX HEAD SCREW
7 532 42 16-13 SPACER
8 532 08 83-49 1/4-20 FLANGE NUT (TOP LOCK)
9 580 67 32-01 KNOB SOFT TOUCH
10 532 17 88-99 HANDLE KNOB
11 819 13 13-16 3/8 WASHER
12 872 12 06-18 CARRIAGE BOLT 3/8-16 X 2.25
13 532 16 96-75 RETAINER

9
REPAIR PARTS CONTROL PANEL / DISCHARGE CHUTE
SNOW THROWER - MODEL NO.
ST 324P
ST 324P (96193009101), PRODUCT NO. 961 93 00-91
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
KEY PART
NO. NO. DESCRIPTION
01.09.029-D
*10
*11
1
2
3
4
5
6
6
6
7
9
8
*12
*13
*14
15
16
1 532 44 40-41 CHUTE WELDMENT
2 532 18 41-13 DEFLECTOR WELDMENT
3 587 03 08-01 DEFLECTOR CONTROL ASSEMBLY
4 532 42 03-25 DEFLECTOR SEAL
5 580 67 32-01 KNOB OVERMOLD BLACK
6 532 12 84-15 POP RIVET
7 817 54 10-08 THREAD ROLLING SCREW 10-24 X .500
8 532 43 03-24 CHUTE SNOW SHIELD
9 532 42 17-28 SHIELD RETAINER STRAP
*10 532 17 98-29 SHOULDER BOLT 1/4-20 X .375
*11 532 19 17-30 NUT 1/4-20
*12 585 83 20-01 CARRIAGE BOLT BLACK 5/16-18 X 5/8
*13 532 75 11-53 NUT 5/16-18
*14 532 18 45-05 DEFLECTOR SPRING
15 585 27 16-01 (SERVICE PART) DEFLECTOR CONTROL
16 587 03 09-01 (SERVICE PART) DEFLECTOR CABLE BLACK
NOTE:
1. ALL ITEMS INDICATED WITH AN * ARE PROVIDED IN THE BAG OF ITEMS SHIPPED LOOSE WITH PRODUCT.
2. ITEMS 15 AND 16 ARE SERVICE PART NUMBERS TO ALLOW PURCHASE OF INDIVIDUAL ITEMS IF NECESSARY.

10
KEY PART
NO. NO. DESCRIPTION
REPAIR PARTS CONTROL PANEL / DISCHARGE CHUTE
SNOW THROWER - MODEL NO.
ST 324P
ST 324P (96193009101), PRODUCT NO. 961 93 00-91
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
1
23
4
2
3
4
05.11.009-B
1 532 42 11-38 SHIELD DEFLECTOR
2 532 42 32-47 STRAP
3 586 11 80-01 SCREW MACHINE 8-32 X .50
BLK
4 586 11 81-01 NUT HEX NYLOCK 8-32 - BLK

11
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
REPAIR PARTS CONTROL PANEL / DISCHARGE CHUTE
SNOW THROWER - MODEL NO.
ST 324P
ST 324P (96193009101), PRODUCT NO. 961 93 00-91
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
1
2
01.15.013-B
1 532 42 57-99 STEER CABLE
2 874 04 10-24 SCREW 10−24 X 1.50
1
2
2
*3
*4 *5
*6
*7
01.09.010-D
1 532 42 82-72 LEVER/CABLE ROTATOR ASSEMBLY
2 817 54 10-08 THREAD ROLLING SCREW 10-24 X .500
*3 532 42 06-78 ROTATOR HEAD
*4 585 19 92-01 ROTATOR PIVOT BRACKET
*5 532 42 06-75 PULLEY PIVOT
*6 532 42 82-73 CABLE ASSEMBLY ADJUSTABLE
*7 532 42 83-10 CABLE ASSEMBLY HEAT SHIELD
NOTES:
1. ITEMS INDICATED WITH AN * ARE LISTED AS REFERENCE FOR SERVICE PARTS ONLY.

12
REPAIR PARTS HANDLES
SNOW THROWER - MODEL NO.
ST 324P
ST 324P (96193009101), PRODUCT NO. 961 93 00-91
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
1
2
3
3
4
4
5
5
5
5
01.05.017-A
1 585 23 81-03 LOWER HANDLE
2 532 44 36-17 PIVOT SUPPORT WELDMENT
3 817 00 05-10 SCREW 5/16-18 X .750
4 817 00 06-16 SCREW 3/8-16 X 1.00
5 817 00 06-12 SCREW 3/8-16 X .750
10
10
1
23
4
5
5
6
6
7
7
9
9
8
8
8
01.08.011-C
1 532 42 17-08 PLOW HANDLE LH
2 532 42 17-09 PLOW HANDLE RH
3 532 42 91-48 PANEL BRACKET LH
4 532 42 91-49 PANEL BRACKET RH
5 532 41 45-15 HEATED HANDLE GRIP
6 874 78 05-12 SCREW 5/16−18 X .750
7 874 78 05-24 SCREW 5/16−18 X 1.50
8 532 75 11-53 NUT 5/16−18
9 532 15 54-15 WASHER
10 532 17 87-75 POP RIVET 1/8

13
REPAIR PARTS HANDLES
SNOW THROWER - MODEL NO.
ST 324P
ST 324P (96193009101), PRODUCT NO. 961 93 00-91
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
1
2
3
4
5
601.08.007-D
1 532 41 62-88 INTERLOCK SPRING
2 532 44 52-91 INTERLOCK CAM
3 532 44 32-15 TORSION SPRING
4 532 16 96-75 RETAINER
5 817 06 04-10 SCREW 1/4−20 X .625
6 532 42 18-14 INTERLOCK STOP
12
3
4
4
5
6
01.10.057-A
1 532 42 13-51 CONSOLE PANEL
2 532 41 77-60 SWITCH GRIP
3 532 17 52-62 SCREW HX WHSR HEAD
10-24 X 1.25
4 532 18 44-71 SCREW SHOULDER
10-24 X .62
5 581 68 42-01 LED LIGHT DUAL STAGE GRAY
6 580 62 56-01 WIRE HARNESS FLOOD / LED
HEATED

14
REPAIR PARTS HANDLES
SNOW THROWER - MODEL NO.
ST 324P
ST 324P (96193009101), PRODUCT NO. 961 93 00-91
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
1
2
3
4
5
6
5
7
8
9
10
01.12.014-C
1 584 80 87-01 ROD IMPELLER CONTROL
2 584 80 88-01 ROD TRACTION CONTROL
3 532 42 55-98 SHIFTER ROD TOP
4 532 18 77-84 SHIFTER ROD BOTTOM
5 532 18 04-47 SPRING SLEEVE
6 580 79 62-01 SPRING CONTROL ROD
7 580 80 21-01 SPRING TRACTION ROD
8 872 27 05-05 CARRIAGE BOLT 5/16-18 X .75
9 532 15 53-77 NUT 5/16-18
10 532 16 96-75 RETAINER HAIRPIN
NOTE: HOOK TRACTION ROD SPRING IN HOLE 9
HOOK IMPELLER ROD SPRING IN HOLE 4

15
REPAIR PARTS DRIVE
SNOW THROWER - MODEL NO.
ST 324P
ST 324P (96193009101), PRODUCT NO. 961 93 00-91
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
1
1
2
2
3
3
01.03.010-C
1 532 17 12-71 RIVET
2 532 12 49-31 THRUST WASHER
3 532 12 47-88 RETAINER

16
REPAIR PARTS DRIVE
SNOW THROWER - MODEL NO.
ST 324P
ST 324P (96193009101), PRODUCT NO. 961 93 00-91
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
10
10
10
10
10
10
10
11
1
1
2
2
3
4
4
5
67
9
9
8
12
12
13
14 15
16
16
17 18
19
20
21
21
22
22 23
23
23
23
24
24
25
26
27
27
28
28
29
29
30
30
31
32
33
34
35
35
36
37
38
39
40
41
41
42
42
42
42
43
43 43
44
45
01.02.009-G
8

17
REPAIR PARTS DRIVE
SNOW THROWER - MODEL NO.
ST 324P
ST 324P (96193009101), PRODUCT NO. 961 93 00-91
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
KEY PART
NO. NO. DESCRIPTION KEY PART NO. NO. DESCRIPTION
1 532 44 33-44 SHIFT BRACKET
2 817 54 10-08 THREAD ROLLING SCREW
10-24 X .500
3 874 76 05-52 SCREW 5/16-18 X 3.25
4 532 17 92-46 PLASTIC WASHER
5 532 42 55-96 SHIFT ASSEMBLY
6 532 15 54-15 WASHER
7 532 19 21-95 FRICTION SPRING
8 873 80 05-00 NUT 5/16-18 LOCK
9 532 44 33-47 CABLE MOUNTING
BRACKET RH
10 532 42 88-67 SCREW 5/16-18 X .750
11 532 40 54-85 CONTROL ARM
12 532 19 85-80 CLEVIS PIN
13 532 43 71-51 REAR PLATE
14 532 05 70-79 WASHER
15 532 42 75-42 CONTROL SHAFT
16 532 44 33-50 STEER LEVER
17 532 44 33-49 PIVOT PLATE
18 532 44 33-48 REAR CLUTCH BRACKET
19 532 19 82-49 CLUTCH ARM
20 532 42 82-88 E-RING .375
21 532 40 28-81 SHOULDER BOLT 1/4-20
22 532 19 17-30 NUT 1/4-20 SIDELOCK
23 532 06 53-22 HAIRPIN RETAINER SMALL
24 532 42 54-96 STEER ROD
25 532 19 41-24 RETURN SPRING
26 532 44 33-46 STABILIZER BRACKET
27 532 44 33-45 TRANSMISISON MOUNTING
BRACKET
28 874 88 04-32 SCREW 1/4-20 X 2.00
29 874 76 05-16 BOLT 5/16-18 X 1.00
30 532 75 11-53 NUT 5/16-18 TOP LOCK
31 532 19 82-51 CLUTCH SHAFT
32 532 44 62-93 CLUTCH ROD
33 532 70 02-79 RETAINER CLIP
34 532 42 54-99 SPEED CONTROL ROD
35 532 16 96-75 HAIRPIN RETAINER LARGE
36 532 42 98-03 FRONT CLUTCH BRACKET
37 532 18 03-55 CARRIAGE BOLT 5/16-18 X .625
38 532 42 53-94 HYDROSTATIC TRANSMISSION
39 532 17 88-28 BRAKE SPRING
40 532 42 54-98 BOTTOM PAN
41 532 18 44-71 SHOULDER SCREW 10-24
42 532 05 38-47 WASHER
43 873 80 04-00 NUT 1/4-20 NYLOCK
44 532 40 65-58 RETURN SPRING
45 584 99 45-01 BELT GUIDE HYDRO 2

18
REPAIR PARTS CHASSIS / ENGINE / PULLEYS
SNOW THROWER - MODEL NO.
ST 324P
ST 324P (96193009101), PRODUCT NO. 961 93 00-91
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
1
2
2
3
3
01.00.036-A
- - 585 33 57-03 COMPLETE LCT ENGINE
PW2HK18750178E
1 586 50 78-03 FRAME
2 532 15 04-06 BOLT 3/8-16
3 532 42 88-67 SCREW 5/16-18 X .750
1
01.01.004-A
1 532 42 92-69 ENGINE MOUNTING PLATE
1
01.21.013-C
1 532 44 30-30 COVER ASSEMBLY

19
REPAIR PARTS CHASSIS / ENGINE / PULLEYS
SNOW THROWER - MODEL NO.
ST 324P
ST 324P (96193009101), PRODUCT NO. 961 93 00-91
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
KEY PART
NO. NO. DESCRIPTION KEY PART NO. NO. DESCRIPTION
10
11
1
2
3
4
56
7
9
8
12
13
14
15
16
17
18
18
19
20
20
21
22
23
01.21.023-M
1 532 40 80-07 IMPELLER BELT
2 532 44 81-83 TRACTION BELT
3 584 23 24-02 IDLER ARM BRACKET
4 532 18 05-23 IDLER PULLEY
5 585 28 49-01 IDLER BRACKET
6 532 42 65-89 NUT 5/16-18
7 874 78 05-24 SCREW 5/16-18 X 1.50
8 532 42 42-97 SHOULDER BOLT 5/16-18 X .50
9 532 75 11-53 NUT 5/16-18 LOCK
10 817 00 05-10 SCREW 5/16-18 X 1.0 HEX
WHS HD
11 585 23 84-01 TRACTION IDLER BRACKET
ASM
12 532 85 10-84 SCREW 3/8-24 X 1.375
13 532 05 92-89 WASHER
14 532 40 00-26 WASHER
15 532 42 64-91 PULLEY ENG IMPELLER
16 532 18 04-78 PULLEY ENG TRACTION
17 874 61 05-20 SCREW 5/16-24 X 1.25
18 810 04 05-00 LOCKWASHER 5/16
19 585 54 05-01 BELT GUIDE
20 532 15 54-15 WASHER .20 X 8.5 X 2.0
21 532 17 53-31 IDLER BUSHING
22 532 40 94-75 SPACER
23 874 61 05-16 SCREW 5/1-24 X 1.0 HEX

20
REPAIR PARTS WHEELS
SNOW THROWER - MODEL NO.
ST 324P
ST 324P (96193009101), PRODUCT NO. 961 93 00-91
NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
KEY PART
NO. NO. DESCRIPTION
1
2
01.06.021-A
1 587 08 14-01 WHEEL ASSEMBLY LH
2 587 08 14-02 WHEEL ASSEMBLY RH
